Page 157 of 342
154 Interior equipment
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Loading instructions
The total load weight including vehicle occupants and
luggage / cargo should not exceed the vehicle capacity
weight indicated on the certification label which can be
found on the left door pillar.
The handling characteristics of a fully loaded vehicle
depend greatly on the load distribution. It is therefore
recommended to load the vehicle according to the
illustrations shown, with the heaviest items being
placed towards the front of the vehicle.Always place items being carried against front or rear
seat backrests, and fasten them as securely as possible.
The heaviest portion of the cargo should always be kept
as low as possible against front or rear seat backrest
since it influences the handling characteristics of the
vehicle.
For additional safety when transporting cargo while the
rear seats are unoccupied, fasten the outer seat belts
crosswise into the opposite side buckles.
Page 276 of 342
273 Battery
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hintsCar care Index If a tire constantly loses air, it should be inspected for
damage.
The spare tire should be checked periodically for
condition and inflation. Spare tire will age and become
worn over time even if never used, and thus should be
inspected and replaced when necessary.Battery
Important!
Battery replacement information:
The maintenance-free battery is located in the engine
compartment.
The service life of the battery is dependent on its
condition of charge. The battery should always be kept
sufficiently charged, in order to last an optimum length
of time.
Wa r n i n g !
Do not overinflate tires. Overinflating tires can
result in sudden deflation (blowout) because they
are more likely to become punctured or damaged
by road debris, potholes etc.. Follow recommended
inflation pressures.Do not overload the tires by exceeding the specified
vehicle capacity weight (as indicated by the label
on the driver’s door latch post). Overloading the
tires can overheat them, possibly causing a
blowout.
Wa r n i n g !
Failure to follow these instructions can result in
severe injury or death.Never lean over batteries while connecting, you
might get injured.Battery fluid contains sulfuric acid. Do not allow
this fluid to come in contact with eyes, skin or
clothing. In case it does, immediately flush affected
area with water and seek medical help if necessary.A battery will also produce hydrogen gas, which is
flammable and explosive. Keep flames or sparks
away from battery, avoid improper connection of
jumper cables, smoking etc..
Page 326 of 342
323 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex Automatic transmission ............................................... 183
Emergency Operation .............................................. 190
Fluid level ...................................................................256
Selector lever position .............................................. 186
Transmission selector lever,
manually unlocking ............................................. 281
BBabySmart
TM airbag deactivation system ..................... 55
Self-test ......................................................................... 55
BAS (Brake assist system) ............................................ 217
Malfunction indicator lamp ..................................... 243
Battery .............................................................................273
Battery recycling ....................................................... 274
Charge indicator lamp ..............................................245
Battery, remote control ................................................. 292
Block heater .................................................................... 201
Blocking of rear door windows .................................... 124
Brake assist system (BAS) ............................................ 217
Malfunction indicator lamp ..................................... 243
Brake fluid .............................................................. 193, 316
Brake warning lamp ................................................. 241
Capacity ...................................................................... 315
Brake pad wear indicator ............................................. 247Brake warning lamp ...................................................... 241
Brake fluid low .......................................................... 241
Brakes ......................................................191, 193, 315, 316
Bulbs
See Replacing bulbs ................................................. 282
CCapacities
Fuels, coolants, lubricants etc. ............................... 314
Cargo area ....................................................................... 149
Hooks .......................................................................... 151
Loading instructions ................................................. 154
Cargo area cover blind .................................................. 155
Cargo compartment lamp ............................................. 129
Cargo floor plates
Removable .................................................................. 147
Storage ........................................................................ 148
Cargo tie-down rings ..................................................... 150
Catalytic converter ......................................................... 178
Cellular telephone .......................................................... 157
Center console .................................................................. 20
Central locking switch .................................................... 32
