2002 Peugeot 307 SW Owner's Manual

2YOUR 307 SW AT A GLANCE

3YOUR 307 SW AT A GLANCE
1 - Speaker (tweeter) location.
2 - Side window demisting
vent.
3 - Windscreen demisting vents.
4 - Passenger air bag.
5 - Brightness sensor.
6 - Multi-function display.
7 - Alarm button.
8 - Central locking button.
9 - Hazard warning lights switch.
10 - Dynamic Stability control (ESP/ASR) switch*.
11 - Lights and direction indicators stalk.
12 - Instrument dials.
13 - Steering wheel adjustment control. 14 - Windscreen wash/wipe
stalk.
Trip computer stalk.
15 - Driver's air bag. Horn.
16 - Audio remote control stalk.
17 - Headlamp height adjustment.
18 - Electric mirror controls. Window controls. Rear window locking control.
19 - Steering lock and igni- tion.
20 - Cruise control switch.
21 - 12 V accessories socket.
22 - Passenger air bag disarming switch*.
23 - Rubbish container.
24 - Panoramic roof shutter switch.
25 - Can holder. 26 - Handbrake.
27 - Rear footwell heating
vent.
28 - Gear lever.
29 - Front ashtray.
30 - Heating / air conditioning controls.
31 - CD changer.
32 - RB3, RD3 audio equipment.
33 - Central adjustable heating/ventilation vent and air flow regulation.
34 - Side adjustable heating/ventilation ventand air flow regulation.
35 - Fuse box.
36 - Glove box.
37 - Bonnet opening control.
* According to destination.

4YOUR 307 SW AT A GLANCE
THE KEYS The keys allow you to switch on the ignition and to independentlyoperate the front doors, the fuelfiller cap, the glove box and thepassenger air bag disarmingswitch. Central locking
From the driver's door, the keys allow you to lock, deadlock orunlock the doors and the tailgateand to fold back the exteriormirrors. If one of the doors or the boot is open, it is impossible to operatethe central locking; an audiblesignal indicates locking by remotecontrol. The remote control performs the same functions at a distance. The remote control key Locking ➜
Press button Ato lock the
vehicle. This is confirmed by fixed lighting of the direction indi-cators for approximately twoseconds.
Note: a long press on button A, in
addition to locking, automaticallycloses the windows.
Vehicles fitted with deadlocking
Deadlocking renders theinternal and external doorlocking controls inoperative.
➜ Press button Ato deadlock
the vehicle.
This is confirmed by fixed lighting of the direction indicators forapproximately two seconds. Note : a long press on button A,
in addition to deadlocking, auto- matically closes the windows.
A second press on button A
within 5 seconds of deadlocking changes this to normal locking.This is confirmed by fixed lightingof the direction indicators forapproximately two seconds.
Unlocking Press button Bto unlock the
vehicle. This is confirmed by rapid flashing of the direction indicators. Note : If the vehicle is locked and
unlocking is activated inadver-
tently, the vehicle will lock auto-matically unless a door is ope-ned within 30 seconds.
STARTING
STOP position:
The ignition is off.
1st notch, Accessories position:
The ignition is off but the acces- sories can be used. 2nd notch, Running position: The ignition is on. Starting position:
Operates the starter.
70

5YOUR 307 SW AT A GLANCE
STEERING WHEEL
STALKS LIGHTING
Front and rear lights (ring A)
Lights off. Side lights.
Dipped / main beam headlamps. Automatic switching on of lights
Automatic switching on of lights
To activate or disarm this func- tion, place the key in the acces-sories posiiton, the lighting stalkin position 0and press for more
than two seconds on the end ofthe stalk.Vehicles fitted with a rear fog lamp (ring B)
Rear fog lamp (rotationof the ring forwards)
Vehicles fitted with front foglamps and a rear fog lamp(ring C) Front fog lamps (first rota-tion of the ring forwards)
Front fog lampsand rear fog lamp(second rotation ofthe ring forwards)
Switching off: rotation ofthe ring backwards.
77
WINDSCREEN WIPERS Front 2 Rapid wipe
1 Normal wipe
I Intermittent wipe
or
AUTO Automatic wipe
0 Off
Single wipe
Windscreen wash: pull the stalk towards you. Rear
Off. Intermittent wipe.
Automatic wipe In the AUTO position,
the wiper operates auto- matically and adjusts its
speed to the intensityof the rainfall.
79
Windscreen wash

6YOUR 307 SW AT A GLANCE
FRONT SEATS 1. Forwards/backwards adjust-
ment.
2 . Seat back angle adjustment.
3 . Driver or passenger seat
height adjustment.
4 . Front removable armrest
5 . Head restraint height and
angle adjustment.
To raise or lower the head restraint, pull it forwards, sli-ding it at the same time.
Never drive with the head
restraints removed.
6. Storage drawer
7 . "Aviation" style table.
56

Moving an additional seat: ➜seat back angle adjustment (1),
➜ head restraint height adjustment (2),
➜ folding down (3),
➜ removal, refitting (4).
7YOUR 307 SW AT A GLANCE
REAR SEATS Moving a side seat: ➜forwards/backwards adjustment (1),
➜ seat back angle adjustment (2),
➜ head restraint height adjustment (3),
➜ folding down (4),
➜ removal, refitting (5). Moving the centre seat: ➜
forwards/backwards adjustment (1),
➜ seat back angle adjustment,table position (2),
➜ head restraint height adjustment (3),
➜ folding down (4),
➜ removal, refitting (5).
58

8YOUR 307 SW AT A GLANCE
SEAT CONFIGURATIONS
67
5 seats Loading bulky items
5 seats with centre seat in boot 6 seats with an additional seat
Transportation of long objects with tray position 7 seats with two additional seats

9YOUR 307 SW AT A GLANCE
AIR BAGS The air bag system has been desi- gned to maximise the safety of theoccupants in the event of seriouscollisions. It works in conjunctionwith the force limiting seat belts. Front air bags These are folded in the centre of the steering wheel for the driverand in the fascia for the front
passenger. They are deployed
simultaneously, except in caseswhere the passenger air bag isdisarmed. Precautions regarding the pas- senger air bag ➜disarm the air bag if you ins-
tall a rear facing child seat,
➜ activate the air bag for an
adult passenger. Disarming the passenger air bag * ➜
with the ignition off, insert the ignition key into slot 1and
turn the passenger air bagswitch to the "OFF"position.
As soon as you remove the childseat, turn the air bag switch to the"ON" position, to activate the air
bag again.
Operating check
With the ignition switched on (2nd notch of the igni-tion), illumination of thiswarning light, accompa-
nied by an audible signal and themessage "Passenger air bag
disarmed" on the multi-function
display, indicates that thepassenger air bag is disarmed(switch in the "OFF"position).
The warning light remains onthroughout the disarming process. Side air bags* and curtain air bags* Side air bags are incorporated into the front seat back frame, onthe door side. Curtain air bags are incorporated into the door pillars and the top ofthe passenger compartment. They are deployed independently
of each other, on whichever sidethe collision occurs.
* According to country.
99100
