Fast forward
The fast forward control works in
tape and CD modes (if equipped).
²In the tape mode, tape direction
will automatically reverse when
the end of the tape is reached.
²In CD mode, pressing the control for less than three seconds results in
slow forward action. Pressing the control for more than three seconds
results in fast forward action.
Tape direction select
Press SIDE 1±2 to play the alternate
side of a tape.
Eject function
Press the control to stop and eject a
tape.
DolbyTnoise reduction
Dolbytnoise reduction operates
only in tape mode. Dolbytreduces
the amount of hiss and static during
tape playback.
Press the
control to activate
(and deactivate) Dolbytnoise reduction.
Dolbytnoise reduction is manufactured under license from Dolby
Laboratories Licensing Corporation. ªDolbytº and the double-D symbol
are registered trademarks of Dolby Laboratories Licensing Corporation.
Compression feature
Compression adjust brings soft and
loud CD passages together for a
more consistent listening level.
Press the COMP control to activate
and deactivate compression adjust.
FF
2
SIDE 1-2
3
EJ
4
COMP
5
Controls and features
30
ENGINE DATA
Engine 5.4L (4V) V8 engine
Cubic inches 330
Required fuel 91 octane
Firing order 1-3-7-2-6-5-4-8
Spark plug gap 1.3-1.4 mm (0.052-0.056 inch)
Ignition system Coil on plug
Compression ratio 9.5:1
BLACKWOOD DIMENSIONS
DimensionBody Style
4x2 mm (in)
(1) Overall length5 613
(221.0)
(2) Overall width
(closed mirrors)2 022
(79.6)
1
(3) Overall height1 842
(72.5)
(4) Wheel base3 518
(138.5)
(5)Track front/rear1 661
(65.4)
Capacities and specifications
222
