2002 Peugeot 406 C Indicator

Sport and Snow programmes In addition to the autoadaptive programme, two special
programmes are available. Theindicator light corresponding to theprogramme selected lights up on theinstrument panel. Sport programme
Once the vehicle has been started and position Dselected, press the
S button.
The gearbox automatically favoursdynamic driving. Snow programme This programme makes starting
easier and offers smooth driving in
conditions when traction is poor.
Once the vehicle has been started and position Dselected, press the
button.
The gearbox adapts to driving on slippery roads. Note : You can return to the
autoadaptive programme at any time.
Press the Sor button again to
cancel the current programme. Operating anomaly Any disruption of the system is indicated by the alternate flashing ofthe sport and snow lights on theinstrument panel. In such a case, the gearbox will operate in downgrade mode (locked
in 3rd gear). You may feel asubstantial knock when reverse isselected from position
Por N(this
does not damage the gearbox). Do not exceed 60 m.p.h. (100 km/h), if regulations permit this.
Contact a PEUGEOT dealer without
delay.
DRIVING YOUR 406 COUPE 123
MANUAL GEARBOX Reverse
To change to reverse gear, lift the ring under the gear lever knob andpush the gear lever to the left then tothe front. Reverse gear can only be engaged when the vehicle is stationary withthe engine idling.
01-07-2002

DRIVING YOUR 406 COUPE125
Handbrake Applying When parking, pull the handbrake to immobilise your vehicle.
Warning: when parking on a slope,
direct your wheels towards the pave- ment and apply the handbrake. Releasing Pull the handle and press the button to release the handbrake.
Disarming the ESP / ASR systems In certain conditions (vehicle stuck in
mud or snow, or on loose ground...),it could prove useful to disarm theASR system to make the wheelsspin and regain grip.
Press the switch
"ESP OFF", sit-
uated to the left of the steering wheel.
The switch lights up and the indicatorlights come on, accompanied by themessage '' ASR/ESP de-activated''
on the multi-function display: the
ESP and ASR systems no longer
affect the operation of the engine orthe brakes. They engage again:
automatically when the ignition is
switched off,
manually by pressing the switch again. The ESP system offersincreased safety duringnormal driving, but shouldnot incite the driver to take
risks or to drive at high speed.The operation of the system isassured to the extent to which therecommendations of the manufac-turer regarding the wheels (tyresand wheel rims), the braking com-ponents, the electronic compo-nents and the assembly andrepair procedures within thePEUGEOT network are respect-ed.After an accident or impact, havethe system checked by a
PEUGEOT dealer.
Operating check When a system malfunctionoccurs, the switch lightflashes and the indicatorlight comes on. Contact a
PEUGEOT dealer to check
the system.
TRACTION CONTROL (ASR)
AND DYNAMIC STABILITY
CONTROL (ESP) These systems are linked and com-
plement the ABS system.
The ASR system optimises drive to prevent the wheels skidding, by act-ing on the brakes of the drive wheelsand on the engine. It also allows thedirectional stability of the vehicle tobe improved on acceleration. If thereis a variation between the trajectoryfollowed by the vehicle and that
required by the driver, the ESP sys-tem automatically acts on the engineand the brake of one or morewheels, in order to put the vehicleback on course.
Operation of the ASR and ESP systems
When one of these two sys-tems is operating, this lightflashes.
01-07-2002

DRIVING YOUR 406 COUPE127
Operating check This is confirmed by an indi- cator light, accompanied byan audible signal and a
message on the multi-function dis-
play. With the ignition on (2nd notch), illu- mination of this warning light accom-panied by an audible signal and themessage "Passenger air bag dis-
armed" on the multi-function display,
indicates that the passenger air bagis disarmed (slot in the "OFF" posi-
tion).
Disarming the passenger air bag*
To ensure the safety of your child, it is essential to disarm the pas-senger air bag when you install arear-facing child seat on the frontpassenger seat.
With the ignition switched off, insert the key into the passengerair bag disarming slot 1, turn it to
the "OFF" position, then remove
it keeping the slot in this position.
The air bag warning light on theinstrument panel is lit throughout thedisarming process. In the "OFF" position, the passenger
air bag will not be triggered in the event of an impact. As soon as the child seat is removed, turn the air bag slot to the"ON" position to re-activate the air
bag and thus ensure the safety ofyour passenger in the event of animpact.
* According to destination. SIDE AIR BAGS The side air bags are incorporated into the backs of the front seats, onthe door side. They are deployed independently of
each other, on whichever side thecollision occurs.
Operating check This is confirmed by an indicator light, accompanied by an audiblesignal and a message on the multi-
function display.
If this indicator light comeson, accompanied by anaudible signal and the mes-sage "Air bag fault" on the
multi-function display, con-
tact a PEUGEOT dealer to have thesystem checked.
01-07-2002

DRIVING YOUR 406 COUPE127
Operating check This is confirmed by an indi- cator light, accompanied byan audible signal and a
message on the multi-function dis-
play. With the ignition on (2nd notch), illu- mination of this warning light accom-panied by an audible signal and themessage "Passenger air bag dis-
armed" on the multi-function display,
indicates that the passenger air bagis disarmed (slot in the "OFF" posi-
tion).
Disarming the passenger air bag*
To ensure the safety of your child, it is essential to disarm the pas-senger air bag when you install arear-facing child seat on the frontpassenger seat.
With the ignition switched off, insert the key into the passengerair bag disarming slot 1, turn it to
the "OFF" position, then remove
it keeping the slot in this position.
The air bag warning light on theinstrument panel is lit throughout thedisarming process. In the "OFF" position, the passenger
air bag will not be triggered in the event of an impact. As soon as the child seat is removed, turn the air bag slot to the"ON" position to re-activate the air
bag and thus ensure the safety ofyour passenger in the event of animpact.
* According to destination. SIDE AIR BAGS The side air bags are incorporated into the backs of the front seats, onthe door side. They are deployed independently of
each other, on whichever side thecollision occurs.
Operating check This is confirmed by an indicator light, accompanied by an audiblesignal and a message on the multi-
function display.
If this indicator light comeson, accompanied by anaudible signal and the mes-sage "Air bag fault" on the
multi-function display, con-
tact a PEUGEOT dealer to have thesystem checked.
01-07-2002

MAINTENANCE OF YOUR 406 COUPE35
CHANGING A BULB
1 - Dipped beam headlamps
2 - Main beam headlamps
Two bulbs
(H7-55W).
- Remove the red plastic cover.
- Press the tab and remove the protective cover corresponding to the faulty bulb.
- Disconnect the connector.
- Press the end of the securing clip to remove it. Change the bulb.
- When fitting, ensure that the direction notches are positioned correctly and that the securing clip is corrrectly fixed.
- Reconnect the connector.
- Replace the protective cover.
3 - Side lights (W 5 W)
Turn the socket using the lever and remove it. Change the bulb.
4 - Direction indicators (PY 21 W)
Turn the bulb holder a quarter turn and remove it. Change the bulb. Notes: only handle H7 bulbs using a dry cloth.
To replace the left-hand bulbs, remove the battery protective cover. Direction indicator repeater (W 5 W)
- Pull the rear section of the transpa-
rent cover and release the assem-
bly.
- Turn the connector a quarter turn and remove it.
- Change the bulb.
Amber bulbs must bereplaced by bulbs of iden-tical specification and
colour.
In certain climatic conditions (lowtemperatures, humidity), the pre-
sence of condensation on theinside of the headlamp glass isnormal ; it disappears a few
minutes after the lights switch on.
01-07-2002

MAINTENANCE OF YOUR 406 COUPE
36
Number plate lights (W 5 W)
Remove the translucent protector.Change the faulty bulb.
Rear lights
1 - Direction indicators (P 21 W).
2 - Reversing lights (P 21 W).
3 - Brake lights/Side lights (P 21/5 W).
4 - Side lights (P 21/5 W).
5 - Fog lamp (P 21 W). These 5 bulbs are changed from inside the boot:
- remove the retaining clips then release the carpet,
- remove the connector by pressing the tab
A,
- remove the bulb holder by squeezing the tabs,
- change the faulty bulb.
01-07-2002
