2002 SUBARU IMPREZA WRX light

Maintenance and service
11-2
Wheel balance 11-41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wear indicators 11-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire rotation 11-42
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire replacement 11-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel replacement 11-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel covers 11-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheels (If equipped) 11-45 . . . . . . . . . . . . . . . .
Windshield washer fluid 11-46 . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement of windshield wiper blades 11-47 . .
Battery 11-50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses 11-51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main fuse 11-53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation of accessories 11-54 . . . . . . . . . . . . . . . . . . . . . . .
Replacing bulbs 11-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight 11-56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front turn signal light and parking light 11-58 . . . . . .
Front fog light (if equipped) 11-61 . . . . . . . . . . . . . . . . . . . . .
Front side marker light 11-62 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear combination lights 11-63 . . . . . . . . . . . . . . . . . . . . . . . . . .
License plate light 11-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Room light, spot light and cargo area light 11-66 . . .
Trunk light 11-67
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High mount stop light 11-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Maintenance and service
11-6
HGB000BA
2. Release the secondary hood release located
under the front grille by moving the lever toward theleft.
HBB003BA
Lift up the hood, release the hood prop from its
retainer and put the end of the hood prop into theslot in the hood.
To close the hood:
1. Lift the hood slightly and remove the hood prop
from the slot in the hood and return the prop to its
retainer.
2. Lower the hood until it approaches about 6 in.
(15 cm) from the closed position and let it drop.
3. After closing the hood, be sure the hood is
securely locked.
If this does not close the hood, release it from a
slightly higher position. Do not push the hood forci-
bly to close it. It could deform the metal.
WARNING
Always check that the hood is properly locked before you start driving. If it is not, it might flyopen while the vehicle is moving and block
your view, which may cause an accident and
serious bodily injury.

Maintenance and service
11-33
– CONTINUED –
Brake booster If the brake booster does not operate as described
below, have it checked by your SUBARU dealer.
1. With the engine off, depress the brake pedal sev-
eral times, applying the same pedal force each time.
The distance the pedal travels should not vary.
2. With the brake pedal depressed, start the en-
gine. The pedal should move slightly down to the
floor.
3. With the brake pedal depressed, stop the engine
and keep the pedal depressed for 30 seconds. The pedal height should not change.
4. Start the engine again and run for about one min-
ute then turn it off. Depress the brake pedal several
times to check the brake booster. Brake booster op-
erates properly if the pedal stroke decreases with
each depression. Brake pedal
Check the brake pedal free play and reserve dis-
tance according to the maintenance schedule in the“
Warranty and Maintenance Booklet ”).
Checking the brake pedal free play
OM-H0224
1) 0.04 – 0.12 in (1.0 – 3.0 mm)
Stop the engine and firmly depress the brake pedal
several times. Lightly press the brake pedal down
with one finger to check the free play with a force ofless than 2 lb (10 N, 1 kg).
If the free play is not within proper specification,
contact your SUBARU dealer.

Maintenance and service
11-35
– CONTINUED –
Checking the clutch pedal free play
OM-H0224
1) 0.16 – 0.51 in (4.0 –13.0 mm)
Lightly press the clutch pedal down with your finger
until you feel resistance, and check the free play.
If the free play is not within proper specification,
contact your SUBARU dealer. Replacement of brake pad and liningOM-H0163
The front disc brakes and the right rear disc brake have an audible wear indicators on the brake pads.If the brake pads wear close to their service limit,
the wear indicator makes a very audible scrapingnoise when the brake pedal is applied.
If you hear this scraping noise each time you apply the brake pedal, have the brake pads serviced byyour SUBARU dealer as soon as possible.

Maintenance and service
11-36
CAUTION
If you continue to drive despite the scraping noise from the audible brake pad wear indica-
tor, it will result in the need for costly brake rotor repair or replacement.
Breaking-in of new brake pads and linings
When replacing the brake pad or lining, use only
genuine SUBARU parts. After replacement, the new
parts must be broken in as follows:
Brake pad and lining
While maintaining a speed of 30 to 40 mph (50 to 65
km/h), step on the brake pedal lightly. Repeat this
five or more times.
Parking brake lining
1. Drive the vehicle at a speed of about 22 mph (35km/h).
2. With the parking brake release button pushed in,
pull the parking brake lever SLOWLY and GENTLY.
(Pulling with a force of approximately 33 lb [147 N,15 kg].)
3. Drive the vehicle for about 220 yards (200 me- ters) in this condition. 4. Wait 5 to 10 minutes for the parking brake to cool
down. Repeat this procedure.
5. Check the parking brake stroke. If the parking
brake stroke is out of the specified range, adjust it
by turning the adjusting nut located on the parking
brake lever.
Parking brake stroke: 7 – 8 notches / 44 lb (196 N, 20 kg)
WARNING
A safe location and situation should be se- lected for break-in driving.
CAUTION
Pulling the parking brake lever too forcefully
may cause the rear wheels to lock. To avoid
this, be certain to pull the lever up slowly and
gently.

Maintenance and service
11-41
– CONTINUED –
increase in temperature could cause tread
separation, and destruction of the tires. Theresulting loss of vehicle control could lead toan accident.
Wheel balance
Each wheel was correctly balanced when your ve-
hicle was new, but the wheels will become unbal-
anced as the tires become worn during use. Wheel
imbalance causes the steering wheel to vibrate
slightly at certain vehicle speeds and detracts from the vehicle ’s straight-line stability. It can also cause
steering and suspension systems problems and ab-
normal tire wear. If you suspect that the wheels are
not correctly balanced, have them checked and ad-
justed by your SUBARU dealer. Also have them ad-
justed after tire repairs and after tire rotation. NOTE Loss of correct wheel alignment* causes the tires to wear on one side and reduces the ve-
hicle’ s running stability. Contact your SUBARU
dealer if you notice abnormal tire wear.
* : The suspension system is designed to hold each wheel
at a certain alignment (relative to the other wheels and to
the road) for optimum straight-line stability and cornering performance.
Wear indicators
Each tire incorporates a tread wear indicator, which
becomes visible when the depth of the tread
grooves decreases to 0.063 in. (1.6 mm). A tire must
be replaced when the tread wear indicator appears
as a solid band across the tread.
OM-H0231
A) New tread
B) Worn tread
1) Tread wear indicator

Maintenance and service
11-50
Battery
WARNING
Before beginning work on or near any bat-
tery, be sure to extinguish all cigarettes,
matches, and lighters. Never expose a batteryto an open flame or electric sparks. Batteriesgive off a gas which is highly flammable andexplosive. For safety, in case an explosion does occur,
wear eye protection or shield your eyes when
working near any battery. Never lean over a
battery. Do not let battery fluid contact eyes, skin,
fabrics, or paint because battery fluid is a cor- rosive acid. If battery fluid gets on your skin or in your eyes, immediately flush the area
with water thoroughly. Seek medical help im-
mediately if acid has entered the eyes.If battery fluid is accidentally swallowed,
immediately drink a large amount of milk or
water, and seek medical attention immediately. To lessen the risk of sparks, remove rings,
metal watchbands, and other metal jewelry.
Never allow metal tools to contact the positive because a short circuit will result.
Keep everyone including children away
from the battery. Charge the battery in a well-ventilated area.
Battery posts, terminals and related acces-
sories contain lead and lead compounds,
chemicals known to the State of California to
cause cancer and reproductive harm.
Wash
hands after handling.
CAUTION
Never use more than 10 amperes when charg- ing the battery because it will shorten batterylife.

Maintenance and service
11-52
HB8003CA
The other one is housed in the engine compartment.
HS0208
1) Fuse puller 2) Spare fuse
The fuse puller and spare fuses are stored in the main fuse box cover in the engine compartment.
If any lights, accessories or other electrical controls
do not operate, inspect the corresponding fuse. If a
fuse has blown, replace it.
HS0204
A) Good B) Blown
1. Turn the ignition switch to the “LOCK” position
and turn off all electrical accessories.
2. Remove the cover.
3. Determine which fuse may be blown. The backside of each fuse box cover and the “Fuse and cir-
cuits” section in chapter 12 in this manual show the
circuit for each fuse.
