17-06-2002
YOUR 206 IN DETAIL87
TAILGATE RELEASE (saloon) This enables the tailgate to be unlocked in the event of a centrallocking fault.
Ð Fold back the rear seats to gain access to the boot from inside the vehicle,
Ð Pull the tailgate trim to release it,
Ð Pull the opening catch 1upwards.
SUNROOF (saloon)
To open Press part Bof the switch. The sun-
roof will open in the intermediate
(comfort) position. To open comple-
tely, press part Bagain.
To close Press part Aof the switch. The sun-
roof will close in the intermediate
(comfort) position. To close comple-
tely, press part Aagain.
Panoramic sunroof screen
To move it to your chosen position, press part Aor Bof the switch.
The lighting is activated on ope- ning the tailgate or the rearscreen. Notes: the tailgate and the rear
screen lock automatically while dri- ving (from 10 km/h) and unlockwhen one of the doors is opened. When the rear windscreen wiper is in a wiping position, the rear screencan only be opned at the end of thecycle. Close the rear screen using the windscreen wiper arm or by pres-sing the centre of the glass.
"Tailgate/rear screen open" warning
With the engine running , if the tail-
gate or the rear screen is not pro- perly closed, you are warned by anaudible signal and a message
"Tailgate open" or a diagram on the
multi-function display. In addition, while driving , if the
courtesy light button is in the "ligh- ting on opening the tailgate or rearscreen" position, the courtesy lightflashes.
Page 91 of 155
17-06-2002
YOUR 206 IN DETAIL87
TAILGATE RELEASE (saloon) This enables the tailgate to be unlocked in the event of a centrallocking fault.
Ð Fold back the rear seats to gain access to the boot from inside the vehicle,
Ð Pull the tailgate trim to release it,
Ð Pull the opening catch 1upwards.
SUNROOF (saloon)
To open Press part Bof the switch. The sun-
roof will open in the intermediate
(comfort) position. To open comple-
tely, press part Bagain.
To close Press part Aof the switch. The sun-
roof will close in the intermediate
(comfort) position. To close comple-
tely, press part Aagain.
Panoramic sunroof screen
To move it to your chosen position, press part Aor Bof the switch.
The lighting is activated on ope- ning the tailgate or the rearscreen. Notes: the tailgate and the rear
screen lock automatically while dri- ving (from 10 km/h) and unlockwhen one of the doors is opened. When the rear windscreen wiper is in a wiping position, the rear screencan only be opned at the end of thecycle. Close the rear screen using the windscreen wiper arm or by pres-sing the centre of the glass.
"Tailgate/rear screen open" warning
With the engine running , if the tail-
gate or the rear screen is not pro- perly closed, you are warned by anaudible signal and a message
"Tailgate open" or a diagram on the
multi-function display. In addition, while driving , if the
courtesy light button is in the "ligh- ting on opening the tailgate or rearscreen" position, the courtesy lightflashes.
Page 140 of 155
17-06-2002
PRACTICAL INFORMATION
128
Fuse No. Rating
Functions
1 15A Heated seat - Alarm
4 20A Multi-function display - Navigation control unit - Boot lighting - Audio equipment
5 15A Automatic gearbox diagnostics
6 10A Coolant level - Automatic gearbox - Audio equipment
7 15A Driving school accessory - Alarm fitted as an accessory
9 30A Rear electric windows
10 40A Rear screen amd mirror demisting 11 15A Rear windscreen wiper
12 30A Front windscreen wiper - Sunroof
14 10A Engine fuse box - Air bags - Steering wheel controls - Rain sensor
15 15A Instrument panel - Multi-function display - Navigation control unit - Air conditioning - Audio equipment
16 30A Locking/unlocking controls for doors, bonnet and boot - Deadlocking controls
20 10A Right-hand brake light
21 15A Left-hand brake light - 3rd brake light
22 30A Front courtesy light and rear courtesy light (206 SW) - Map reading light - Glove box lighting - Lighter - Rear 12 volt socket (206 SW)
S1 Shunt PARC shunt
Page 141 of 155
17-06-2002
PRACTICAL INFORMATION131
BATTERY
To charge the battery using a battery charger:
Ð Disconnect the battery,
Ð Follow the instructions for use given by the battery charger manufacturer,
Ð Reconnect starting with the negative (Ð) terminal,
Ð Check that the terminals and connectors are clean. If they are covered with sulphate (white or greenish deposit), disconnect them and clean them.
To start the vehicle from another battery:
Ð Connect the red cable to the positive (+) terminals of the two batteries,
Ð Connect one end of the green or black cable to the negative (Ð) terminal of the slave battery,
Ð Connect the other end of the green or black cable to an earth point on the bro- ken down vehicle as far as possible from the battery,
Operate the starter, let the engine run.
Wait for the engine to return to idle, then disconnect the cables.
- Never disconnect a terminal when the engine is running. - Never charge a battery without first disconnecting the terminals.
- After every disconnection of the battery, switch on the ignition and wait 1 minute before starting to allow the electronic systems to be initialised. If slight difficulties are experienced after this, please contact a
PEUGEOT dealer.
It is advisable to disconnect the battery if the vehicle is
not to be used for a period of more than one month.
ECONOMY MODE FUNCTION After the engine has stopped, with the key in the accessories position,
certain functions (windscreen wiper,electric windows, sunroof, courtesylights, audio equipment etc.) canonly be used for thirty minutes, to
prevent discharging the battery.
Once the thirty minutes are over, the message "Economy mode active"
appears on the multi-function dis-play and the active functions are put
on standby.
A flat battery will prevent the engine from starting.
Page 142 of 155
17-06-2002
PRACTICAL INFORMATION
132
FITTING AUDIO EQUIPMENT
Your vehicle is equipped with certain factory-fitted audio equipment:
Ð roof aerial,
Ð coaxial aerial cable,
Ð basic interference suppression,
Ð supply to front speakers,
Ð supply to rear speakers and twee-ters,
Ð two 8-way connectors. Making the connections
A1 : Ð
A2 : Ð
A3 : Ð
A4 : Ð
A5 : Ð
A6 : (+ve) Ignition positive
A7 : (+ve) Permanent
A8 : Earth
B1 : (+) Rear right speaker
B2 : (Ð) Rear right speaker
B3 : (+) Front right speaker and
tweeter
B4 : (-) Front right speaker and tweeter
B5 : (+) Front left speaker and tweeter
B6 : (Ð) Front left speaker and tweeter
B7 : (+) Rear left speaker
B8 : (Ð) Rear left rear speaker
FITTING SPEAKERS The factory-fitted equipment allows the fitting of:
Ð 165 mm diameter speakers in the
front doors,
Ð 130 mm diameter speakers in the rear doors,
Ð 22.5 mm diameter tweeters in the mirror trims.
Consult a PEUGEOT dealer.
Page 145 of 155
17-06-2002
PRACTICAL INFORMATION135
Removing the mat When removing the mat on the dri- ver's side, move the seat as far backas possible and remove the fixings. When refitting the mat, position it and replace the fixings by turningthem a quarter of a turn.
When fitting transverse roof bars, ensure that they are positioned cor-
rectly. The correct positions are shown by marks on each of the longitudinalbars. Use accessories approved by
PEUGEOT and follow the manufac-turer's fitting instructions.
Maximum authorised
weight on the roof rack: 75 kg
FITTING ROOF BARS (206 SW)
Page 147 of 155
17-06-2002
PRACTICAL INFORMATION137
206 ACCESSORIES
For your PEUGEOT only use accessories and original parts approved by the manufacturer.
These accessories and parts are all adapted to your PEUGEOT, after being tested and approved for reliability and safety,
which PEUGEOT cannot guarantee for other products.
A wide choice of original accessories, approved by PEUGEOT, is available through the dealer network. They all carry the
PEUGEOT guarantee.
Safety : Anti-theft alarms, window engraving, wheel locks, warning triangle, first aid kit...
Protection : Covers compatible with side air bags, carpets, boot tray...
Communication : Telephone, on-board satellite navigation system, CD changers, radios, speakers, radio trim, rear fitted with 4 speakers (saloon)...
Customising : Alloy wheels, trims, sunroof* (saloon), front fog lamps, mud flaps, tailgate spoiler (saloon),sport exhaust, aluminium and wood panel trim...
* To fit a sunroof, it is essential that only original PEUGEOT products are used.
Comfort : Centre armrest, writing table, passenger seat protection, large storage box, bottle holder, CD
or cassette storage, telephone console, door deflectors, under shelf storage (saloon)....
Leisure : Tow bar, roof bars, ski carrier, bicycle carrier**, snow chains...
** Do not fit the bicycle carrier on the spoiler or on the rear screen.
Children : Booster seats and child seats, sun blinds...
Maintenance products : Windscreen wash fluid, interior and exterior maintenance and cleaning products...
Va n : Kit for conversion into a van...
