2002 MERCEDES-BENZ CLK-CLASS engine

320 Fuels, coolants, lubricants etc.
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Gasoline additives
A major concern among engine manufacturers is carbon
build up caused by gasoline. Mercedes-Benz
recommends the use of only quality gasoline containing
additives that prevent the build up of carbon deposits.
After an extended period of using fuels without such
additives, carbon deposits can build up especially on the
intake valves and in the combustion area, leading to
engine performance problems such as:
•Warm-up hesitation
•Unstable idle
•Knocking/pinging
•Misfire
•Power loss
Do not blend other specific fuel additives with fuel.
They only result in unnecessary cost, and may be
harmful to the engine operation.
Damage or malfunctions resulting from poor fuel
quality or from blending specific fuel additives are not
covered by the Mercedes-Benz Limited Warranty.Coolants
The engine coolant is a mixture of water and
anticorrosion/antifreeze, which provides:
•Corrosion protection
•Freeze protection
•Boiling protection (by increasing the boiling point)
The cooling system was filled at the factory with a
coolant providing freeze protection to approximately
-22
°F (-30
°C) and corrosion protection.
If the antifreeze mixture is effective to -22
°F (-30
°C), the
boiling point of the coolant in the pressurized cooling
system is reached at approximately 266
°F (130
°C).
The coolant solution must be used year-round to provide
the necessary corrosion protection and increase boil-
over protection. You should have it replaced every 15
years or 150 000 miles (250 000 km), whichever comes
first. Coolant system design and coolant used stipulate
the replacement interval. The above replacement
interval is only applicable if MB 325.0 anticorrosion/
antifreeze solution or other Mercedes-Benz approved
products of equal specification (see Factory Approved
Service Products pamphlet) are used to renew the
coolant concentration or bring it back up to the proper
level.
ProCarManuals.com

321 Fuels, coolants, lubricants etc.
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index To provide the important corrosion protection, the
solution must be at least 45% anticorrosion/antifreeze
(equals a freeze protection to approx. - 22
°F [-30
°C]). If
you use a solution that is more than 55% anticorrosion/
antifreeze (freeze protection to approx. - 49
°F [-45
°C]),
the engine temperature will increase due to the lower
heat transfer capability of the solution. Therefore, do not
use more than this amount of anticorrosion/antifreeze.
If the coolant level is low, water and MB 325.0
anticorrosion/ antifreeze should be used to bring it up
to the proper level (have cooling system checked for
signs of leakage).
Please make sure that the mixture is in accordance with
label instructions.
The water in the cooling system must meet minimum
requirements, which are usually satisfied by normal
drinking water. If your are not sure about the water
quality, consult your authorized Mercedes-Benz Center.
Anticorrosion/antifreeze
Your vehicle contains a number of aluminum parts. The
use of aluminum components in motor vehicle engines
necessitates that anticorrosion/antifreeze coolant used
in such engines be specifically formulated to protect the aluminum parts. (Failure to use such anticorrosion/
antifreeze coolant will result in a significantly
shortened service life.)
Therefore the following product is strongly
recommended for use in your vehicle: Mercedes-Benz
325.0 Anticorrosion/Antifreeze Agent.
Before the start of the winter season (or once a year in
the hot southern regions), you should have the
anticorrosion/antifreeze concentration checked. The
coolant is also regularly checked each time you bring
your vehicle to your authorized Mercedes-Benz Center
for service.
Anticorrosion/antifreeze quantity
Model Approx. freeze protection
-35
°F
(-37°C)-49
°F (
-45°C)
CLK 320 4.8 US qt
(4.5 l)5.3 US qt
(5.0 l)
CLK 430 5.9 US qt 6.5 US qt
ProCarManuals.com

325 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex Defrosting .................................................................... 119
Display and controls ..................................................118
Dust filter ................................................................... 122
Economy ...................................................................... 119
Rear window defroster ............................................. 120
Residual engine heat utilization (REST) ............... 121
Special settings .......................................................... 119
Automatic transmission................................................ 191
Emergency operation ............................................... 199
Fluid level................................................................... 253
Program mode selector switch................................ 198
Selector lever position.............................................. 194
Transmission selector lever,
manually unlocking .................................................. 276
BBabySmart
TM airbag deactivation system..................... 59
Self-test ......................................................................... 59
Backrest, front seat.......................................................... 49
BAS (Brake assist system) ............................................ 212
Malfunction indicator lamp..................................... 227
Battery ............................................................................. 270
Battery recycling ....................................................... 271BATTERY/ALTERNATOR - malfunction and warning
messages ................................................................... 232
Block heater ................................................................... 209
BRAKE ASSIST - malfunction and
warning messages ........................................................ 233
Brake assist system (BAS) ............................................. 212
Malfunction indicator lamp .................................... 227
Brake fluid...................................................... 225, 316, 318
Capacity ...................................................................... 316
BRAKE FLUID - malfunction and
warning messages ........................................................ 234
BRAKE LINING WEAR - malfunction and
warning messages ........................................................ 234
Brake pad wear .............................................................. 234
Brake warning lamp ..................................................... 225
Brake fluid low ......................................................... 225
Brakes .................................................... 200, 202, 212, 216
Bulbs
See Replacing bulbs................................................. 277
ProCarManuals.com

326 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
CCapacities
Fuels, coolants, lubricants etc. ............................... 316
Cargo tie-down rings ..................................................... 152
Catalytic converter......................................................... 176
CD changer
See Audio system ...................................................... 136
Cellular telephone ......................................................... 153
Center console .................................................................. 18
Central locking switch .................................................... 33
Central locking system ................................................... 25
Automatic central locking ......................................... 34
Choosing global or selective mode........................... 28
Electronic key .............................................................. 23
Locking and unlocking............................................... 27
Mechanical keys ........................................................... 30
Remote control ............................................................ 25
Changing wheels ........................................................... 263
CHECK ENGINE malfunction indicator lamp............ 224
Check regularly and before a long trip ...................... 222
Checking engine oil level
Via engine oil level indicator .................................. 108
Via oil dipstick........................................................... 252Child restraint .............................................. 53, 58, 59, 69
Child seat
See Infant and child restraint systems .................... 69
Cleaning and care of the vehicle ................................ 300
Clock, setting .................................................................. 102
COMAND, radio and telephone.................................... 174
Combination switch ....................................................... 113
Consumer information ................................................. 322
Control and operation of radio transmitters .............. 174
COOLANT (coolant level) - malfunction and warning
messages ................................................................... 236
Coolant level
Adding coolant.......................................................... 254
Checking .................................................................... 253
COOLANT TEMP. (coolant temperature) - malfunction
and warning messages ............................................ 237
Coolant temperature gauge ............................................ 82
Coolants .......................................................................... 320
Anticorrosion/antifreeze quantity ........................ 320
Cruise control ................................................................. 210
Cup holder
Center console, front ................................................ 149
ProCarManuals.com

327 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
DDaytime running lamps ................................................. 111
Standing water
Driving instructions ................................................. 209
DISPLAY DEFECTIVE (engine control unit) -
malfunction and warning messages ...................... 231
DISPLAY DEFECTIVE (several systems) - malfunction
and warning messages ............................................ 231
Display illumination ........................................................ 81
Doors .................................................................................. 31
Drinking and driving .................................................... 201
Drive sensibly - save fuel .............................................. 201
Driving instructions ....................................................... 201
Driving off .......................................................................203EELEC. STABIL. PROG. - malfunction and warning
messages .................................................................... 241
Electronic key ................................................................... 23
Changing batteries ................................................... 285
Synchronizing remote control ................................ 287
Electronic stability program (ESP)
Control switch ........................................................... 218
Malfunction and warning messages ...................... 241Malfunction indicator lamp .................................... 227
Synchronizing............................................................ 217
Warning lamp ........................................................... 227
Emergency call
See Tele Aid................................................................ 179
Emergency tensioning device (ETD) ............................. 60
Emergency trunk lid release button ............................. 38
Emergency unlocking in case of accident.................... 34
Emission control ............................................................ 177
Emission control label ................................................... 310
Engine compartment .................................................... 250
ENGINE FAN - malfunction and
warning messages ........................................................ 235
Engine malfunction
CHECK ENGINE malfunction indicator lamp ...... 224
Engine oil additives ....................................................... 318
Engine oil consumption ................................................ 109
Engine oil level
Checking............................................................ 108, 252
Warning ..................................................................... 240
ENGINE OIL LEVEL - malfunction and warning
messages ................................................................... 240
Engine oil level indicator .............................................. 108
ENGINE OIL LEVEL NOT WHEN ENGINE ON
(measuring) - multifunction indicator ................... 109
Engine oils....................................................................... 318
ProCarManuals.com

330 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
LLamps, exterior
Fog lamps ....................................................................110
Headlamp, adjusting ................................................282
Headlamps ..................... 110, 238, 239, 278, 282, 303
Low and high beam .......................................... 113, 279
Parking lamps ...................................................110, 279
Replacing bulbs ......................................................... 277
Side marker lamp, front ........................................... 281
Standing lamps ..................................................110, 279
Taillamp assemblies ......................................... 110, 280
Turn signal lamps ............................................. 113, 279
Layout of poly-V-belt drive ............................................ 310
LIGHT SENSOR - malfunction and
warning messages ......................................................... 239
Lighter ............................................................................. 151
LIGHTING SYSTEM - malfunction and
warning messages ......................................................... 238
Limp home mode (Automatic transmission) ............. 199
Locking and unlocking ................................................... 27
Low beams
See Exterior lamps .................................................... 277
Low engine coolant level warning............................... 236
Luggage cover .................................................................246
MMaintenance ................................................................... 175
Malfunction and indicator lamps in the
instrument cluster ....................................................... 224
Malfunction and warning messages .......................... 230
ABS-SYSTEM ............................................................. 233
BATTERY/ALTERNATOR ......................................... 232
BRAKE ASSIST ......................................................... 233
BRAKE FLUID ........................................................... 234
BRAKE LINING WEAR ............................................ 234
COOLANT (coolant level) ........................................ 236
COOLANT TEMP. (coolant temperature) .............. 237
DISPLAY DEFECTIVE (engine control unit) .........231
DISPLAY DEFECTIVE (several systems) ................231
ELEC. STABIL. PROG. ............................................... 241
ENGINE FAN ............................................................. 235
ENGINE OIL LEVEL ................................................. 240
LIGHT SENSOR ......................................................... 239
LIGHTING SYSTEM .................................................. 238
PARKING BRAKE ..................................................... 235
REMOVE KEY ............................................................ 241
STEER. WHEEL ADJUST. ......................................... 239
TELE AID ................................................................... 243
WASHER FLUID ........................................................ 242
Malfunction/warning message memory .................... 100
ProCarManuals.com

331 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex Manual operation of soft top ........................................288
Mechanical keys ........................................................ 23, 30
Memory
Recalling ................................................................. 44, 76
Storing .......................................................................... 43
Mirror, exterior, adjusting .............................................. 75
Mirror, exterior, rear view .............................................. 75
Mirror, inside, rear view ................................................. 74
Multicontour seat ............................................................ 50
Multifunction display ...................................................... 84
Engine oil level indicator ........................................... 88
FSS (Flexible service system) ................................... 88
Setting the audio volume ......................................... 104
Trip and main odometer ............................................ 88
Vehicle speed ............................................................... 88
Multifunction steering wheel ........................................ 84
NNavigation system - Multifunction display .................. 97
Night security illumination............................................ 111OOn-board diagnostic system ......................................... 224Operator’s Manual ............................................................. 7
Outside temperature indicator ....................................... 82
Overhead control panel ................................................... 19
PPanic button ......................................................................30
Parcel net in front passenger footwell ........................ 152
Parking ........................................................................... 204
Parking brake .....................150, 190, 200, 204, 225, 263
PA R K I N G B R A K E - m a l f u n c t i o n a n d
warning messages ........................................................ 235
Power assistance ........................................................... 202
Power seats, front............................................................. 41
Backres ....................................................................... t 49
Power windows ............................................................... 142
Express opening and closing .................................. 143
Opening and closing ...................................................29
Operated with soft top switch ................................. 144
Synchronizing............................................................ 143
Problems with your vehicle ............................................ 13
Product information........................................................... 6
ProCarManuals.com

332 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
RRadio
See Audio ................................................................... 129
Radio transmitters ......................................................... 174
Rain sensor ......................................................................114
Rear view mirrors
Exterior ......................................................................... 75
Inside ............................................................................ 74
Rear window defroster .................................................. 120
Remote control ................................................................. 25
Battery replacement ................................................. 285
REMOVE KEY - malfunction and
warning messages ......................................................... 241
Replacing bulbs .............................................................. 277
Replacing wiper blade insert ....................................... 296
Reporting Safety Defects ................................................ 14
Residual engine heat utilization (REST) .................... 121
Roadside assistance........................................................... 9
Roadside assistance call
See Tele Aid ............................................................... 182
Roll bar
Switch ........................................................................... 47
Warning lamp ............................................................ 229
Roller blind
Horizontal .................................................................. 170Vertical ........................................................................ 171
SSafety guidelines for the seat belt, emergency
tensioning device and airbag .................................... 67
Seat belts ........................................................................... 53
Fastening ......................................................................55
Seat belt nonusage warning system......................... 54
Unfastening .................................................................. 56
Warning lamp ........................................................... 228
Seat belts and supplemental
restraint system (SRS) .................................................... 52
Seats
Backrest ........................................................................ 49
Front seat adjustment ................................................ 41
Heated ........................................................................... 51
Memory ........................................................................ 43
Multicontour ................................................................ 50
Power seat .................................................................... 41
Selective locking
See Central locking system ....................................... 27
Service indicator
See Flexible service system (FSS) .......................... 105
Setting the audio volume .............................................. 104
ProCarManuals.com
