4Exterior
IB1736
Roof-rack load _______________ 176
Mounting holes for roof rack ____ 176
Maximum loads ______________ 248
Rearview mirrors _____________ 123
Hood ______________________ 188
Engine compartment: washing __ 233
Central lock ____________ 38
Interior locking buttons ____ 40
Child safety lock catch ____ 41
Trunk/tailgate lid lock _____ 41
Car alarm (anti-theft alarm) 43Front lights _____________ 65
Headlight switch _________ 65
High/low beam
control stalk ____________ 65
Turn signal &
lane change indicators ___ 67
Headlight washers _______ 70
Changing bulbs ________ 204
Fuel gauge __________________ 57
Fuel filler flap ________________ 152
Refueling ___________________ 152
Fuel economy _______________ 170
Fuel grade __________________ 250
Economical motoring __________ 170
Tire pressure ___________ back cover
Wheel and tire specifications ____ 256
Brakes and braking ___________ 165
Winter driving ________________ 171
Wheels and tires _____________ 222
Wheel changing ______________ 227
Spare wheel _________________ 179
Luggage compartment _________ 132
Folding down the rear seat,
9-5 Sedan ___________________ 132
Folding down the rear seat,
9-5 Wagon __________________ 135
Trunk _______________________ 132
Tool kit ______________________ 142
Spare wheel _____________ 142, 179
Jack ________________________ 227Driving with a trailer ______ 173
Towing ________________ 180
Towrope attachment eye __ 180Light switches ___________ 65
Changing bulbs _________ 204
 Taillights _____________ 209
 Stop lights ___________ 209Sunroof _______________ 126
Washing the car ________ 233
Waxing and polishing ____ 233
Touching-up of paintwork _ 235
Anticorrosion treatment ___ 235
ProCarManuals.com

187 Car care and technical information
Car care and
technical
information
772
Hood release handle ....... 188
Engine compartment,
4-cyl. engine ................... 189
Engine compartment,
6-cyl. (3.0t V6)................. 190
Emission control systems 191
Engine............................... 192
Engine oil ......................... 193
Transmission fluid........... 195
Coolant ............................. 196
Brake and clutch fluid ..... 197
Power steering fluid ........ 198
Air filter ............................. 198 Battery .............................. 199
Drive belts ........................ 201
Wipers and washers ....... 202
Changing bulbs ............... 204
Fuses ................................ 216
Wheels .............................. 222
Compact spare wheel ..... 226
Flat spotting..................... 230
Air conditioning (ACC) ... 231
Safety belts ...................... 232
Upholstery and trim ........ 232
Textile carpeting.............. 232
Washing the car .............. 233 Waxing and polishing ...... 233
Engine compartment ....... 233
Touching up the paint ..... 234
Anti-corrosion treatment . 235
For long trips .................... 237
Recovery and/or recycling
of automotive materials. 237
Headlight aiming .............. 239
ProCarManuals.com

204 Car care and technical informationChanging bulbs Check that the new bulb is working when finished.
Some bulbs are of the ”Long-Life” type. Make sure the same type is
fitted when changing one of these.
Headlight aiming, see page 239.
Xenon headlight (certain models only)Xenon headlights produce roughly twice as much light as halogen
bulbs and have a significantly longer service life.
The lamp units consist of a gas discharge lamp containing xenon.
When the lights are switched on a very high voltage activates the
xenon gas. The lamps soon reach full intensity.
Cars with xenon headlights have automatic levelling. The levelling
system comprises two sensors on the front axle, one on the rear axle
and a control unit under the headlight housing. Headlight alignment
is regulated automatically to prevent dazzling oncoming traffic.
Alignment is also adjusted during braking.
WARNING
Before changing a bulb in the engine bay, switch off the engine to
avoid danger of fingers and hands being injured by moving parts.
The radiator fan can start up even when the engine is switched off.
Xenon headlights are high tension and must therefore be
changed at an authorized Saab workshop. Work involving
high-tension components is potentially lethal.NOTE Since the headlight lenses are made of plastic, rinse dried-on
dirt with water and allow it time to soften up before cleaning
the lenses. Avoid rubbing the lenses when dry and never use
solvents.
 Use de-icer spray instead of scraping the ice off.
NOTE Do not fit bulbs with a higher rating than 55 W, since the head-
light reflector and the wiring of the car are not designed for a
higher wattage.
 Switch off the ignition before changing a bulb, to avoid possi-
ble short-circuiting.
ProCarManuals.com

205 Car care and technical information
Headlight bulb for high beamOn cars equipped with xenon lamps the Halogen lamps are used
only for high beam flasher.
1 Unscrew the cover from the back of the lamp unit. To improve
accessibility to the right-hand headlight, hold aside the induction
air hose. To improve accessibility to the left-hand headlight,
remove the battery cover. Release the two clips along the long
sides of the cover.
2 Unplug the connector.
3 To remove the spring clip, push it in and then move it to the right.
4 Remove the bulb.
5 Without touching the glass with your fingers, insert the new bulb.
6 Line up the bulb with the guide in the reflector and secure it with
the spring clip. Look through the headlight lens to help fit the bulb
correctly.
7 Plug in the connector.
8 Screw on the cover. Make sure that the guide on the cover is
aligned with the recess in the lamp housing.
IB1785
IB1883
Make sure the cover is correctly fitted before locking it in place
ProCarManuals.com

206 Car care and technical informationHeadlight bulb for low beam (Halogen)1 Unscrew the cover from the back of the lamp unit. To improve
accessibility to the right-hand headlight, hold aside the induction
air hose. To improve accessibility to the left-hand headlight,
remove the battery cover. Release the two clips along the long
sides of the cover.
2 Unplug the connector.
3 To remove the spring clip, push it in and then move it to the right.
4 Remove the bulb.
5 Without touching the glass with your fingers, insert the new bulb.
Look through the headlight lens to help fit the bulb correctly.
6 Line up the bulb with the guide in the reflector and secure it with
the spring clip.
7 Plug in the connector.
8 Screw on the cover. Make sure that the guide on the cover is
aligned with the recess in the lamp housing.
IB1786
IB1882
Make sure the cover is correctly fitted before locking it in place
IB1910
Contact an
authorized
Saab workshop
if a xenon
headlight
requires
replacement
ProCarManuals.com

207 Car care and technical information
Parking-light bulb (cars with halo-
gen low beam)The parking-light bulb is adjacent to the bulb
for low beam.
1 Unscrew the cover from the back of the
lamp unit.
2 Withdraw the bulb holder.
3 Change the bulb.
Parking-light bulb (cars with xenon
low beam)The parking light bulb is adjacent to the
xenon lamp.
1 Unscrew the cover from the back of the
lamp unit.
2 Take hold of the lamp leads and pull out
the bulb holder. The lamp leads are rein-
forced to facilitate changing bulbs.
3 Change the bulb. Look through the
headlight lens to help fit the bulb cor-
rectly.
Front fog lights 1 From under the front bumper, grip the
bulb holder and twist counterclockwise.
2 Unplug the connector.
3 Change the bulb.
Refit in the reverse order.
WARNING
 Never crawl under a car that is sup-
ported only by a jack.
 Always use axle stands. Refer to the
information on jacks on page 227.
IB1787
Parking-light bulb (cars with halogen low
beam)
IB1788
Front fog lights
IB1909
Parking-light bulb (cars with xenon low
beam)
ProCarManuals.com

208 Car care and technical information
Front turn signal bulbsTo change the bulb, the complete lamp unit
has to be removed.
1 Depress the catch, accessed from the
engine bay.
2 Carefully pull out the lamp unit.
3 The bulb holder has a bayonet fitting.
Grip the holder and twist it counterclock-
wise.
4 Withdraw the bulb holder from the lamp
unit.
5 The bulb also has a bayonet fitting.
Press in the bulb and twist it counter-
clockwise.
6 Fit the new bulb and check that it is cor-
rectly seated.
To re-install the lamp unit1 Align the catch with the recess in the
lamp housing holder.
2 Press the lamp housing towards the
headlight slightly and press the housing
towards the rear of the car.
3 Make sure the locating pin and the two
plastic lugs enter their respective holes.
4 Press the lamp housing until it click into
place.
IB1789
2
13
3
Front turn signal bulb1Catch
2 Bayonet pin
3 Plastic lugs
IB1875
Catch seen from engine bay, left-hand
side
IB1876
Catch seen from engine bay, right-hand
side
IB1790
ProCarManuals.com

215 Car care and technical information
Bulb tableA special kit containing spare bulbs and fuses is available as an
accessory from your Saab dealer. A storage space for this is pro-
vided adjacent to the toolkit and jack, under the panel in the luggage
compartment.# Cap Wattage
1 H7 55 Headlight
2 H1 55 Fog light
3 P21W 21 Reversing lamp; side reversing
lamp; rear fog lamp; cornering lamp
4 P21/5W 21/5 Stop/tail lamp
5 P21W 21 Direction indicator, front/rear
6 R10W 10 Dome light; courtesy lights; glove
compartment; luggage compartment
7 R5W 5 Safety belt reminder
8 H6W 5 Reading light, overhead panel
9 T4W 4 Reading light, rear
10 WY5W/
W5W5 Side indicators (yellow);/
High-mounted stop light (9-5 Sedan);
parking lights; license plate illumina-
tion
11 W2W 1,2 Switches; front ashtray NOTEDo not interchange. Always use the correct Wattage bulb accord-
ing to application.
IB1336
123456
7891011
