2002 Peugeot 307 Break Owner's Manual

S: sport programme.

: snow programme.
P ark: to parkthe vehicle or start the engine , with the
handbrake on or off.
R everse: for reversing (select this function with the
vehicle stationary, engine at idle).
N eutral: to start the engine and to park, with the hand-
brake on. Note: if function Nis inadvertently engaged while dri-
ving, allow the engine to return to idle before engaging function Dto accelerate.
D rive : for driving in automatic mode.
M anual: for driving in manual mode.
YOUR 307 IN DETAIL
86
Moving Off
With the engine running, to move off from position P:
it is essential to press the
brake pedal to exit position P,
select function R, D or M, then
gradually release the pressureon the brake pedal; the vehicle
moves off immediately.
You can also move off from function N:
release the handbrake, with yourfoot on the brake,
select function R, D or M, then
gradually release the pressureon the brake pedal; the vehicle
moves off immediately.
WARNING When the engine is at idle, brakes not applied, if function R, D or Mis
selected the vehicle moves evenwithout the accelerator being pres-sed.For this reason, do not leave
children unsupervised inside thevehicle, with the engine running. When maintenance operations need to be carried out with the engine run-ning, apply the handbrake and selectfunction P.
"PORSCHE TIPTRONIC SYSTEM" AUTOMATIC GEARBOX The four speed automatic gearbox offers a choice between the comfort of inte-
gral automatic operation , enhanced by a sport and a snow programme, or the
pleasure of manual gear changing.
Gear selection gate Move the lever in the gate to select a function. Once the function is selected, the corresponding indicator light appears on
the instrument panel display.

Automatic operation Automatic changing of the four
gears: select function Din the gate.
The gearbox always selects the most suitable gear according to the follo-wing parameters:
- the style of driving,
- the road profile,
- the vehicle load. The gearbox is then operating in auto-adaptive mode, without anyaction on your part.
WARNING Never select position Nwhen the
vehicle is moving. Never select functions Por Runless
the vehicle is stationary.Never change betwen functions to optimise braking on a slippery surface. Notes For immediate maximum accelera-
tion without touching the gear lever,press the accelerator pedal down as
far as it will go (kickdown). The gear-box will automatically change downor maintain the gear selected untilmaximum engine speed is reached. When the brake is applied, the gear- box will automatically change down
in order to provide efficient enginebraking. If you take your foot off the accelera-
tor suddenly, the gearbox will notchange to a higher gear for reasons
of safety. Sport and snow programmes In addition to the auto-adaptive pro- gramme, there are two special pro-grammes. The programme is displayed on the instrument panel screen. Sport programme
Press button Sonce the vehicle
has been started and function D
selected.
The gearbox automatically favours sporty driving and more dynamicacceleration. Snow programme This programme improves starting
and drive when traction is poor. Press button
once the vehicle
has been started and function D
selected.
The gearbox adapts to driving on slippery roads. Note: you can return to the auto-
adaptive programme at any time. Press button Sor
again to
switch off the programme you are in. Manual operation Manual changing of the
four gears:
select function Min the gate,
push the lever to the +sign to
change to a higher gear,
pull the lever to the -sign to
change to a lower gear.
You can change from position D (dri-
ving in automatic mode) to position M (driving in manual mode) at any
time. Note It is only possible to change from one gear to another if the vehicle speedand engine speed permit. If they donot, the vehicle will operate tempora-rily in automatic mode. When the vehicle is stationary or
moving very slowly, the gearboxautomatically selects gear M1.
Programmes S(sport) and
(snow)
do not operate in manual mode.
YOUR 307 IN DETAIL 87

Unlocking Pull on the handle and press the but- ton to release the handbrake.Illumination of this light,accompanied by an audiblesignal and the message"Handbrake on" on the
multifunction display, indi-
cates that the handbrake is still on orhas not been properly released.
Operating abnormality Any operating abnormality is indica- ted by an audible signal accompa-nied by the message "Automatic
gearbox faulty" on the multi-func-
tion display and flashing of the Sportand Snow warning lights on the ins-trument panel. In this situation the gearbox operates in downgrade mode (locked in 3rd
gear). You may feel a substantialknock when changing from Pto R
and from Nto R(this will not cause
any damage to the gearbox). Do not exceed 60 mph (100 km/h), speed restrictions permitting.
Contact a PEUGEOT dealer as soon as possible. Illumination of this warninglight comes on, accompa-nied by an audible signaland the message
"Braking
fault" , indicates that there is
a malfunction of the electronic brakeforce distribution, which can cause aloss of control of the vehicle whenbraking.
Stop immediately.
Contact a PEUGEOT dealer.
HANDBRAKE Locking Pull the handbrake to immobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull the handbrake.
ABS ANTI-LOCK BRAKING SYSTEM
The ABS with Electronic Brake Force Distribution (EBFD) increases thestability and manoevrability of yourvehicle, particularly on poor or slip-pery road surfaces. Note: when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
YOUR 307 IN DETAIL
88
If the battery is flat and the lever is in position
P, it
will be impossible tochange to another posi-tion.
Normal operation of the ABS may make itself felt by slight vibrationsof the brake pedal. In emergency braking, press very firmly without releasingthe pressure.
EMERGENCY BRAKING
ASSISTANCE SYSTEM
In an emergency, this system enables the optimum braking pressure to be
reached more quickly, thus reducingthe stopping distance. It is triggered by the speed at which the
brake pedal is activated, the effect ofwhich is a reduction in the resistance ofthe pedal and an increase in braking
efficiency.

Unlocking Pull on the handle and press the but- ton to release the handbrake.Illumination of this light,accompanied by an audiblesignal and the message"Handbrake on" on the
multifunction display, indi-
cates that the handbrake is still on orhas not been properly released.
Operating abnormality Any operating abnormality is indica- ted by an audible signal accompa-nied by the message "Automatic
gearbox faulty" on the multi-func-
tion display and flashing of the Sportand Snow warning lights on the ins-trument panel. In this situation the gearbox operates in downgrade mode (locked in 3rd
gear). You may feel a substantialknock when changing from Pto R
and from Nto R(this will not cause
any damage to the gearbox). Do not exceed 60 mph (100 km/h), speed restrictions permitting.
Contact a PEUGEOT dealer as soon as possible. Illumination of this warninglight comes on, accompa-nied by an audible signaland the message
"Braking
fault" , indicates that there is
a malfunction of the electronic brakeforce distribution, which can cause aloss of control of the vehicle whenbraking.
Stop immediately.
Contact a PEUGEOT dealer.
HANDBRAKE Locking Pull the handbrake to immobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull the handbrake.
ABS ANTI-LOCK BRAKING SYSTEM
The ABS with Electronic Brake Force Distribution (EBFD) increases thestability and manoevrability of yourvehicle, particularly on poor or slip-pery road surfaces. Note: when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
YOUR 307 IN DETAIL
88
If the battery is flat and the lever is in position
P, it
will be impossible tochange to another posi-tion.
Normal operation of the ABS may make itself felt by slight vibrationsof the brake pedal. In emergency braking, press very firmly without releasingthe pressure.
EMERGENCY BRAKING
ASSISTANCE SYSTEM
In an emergency, this system enables the optimum braking pressure to be
reached more quickly, thus reducingthe stopping distance. It is triggered by the speed at which the
brake pedal is activated, the effect ofwhich is a reduction in the resistance ofthe pedal and an increase in braking
efficiency.

TRACTION CONTROL (ASR)*
AND DYNAMIC STABILITY
CONTROL (ESP)* These systems are linked and com-
plement the ABS system.
The ASR system optimises drive to prevent the wheels skidding, byacting on the brakes and the engine.It also allows the directional stabilityof the vehicle to be improved onacceleration. If there is a variation between the tra- jectory followed by the vehicle and
that required by the driver, the ESPsystem automatically acts on theengine and the brake of one or morewheels, in order to put the vehicleback on course.
Operation of the ASR and
ESP systemsWhen one of these two sys- tems is operating, this lightflashes.
* During the year Disarming the ESP / ASR systems In certain conditions (vehicle stuck in
mud or snow, or on loose ground...),it could prove useful to disarm theASR system to make the wheelsspin and regain grip.
Press the switch "ESP OFF",
situated on the central part of the fascia.
The switch lights up and theindicator light comes on;the
ESP and ASR systems nolonger act on the brake andengine operation.
They engage again: automatically when the ignition is
switched off,
manually by pressing the switchagain. Operating check
When a malfunction of thesystem occurs, the switchlight flashes and the indica-tor light comes on, accom-panied by an audible signal
and the message "ESP/ASR not
operational" on the multifunction
display.
Contact a PEUGEOT dealer to have the system checked.
YOUR 307 IN DETAIL 89
The ESP system offers increased safety duringnormal driving, but shouldnot incite the driver totake risks or to drive at
high speed. The operation of the system is ensured to the extent to which therecommendations of the manufac-turer regarding the wheels (tyresand wheel rims), the braking com-ponents, the electronic compo-nents and the assembly andrepair procedures within the PEUGEOT network are observed. After an impact, have the system
checked by a PEUGEOT dealer.

YOUR 307 IN DETAIL
90
CRUISE CONTROL* Cruise control enables the vehicle to maintain a steady speed program-
med by the driver, regardless of theroad characteristics and without thedriver having to touch the acceleratoror brake pedals. In order for it to be memorised, the vehicle speed must be greater thanapproximately 25 mph (40 km/h).
* According to specification Operation
Place switch 1in the ONposition.
A speed can be memorised. Illumination of this indicator light confirms that the cruise control isactivated. Place switch 1in the OFFposi-
tion to deactivate.
Memorising a speed As soon as you reach the chosen speed, press button 2or 3.
This memorises the speed, which
will be maintained automatically. Note: It is possible to accelerate
momentarily without deactivating the cruise control. Cancelling the memorised speed If you wish to cancel the memorised speed: Press button 4or the brake or
clutch pedal.
The indicator light goes out, confir- ming that the cruise control is deacti-vated. Recalling the memorised speed After cancellation, press button
4.
Your vehicle will return to the last memorised speed. Illumination of the indicator light confirms that the cruise control isactivated again. Changing a memorised speed
To memorise a speed higher than the previous one: press button 3;
release it when you have rea- ched the required speed.
To memorise a speed lower than theprevious one: press button 2;
release it when you have rea- ched the required speed.
Cancelling the cruise control place switch 1in the OFFposi-
tion or switch off the ignition
Do not use cruise control on slippery roads or in heavy traffic.

YOUR 307 IN DETAIL91
AIR BAGS The air bags have been designed to maximise the safety of the occupantsin the event of serious collisions;they work in conjunction with theforce-limiting seat belts. In the event of a serious collision, the electronic detectors record and ana-lyse any abrupt deceleration of thevehicle: if the triggering threshold isreached, the air bags inflate instantlyand protect the occupants of thevehicle. Immediately after the impact, the air
bags deflate rapidly, so that they donot hinder the visibility nor the pos-sible exit of the occupants from thevehicle. The air bags will not be deployed in collisions which are not serious, for
which the seat belt is sufficient to
provide maximum protection. Theseriousness of the collision dependson the nature of the obstacle and thespeed of the vehicle at the momentof impact. Air bags operate only when the ignition is switched on. Note:
the gas escaping from the air
bags can be a minor irritant. FRONT AIR BAGS These are folded in the centre of the steering wheel for the driver and in
the fascia for the front passenger.
They are deployed simultaneously,except in cases where the air bag isdisarmed. Front air bag malfunction
If this warning light comes on, accompanied by a buzzer and the message"Air bag fault" on the multi-
function display, contact a
PEUGEOT dealer to have the sys-tem checked. Disarming the passenger airbag*
To ensure the safety of your child, it is essential to disarm the pas-senger airbag when you install arear-facing child seat on the frontpassenger seat.
With the ignition switched off, insert the key into the passengerair bag disarming slot 1turn it to
the "OFF" position, then remove
it keeping it in this position.
The airbag warning light on the instru-ment panel is lit throughout the disar-ming process.
* According to country

YOUR 307 IN DETAIL
92
In the
"OFF" position the passenger
airbag will not be deployed in an impact. As soon as the child seat is remo- ved, turn the air bag slot to the "ON"
position to re-activate the air bag andthus ensure the safety of your pas-senger in the event of an impact.
Operating check This is confirmed by an indicator light, accompanied by an audiblesignal and a message on the multi-
function display. With the ignition on (2ndnotch), illumination of thiswarning light, accompaniedby an audible signal and themessage "Passenger air
bag disarmed" on the multifunction
display, indicates that the passengerair bag is disarmed (slot in the"OFF" position). SIDE AIRBAGS* AND
CURTAIN AIRBAGS* The side airbags are incorporated into the front seat backs on the doorside. The curtain airbags are incorporated into the door pillars and the upperpart of the passenger compartment. They are deployed independently of each other depending on which sidethe collision occurs. Operating check This is confirmed by an indicator light, accompanied by an audiblesignal and a message on the multi-
function display.
If this indicator light comeson, accompanied by anaudible signal and the mes-sage "Air bag(s) faulty" on
the multifunction display,
contact a PEUGEOT dealer to havethe system checked.
* According to specification.
