YOUR 406 COUPE IN DETAIL103
1 -
Fuel filler cap warning light.
2 - Door open warning light.
3 - Dipped beam headlamps indi- cator light.
4 - Main beam headlamps indicatorlight.
5 - Rev. counter.
6 - Left-hand direction indicator.
7 - Central (STOP) warning light.
8 - Low fuel level warning light.
9 - Fuel gauge. 10 -
Service indicator, oil level indicator and total distance
recorder.
11 - Right-hand direction indicator.
12 - Speedometer.
13 - Front fog lamps indicator light.
14 - Rear fog lamp indicator light.
15 - Dynamic Stability Control(ASR/ESP) warning light.
16 - Low coolant level warning light. 17 -
Coolant temperature indicator.
18 - Trip recorder zero reset button.
19 - Handbrake and low brake fluid level warning light.
20 - Seat belt not fastened warninglight.
21 - Air bags warning light.
22 - ABS system warning light.
23 - Engine diagnostics warninglight.
24 - Battery charge warning light.
25 - Passenger air bag disarmingwarning light.
26 - Front brake pad wear warninglight.
27 - Engine oil pressure warninglight.
28 - Operating programmes.
29 - Gear lever position indicator.
30 - Electronic immobiliser warninglight.
31 - Lighting rheostat.
32 - Engine oil temperature indicator.
INSTRUMENT PANEL DIALS: AUTOMATIC GEARBOX
01-07-2002

YOUR 406 COUPE IN DETAIL
104
WARNING LIGHTS AND INDICATORS
A permanently lit warning light, or flashing with the engine running, is an indication of a malfunction in the relevant unit. Some warning lights may
be linked to buzzers and a message on the multiÐfunction display. Do notignore this warning: contact a PEUGEOT dealer as quickly as possible.
If the Central (STOP) warning light comes on when you are driving, stop your vehicle immediately where it is safe to do so.
Central (STOP) warning light Linked to the "engine oil pressure", ''the low brake fluid level'', '' the coolant temperature gauge'' and ''electronic brake force distribu-tion system fault'' warning lights. It comes on each time the igni-tion is switched on.
Stop immediately if it flashes with the engine running.
Contact a PEUGEOT dealer.
Engine oil pressure warning light
Linked to the central (STOP) warning light.Stop immediately if it comes on with the engine running.
It indicates either:
Ðinsufficient oil pressure,Ðlack of oil in the lubrication circuit. Top up the oil level.
Contact a PEUGEOT dealer as soon as possible. Low coolant level warning light
Stop immediately. Allow the engine to cool before top- ping up. The cooling system is pressurised.In the event of a breakdown and to prevent the risk of scalding, turn thecap to the first notch to allow thepressure to drop. Once the pressure has dropped, remove the cap and top up the level.
Contact a PEUGEOT dealer.
Fuel filler cap warning light This comes on if the fuel cap is not correctly screwed
on or is missing.
01-07-2002

YOUR 406 COUPE IN DETAIL105
Handbrake, low brake fluid level and electronic brake force distribution warning light. This comes on each time the ignition is switched on.
It indicates either:
Ðthat the handbrake is on or has not been released correctly,
and when coupled with the central (STOP) warning light:
Ðan excessive drop in the brake fluid level (if the light remains on even with the handbrake released),
Ðlit at the same time as the ABS warning light, it indicates a malfunction of theelectronic brake force distribution system.
Stop immediately.
Contact a PEUGEOT dealer.
Anti-lock braking system (ABS) warning light This comes on for 3 seconds each time the ignition is switched on.If it comes on at over 8 m.p.h. (12 km/h), it indicates a malfunction of the ABS.
However, the vehicle retains conventional servo-assisted braking.
Contact a PEUGEOT dealer.
Clogging of the partic- ulate emission filterwarning light (dieselengine)
Display of this warning light is accompanied by an audible signal. The flashing of this light while the engine is running is caused either bythe particulate emission filter being
overloaded or by the engine runningtoo long at idle (white smoke from
the exhaust). There is a risk of the fil-ter clogging if the same conditions ofoperation are maintained. As soon as possible, drive for at least three minutes at a speedexceeding 37 m.p.h. (60 km/h), if driving conditions allow this. If the light comes on, contact a
PEUGEOT dealer as soon as possi-ble. Front brake pad wear warning light
For your safety, have the pads replaced as soon as this light comes on.
ESP Electronic Stabili- ty Programme opera-
tion indicator light
This flashes when the system is operating. It is lit continuously if disarmed or if there is a fault.
01-07-2002

YOUR 406 COUPE IN DETAIL
106
Passenger air bag disarming warninglight Illumination of this warning
light is accompanied by an audible signal and a message on the multi-
function display. If the passenger airbag is disarmed, the indicator lightcomes on when the ignition isswitched on and remains on. In all cases, if the warning light flash-
es, contact a PEUGEOT dealer.
Air bag warning light The warning light comes on for 6 seconds when theignition is switched on.
Illumination of this warning light, withthe engine running, is accompaniedby an audible signal and a messageon the multi-function display indicat-ing the cause of the front, side or curtain air bag fault.
Contact a PEUGEOT dealer.
Water in diesel filter warning light (according to destination)
Contact a PEUGEOT dealer as soon as possible.
There is a risk of damage to the injection system. Diesel pre-heating indicator lightIf the engine is warm enough, the light will not come on and you can start the engine without waiting.
If the light comes on, wait until it goes out before trying the starter. Engine diagnostics warning light This comes on each time the ignition is switched on. If it is lit continuously with the engine runnning, this indicates a fault in the emission control system.
If it flashes with the engine running, this indicates a malfunction in the injection
or ignition system. There is a risk of damage to the catalytic converter (petrolengine only).
Contact a PEUGEOT dealer as soon as possible. Battery charge warning light This comes on each time the ignition is switched on.If it comes on with the engine running it can indicate:
Ðfaulty operation of the charging circuit,
Ðloose battery or starter terminals,
Ða cut or slack alternator belt,
Ðan alternator fault.
Contact a PEUGEOT dealer.
01-07-2002

Door open warning light When the engine is running, the warning light indicatesthat a door has not been
closed properly or that the boot isopen.
Electronic immobiliser warning light This indicates a malfunction
of the electronic immobiliser.
Contact a PEUGEOT dealer.
Low fuel level warning light. When this warning light comes on, you
have enough fuel to drive at least
30 miles (50 km). The tank capacityis approximately 70 litres (15.4 gal-lons). Coolant temperature indicator When the needle is in zone
A,the
temperature is correct.When the needle is in zone B, the
temperature is too high. The central
(STOP) warning light flashes.
You must stop immediately.
Contact a PEUGEOT dealer.
Seat belt not fastened warning light With the engine running, the indicator light comes onwhen the driver's seat belt isnot fastened.
YOUR 406 COUPE IN DETAIL
107
01-07-2002

Door open warning light When the engine is running, the warning light indicatesthat a door has not been
closed properly or that the boot isopen.
Electronic immobiliser warning light This indicates a malfunction
of the electronic immobiliser.
Contact a PEUGEOT dealer.
Low fuel level warning light. When this warning light comes on, you
have enough fuel to drive at least
30 miles (50 km). The tank capacityis approximately 70 litres (15.4 gal-lons). Coolant temperature indicator When the needle is in zone
A,the
temperature is correct.When the needle is in zone B, the
temperature is too high. The central
(STOP) warning light flashes.
You must stop immediately.
Contact a PEUGEOT dealer.
Seat belt not fastened warning light With the engine running, the indicator light comes onwhen the driver's seat belt isnot fastened.
YOUR 406 COUPE IN DETAIL
107
01-07-2002

Lighting rheostat
With the lights on, press the button to vary the intensity of the lighting of theinstruments and controls. When thelighting reaches the minimum (ormaximum) setting, release the but-ton then press it again to increase (orreduce) the brightness. As soon as the lighting is of the required brightness, release the but-ton.
Trip recorder zero reset With the ignition on, press the button. Instrument panel display After switching on the ignition, three functions are shown in succession:
-engine oil level indicator,
-service indicator,
-total distance recorder.
Engine oil level When the ignition is switched on, the engine oil level indicator is displayed for approximately five seconds, then the service indicator is displayed for five sec-onds. Maximum Use the dipstick to confirm the level on the indicator; a surplus of oil can cause damage to the engine.
Contact a PEUGEOT dealer as soon as possible.
Minimum Check the level with the dipstick and top it up. The indication isonly correct if the vehicle has been on stable, level ground, withthe engine stopped, for 10 minutes.
No oil It is essential to top up the oil to the correct level, otherwise thereis a risk engine will be damaged.
YOUR 406 COUPE IN DETAIL
108
01-07-2002

01-07-2002
