2002 PONTIAC FIREBIRD light

2-43
This feature helps you get the best possible fuel economy.
It will come on under these conditions:

The engine coolant temperature is greater than
170F (77C),

you are going 15 to 20 mph (24 to 32 km/h) and

you are at 35 percent throttle or less.
Follow the shift speeds listed below when the SKIP
SHIFT light is on.
Computer
-Aided Manual Transmission Shift Speeds

1st to 4th @ 15 mph (24 km/h)

4th to 5th @ 25 mph (40 km/h)*

5th to 6th @ 49 mph (64 km/h)**
Each time you come to a stop, the engine's Powertrain
Control Module (PCM) determines when to activate
the skip shift upshift system. The skip shift upshift
system is bypassed when you accelerate with more
than 35 percent throttle.
*30 mph (48 km/h) when accelerating to highway speeds.
**45 mph (72 km/h) when accelerating to highway speeds.
Parking Brake
To set the parking brake, hold the brake pedal down and
pull up on the parking brake lever. If the ignition is on,
the brake system warning light will come on.

2-52 Headlamp High/Low-Beam Changer
When the high beams are
on, this light located on the
instrument panel cluster
also will be on.
To change the headlamps from low beam to high or
from high beam to low, pull the turn signal lever all the
way toward you. Then release it.
Windshield Wipers
You can control the windshield wipers by turning the
band with the wiper symbol on it, located on the turn
signal/multifunction lever.
For a single wiping cycle, turn the band to MIST.
Hold it there until the wipers start, then let go.
The wipers will stop after one cycle. If you want
more cycles, hold the band on MIST longer.
You can set the wiper speed for a long or short delay
between wipes. This can be very useful in light rain
or snow. Turn the band to choose the delay time.
The closer to LO, the shorter the delay.For steady wiping at low speed, turn the band away
from you to the LO position. For high
-speed wiping,
turn the band further, to HI. To stop the wipers,
turn the band to OFF.
Damaged wiper blades may prevent you from seeing
well enough to drive safely. To avoid damage, be sure to
clear ice and snow from the wiper blades before using
them. If they're frozen to the windshield, carefully
loosen or thaw them. If your blades do become
damaged, get new blades or blade inserts.
Heavy snow or ice can overload your wipers.
A circuit breaker will stop them until the motor cools.
Clear away snow or ice to prevent an overload.
Windshield Washer
There is a paddle with the word PUSH on it at the top of
the turn signal/multifunction lever. To spray washer fluid
on the windshield, push the paddle briefly. The washer
will continue to spray until you release the paddle.
The wipers will clear the window and wipe a few more
times before stopping or returning to the previous setting.
See ªWindshield Washer Fluidº in the Index.

2-55
Reducing Speed While Using Cruise Control
There are two ways to reduce your speed while using
cruise control:

Push in the button at the end of the lever until you
reach the lower speed you want, then release it.

To slow down in very small amounts, briefly push
the button. Each time you do this, you'll go about
1 mph (1.6 km/h) slower.
Passing Another Vehicle While Using Cruise Control
Use the accelerator pedal to increase your speed.
When you take your foot off the pedal, your vehicle will
slow down to the cruise control speed you set earlier.Using Cruise Control on Hills
How well your cruise control will work on hills depends
upon your speed, load and the steepness of the hills.
When going up steep hills, you may have to step on the
accelerator pedal to maintain your speed. When going
downhill, you may have to brake or shift to a lower gear
to keep your speed down. Of course, applying the brake
takes you out of cruise control. Many drivers find this to
be too much trouble and don't use cruise control on
steep hills.
Ending Out of Cruise Control
There are several ways to turn off the cruise control:

Step lightly on the brake pedal or push the clutch
pedal, if you have a manual transmission, or

move the cruise switch to OFF.
Erasing Speed Memory
When you turn off the cruise control or the ignition,
your cruise control set speed memory is erased.

2-56
Exterior Lamps
The control located on the instrument panel to the left
of the steering column operates the exterior lamps.The exterior lamp control has three positions:
OFF: Turning the control to this position turns off all
lamps, except the Daytime Running Lamps (DRL).
(Parking Lamps): Turning the control to this
position turns on the parking lamps, together with
the following:

Sidemarker Lamps

Taillamps

License Plate Lamps

Instrument Panel Lights
(Headlamps): Turning the control to this position
turns on the headlamps, together with the previously
listed lamps and lights.

2-58 Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier
for others to see the front of your vehicle during
the day. DRL can be helpful in many different
driving conditions, but they can be especially helpful
in the short periods after dawn and before sunset.
Fully functional daytime running lamps are required
on all vehicles first sold in Canada.
For Canadian vehicles, a light sensor on top of the
instrument panel automatically turns the headlamps on,
so be sure it isn't covered.
The DRL system will not activate if the parking brake
is engaged prior to turning the ignition on.
The DRL system will make your front turn signal lamps
come on when the following conditions are met:

The ignition is on,

the exterior lamp control is off,

the parking brake is released, and

it is bright enough outside (on Canadian vehicles).When the DRL are on, only your front turn signal lamps
will be on. The taillamps, sidemarker and other lamps
won't be on. Your instrument panel won't be lit up
either. When you use your turn signals, the front turn
signal and the taillamp on the desired side will flash.
For Canadian vehicles, when it's dark enough outside,
your front turn signal lamps will go out and your
headlamps will come on. The other lamps that come
on with your headlamps will also come on. When it's
bright enough outside, the regular lamps will go off,
and your front turn signal lamps will come on.
On a non
-Canadian vehicle, the headlamps have to be
turned on manually when you need them. On Canadian
and non
-Canadian vehicles, when the headlamps are
turned on, the front turn signal lamps will go out.
When you use your turn signals, the front turn signal
lamp and the taillamp on the desired side will flash.
As with any vehicle, you should turn on the regular
headlamp system when you need it.

2-59 Fog Lamps
Use your fog lamps for better vision in foggy or misty
conditions. Your parking lamps must be on or your
fog lamps won't work.
Your fog lamp switch is
located on your instrument
panel to the left of the
steering wheel.
To turn the fog lamps on, push the right side of the
fog lamp switch and a light on the switch will come on
indicating that the fog lamps are on. Push the left side
of the fog lamp switch to turn the fog lamps off.
The fog lamps will go off whenever your high
-beam
headlamps come on. When the high
-beam headlamps
go off, the fog lamps will come on again.
If your vehicle is equipped with the content
theft
-deterrent/alarm system and your fog lamp switch
is on, the fog lamps may flash to indicate operation of the
content theft
-deterrent/alarm system. See ªContent
Theft
-Deterrent/Alarm Systemº in the Index.
Interior Lamps
Instrument Panel Brightness Control
This feature controls the brightness of the instrument
panel lights.
The thumbwheel for this feature is located on the
instrument panel to the left of the steering column.
Move the thumbwheel up or down to brighten or dim
the lights. If you move the thumbwheel all the way up,
your courtesy lamps will come on.

2-60 Courtesy Lamps
When either door is opened, several interior lamps
go on. These lamps are courtesy lamps. They make it
easier for you to enter and leave your vehicle.
Courtesy lamps include two map lamps on the inside
rearview mirror and other lamps throughout the interior
of your vehicle.
To prevent battery rundown, your interior lamps will be
disabled for about 10 minutes after the ignition is turned
to OFF. The 10
-minute timer will be restarted if you do
any of the following:

Turn the ignition on.

Open either door.

Press any button on your remote keyless entry
transmitter (if equipped).

Turn the interior lamps from off to on.

Open the hatch.
Delayed Illumination
With delayed illumination, the courtesy lamps will
come on and stay on for 25 seconds after you enter
the vehicle and close the doors. They will also stay on
for five seconds after you exit the vehicle and close the
doors. Delayed illumination will be shortened if the
ignition is turned to RUN or if the power locks are
activated. To turn this feature on or off, see ªFeature
Customizationº in the Index.
Exit Lighting
With exit lighting, the interior lamps will come on when
you remove the key from the ignition to help you see
while exiting the vehicle. To turn this feature on or off,
see ªFeature Customizationº in the Index.
Front Map Lamps
Your inside rearview mirror includes two map lamps.
Each lamp has its own switch. Use the switch closest
to the lamp to turn it on. The lamps will also come on
when a door is opened.

2-64
Ashtray and Cigarette Lighter
Lift up the cover to open the ashtray. To remove it, lift
up on either side of the ashtray. If you have an automatic
transmission, the ashtray is near the front of the console.
If you have a manual transmission, the ashtray is in front
of the cupholder.
NOTICE:
Don't put papers and other things that burn
into your ashtray. If you do, cigarettes or
other smoking materials could set them on fire,
causing damage.
To use the lighter, push it in all the way and let go.
When it's ready, it will pop back out by itself.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.
If you plug accessories into your cigarette lighter, such
as heating devices or air compressors, these accessories
should have a rated current of less than 15 amps.
Exceeding this limit will result in a blown fuse.
