2002 LINCOLN BLACKWOOD rear view mirror

Rear door lamps
The rear door lamps light when:
²any door or tonneau cover is
opened.
²the instrument panel dimmer
switch is held up until the
courtesy lamps come on.
²the remote entry controls are
pressed and the ignition is OFF.
The rear door lamps can be turned on by pressing the rocker controls
next to each lamp.
AUTOMATIC DIMMING REAR VIEW MIRROR
Your vehicle is equipped with an inside rear view mirror with an
auto-dimming function. The electronic day/night mirror will change from
the normal state to the non-glare state when bright lights (glare) reach
the inside rear view mirror. When the inside rear view mirror detects
bright light from in front of or behind the vehicle, the inside rear view
mirror will automatically adjust (darken) to minimize glare.
Do not block the sensor on the backside of the inside rear view mirror
since this may impair proper system performance.
Press the control to turn the mirror
on or off.
The mirror will automatically return
to the normal state whenever the
vehicle is placed in R
(Reverse)(when the mirror is on) to ensure a bright clear view when
backing up.
OFF AUTO
Controls and features
64

CHILDPROOF DOOR LOCKS
When these locks are set, the rear
doors cannot be opened from the
inside. The rear doors can be
opened from the outside when the
doors are unlocked.
The childproof locks are located on
rear edge of each rear door and
must be set separately for each
door. Setting the lock for one door
will not automatically set the lock
for both doors.
Move lock control up to engage the childproof lock. Move control down
to disengage childproof locks.
POWER SIDE VIEW MIRRORS
The ignition may be in any position to adjust the power side view mirrors.
To adjust your mirrors:
1. Select
to adjust
the left mirror or
to
adjust the right mirror.
2. Move the control in the direction
you wish to tilt the mirror.
3. Return to the center position to lock mirrors in place.
Controls and features
71

Power fold mirrors (if equipped)
Press the control to retract or
extend the outside rear view
mirrors.
If the mirrors are extended and are pushed-in manually, they will deploy
back out after a short period of time; likewise, if they are retracted and
pulled-out manually, they will deploy back in.
Use caution in certain instances (i.e. automatic car washes) in order to
avoid damage to the mirrors.
Signal mirrors
When the turn signal is activated,
the outer portion of the appropriate
mirror housing will blink red.
This provides an additional warning
to other drivers that your vehicle is
about to turn.
Heated outside mirrors
Both mirrors are heated
automatically to remove ice, mist
and fog when the rear window
defrost is activated.
Do not remove ice from the mirrors
with a scraper or attempt to
readjust the mirror glass if it is
frozen in place. These actions could
cause damage to the glass and
mirrors.
Controls and features
72

Using the power lumbar support
The power lumbar control is located
on the outboard side of the seat.
Press one side of the control to
adjust firmness.
Press the other side of the control
to adjust softness.
Memory seats/rearview mirrors/adjustable pedals
This system allows automatic
positioning of the driver seat,
outside rearview mirrors, and
adjustable pedals to three
programmable positions.
The memory seat control is located
on the driver door.
²To program position one, move
the driver seat to the desired
position using the seat controls.
Press the SET control. The SET control indicator light will briefly
illuminate. While the light is illuminated, press control 1.
²To program position two, repeat the previous procedure using control
2.
²To program position three, repeat the previous procedure but press
controls 1 and 2 simultaneously.
A position can only be recalled when the transmission gearshift is in
Park. A memory seat position may be programmed at any time.
The memory seat positions are also recalled when you press your remote
entry transmitter UNLOCK control.
To program the memory seat to remote entry transmitter, refer to
Remote entry systemin theControls and features chapter.
SE T
12
Seating and safety restraints
92

low washer fluid .......................12
safety belt ...................................9
service engine soon ....................8
traction control active ..............12
turn signal indicator .................10
Load limits .................................139
GAWR ......................................139
GVWR ......................................139
trailer towing ..........................139
Loading instructions .................141
Locks
autolock .....................................85
childproof ..................................71
doors ..........................................70
Lubricant specifications ...220, 222
Lumbar support, seats ...............92
M
Message center ...........................57
english/metric button ...............58
menu button .............................59
Mirrors .........................................65
automatic dimming rearview
mirror ........................................64
heated ........................................72
programmable memory ............86
side view mirrors
(power) ...............................71±72
Moon roof ....................................62
Motorcraft parts ................198, 218
O
Octane rating ............................196
Odometer .....................................15
Oil (see Engine oil) ..................171Overdrive .....................................57
P
Panic alarm feature, remote
entry system ................................83
Parking brake ............................130
Parts
(see Motorcraft parts) ..............218
Pedals (see Power
adjustable foot pedals) ...............18
Power distribution box
(see Fuses) ...............................153
Power door locks ..................70, 85
Power steering ..........................132
fluid, checking and adding ....182
fluid, refill capacity ................218
fluid, specifications .........220, 222
Preparing to drive
your vehicle ...............................135
R
Radio ............................................23
Rear window defroster ...............19
Relays ........................................150
Remote entry system ...........80, 83
illuminated entry ......................85
locking/unlocking doors .....81±82
panic alarm ...............................83
replacement/additional
transmitters ...............................84
replacing the batteries .............83
Reverse sensing system .............21
Index
242
