2002 SUBARU IMPREZA WRX automatic transmission fluid

Maintenance and service
11-25
– CONTINUED –
HGB001EB
1) Yellow handle
HBA008BC
A) HOT range
B) COLD range 1) Upper level
2) Lower level 4. Pull out the dipstick and check the fluid level on the gauge. If it is below the lower level on the
“HOT”
range, add the recommended automatic transmis-sion fluid up to the upper level.
Checking the fluid level when the fluid is cold
When the fluid level has to be checked without time
to warm up the automatic transmission, check to see that the fluid level is between the lower level and upper level on the “COLD” range. If it is below
that range, add fluid up to the upper level. Be care-
ful not to overfill. Recommended fluid
“ Dexron III ” Type Automatic Transmission Fluid

Maintenance and service
11-30
If the fluid level is extreme low, it may indicate pos-
sible leakage. Consult your SUBARU dealer for in-spection.
WARNING
Be careful not to burn yourself because the fluid may be hot.
CAUTION
When power steering fluid is being added,
use only clean fluid, and be careful not to al- low any dirt into the tank. And never use dif-
ferent brands together. Avoid spilling fluid when adding it in the
tank.
Recommended fluid
“ Dexron III ” Type Automatic Transmission Fluid
Brake fluid Checking the fluid level
Check the fluid level monthly.
HGB001GB
1) “MAX” level mark
2) “MIN” level mark
Check the fluid level on the outside of the reservoir. If the level is below “MIN”, add the recommended
brake fluid to “MAX”.
Use only brake fluid from a sealed container.

Specifications
12-4
Capacities
Fuel tank
15.9 US gal (60 liters, 13.2 Imp gal)
Engine oil2.5-liter engine model4.2 US qt (4.0 liters, 3.5 Imp qt)
Turbo engine model4.8 US qt (4.5 liters, 4.0 Imp qt)
Transmission oil (MT)3.7 US qt (3.5 liters, 3.1 Imp qt)
Transmission oil (AT)10.0 US qt (9.5 liters, 8.4 Imp qt)
Power steering gear fluid0.7 US qt (0.7 liter, 0.6 Imp qt)
Engine coolant2.5-liter engine modelMT7.4 US qt (7.0 liters, 6.2 Imp qt)
AT7.3 US qt (6.9 liters, 6.1 Imp qt)
Turbo engine modelMT8.1 US qt (7.7 liters, 6.8 Imp qt)
AT8.0 US qt (7.6 liters, 6.7 Imp qt)
AT : Automatic transmission MT : Manual transmission

Index
14-2
A
ABS (Anti-lock Brake System) 7-22. . . . . . . . . . . . . . . . . . . .
ABS system self-check 7-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ABS warning light 3-12, 7-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ACC 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessory power socket 6-7 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air cleaner element 11-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioner compressor shut-off when
engine is heavily loaded 4-11 . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioner operation 4-8 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air filtration system (if equipped) 4-12 . . . . . . . . . . . . . . . . .
Air flow selection 4-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
All AWD models except OUTBACK SPORT 8-8 . . .
Aluminum wheels (If equipped) 11-45 . . . . . . . . . . . . . . . . . .
Antenna system 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Arming the system 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Armrest (if equipped) 1-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ashtray 6-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AT OIL TEMPerature warning light (for AT vehicles) 3-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio set 5-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic/Emergency Locking Retractor (A/ELR) 1-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission 7-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission fluid 11-24 . . . . . . . . . . . . . . . . . . . . . . B
Battery
11-50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake booster 11-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake fluid 11-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pedal 11-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system 7-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system warning light 3-13 . . . . . . . . . . . . . . . . . . . . . . . .
Braking 7-21
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking tips 7-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Breaking-in of new brake pads and linings 11-36 . . .
Built in CD changer operation 5-22 . . . . . . . . . . . . . . . . . . . .
Bulb chart 12-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CCapacities 12-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cargo anchorage eyelets (if equipped) 6-14 . . . . . . . .
Cassette player operation 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . .
Catalytic converter 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD changer control (If optional in-dash CD
changer is connected) 5-10 . . . . . . . . . . . . . . . . . . . . . . . . . .
Center and side ventilators 4-3 . . . . . . . . . . . . . . . . . . . . . . . .
Center console 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center visor 6-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a flat tire 9-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the oil and oil filter 11-10 . . . . . . . . . . . . . . . . . . . . . .
Charge warning light 3-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
