2002 OLDSMOBILE AURORA buttons

2-59
Emergency Button: In an emergency situation,
press the emergency service button. Upon receiving the
call, an advisor at the center will locate your vehicle and
assess the situation. If necessary, the advisor will alert
the nearest emergency service provider.
Communication Button: Press this button at
the end of a call. Also press this button to answer a call
from the center, or cancel a call if one of the other
buttons is accidentally pressed. This button is also
used to access OnStar Personal Calling and Virtual
Advisor services. See the OnStar owner package for
more information.
Volume Control: You can control the volume of the
OnStar System using either the volume knob on the
radio or using the steering wheel volume control.
Telltale Light: This light will indicate the status of
the system. A solid green light will come on when you
start the vehicle to let you know that the system is on
and is ready to make or receive calls.
If the light blinks green it means that an incoming or
outgoing call is in progress. Press the Communication
button if you notice the light blinking and you are not
on a call.The light will be red in the event of an OnStar system
malfunction. If this occurs press the OnStar Services
button to attempt to contact an advisor. If the connection
is made, the advisor will assist you with steps to take to
make sure that the system is functioning properly. If you
cannot contact the advisor, take your vehicle to your
dealership as soon as possible for assistance.
Cellular Antenna
The cellular antenna on the outside of your vehicle is
critical to effective communications using the OnStar
system. Optimum cellular reception can be obtained
when the mast is straight up and down.
OnStar Services
The following services are available with OnStar service
plans. Your vehicle comes with a specific one
-year
service plan that allows use of some or all of the
following services.
Automatic Notification of Air Bag Deployment: If
an air bag deploys, a priority emergency signal is
automatically sent to the center. An advisor will locate
your vehicle's position, try to contact you and assist you
in the situation. If the center is unable to contact you, an
emergency service provider will be contacted.
ProCarManuals.com

2-63
HomeLink
Transmitter (If Equipped)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation of
the device.Changes and modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.
Programming the HomeLink Transmitter
Do not use the HomeLink Transmitter with any garage
door opener that does not have the ªstop and reverseº
safety feature. This includes any garage door opener
model manufactured before April 1, 1982.
Be sure that people and objects are clear of the garage
door you are programming.
It is recommended that a new battery be installed in
your hand
-held transmitter for quicker and more
accurate transmission of the radio frequency.
Your vehicle's engine should be turned off while
programming the transmitter. Follow these steps to
program up to three channels:
1. Decide which one of the three channels (one of the
three HomeLink buttons) you want to program.
2. Press and hold the desired button on HomeLink
through Step 3.
ProCarManuals.com

2-64
3. When the HomeLink indicator light begins to blink
slowly (this may take up to 30 seconds), hold the
hand
-held transmitter about 1 to 3 inches (3 to 8 cm)
from HomeLink and then press and hold the transmit
button on the hand
-held transmitter. Continue to
hold both buttons until the indicator light on
HomeLink begins to flash rapidly (this may take
up to 90 seconds).
If you have trouble programming HomeLink, make sure
that you have followed the directions exactly as
described and that the battery in the hand
-held
transmitter is not weak. If you still cannot program it,
move the hand
-held transmitter to the left or right or
forward or backward or flip it upside down. HomeLink
may not work with older garage door openers that do
not meet current Federal Consumer Safety Standards.
If you cannot program the transmitter after repeated
attempts, refer to ªTraining a Garage Door Opener
with Rolling Codesº later in this section or contact the
manufacturer of HomeLink at 1
-800-355-3515,
or on the internet at www.homelink.com.
Be sure to keep the original hand
-held transmitter in
case you need to erase and reprogram HomeLink.
Training a Garage Opener with a ªRolling
Codeº Feature (If Equipped)
If you have not previously programmed the hand-held
transmitter to HomeLink, see ªProgramming the
HomeLink Transmitterº listed previously. If you have
completed this programming already, you now need to
train the garage door opener motor head unit to
recognize HomeLink.
1. Find the ªLearnº or ªSmartº button on the
garage door opener motor head unit. The exact
location and color will vary by garage door opener
brand. If you have difficulty finding the Learn or
Smart button, refer to your garage door opener
owner's manual or contact the manufacturer of
HomeLink at 1
-800-355-3515, or on the internet
at www.homelink.com.
Because of the steps involved, it may be helpful
to have another person assist in programming
the transmitter.
2. Press the Learn or Smart button on the garage
door opener motor head unit. An indicator light will
begin to flash when the motor head unit enters the
training mode.
Following this step, you have 30 seconds to
start Step 3.
ProCarManuals.com

2-65
3. Return to HomeLink in your vehicle and firmly
press and release the programmed HomeLink
button three times.
The rolling
-code garage door opener should now
recognize HomeLink. You may either use HomeLink or
the hand
-held transmitter to open the garage door.
If after following these instructions, you still have
problems training the garage door opener, contact the
manufacturer of HomeLink at 1
-800-355-3515,
or on the internet at www.homelink.com.
Canadian Programming
Canadian Owners: During programming, the
hand
-held transmitter may automatically stop
transmitting after two seconds. In this case, you should
press and hold the HomeLink button (see Steps 2 and 3
under ªProgramming the HomeLink Transmitterº) while
you press and repress (cycle) your hand
-held transmitter
every two seconds until HomeLink is trained.
Operating the HomeLink Transmitter
Press and hold the appropriate button on HomeLink for
at least a half of a second. The indicator light will come
on while the signal is being transmitted. The trunk
release lockout switch must be OFF.
Erasing Channels
To erase all three programmed channels, hold down the
two outside buttons on HomeLink until the indicator
light begins to flash (approximately 20 seconds).
Release both buttons.
Resetting Defaults
To reset HomeLink to default settings, hold down the
two outside buttons on HomeLink until the indicator
light begins to flash (approximately 20 seconds).
Continue to hold the buttons until the HomeLink
indicator light turns off and then release both buttons.
Accessories
Accessories for HomeLink are available. If you
would like additional information, please contact the
manufacturer of HomeLink at 1
-800-355-3515,
or on the internet at www.homelink.com.
ProCarManuals.com

2-67
The main components of your instrument panel are the following:
A. Air Outlet
B. Turn Signal/Multifunction Lever
C. Steering Wheel Controls for Climate Control System
D. Steering Wheel Controls for Audio System
E. Windshield Wiper/Washer Control
F. Driver Information Center (DIC)
G. Hazard Warning Flasher Button
H. Climate Control System
I. Instrument Panel Brightness KnobJ. Trip Odometer Buttons
K. Hood Release
L. Parking Brake
M. Cruise Control Lever
N. Ignition Switch
O. Audio System
P. Accessory Power Outlet
Q. Glove Box (Trunk Release Lockout Switch inside)
ProCarManuals.com

2-69 Speedometer and Odometer
Your speedometer lets you see your speed in both miles
per hour (mph) and kilometers per hour (km/h). Your
odometer shows how far your vehicle has been driven,
in either miles (used in the United States) or kilometers
(used in Canada).
The speedometer shows a top speed of 140 mph
(220 km/h). This is not intended to be the vehicle's
top speed.
You may wonder what happens if your vehicle needs a
new odometer installed. If the new one can be set to the
mileage total of the old odometer, then it must be. But if
it can't, then it's set at zero and a label must be put on
the driver's door to show the old mileage reading when
the new odometer was installed.
Trip Odometer
Your trip odometer tells you how far you have driven
since you last reset it. Your vehicle is equipped with two
trip odometers, A and B. The buttons for this feature
are located to the left of the steering column. The trip
odometer displays are located in the center of the
instrument panel cluster. Press the TRIP A/B button
to change which trip odometer is displayed.
Press and hold the TRIP RESET button to reset the trip
odometer that is currently being displayed.
ProCarManuals.com

2-83
Here are four things that some owners ask about. None
of these show a problem with your fuel gage:

At the service station, the gas pump shuts off before
the gage reads full.

It takes a little more or less fuel to fill up than the
gage indicated. For example, the gage may have
indicated the tank was half full, but it actually took
a little more or less than half the tank's capacity to
fill the tank.

The gage moves a little when you turn a corner or
speed up.

The tank is not necessarily empty when the gage
reads empty. There is a reserve of about 1.5 gallons
(5.6 L) in the tank. You should still get more fuel as
soon as possible.Driver Information Center (DIC)
The DIC has different display modes which can be
accessed by pressing the four buttons on the DIC.
These buttons are labeled ON/OFF, SELECT right
arrow, SELECT down arrow and RESET. The button
functions are detailed in the following.
Turn the system on or off by pressing the ON/OFF
button once. When you turn on the ignition, the DIC
will be in the mode last displayed when the engine was
turned off.
ProCarManuals.com

2-84
To turn off messages on the DIC (except LOW OIL
PRESSURE, LOW BRAKE FLUID, PARK BRAKE
SET, STARTING DISABLED and the HOT...STOP
ENGINE warning), press the RESET button.
Pressing the SELECT right arrow button will allow you
to access the following modes, DATE/ET, FUEL,
ECON, OIL and GAGE. While in any of these modes,
warning messages can interrupt and take over the
display until you acknowledge the message, or the
condition causing the problem goes away.
English/Metric
The DIC can display information in either English or
metric. To change the display, press and hold the
ON/OFF button for about three seconds. This will also
change the digital screen for the climate control system
between English and metric.
Date/Elapsed Time
Pressing the SELECT down arrow while in DATE/ET
mode will allow you to choose between the date and the
elapsed time menus.Date
To set the date, press and hold the RESET button for
about three seconds while the date is being displayed on
the DIC. When the date set mode is entered the display
will show the following:
YEAR?_____ MM/DD/00
The year will be flashing. To increase the item that is
flashing press SELECT right arrow. To decrease the
item that is flashing press SELECT down arrow.
When you reach the current year press the RESET
button. The DIC will ask for the month. The month will
flash the same as the year. Use the SELECT buttons to
reach the current month and press RESET. The DIC will
then ask for the day. The day will flash the same as the
year. Use the SELECT buttons to reach the current day.
Press the RESET button again and the set display will
stop flashing and go back to the normal operation mode.
ProCarManuals.com
