2002 PONTIAC BONNEVILLE keyless entry

2-16
To change to another mode, do the following:
1. Keep all doors closed, the vehicle in PARK (P) and
the ignition on throughout this procedure.
2. Press and hold the driver's power door lock switch in
LOCK through Step 4.
3. Press the button with the trunk symbol on the
transmitter. The transmitter will remain in its current
mode and the horn will chirp as feedback.
4. Press the button with the trunk symbol again.
Each time the transmitter's trunk button is pressed,
the mode will advance by one, going from Mode 2 to
3 to 4, etc. and the horn will chirp as feedback.
5. Release the power door lock switch. The security
feedback will remain in the most recent
mode selected.
This procedure changes the mode for only the
transmitter used to change this setting. The procedure
will need to be repeated for the second transmitter.To verify the mode selected, remove the key from the
ignition and close all of the doors after you've exited the
vehicle. Press the lock button on the transmitter to be
verified and confirm the appropriate feedback. Repeat
with the unlock button.
If your vehicle is equipped with the Driver Information
Center (DIC), you must program this feature through the
DIC. See ªDriver Information Center Personalization
Programmingº in the Index.
Matching Transmitter(s) to Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring any
remaining transmitters with you when you go to your
dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock your
vehicle. Each vehicle can have a maximum of four
transmitters matched to it.
See your dealer to match additional transmitters to
your vehicle.

2-17 Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about four years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.
NOTICE:
When replacing the battery, use care not to touch
any of the circuitry. Static from your body
transferred to these surfaces may damage
the transmitter.
For battery replacement, use one Duracell
battery, type
DL
-2032, or a similar type.

2-19 Trunk Lock Release
To unlock the trunk from the outside, insert the master
key and turn it.
Remote Trunk Release (Option)
If you have this option,
press the trunk release
button located in the glove
box to open the trunk lid.
The key does not have to be in the ignition for the
remote trunk button to work. The transaxle must be in
PARK (P) or NEUTRAL (N). The system also works
with the remote keyless entry system, if your vehicle has
this feature.
Remote Trunk Release Lockout (Option)
To secure items in the trunk, lock the glove box with the
master key and take your key and remote keyless entry
transmitter with you. The valet key cannot open the
trunk or the glovebox.
Trunk Security Override (Option)
Pressing the trunk symbol on the remote keyless
entry transmitter opens the trunk even if the glove
box is locked.

2-21 Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
Even if you park in a lot where someone will be
watching your vehicle, it's still best to lock it up and
take your keys. But what if you have to leave your
ignition key?

If possible, park in a busy, well
-lit area.

Put your valuables in a storage area, like your trunk
or glove box.

Be sure to close and lock the storage area.

Close all windows.

Lock the glove box.

Lock all doors except the driver's.

Give the valet key to the valet. Then take the master
key with you.
Universal Theft-Deterrent
(If Equipped)
If your vehicle has this feature, it has a theft-deterrent
alarm system. With this system, the SECURITY
light will flash as you open the door (if your ignition is
in OFF).
This light on the instrument
panel cluster reminds you to
activate the theft
-deterrent
system when leaving
your vehicle.
To activate the system, do the following:
1. Open the door.
2. Lock the door with the power door lock switch while
the door is open, or use the remote keyless entry
transmitter (if equipped). The SECURITY light
should come on and stay on.
3. Close all doors. The SECURITY light should go
off after about 30 seconds and the system will then
be armed.

2-22
If the SECURITY light comes on for one minute
and then shuts off while the ignition is on, the security
system has detected a problem. See your dealer
for service.
If a door is opened without the key or remote keyless
entry transmitter, or if the door key cylinders are
damaged, the alarm will go off. The exterior lamps will
flash and the horn will sound for 30 seconds, then will
go off in order to save battery power.
Remember, the theft
-deterrent system won't activate if
you lock the doors with a key or manual door lock. It
activates only if you use a power door lock switch while
the door is open, or the remote keyless entry transmitter.
Avoid setting off the alarm by accident.
Always unlock a door with a key, or use the remote
keyless entry transmitter. Unlocking a door any other
way will set off the alarm.
If you set off the alarm by accident, unlock the driver's
door with your key. You can also turn off the alarm by
pressing the button with the unlock symbol on the
remote keyless entry transmitter. The alarm won't stop if
you try to unlock a door any other way.
Testing the Alarm
1. From inside the vehicle, roll down the window.
2. Activate the system by locking the doors with the
power door lock switch while the door is open, or
with the remote keyless entry transmitter.
3. Get out of the vehicle, close the door and wait for the
SECURITY light to go out.
4. Then, reach in through the window, unlock the door
with the manual door lock and open the door. This
should set off the alarm.
If the alarm does not sound when it should, check to see
if the horn works. The horn fuse may be blown. To
replace the fuse, see ªFuses and Circuit Breakersº in
the Index.
If the alarm does not sound, or the exterior lamps do not
flash, see your dealer.

2-23
Content Theft-Deterrent (Option)
If your vehicle has this option, it has a theft-deterrent
alarm system.
A light located in your Twilight Sentinel

cluster, above
the fog lamp button, will begin to flash 30 seconds after
the vehicle ignition is turned off to let you know the
system has been armed.
While armed, the doors will not unlock with the power
door lock switch.
Once armed, the alarm will go off if someone tries to
enter the vehicle without using the remote keyless entry
transmitter or a key, breaks a window, tries to damage
the vehicle or turns the ignition to ON. If any of these do
occur, the horn will sound and the parking lamps will
flash for up to two minutes.
PASS-Key
III
Your vehicle is equipped
with the PASS
-Key III
(Personalized Automotive
Security System)
theft
-deterrent system.
PASS
-Key III is a passive
theft
-deterrent system.
This means you don't have to do anything different to
arm or disarm the system. It works when you insert or
remove the key from the ignition.
Your PASS
-Key III system operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.

2-51
Interior Lamps
Instrument Panel Brightness Control
When it is dark outside, you can brighten or dim your
instrument panel cluster lights using the DIM knob,
located to the left of the steering wheel on the
instrument panel.
Turn the knob clockwise to brighten the instrument
panel cluster lights and displays. Turn the knob
clockwise all the way to turn on the interior courtesy
lamps. Turn the knob counterclockwise to dim the
instrument panel cluster lights and displays and to turn
off the courtesy lamps.
Courtesy Lamps
If it is dark enough outside, when any door is opened,
several lamps will come on. They make it easier for you
to enter and leave the vehicle. Turn the dimmer knob all
the way clockwise to turn the interior courtesy lamps on.
Illuminated Entry
If it is dark enough outside and you press the button
with the unlock symbol on the remote keyless entry
transmitter (if equipped), the interior courtesy lamps
will come on and stay on for approximately 25 seconds.
The lamps will turn off immediately by pressing the
button with the lock symbol on the remote keyless entry
transmitter, by turning the ignition key to ON or by
activating the power door locks.
If a door is left ajar, your interior lamps will turn off
after 10 minutes to save your battery.
Delayed Entry Lighting
When you open the door to enter your vehicle, the
interior lamps will come on if it is dark enough outside.
When you close the door with the ignition off, the
interior lamps will stay on for 25 seconds or until the
ignition is turned on. Locking the doors with the
power door lock switch, or with the lock button on the
remote keyless entry transmitter (if equipped), will
override the delayed entry lighting and the lamps will
turn off immediately.

2-52
Theater Dimming
This feature allows for a three to five-second fade out of
the courtesy lamps instead of immediate turn off after
you remove the key from the ignition.
Delayed Exit Lighting
This feature will turn on the interior lamps for
25 seconds after you remove the key from the ignition
while the doors are closed and it is night. This will give
you time to find the door handle or lock switches as you
exit the vehicle.
This lighting will only be deactivated if the key is
reinserted into the ignition switch or the power door
locks are activated.
Parade Dimming
To activate the instrument panel backlighting during the
day, turn the exterior lamp switch to the parking lamp or
headlamp position. Dimming of the instrument panel
display is not possible during daylight hours. The
instrument panel display can only be adjusted when
the parking lamps or headlamps are on and it is
dark outside.
Perimeter Lighting
When the button with the unlock symbol on the remote
keyless entry transmitter (if equipped) is pressed, the
DRL headlamps, parking lamps and back
-up lamps will
turn on if it is dark enough outside.
Personalization Programming
This feature can be programmed in the on or off mode
for each transmitter.
To turn the feature off do the following:
1. Keep all doors closed, the vehicle in PARK (P) and
the ignition on throughout this procedure.
2. Press and hold LOCK on the power door lock switch
throughout this procedure. All the doors will lock.
3. Press the instant alarm on the transmitter. Perimeter
lighting remains on at this time and the horn will
chirp twice.
4. Press the instant alarm on the transmitter again.
Perimeter lighting is disabled and the horn will
chirp once.
5. Release the door lock switch. The perimeter lighting
feature is now off.
