Pressure Diagnosis
Condition Possible Causes Correction
4. Faulty compressor. 4. See A/C Compressor in this group. Replace
the compressor, if required.
The low side pressure is
normal or slightly high, and
the high side pressure is too
high.1. Condenser air flow
restricted.1. Check the condenser for damaged fins, foreign
objects obstructing air flow through the condenser
fins, and missing or improperly installed air seals.
Refer to Cooling for more information on air
seals. Clean, repair, or replace components as
required.
2. Inoperative cooling fan. 2. Refer to Cooling for more information. Test the
cooling fan and replace, if required.
3. Refrigerant system
overcharged.3. See Plumbing/Standard Procedure -
Refrigerant System Charge in this group. Recover
the refrigerant from the refrigerant system.
Charge the refrigerant system to the proper level,
if required.
4. Air in the refrigerant
system.4. See Plumbing/Diagnosis and Testing -
Refrigerant System Leaks in this group. Test the
refrigerant system for leaks. Repair, evacuate and
charge the refrigerant system, if required.
5. Engine overheating. 5. Refer to Cooling for more information. Test the
cooling system and repair, if required.
The low side pressure is too
high, and the high side
pressure is too low.1. Accessory drive belt
slipping.1. Refer to Cooling for more information. Inspect
the accessory drive belt condition and tension.
Tighten or replace the accessory drive belt, if
required.
2. Fixed orifice tube not
installed.2. See A/C Orifice Tube in this group. Replace
the liquid line, if required.
3. Faulty compressor. 3. See A/C Compressor in this group. Replace
the compressor, if required.
The low side pressure is too
low, and the high side
pressure is too high.1. Restricted refrigerant flow
through the refrigerant lines.1. See Liquid, Suction, and Discharge Line in this
group. Inspect the refrigerant lines for kinks, tight
bends or improper routing. Correct the routing or
replace the refrigerant line, if required.
2. Restricted refrigerant flow
through the fixed orifice tube.2. See A/C Orifice Tube in this group. Replace
the liquid line, if required.
3. Restricted refrigerant flow
through the condenser.3. See A/C Condenser in this group. Replace the
restricted condenser, if required.
KJHEATING & AIR CONDITIONING 24 - 5
HEATING & AIR CONDITIONING (Continued)

DIAGNOSIS AND TESTING - HEATER
PERFORMANCE
Before performing the following tests, refer to Cool-
ing for the procedures to check the radiator coolant
level, serpentine drive belt tension, radiator air flow
and the radiator fan operation. Also be certain that
the accessory vacuum supply line is connected at the
engine intake manifold.
MAXIMUM HEATER OUTPUT
Engine coolant is delivered to the heater core
through two heater hoses. With the engine idling atnormal operating temperature, set the temperature
control knob in the full hot position, the mode control
switch knob in the floor heat position, and the blower
motor switch knob in the highest speed position.
Using a test thermometer, check the temperature of
the air being discharged at the HVAC housing floor
outlets. Compare the test thermometer reading to the
Temperature Reference chart.
Temperature Reference
Ambient Air Temperature15.5É C
(60É F)21.1É C
(70É F)26.6É C
(80É F)32.2É C
(90É F)
Minimum Air Temperature at
Floor Outlet52.2É C
(126É F)56.1É C
(133É F)59.4É C
(139É F)62.2É C
(144É F)
If the floor outlet air temperature is too low, refer
to Cooling to check the engine coolant temperature
specifications. Both of the heater hoses should be hot
to the touch. The coolant return heater hose should
be slightly cooler than the coolant supply heater
hose. If the return hose is much cooler than the sup-
ply hose, locate and repair the engine coolant flow
obstruction in the cooling system. Refer to Cooling
for the procedures.
OBSTRUCTED COOLANT FLOW Possible loca-
tions or causes of obstructed coolant flow:
²Pinched or kinked heater hoses.
²Improper heater hose routing.
²Plugged heater hoses or supply and return ports
at the cooling system connections.
²A plugged heater core.
If proper coolant flow through the cooling system is
verified, and heater outlet air temperature is still
low, a mechanical problem may exist.
MECHANICAL PROBLEMS Possible locations or
causes of insufficient heat:
²An obstructed cowl air intake.
²Obstructed heater system outlets.
²A blend door not functioning properly.
TEMPERATURE CONTROL
If the heater outlet air temperature cannot be
adjusted with the temperature control knob on theA/C Heater control panel, the following could require
service:
²The A/C Heater control.
²The blend door actuator.
²The blend door.
²Improper engine coolant temperature.
DIAGNOSIS AND TESTING - VACUUM SYSTEM
Vacuum control is used to operate the mode doors
in the heater-only and a/c heater housings. Testing of
the heater-only and A/C Heater mode control switch
operation will determine if the vacuum, electrical,
and mechanical controls are functioning. However, it
is possible that a vacuum control system that oper-
ates perfectly at engine idle (high engine vacuum)
may not function properly at high engine speeds or
loads (low engine vacuum). This can be caused by
leaks in the vacuum system, or a faulty vacuum
check valve.
A vacuum system test will help to identify the
source of poor vacuum system performance or vac-
uum system leaks. Before starting this test, stop the
engine and make certain that the problem is not a
disconnected vacuum supply tube at the engine
intake manifold vacuum tap or at the vacuum reser-
voir.
24 - 6 HEATING & AIR CONDITIONINGKJ
HEATING & AIR CONDITIONING (Continued)

The pump contains a 3 port solenoid, a pump that
contains a switch, a spring loaded canister vent valve
seal, 2 check valves and a spring/diaphragm.
OPERATION
Immediately after a cold start, engine temperature
between 40ÉF and 86ÉF, the 3 port solenoid is briefly
energized. This initializes the pump by drawing air
into the pump cavity and also closes the vent seal.
During non-test test conditions, the vent seal is held
open by the pump diaphragm assembly which pushes
it open at the full travel position. The vent seal will
remain closed while the pump is cycling. This is due
to the operation of the 3 port solenoid which prevents
the diaphragm assembly from reaching full travel.
After the brief initialization period, the solenoid is
de-energized, allowing atmospheric pressure to enter
the pump cavity. This permits the spring to drive the
diaphragm which forces air out of the pump cavity
and into the vent system. When the solenoid is ener-
gized and de-energized, the cycle is repeated creating
flow in typical diaphragm pump fashion. The pump
is controlled in 2 modes:
PUMP MODE:The pump is cycled at a fixed rate
to achieve a rapid pressure build in order to shorten
the overall test time.
TEST MODE:The solenoid is energized with a
fixed duration pulse. Subsequent fixed pulses occur
when the diaphragm reaches the switch closure
point.
The spring in the pump is set so that the system
will achieve an equalized pressure of about 7.5 inches
of water.
When the pump starts, the cycle rate is quite high.
As the system becomes pressurized pump rate drops.
If there is no leak the pump will quit. If there is a
leak, the test is terminated at the end of the test
mode.
If there is no leak, the purge monitor is run. If the
cycle rate increases due to the flow through the
purge system, the test is passed and the diagnostic is
complete.
The canister vent valve will unseal the system
after completion of the test sequence as the pump
diaphragm assembly moves to the full travel position.
REMOVAL
The Leak Detection Pump (LDP) is attached (bolt-
ed) to the front of the fuel tank (Fig. 3). The LDP
fresh air filter is located on the end of a hose. This
hose is attached to the fuel fill tube assembly below
and near the fuel fill opening (Fig. 1). The LDP and
LDP filter are typically replaced (serviced) as one
unit.
(1) Raise vehicle.(2) Carefully remove two 3/4º vent hoses at sides
of LDP.
(3) Carefully remove other vapor/vacuum hoses
from LDP.
(4) Place a hydraulic jack under fuel tank.
(5) Loosen 2 fuel tank strap mounting bolts at
front of tank about 10 turns.
(6) Lower front of fuel tank about 1/2º.
(7) Remove 2 LDP mounting nuts (Fig. 3) and
lower LDP slightly to gain access to electrical connec-
tor (Fig. 4).
(8) Disconnect electrical connector at LDP. To dis-
connect: Slide red colored tab upward. Push on black
colored tab while removing connector.
(9) Remove LDP from vehicle.
INSTALLATION
The Leak Detection Pump (LDP) is attached (bolt-
ed) to the front of the fuel tank. The LDP filter is
located on the end of a hose. This hose is attached to
the fuel fill tube assembly below and near the fuel
fill opening. The LDP and LDP filter are replaced
(serviced) as one unit.
(1) Install electrical connector to LDP. Push red
colored tab downward to lock connector to LDP.
(2) Position LDP and LDP bracket to fuel tank
mounting studs and install 2 nuts. Tighten nuts to 1
N´m (11 in. lbs.) torque.
(3) Raise fuel tank to body and tighten 2 strap
bolts to 61 N´m (45 ft. lbs.) torque.
Fig. 3 LDP LOCATION / MOUNTING
1 - LDP
2 - FLOW MANAGEMENT VALVE
3 - MOUNTING NUTS
4 - FRONT OF FUEL TANK
25 - 28 EVAPORATIVE EMISSIONSKJ
LEAK DETECTION PUMP (Continued)

OPERATION
The PCV system operates by engine intake mani-
fold vacuum. Filtered air is routed into the crankcase
through the air cleaner hose and crankcase breath-
er(s) (if used). The metered air, along with crankcase
vapors, are drawn through the PCV valve and into a
passage in the intake manifold. The PCV system
manages crankcase pressure and meters blow-by
gases to the intake system, reducing engine sludge
formation.
The PCV valve contains a spring loaded plunger.
This plunger meters the amount of crankcase vapors
routed into the combustion chamber based on intake
manifold vacuum.
TYPICALPCV valves are shown in (Fig. 9), (Fig.
10) and (Fig. 11).
When the engine is not operating, or during an
engine pop-back, the spring forces the plunger back
against the seat (Fig. 9). This will prevent vapors
from flowing through the valve.
During periods of high manifold vacuum, such as
idle or cruising speeds, vacuum is sufficient to com-
pletely compress spring. It will then pull the plunger
to the top of the valve (Fig. 10). In this position there
is minimal vapor flow through the valve.
During periods of moderate manifold vacuum, the
plunger is only pulled part way back from inlet. This
results in maximum vapor flow through the valve
(Fig. 11).
DIAGNOSIS AND TESTING - PCV VALVE
3.7L
(1) Disconnect PCV line/hose (Fig. 7) by discon-
necting rubber connecting hose at PCV valve fitting.
(2) Remove PCV valve at oil filler tube by rotating
PCV valve downward until locating tabs have been
freed at cam lock (Fig. 7). After tabs have cleared,
pull valve straight out from filler tube.To prevent
damage to PCV valve locating tabs, valve must
be pointed downward for removal. Do not force
valve from oil filler tube.
(3) After valve is removed, check condition of valve
o-ring (Fig. 7). Also, PCV valve should rattle when
shaken.
(4) Reconnect PCV valve to its connecting line/
hose.
(5) Start engine and bring to idle speed.
(6) If valve is not plugged, a hissing noise will be
heard as air passes through valve. Also, a strong vac-
uum should be felt with a finger placed at valve
inlet.
(7) If vacuum is not felt at valve inlet, check line/
hose for kinks or for obstruction. If necessary, clean
out intake manifold fitting at rear of manifold. Do
this by turning a 1/4 inch drill (by hand) through the
fitting to dislodge any solid particles. Blow out the
fitting with shop air. If necessary, use a smaller drill
to avoid removing any metal from the fitting.
(8)Do not attempt to clean the old PCV valve.
(9) Return PCV valve back to oil filler tube by
placing valve locating tabs (Fig. 7) into cam lock.
Press PCV valve in and rotate valve upward. A slight
click will be felt when tabs have engaged cam lock.
Valve should be pointed towards rear of vehicle.
(10) Connect PCV line/hose and connecting rubber
hose to PCV valve.
(11) Disconnect rubber hose from fresh air fitting
at air cleaner resonator box. Start engine and bring
to idle speed. Hold a piece of stiff paper (such as a
parts tag) loosely over the opening of the discon-
nected rubber hose.
(12) The paper should be drawn against the hose
opening with noticeable force. This will be after
allowing approximately one minute for crankcase
pressure to reduce.
Fig. 9 Engine Off or Engine Pop-BackÐNo Vapor
Flow
Fig. 10 High Intake Manifold VacuumÐMinimal
Vapor Flow
Fig. 11 Moderate Intake Manifold VacuumÐ
Maximum Vapor Flow
KJEVAPORATIVE EMISSIONS 25 - 31
PCV VALVE (Continued)

ENGINE - DESCRIPTION, COOLING
SYSTEM 3.7L.........................7-1
ENGINE - DESCRIPTION, COOLING
SYSTEM ROUTING 3.7L.................7-2
ENGINE - INSTALLATION, 3.7L . . . 7-17,7-18,7-22
ENGINE - REMOVAL, 3.7L...........7-17,7-21
ENGINE - STANDARD PROCEDURE,
DRAINING COOLING SYSTEM 3.7L........7-12
ENGINE - STANDARD PROCEDURE,
REFILLING COOLING SYSTEM 3.7L.......7-12
ENGINE BLOCK - CLEANING.............9-39
ENGINE BLOCK - DESCRIPTION..........9-39
ENGINE BLOCK - INSPECTION...........9-40
ENGINE COOLANT - DESCRIPTION.........0-3
ENGINE COOLANT TEMPERATURE
SENSOR - DESCRIPTION...............7-19
ENGINE COOLANT TEMPERATURE
SENSOR - INSTALLATION...............7-21
ENGINE COOLANT TEMPERATURE
SENSOR - OPERATION.................7-20
ENGINE COOLANT TEMPERATURE
SENSOR - REMOVAL...................7-20
ENGINE COOLANT THERMOSTAT -
OPERATION..........................7-21
ENGINE CORE AND OIL GALLERY PLUGS
- STANDARD PROCEDURE..............9-10
ENGINE CRADLE CROSSMEMBER -
INSTALLATION........................13-6
ENGINE CRADLE CROSSMEMBER -
REMOVAL...........................13-6
ENGINE DIAGNOSIS - INTRODUCTION -
DIAGNOSIS AND TESTING.................9-4
ENGINE DIAGNOSIS - LUBRICATION -
DIAGNOSIS AND TESTING...............9-7
ENGINE DIAGNOSIS - MECHANICAL -
DIAGNOSIS AND TESTING...............9-6
ENGINE DIAGNOSIS - PERFORMANCE -
DIAGNOSIS AND TESTING...............9-4
ENGINE FIRING ORDER, 2.4L 4-
CYLINDER...........................8I-2
ENGINE FIRING ORDER, 3.7L V-6.........8I-2
ENGINE GASKET SURFACE
PREPARATION - STANDARD
PROCEDURE..........................9-9
ENGINE OIL - STANDARD PROCEDURE....9-61
ENGINE OIL LEAK - DIAGNOSIS AND
TESTING............................9-60
ENGINE OIL PRESSURE - DIAGNOSIS
AND TESTING........................9-60
ENGINE, SPECIAL TOOLS - 3.7L..........9-15
ENGINE, SPECIFICATIONS - 3.7L.........9-12
ENGINE TEMPERATURE GAUGE -
DESCRIPTION.......................8J-18
ENGINE TEMPERATURE GAUGE -
OPERATION.........................8J-18
ENGINES - GENERATOR RATINGS, GAS . . . 8F-23
ENTRY MODULE - DESCRIPTION,
REMOTE KEYLESS....................8N-7
ENTRY MODULE - DIAGNOSIS AND
TESTING, REMOTE KEYLESS............8N-7
ENTRY MODULE - INSTALLATION,
REMOTE KEYLESS....................8N-7
ENTRY MODULE - OPERATION, REMOTE
KEYLESS............................8N-7
ENTRY MODULE - REMOVAL, REMOTE
KEYLESS............................8N-7
ENTRY TRANSMITTER - DIAGNOSIS AND
TESTING, REMOTE KEYLESS............8N-8
ENTRY TRANSMITTER -
SPECIFICATIONS, REMOTE KEYLESS......8N-9
EQUIPMENT - STANDARD PROCEDURE,
REFRIGERANT SYSTEM SERVICE........24-40
ERASING TRANSMITTER CODES -
STANDARD PROCEDURE...............8M-8
EVACUATE - STANDARD PROCEDURE,
REFRIGERANT SYSTEM...............24-41
EVAPORATION CONTROL SYSTEM -
DESCRIPTION.......................25-24
EVAPORATOR - DESCRIPTION, A/C.......24-49
EVAPORATOR - INSTALLATION, A/C......24-49
EVAPORATOR - OPERATION, A/C........24-49
EVAPORATOR - REMOVAL, A/C..........24-49
EVAP/PURGE SOLENOID - DESCRIPTION . . 25-27
EVAP/PURGE SOLENOID - INSTALLATION
. 25-27
EVAP/PURGE SOLENOID - OPERATION
....25-27
EVAP/PURGE SOLENOID - REMOVAL
.....25-27
EXCEPT DIESEL - TORQUE
.............8F-23
EXHAUST MANIFOLD - DESCRIPTION
.....9-69EXHAUST MANIFOLD - INSTALLATION.....9-70
EXHAUST MANIFOLD - REMOVAL.........9-69
EXHAUST SYSTEM - DESCRIPTION.......11-1
EXHAUST SYSTEM - DIAGNOSIS AND
TESTING............................11-2
EXTENSION HOUSING BUSHING -
NV3550 - INSTALLATION...............21-74
EXTENSION HOUSING BUSHING -
NV3550 - REMOVAL..................21-73
EXTENSION HOUSING SEAL - NV1500 -
INSTALLATION.......................21-32
EXTENSION HOUSING SEAL - NV1500 -
REMOVAL..........................21-32
EXTENSION HOUSING SEAL - NV3550 -
INSTALLATION.......................21-74
EXTENSION HOUSING SEAL - NV3550 -
REMOVAL..........................21-74
EXTERIOR - DESCRIPTION, LAMPS/
LIGHTING...........................8L-2
EXTERIOR - DIAGNOSIS AND TESTING,
LAMPS/LIGHTING.....................8L-7
EXTERIOR - OPERATION, LAMPS/
LIGHTING...........................8L-5
EXTERIOR - SPECIFICATIONS,
LAMPS/LIGHTING....................8L-15
EXTERIOR HANDLE - INSTALLATION....23-123,
23-130,23-136
EXTERIOR HANDLE - REMOVAL . 23-123,23-130,
23-136
EXTERIOR NAME PLATES -
INSTALLATION......................23-141
EXTERIOR NAME PLATES - REMOVAL . . . 23-140
FAN - ELECTRIC - DESCRIPTION,
RADIATOR...........................7-26
FAN - ELECTRIC - INSTALLATION,
RADIATOR...........................7-27
FAN - ELECTRIC - OPERATION,
RADIATOR...........................7-26
FAN - ELECTRIC - REMOVAL, RADIATOR . . . 7-26
FAN - VISCOUS - CLEANING, RADIATOR . . . 7-29
FAN - VISCOUS - DESCRIPTION,
RADIATOR...........................7-27
FAN - VISCOUS - INSPECTION,
RADIATOR...........................7-29
FAN - VISCOUS - INSTALLATION,
RADIATOR...........................7-29
FAN - VISCOUS - OPERATION,
RADIATOR...........................7-27
FAN - VISCOUS - REMOVAL, RADIATOR....7-28
FAN DRIVE - DIAGNOSIS AND TESTING,
VISCOUS............................7-28
FASCIA - INSTALLATION, FRONT.........13-2
FASCIA - INSTALLATION, REAR..........13-2
FASCIA - REMOVAL, FRONT.............13-1
FASCIA - REMOVAL, REAR..............13-2
FASCIA SUPPORT - INSTALLATION,
REAR...............................13-3
FASCIA SUPPORT - REMOVAL, REAR......13-3
FASTENER IDENTIFICATION -
DESCRIPTION......................Intro.-1
FENDER - INSTALLATION, FRONT.......23-141
FENDER - REMOVAL, FRONT..........23-141
FILL - STANDARD PROCEDURE, FLUID
DRAIN......................21-208,21-246
FILL - STANDARD PROCEDURE,
TRANSMISSION.....................21-128
FILL DOOR/HOUSING - INSTALLATION,
FUEL.............................23-141
FILL DOOR/HOUSING - REMOVAL, FUEL . 23-141
FILL/CHECK LOCATIONS - DESCRIPTION,
FLUID...............................0-4
FILLER CAP - DESCRIPTION, FUEL.......25-27
FILLER CAP - OPERATION, FUEL........25-27
FILTER - DESCRIPTION, FUEL............14-7
FILTER - INSTALLATION, FUEL...........14-8
FILTER - INSTALLATION, INLET..........14-28
FILTER - INSTALLATION, OIL............9-63
FILTER - REMOVAL, FUEL...............14-7
FILTER - REMOVAL, INLET.............14-28
FILTER - REMOVAL, OIL
................9-63
FILTER REPLACEMENT - STANDARD
PROCEDURE, FLUID
.................21-126
FINESSE SANDING/BUFFING &
POLISHING - DESCRIPTION
...........23-163
FINISH - DESCRIPTION, BASE
COAT/CLEAR COAT
..................23-162
FIRING ORDER, 2.4L 4-CYLINDER -
ENGINE
..............................8I-2FIRING ORDER, 3.7L V-6 - ENGINE........8I-2
FITTING - CONNECTING ROD BEARING....9-49
FITTING - DESCRIPTION, QUICK
CONNECT...........................14-10
FITTING - MAIN BEARING...............9-45
FITTING - STANDARD PROCEDURE,
CONNECTING ROD BEARING............9-40
FITTING - STANDARD PROCEDURE,
PISTON.............................9-50
FITTING - STANDARD PROCEDURE,
PISTON RING........................9-52
FITTINGS - STANDARD PROCEDURE,
QUICK-CONNECT.....................14-10
FLARE MOLDINGS - INSTALLATION,
FRONT WHEEL OPENING.............23-145
FLARE MOLDINGS - INSTALLATION,
REAR WHEEL OPENING..............23-145
FLARE MOLDINGS - REMOVAL, FRONT
WHEEL OPENING...................23-145
FLARE MOLDINGS - REMOVAL, REAR
WHEEL OPENING...................23-145
FLARING - STANDARD PROCEDURE,
DOUBLE INVERTED.....................5-8
FLARING - STANDARD PROCEDURE, ISO....5-8
FLASHER - DESCRIPTION, COMBINATION . 8L-19
FLASHER - OPERATION, COMBINATION . . . 8L-19
FLEX PLATE - INSTALLATION............9-49
FLEX PLATE - REMOVAL................9-49
FLIP-UP GLASS - INSTALLATION.......23-136
FLIP-UP GLASS - REMOVAL...........23-136
FLIP-UP GLASS AJAR SWITCH -
DESCRIPTION.......................8L-77
FLIP-UP GLASS AJAR SWITCH -
OPERATION.........................8L-77
FLIP-UP GLASS LATCH - INSTALLATION . 23-136
FLIP-UP GLASS LATCH - REMOVAL.....23-136
FLIP-UP GLASS RELEASE SWITCH -
DIAGNOSIS AND TESTING..............8N-5
FLIP-UP GLASS SUPPORT CYLINDER -
INSTALLATION......................23-139
FLIP-UP GLASS SUPPORT CYLINDER -
REMOVAL.........................23-139
FLOOR - DEFROST DOO - INSTALLATION . . 24-37
FLOOR - DEFROST DOOR - REMOVAL....24-36
FLOOR - DEFROST DOOR ACTUATOR -
INSTALLATION.......................24-25
FLOOR - DEFROST DOOR ACTUATOR -
REMOVAL..........................24-24
FLOOR CONSOLE - INSTALLATION......23-158
FLOOR CONSOLE - REMOVAL..........23-158
FLOOR CONSOLE DUCT - INSTALLATION . . 24-31
FLOOR CONSOLE DUCT - REMOVAL.....24-31
FLOOR CONSOLE LID LATCH -
INSTALLATION......................23-158
FLOOR CONSOLE LID LATCH - REMOVAL . 23-158
FLOOR DUCT - INSTALLATION..........24-32
FLOOR DUCT - REMOVAL..............24-32
FLOOR MATS - INSTALLATION, CARPETS . 23-158
FLOOR MATS - REMOVAL, CARPETS....23-158
FLOOR SHIFT BOOT - INSTALLATION,
4WD .............................23-156
FLOOR SHIFT BOOT - REMOVAL, 4WD . . . 23-156
FLOW AND PRESSURE - DIAGNOSIS
AND TESTING, POWER STEERING........19-3
FLOW MANAGEMENT VALVE -
DESCRIPTION........................14-6
FLOW MANAGEMENT VALVE -
INSTALLATION........................14-7
FLOW MANAGEMENT VALVE -
OPERATION..........................14-6
FLOW MANAGEMENT VALVE - REMOVAL . . . 14-6
FLUID - DESCRIPTION, AUTOMATIC
TRANSMISSION.......................0-2
FLUID - DIAGNOSIS AND TESTING,
CAUSES OF BURNT..................21-125
FLUID - OPERATION, AUTOMATIC
TRANSMISSION.......................0-4
FLUID AND FILTER REPLACEMENT -
STANDARD PROCEDURE..............21-126
FLUID CAPACITIES - SPECIFICATIONS......0-4
FLUID CONTAMINATION - DIAGNOSIS
AND TESTING......................21-125
FLUID CONTAMINATION - DIAGNOSIS
AND TESTING, BRAKE
..................5-26
FLUID COOLER - DESCRIPTION
.........19-20
FLUID COOLER - INSTALLATION
.........19-20
FLUID COOLER - OPERATION
...........19-20
FLUID COOLER - REMOVAL
............19-20
KJINDEX 9
Description Group-Page Description Group-Page Description Group-Page

LATCH - ACCESS PANEL - REMOVAL....23-139
LATCH - INSTALLATION . . 23-120,23-124,23-131,
23-137
LATCH - INSTALLATION, FLIP-UP GLASS . 23-136
LATCH - INSTALLATION, FLOOR
CONSOLE LID......................23-158
LATCH - INSTALLATION, GLOVE BOX....23-148
LATCH / LOCK - INSTALLATION,
FOLDING REAR SEAT BACK...........23-170
LATCH / LOCK - REMOVAL, FOLDING
REAR SEAT BACK...................23-170
LATCH - REMOVAL......23-120,23-124,23-131,
23-137
LATCH - REMOVAL, FLIP-UP GLASS.....23-136
LATCH - REMOVAL, FLOOR CONSOLE
LID...............................23-158
LATCH - REMOVAL, GLOVE BOX........23-148
LATCH RELEASE CABLE - INSTALLATION . 23-120
LATCH RELEASE CABLE - REMOVAL....23-120
LATCH RELEASE HANDLE -
INSTALLATION......................23-120
LATCH RELEASE HANDLE - REMOVAL . . . 23-120
LATCH STRIKER - INSTALLATION......23-124,
23-132,23-137
LATCH STRIKER - INSTALLATION, GLOVE
BOX ..............................23-149
LATCH STRIKER - INSTALLATION, REAR
SEAT BACK........................23-171
LATCH STRIKER - REMOVAL....23-124,23-132,
23-137
LATCH STRIKER - REMOVAL, GLOVE
BOX ..............................23-148
LATCH STRIKER - REMOVAL, REAR
SEAT BACK........................23-170
LEAK - DIAGNOSIS AND TESTING,
CONVERTER HOUSING FLUID...........21-80
LEAK - DIAGNOSIS AND TESTING,
ENGINE OIL..........................9-60
LEAK DETECTION PUMP - DESCRIPTION . . 25-27
LEAK DETECTION PUMP - INSTALLATION . 25-28
LEAK DETECTION PUMP - OPERATION....25-28
LEAK DETECTION PUMP - REMOVAL.....25-28
LEAK DOWN TEST - DIAGNOSIS AND
TESTING, FUEL PRESSURE..............14-3
LEAKAGE - DIAGNOSIS AND TESTING,
CYLINDER COMBUSTION PRESSURE.......9-8
LEAKS - DIAGNOSIS AND TESTING,
COOLING SYSTEM.....................7-4
LEAKS - DIAGNOSIS AND TESTING,
INTAKE MANIFOLD....................9-68
LEAKS - DIAGNOSIS AND TESTING,
REAR SEAL AREA.....................9-61
LEAKS - DIAGNOSIS AND TESTING,
WATER .............................23-2
LEAKS - STANDARD PROCEDURE,
REPAIRING..........................22-8
LEARN - STANDARD PROCEDURE, TCM
QUICK.............................8E-21
LEFT POWER SEAT SWITCH -
DESCRIPTION.......................8N-16
LEFT POWER SEAT SWITCH -
DIAGNOSIS AND TESTING.............8N-17
LEFT POWER SEAT SWITCH -
INSTALLATION......................8N-18
LEFT POWER SEAT SWITCH -
OPERATION
.........................8N-17
LEFT POWER SEAT SWITCH - REMOVAL
. . 8N-18
LEFT SIDE - INSTALLATION
.........2-12,2-15
LEFT SIDE - REMOVAL
.............2-11,2-15
LEVEL - DIAGNOSIS AND TESTING,
EFFECTS OF INCORRECT FLUID
........21-125
LEVEL - STANDARD PROCEDURE,
REFRIGERANT OIL
...................24-54
LEVEL - STANDARD PROCEDURES,
MASTER CYLINDER FLUID
..............5-26
LEVEL CHECK - STANDARD
PROCEDURE, FLUID
.................21-126
LEVEL SENDING UNIT - DIAGNOSIS AND
TESTING, FUEL
.......................14-9
LEVEL SENDING UNIT / SENSOR -
DESCRIPTION, FUEL
...................14-9
LEVEL SENDING UNIT / SENSOR -
INSTALLATION, FUEL
.................14-10
LEVEL SENDING UNIT / SENSOR -
OPERATION, FUEL
.....................14-9
LEVEL SENDING UNIT / SENSOR -
REMOVAL, FUEL
......................14-9LEVEL SWITCH - DESCRIPTION,
WASHER FLUID.....................8R-17
LEVEL SWITCH - INSTALLATION,
WASHER FLUID.....................8R-18
LEVEL SWITCH - OPERATION, WASHER
FLUID.............................8R-17
LEVEL SWITCH - REMOVAL, WASHER
FLUID.............................8R-17
LEVELING MOTOR - DESCRIPTION,
HEADLAMP.........................8L-35
LEVELING MOTOR - INSTALLATION,
HEADLAMP.........................8L-36
LEVELING MOTOR - OPERATION,
HEADLAMP.........................8L-36
LEVELING MOTOR - REMOVAL,
HEADLAMP.........................8L-36
LEVELING SWITCH - DESCRIPTION,
HEADLAMP.........................8L-37
LEVELING SWITCH - DIAGNOSIS AND
TESTING, HEADLAMP.................8L-37
LEVELING SWITCH - INSTALLATION,
HEADLAMP.........................8L-38
LEVELING SWITCH - OPERATION,
HEADLAMP.........................8L-37
LEVELING SWITCH - REMOVAL,
HEADLAMP.........................8L-38
LEVER - INSTALLATION................5-31
LEVER - INSTALLATION, SHIFT . . . 21-214,21-249
LEVER - REMOVAL....................5-31
LEVER - REMOVAL, SHIFT......21-213,21-248
LHD - INSTALLATION...............8W-97-6
LHD - REMOVAL....................8W-97-5
LICENSE PLATE LAMP BULB -
INSTALLATION.......................8L-45
LICENSE PLATE LAMP BULB - REMOVAL . . 8L-44
LICENSE PLATE LAMP UNIT -
INSTALLATION.......................8L-46
LICENSE PLATE LAMP UNIT - REMOVAL . . 8L-45
LID LATCH - INSTALLATION, FLOOR
CONSOLE..........................23-158
LID LATCH - REMOVAL, FLOOR
CONSOLE..........................23-158
LIGHTER OUTLET - DESCRIPTION,
CIGAR...........................8W-97-2
LIGHTER OUTLET - DIAGNOSIS AND
TESTING, CIGAR...................8W-97-2
LIGHTER OUTLET - OPERATION, CIGAR . 8W-97-2
LIMITS - DESCRIPTION, HIGH AND LOW . . 25-20
LINE - DESCRIPTION, REFRIGERANT.....24-38
LINE - INSTALLATION, A/C DISCHARGE . . . 24-47
LINE - INSTALLATION, A/C LIQUID.......24-47
LINE - INSTALLATION, A/C SUCTION.....24-49
LINE - REMOVAL, A/C DISCHARGE.......24-46
LINE - REMOVAL, A/C LIQUID...........24-47
LINE - REMOVAL, A/C SUCTION.........24-48
LINE AND HOSES - DIAGNOSIS AND
TESTING, BRAKE.......................5-8
LINE PRESSURE (LP) SENSOR -
DESCRIPTION......................21-144
LINE PRESSURE (LP) SENSOR -
INSTALLATION......................21-144
LINE PRESSURE (LP) SENSOR -
OPERATION........................21-144
LINE PRESSURE (LP) SENSOR -
REMOVAL.........................21-144
LINES - DESCRIPTION, BRAKE............5-8
LINES - DESCRIPTION, FUEL...........14-10
LINES - DESCRIPTION, VACUUM........25-33
LINK - INSTALLATION, STABILIZER.......2-14
LINK - REMOVAL, STABILIZER...........2-14
LINK CONNECTOR - DESCRIPTION, DATA . 8E-10
LINK CONNECTOR - OPERATION, DATA . . . 8E-10
LINKAGE - INSTALLATION................6-9
LINKAGE - REMOVAL...................6-8
LINKAGE - STANDARD PROCEDURE,
STEERING..........................19-16
LIQUID LINE - INSTALLATION, A/C.......24-47
LIQUID LINE - REMOVAL, A/C...........24-47
LOAD TEST - STANDARD PROCEDURE....8F-12
LOAD VALUE - DESCRIPTION
...........25-20
LOADS - STANDARD PROCEDURE,
TESTING FOR A SHORT TO GROUND
ON FUSES POWERING SEVERAL
......8W-01-9
LOCATION - DESCRIPTION, CONNECTOR/
GROUND/SPLICE
...................8W-91-1
LOCATIONS - DESCRIPTION, FLUID
FILL/CHECK
...........................0-4
LOCATIONS - SPECIFICATIONS, SEALER
. . 23-87LOCATIONS - SPECIFICATIONS, WELD
AND STRUCTURAL ADHESIVE...........23-9
LOCK - INSTALLATION, FOLDING REAR
SEAT BACK LATCH..................23-170
LOCK - REMOVAL, FOLDING REAR SEAT
BACK LATCH.......................23-170
LOCK / UNLOCK SWITCH -
INSTALLATION, DOOR.................8N-5
LOCK / UNLOCK SWITCH - REMOVAL,
DOOR..............................8N-4
LOCK CYLINDER - INSTALLATION......23-125,
23-138
LOCK CYLINDER - INSTALLATION.......19-11
LOCK CYLINDER - REMOVAL....23-125,23-137
LOCK CYLINDER - REMOVAL...........19-10
LOCK MOTOR - DESCRIPTION, DOOR.....8N-5
LOCK MOTOR - DIAGNOSIS AND
TESTING, DOOR......................8N-5
LOCK MOTOR - OPERATION, DOOR.......8N-5
LOCK OUT - ADJUSTMENT..............5-30
LOCK RELAY - DESCRIPTION, DOOR......8N-6
LOCK RELAY - DIAGNOSIS AND
TESTING, DOOR......................8N-6
LOCK RELAY - INSTALLATION, DOOR.....8N-7
LOCK RELAY - OPERATION, DOOR........8N-6
LOCK RELAY - REMOVAL, DOOR.........8N-6
LOCK SWITCH - DESCRIPTION, DOOR
CYLINDER...........................8Q-9
LOCK SWITCH - DESCRIPTION,
TAILGATE CYLINDER...................8N-9
LOCK SWITCH - DIAGNOSIS AND
TESTING, DOOR CYLINDER............8Q-10
LOCK SWITCH - DIAGNOSIS AND
TESTING, TAILGATE CYLINDER..........8N-9
LOCK SWITCH - INSTALLATION, DOOR
CYLINDER..........................8Q-10
LOCK SWITCH - INSTALLATION,
TAILGATE CYLINDER..................8N-10
LOCK SWITCH - OPERATION, DOOR
CYLINDER..........................8Q-10
LOCK SWITCH - OPERATION, TAILGATE
CYLINDER...........................8N-9
LOCK SWITCH - REMOVAL, DOOR
CYLINDER..........................8Q-10
LOCK SWITCH - REMOVAL, TAILGATE
CYLINDER..........................8N-10
LOCKS - DESCRIPTION, POWER.........8N-1
LOCKS - DIAGNOSIS AND TESTING,
POWER.............................8N-3
LOCKS - OPERATION, POWER...........8N-3
LOCK/UNLOCK SWITCH - DIAGNOSIS
AND TESTING, DOOR..................8N-4
LOOP ADJUSTER - INSTALLATION, SEAT
BELT TURNING......................8O-38
LOOP ADJUSTER - REMOVAL, SEAT
BELT TURNING......................8O-37
LOW BEAM RELAY - DESCRIPTION,
HEADLAMP.........................8L-39
LOW BEAM RELAY - DIAGNOSIS AND
TESTING, HEADLAMP.................8L-40
LOW BEAM RELAY - INSTALLATION,
HEADLAMP.........................8L-41
LOW BEAM RELAY - OPERATION,
HEADLAMP.........................8L-39
LOW BEAM RELAY - REMOVAL,
HEADLAMP
.........................8L-40
LOW FUEL INDICATOR - DESCRIPTION
. . . 8J-22
LOW FUEL INDICATOR - OPERATION
.....8J-22
LOW INDICATOR - DESCRIPTION,
COOLANT
...........................8J-15
LOW INDICATOR - OPERATION,
COOLANT
...........................8J-16
LOW LIMITS - DESCRIPTION, HIGH
......25-20
LOW MODE INDICATOR - DESCRIPTION,
FOUR
..............................8J-29
LOW MODE INDICATOR - OPERATION,
FOUR
..............................8J-30
LOW OIL PRESSURE INDICATOR -
DESCRIPTION
.......................8J-23
LOW OIL PRESSURE INDICATOR -
OPERATION
.........................8J-23
LOW PRESSURE SWITCH -
DESCRIPTION, A/C
...................24-18
LOW PRESSURE SWITCH - DIAGNOSIS
AND TESTING, A/C
...................24-19
LOW PRESSURE SWITCH -
INSTALLATION, A/C
...................24-19
KJINDEX 15
Description Group-Page Description Group-Page Description Group-Page

OPERATION - DESCRIPTION, MODES OF . . 8E-11
OPERATION - DIAGNOSIS AND TESTING,
AIR CHECKING TRANSMISSION
CLUTCH............................21-80
ORDER, 2.4L 4-CYLINDER - ENGINE
FIRING..............................8I-2
ORDER, 3.7L V-6 - ENGINE FIRING........8I-2
ORIFICE TUBE - DESCRIPTION, A/C......24-50
ORIFICE TUBE - INSTALLATION, A/C......24-50
ORIFICE TUBE - OPERATION, A/C........24-50
ORIFICE TUBE - REMOVAL, A/C.........24-50
ORVR - DESCRIPTION.................25-29
ORVR - OPERATION..................25-29
OUT - ADJUSTMENT, LOCK..............5-30
OUTBOARD SEAT BELT & RETRACTOR -
INSTALLATION, REAR.................8O-34
OUTBOARD SEAT BELT & RETRACTOR -
REMOVAL, REAR....................8O-33
OUTER BELT MOLDING - INSTALLATION,
FRONT DOOR......................23-186
OUTER BELT MOLDING - INSTALLATION,
REAR DOOR.......................23-186
OUTER BELT MOLDING - REMOVAL,
FRONT DOOR......................23-186
OUTER BELT MOLDING - REMOVAL,
REAR DOOR.......................23-186
OUTER TIE ROD END REMOVAL TOOL,
SPECIAL TOOLS.....................19-15
OUTLET - DESCRIPTION, CIGAR
LIGHTER.........................8W-97-2
OUTLET - DESCRIPTION, POWER......8W-97-11
OUTLET - DIAGNOSIS AND TESTING,
CIGAR LIGHTER...................8W-97-2
OUTLET - DIAGNOSIS AND TESTING,
POWER.........................8W-97-11
OUTLET - INSTALLATION, POWER....8W-97-13
OUTLET - OPERATION, CIGAR LIGHTER . 8W-97-2
OUTLET - OPERATION, POWER......8W-97-11
OUTLET - REMOVAL, POWER........8W-97-12
OUTLET BARRELS - INSTALLATION,
PANEL.............................24-29
OUTLET BARRELS - REMOVAL, PANEL . . . 24-29
OUTLETS - DESCRIPTION, DEMISTER....24-29
OUTPUT - DESCRIPTION, PCM...........8I-4
OUTPUT - OPERATION, PCM............14-33
OUTPUT - OPERATION, PCM.............8I-4
OUTPUT SHAFT SEAL - INSTALLATION,
FRONT......................21-208,21-246
OUTPUT SHAFT SEAL - INSTALLATION,
REAR.............................21-212
OUTPUT SHAFT SEAL - REMOVAL,
FRONT......................21-208,21-246
OUTPUT SHAFT SEAL - REMOVAL, REAR . 21-210
OUTPUT SPEED SENSOR - DESCRIPTION . 21-152
OUTPUT SPEED SENSOR -
INSTALLATION......................21-152
OUTPUT SPEED SENSOR - OPERATION . . 21-152
OUTPUT SPEED SENSOR - REMOVAL . . . 21-152
OVERDRIVE OFF INDICATOR -
DESCRIPTION.......................8J-26
OVERDRIVE OFF INDICATOR -
OPERATION.........................8J-26
OVERDRIVE SWITCH - DESCRIPTION....21-153
OVERDRIVE SWITCH - OPERATION.....21-153
OVERHEAD CONSOLE - DESCRIPTION....8M-1
OVERHEAD CONSOLE - OPERATION......8M-2
OVERHEAD CONSOLE, REMOVAL........8M-4
OVERRIDE RELAY - DESCRIPTION,
CLUTCH SWITCH......................6-10
OVERRIDE RELAY - INSTALLATION,
CLUTCH SWITCH......................6-10
OVERRIDE RELAY - OPERATION,
CLUTCH SWITCH......................6-10
OVERRIDE RELAY - REMOVAL, CLUTCH
SWITCH.............................6-10
OXYGEN SENSOR - DESCRIPTION.......14-40
OXYGEN SENSOR - INSTALLATION.......14-43
OXYGEN SENSOR - OPERATION.........14-40
OXYGEN SENSOR - REMOVAL..........14-41
PADS - INSTALLATION, FRONT BRAKE.....5-11
PADS - REMOVAL, FRONT BRAKE........5-11
PAINT CODE - DESCRIPTION..........23-162
PAINT CODES - SPECIFICATIONS.......23-162
PAINT TOUCH-UP - DESCRIPTION
......23-163
PAN - CLEANING, OIL
..................9-63
PAN - DESCRIPTION, OIL
...............9-63
PAN - INSPECTION, OIL
................9-63
PAN - INSTALLATION, OIL
...............9-64PAN - REMOVAL, OIL..................9-63
PANEL - DESCRIPTION, LATCH - ACCESS . 23-139
PANEL - INSTALLATION, GLASS........23-178
PANEL - INSTALLATION, LATCH -
ACCESS...........................23-139
PANEL - INSTALLATION, QUARTER TRIM . 23-159
PANEL - INSTALLATION, TRIM . . . 23-126,23-132,
23-138
PANEL - REMOVAL, GLASS............23-178
PANEL - REMOVAL, LATCH - ACCESS . . . 23-139
PANEL - REMOVAL, QUARTER TRIM....23-159
PANEL - REMOVAL, TRIM . 23-125,23-132,23-138
PANEL ADJUSTMENT, ADJUSTMENTS -
SUNROOF GLASS...................23-178
PANEL ANTENNA CABLE -
INSTALLATION, INSTRUMENT............8A-8
PANEL ANTENNA CABLE - REMOVAL,
INSTRUMENT........................8A-7
PANEL ASSEMBLY - INSTALLATION,
INSTRUMENT......................23-151
PANEL ASSEMBLY - REMOVAL,
INSTRUMENT......................23-149
PANEL CENTER BEZEL - INSTALLATION,
INSTRUMENT......................23-154
PANEL CENTER BEZEL - REMOVAL,
INSTRUMENT......................23-154
PANEL DOOR - INSTALLATION..........24-36
PANEL DOOR ACTUATOR -
INSTALLATION.......................24-25
PANEL DOOR ACTUATOR - REMOVAL....24-24
PANEL DRIVER SIDE BEZELS -
INSTALLATION, INSTRUMENT..........23-154
PANEL DRIVER SIDE BEZELS -
REMOVAL, INSTRUMENT.............23-153
PANEL END CAP - INSTALLATION,
INSTRUMENT......................23-153
PANEL END CAP - REMOVAL,
INSTRUMENT......................23-153
PANEL OUTLET BARRELS -
INSTALLATION.......................24-29
PANEL OUTLET BARRELS - REMOVAL....24-29
PANEL PASSENGER SIDE BEZEL -
INSTALLATION, INSTRUMENT..........23-154
PANEL PASSENGER SIDE BEZEL -
REMOVAL, INSTRUMENT.............23-154
PANEL SEAL - INSTALLATION, GLASS . . . 23-178
PANEL SEAL - REMOVAL, GLASS.......23-178
PANEL TOP COVER - INSTALLATION,
INSTRUMENT......................23-153
PANEL TOP COVER - REMOVAL,
INSTRUMENT......................23-152
PARK - INTERLOCK CABLE -
INSTALLATION......................21-153
PARK - INTERLOCK CABLE - REMOVAL . . 21-153
PARK LAMP RELAY - DESCRIPTION......8L-54
PARK LAMP RELAY - DIAGNOSIS AND
TESTING...........................8L-55
PARK LAMP RELAY - INSTALLATION.....8L-56
PARK LAMP RELAY - OPERATION.......8L-54
PARK LAMP RELAY - REMOVAL.........8L-55
PARK RAMP - INSTALLATION, WIPER
ARM ..............................8R-43
PARK RAMP - REMOVAL, WIPER ARM . . . 8R-43
PARKING BRAKE - DESCRIPTION.........5-29
PARKING BRAKE - OPERATION...........5-29
PARK-INTERLOCK CABLE -
ADJUSTMENTS.....................21-154
PART TIME INDICATOR - DESCRIPTION . . . 8J-29
PART TIME INDICATOR - OPERATION.....8J-29
PASSENGER AIRBAG - DESCRIPTION....8O-27
PASSENGER AIRBAG - INSTALLATION....8O-29
PASSENGER AIRBAG - OPERATION......8O-27
PASSENGER AIRBAG - REMOVAL........8O-28
PASSENGER AIRBAG DOOR -
INSTALLATION......................8O-30
PASSENGER AIRBAG DOOR - REMOVAL . . 8O-29
PASSENGER AIRBAG MOUNTING
BRACKET - INSTALLATION.............8O-31
PASSENGER AIRBAG MOUNTING
BRACKET - REMOVAL
.................8O-31
PASSENGER SEAT HEATER SWITCH -
DESCRIPTION
.......................8G-14
PASSENGER SEAT HEATER SWITCH -
INSTALLATION
......................8G-15
PASSENGER SEAT HEATER SWITCH -
OPERATION
.........................8G-14
PASSENGER SEAT HEATER SWITCH -
REMOVAL
..........................8G-15PASSENGER SIDE BEZEL -
INSTALLATION, INSTRUMENT PANEL....23-154
PASSENGER SIDE BEZEL - REMOVAL,
INSTRUMENT PANEL.................23-154
PATTERNS - DIAGNOSIS AND TESTING,
TIRE WEAR..........................22-8
PCM - DESCRIPTION..................8E-11
PCM - OPERATION...................8E-14
PCM INPUT - OPERATION, ASD SENSE.....8I-4
PCM OUTPUT - DESCRIPTION............8I-4
PCM OUTPUT - OPERATION............14-33
PCM OUTPUT - OPERATION.............8I-4
PCM/SKIM PROGRAMMING - STANDARD
PROCEDURE.........................8E-1
PCV VALVE - DESCRIPTION............25-29
PCV VALVE - DIAGNOSIS AND TESTING . . . 25-31
PCV VALVE - INSTALLATION............25-32
PCV VALVE - OPERATION..............25-31
PCV VALVE - REMOVAL...............25-32
PEDAL - DESCRIPTION.................5-20
PEDAL - INSTALLATION................5-20
PEDAL - INSTALLATION, ACCELERATOR . . . 14-30
PEDAL - INSTALLATION, CLUTCH.........6-10
PEDAL - OPERATION...................5-20
PEDAL - REMOVAL....................5-20
PEDAL - REMOVAL, ACCELERATOR......14-29
PEDAL - REMOVAL, CLUTCH............6-10
PEDAL POSITION SWITCH -
DESCRIPTION, CLUTCH.................6-11
PEDAL POSITION SWITCH - DIAGNOSIS
AND TESTING, CLUTCH.................6-11
PEDAL POSITION SWITCH - OPERATION,
CLUTCH.............................6-11
PERFORMANCE - DIAGNOSIS AND
TESTING, A/C........................24-2
PERFORMANCE - DIAGNOSIS AND
TESTING, ENGINE DIAGNOSIS............9-4
PERFORMANCE - DIAGNOSIS AND
TESTING, HEATER.....................24-6
PILOT BEARING - INSTALLATION..........6-8
PILOT BEARING - REMOVAL..............6-8
PINION GEAR/RING GEAR -
INSTALLATION........................3-46
PINION GEAR/RING GEAR - REMOVAL.....3-44
PINION GEAR/RING GEAR/TONE RING -
INSTALLATION...................3-112,3-82
PINION GEAR/RING GEAR/TONE RING -
REMOVAL......................3-110,3-79
PINION SEAL - INSTALLATION . . 3-103,3-39,3-68
PINION SEAL - REMOVAL......3-102,3-38,3-68
PIPE - INSTALLATION, CROSS-OVER......11-3
PIPE - REMOVAL, CROSS-OVER..........11-3
PISTON & CONNECTING ROD -
DESCRIPTION........................9-49
PISTON FITTING - STANDARD
PROCEDURE.........................9-50
PISTON RING FITTING - STANDARD
PROCEDURE.........................9-52
PISTONS - DESCRIPTION.............21-155
PISTONS - OPERATION...............21-155
PLANETARY GEARTRAIN - ASSEMBLY . . . 21-160
PLANETARY GEARTRAIN - CLEANING....21-159
PLANETARY GEARTRAIN - DESCRIPTION . 21-157
PLANETARY GEARTRAIN -
DISASSEMBLY......................21-159
PLANETARY GEARTRAIN - INSPECTION . . 21-159
PLANETARY GEARTRAIN - OPERATION . . 21-157
PLATE - INSTALLATION, DOOR SILL
SCUFF............................23-157
PLATE - INSTALLATION, FLEX............9-49
PLATE - INSTALLATION, FRONT SKID......13-6
PLATE - INSTALLATION, FUEL TANK
SKID...............................13-9
PLATE - INSTALLATION, REAR DOOR
SCUFF............................23-160
PLATE - INSTALLATION, TRANSFER
CASE SKID..........................13-7
PLATE - REMOVAL, DOOR SILL SCUFF . . . 23-157
PLATE - REMOVAL, FLEX...............9-49
PLATE - REMOVAL, FRONT SKID.........13-6
PLATE - REMOVAL, FUEL TANK SKID
......13-9
PLATE - REMOVAL, REAR DOOR SCUFF
. . 23-160
PLATE - REMOVAL, TRANSFER CASE
SKID
...............................13-7
PLATE LAMP BULB - INSTALLATION,
LICENSE
...........................8L-45
PLATE LAMP BULB - REMOVAL,
LICENSE
...........................8L-44
18 INDEXKJ
Description Group-Page Description Group-Page Description Group-Page

SPARK PLUG - OPERATION.............8I-12
SPARK PLUG - REMOVAL..............8I-15
SPARK PLUG CABLE RESISTANCE, 2.4L....8I-3
SPARK PLUG CONDITIONS - DIAGNOSIS
AND TESTING........................8I-13
SPARK PLUGS, SPARK PLUG -
CLEANING..........................8I-15
SPARK PLUGS, SPECIFICATIONS..........8I-3
SPEAKER - DESCRIPTION..............8A-13
SPEAKER - INSTALLATION.............8A-15
SPEAKER - OPERATION...............8A-14
SPEAKER - REMOVAL.................8A-14
SPECIAL TOOLS - 3.7L ENGINE..........9-15
SPECIAL TOOLS - 8 1/4 AXLE...........3-98
SPECIAL TOOLS - BASE BRAKES..........5-7
SPECIAL TOOLS - BODY................23-5
SPECIAL TOOLS - COOLING.............7-14
SPECIAL TOOLS - FRONT AXLE..........3-34
SPECIAL TOOLS - FRONT SUSPENSION.....2-8
SPECIAL TOOLS - FUEL SYSTEM.........14-6
SPECIAL TOOLS - OUTER TIE ROD END
REMOVAL TOOL.....................19-15
SPECIAL TOOLS - POWER
DISTRIBUTION SYSTEMS............8W-97-2
SPECIAL TOOLS - POWER STEERING
PUMP.............................19-20
SPECIAL TOOLS - REAR AXLE...........3-63
SPECIAL TOOLS - RFE TRANSMISSION....21-120
SPECIAL TOOLS - STEERING COLUMN....19-8
SPECIAL TOOLS - WIRING/TERMINAL . 8W-01-10
SPECIAL TOOLS, BATTERY SYSTEM.......8F-7
SPECIFICATIONS, BATTERY SYSTEM......8F-6
SPECIFICATIONS, BRAKES - ABS.........5-33
SPECIFICATIONS, CHARGE CAPACITY.....24-42
SPECIFICATIONS, CLUTCH...............6-5
SPECIFICATIONS, DIAGNOSIS AND
TESTING............................22-8
SPECIFICATIONS, FLUID CAPACITIES.......0-4
SPECIFICATIONS, FRAME DIMENSIONS....13-3
SPECIFICATIONS, FRONT AXLE...........3-33
SPECIFICATIONS, GAP AND FLUSH.....23-116
SPECIFICATIONS, IGNITION TIMING.......8I-2
SPECIFICATIONS, LAMPS/LIGHTING -
EXTERIOR..........................8L-15
SPECIFICATIONS, LAMPS/LIGHTING -
INTERIOR..........................8L-71
SPECIFICATIONS, NV1500..............21-30
SPECIFICATIONS, OPENING DIMENSIONS . 23-111
SPECIFICATIONS, PAINT CODES........23-162
SPECIFICATIONS, REAR AXLE............3-62
SPECIFICATIONS, REMOTE KEYLESS
ENTRY TRANSMITTER.................8N-9
SPECIFICATIONS, SEALER LOCATIONS....23-87
SPECIFICATIONS, SPECIFICATIONS.......24-10
SPECIFICATIONS, STANDARD
PROCEDURE.........................23-4
SPECIFICATIONS, TORQUE..............13-6
SPECIFICATIONS, WELD AND
STRUCTURAL ADHESIVE LOCATIONS......23-9
SPEED CONTROL - DESCRIPTION........8P-1
SPEED CONTROL - OPERATION..........8P-1
SPEED CONTROL - TORQUE.............8P-2
SPEED SENSOR - DESCRIPTION, INPUT . 21-143
SPEED SENSOR - DESCRIPTION,
OUTPUT...........................21-152
SPEED SENSOR - INSTALLATION, FRONT
WHEEL.............................5-34
SPEED SENSOR - INSTALLATION, INPUT . 21-143
SPEED SENSOR - INSTALLATION,
OUTPUT...........................21-152
SPEED SENSOR - INSTALLATION, REAR
WHEEL.............................5-35
SPEED SENSOR - OPERATION, INPUT . . . 21-143
SPEED SENSOR - OPERATION, OUTPUT . . 21-152
SPEED SENSOR - REMOVAL, FRONT
WHEEL.............................5-34
SPEED SENSOR - REMOVAL, INPUT.....21-143
SPEED SENSOR - REMOVAL, OUTPUT . . . 21-152
SPEED SENSOR - REMOVAL, REAR
WHEEL.............................5-35
SPEEDOMETER - DESCRIPTION
.........8J-32
SPEEDOMETER - OPERATION
...........8J-32
SPLASH SHIELD - INSTALLATION,
FRONT WHEELHOUSE
................23-143
SPLASH SHIELD - INSTALLATION, REAR
WHEELHOUSE
......................23-144
SPLASH SHIELD - REMOVAL, FRONT
WHEELHOUSE
......................23-143SPLASH SHIELD - REMOVAL, REAR
WHEELHOUSE......................23-144
SPLICE INFORMATION - DESCRIPTION,
CONNECTOR, GROUND..............8W-01-7
SPLICING - STANDARD PROCEDURE,
WIRE...........................8W-01-14
SPRING - INSTALLATION...........2-13,2-18
SPRING - REMOVAL...............2-13,2-18
SPRINGS - DESCRIPTION, VALVE.....9-29,9-38
SPRINGS - INSTALLATION, VALVE....9-29,9-38
SPRINGS - REMOVAL, VALVE........9-29,9-38
STABILIZER BAR - INSTALLATION....2-14,2-19
STABILIZER BAR - REMOVAL........2-14,2-19
STABILIZER BAR BUSHINGS -
INSTALLATION.........................2-9
STABILIZER BAR BUSHINGS - REMOVAL....2-9
STABILIZER LINK - INSTALLATION........2-14
STABILIZER LINK - REMOVAL............2-14
STAKING - STANDARD PROCEDURE,
HEAT ...............................23-3
STARTER MOTOR - DIAGNOSIS AND
TESTING...........................8F-39
STARTER MOTOR - INSTALLATION.......8F-41
STARTER MOTOR - REMOVAL..........8F-39
STARTER MOTOR, GAS POWERED.......8F-39
STARTER MOTOR RELAY - DESCRIPTION . 8F-41
STARTER MOTOR RELAY -
INSTALLATION.......................8F-43
STARTER MOTOR RELAY - OPERATION.....8F-42
STARTER MOTOR RELAY - REMOVAL.....8F-43
STARTER RELAY - DIAGNOSIS AND
TESTING...........................8F-42
STARTING PROCEDURE - STANDARD
PROCEDURE, JUMP....................0-5
STARTING SYSTEM - DESCRIPTION......8F-32
STARTING SYSTEM - DIAGNOSIS AND
TESTING...........................8F-33
STARTING SYSTEM - INSPECTION.......8F-37
STARTING SYSTEM - OPERATION........8F-32
STATE DISPLAY TEST MODE -
DESCRIPTION........................25-2
STEERING - DESCRIPTION..............19-1
STEERING - OPERATION................19-1
STEERING COLUMN, SPECIAL TOOLS.....19-8
STEERING FLOW AND PRESSURE -
DIAGNOSIS AND TESTING, POWER.......19-3
STEERING LINKAGE - STANDARD
PROCEDURE........................19-16
STEERING PRESSURE SWITCH -
DESCRIPTION, POWER................19-22
STEERING PRESSURE SWITCH -
INSTALLATION, POWER...............19-22
STEERING PRESSURE SWITCH -
OPERATION, POWER..................19-22
STEERING PRESSURE SWITCH -
REMOVAL, POWER...................19-22
STEERING PUMP - INITIAL OPERATION -
STANDARD PROCEDURE, POWER.......19-18
STEERING PUMP, SPECIAL TOOLS -
POWER............................19-20
STEERING SYSTEM - DIAGNOSIS AND
TESTING, POWER.....................19-1
STEERING SYSTEM - DIAGNOSIS AND
TESTING, SUSPENSION.................2-1
STEERING WHEEL - INSTALLATION......19-12
STEERING WHEEL - REMOVAL..........19-12
STOP LAMP BULB - INSTALLATION,
CENTER HIGH MOUNTED..............8L-19
STOP LAMP BULB - REMOVAL, CENTER
HIGH MOUNTED.....................8L-18
STOP LAMP UNIT - INSTALLATION,
CENTER HIGH MOUNTED..............8L-19
STOP LAMP UNIT - REMOVAL, CENTER
HIGH MOUNTED.....................8L-19
STRAP - DESCRIPTION, RADIO NOISE
SUPPRESSION GROUND................8A-9
STRAP - INSTALLATION, CHECK . 23-121,23-128,
23-135
STRAP - INSTALLATION, RADIO NOISE
SUPPRESSION GROUND
...............8A-11
STRAP - OPERATION, RADIO NOISE
SUPPRESSION GROUND
...............8A-10
STRAP - REMOVAL, CHECK
.....23-121,23-128,
23-135
STRAP - REMOVAL, RADIO NOISE
SUPPRESSION GROUND
...............8A-10
STRIKER - INSTALLATION, GLOVE BOX
LATCH
............................23-149STRIKER - INSTALLATION, HOOD AJAR
SWITCH............................8Q-14
STRIKER - INSTALLATION, LATCH......23-124,
23-132,23-137
STRIKER - INSTALLATION, REAR SEAT
BACK LATCH.......................23-171
STRIKER - REMOVAL, GLOVE BOX
LATCH ............................23-148
STRIKER - REMOVAL, HOOD AJAR
SWITCH............................8Q-13
STRIKER - REMOVAL, LATCH . . . 23-124,23-132,
23-137
STRIKER - REMOVAL, REAR SEAT BACK
LATCH ............................23-170
STRUCTURAL ADHESIVE LOCATIONS -
SPECIFICATIONS, WELD................23-9
STRUCTURAL COVER - DESCRIPTION.....9-55
STRUCTURAL COVER - INSTALLATION.....9-55
STRUCTURAL COVER - OPERATION.......9-55
STRUCTURAL COVER - REMOVAL........9-55
STUDS - INSTALLATION...............22-11
STUDS - REMOVAL...................22-11
SUCTION LINE - INSTALLATION, A/C.....24-49
SUCTION LINE - REMOVAL, A/C.........24-48
SUN VISOR - INSTALLATION..........23-160
SUN VISOR - REMOVAL..............23-160
SUN VISOR SUPPORT - INSTALLATION . . 23-160
SUN VISOR SUPPORT - REMOVAL......23-160
SUNROOF - DESCRIPTION............23-175
SUNROOF GLASS PANEL ADJUSTMENT,
ADJUSTMENTS.....................23-178
SUNSHADE - INSTALLATION...........23-179
SUNSHADE - REMOVAL..............23-179
SUPPLEMENTAL RESTRAINT
DEPLOYMENT - STANDARD
PROCEDURE, SERVICE AFTER A.........8O-6
SUPPLEMENTAL RESTRAINT SYSTEM -
DIAGNOSIS AND TESTING..............8O-6
SUPPLEMENTAL RESTRAINTS -
STANDARD PROCEDURE, HANDLING
NON-DEPLOYED......................8O-6
SUPPLIES - DESCRIPTION, 5 VOLT......8E-13
SUPPLIES - OPERATION, 5 VOLT........8E-15
SUPPORT - INSTALLATION, REAR
FASCIA..............................13-3
SUPPORT - INSTALLATION, SUN VISOR . . 23-160
SUPPORT - REMOVAL, REAR FASCIA......13-3
SUPPORT - REMOVAL, SUN VISOR.....23-160
SUPPORT BRACKET - INSTALLATION,
REARVIEW MIRROR.................23-161
SUPPORT CYLINDER - INSTALLATION . . . 23-120
SUPPORT CYLINDER - INSTALLATION,
FLIP-UP GLASS.....................23-139
SUPPORT CYLINDER - REMOVAL.......23-120
SUPPORT CYLINDER - REMOVAL,
FLIP-UP GLASS.....................23-139
SUPPRESSION GROUND STRAP -
DESCRIPTION, RADIO NOISE............8A-9
SUPPRESSION GROUND STRAP -
INSTALLATION, RADIO NOISE...........8A-11
SUPPRESSION GROUND STRAP -
OPERATION, RADIO NOISE.............8A-10
SUPPRESSION GROUND STRAP -
REMOVAL, RADIO NOISE..............8A-10
SURFACE PREPARATION - STANDARD
PROCEDURE, ENGINE GASKET............9-9
SUSPENSION - DIAGNOSIS AND
TESTING, REAR.......................2-17
SUSPENSION AND STEERING SYSTEM -
DIAGNOSIS AND TESTING...............2-1
SUSPENSION ARM, BUSHINGS, AND
BALL JOINT - DESCRIPTION, UPPER......2-20
SUSPENSION ARM, BUSHINGS, AND
BALL JOINT - OPERATION, UPPER........2-20
SUSPENSION, SPECIAL TOOLS - FRONT....2-8
SWING GATE - INSTALLATION.........23-138
SWING GATE - REMOVAL.............23-138
SWING GATE BELTLINE WEATHERSTRIP
- INSTALLATION....................23-186
SWING GATE BELTLINE WEATHERSTRIP
- REMOVAL
........................23-186
SWING GATE OPENING WEATHERSTRIP
- INSTALLATION
....................23-186
SWING GATE OPENING WEATHERSTRIP
- REMOVAL
........................23-186
SWITCH - DESCRIPTION
................8P-5
SWITCH - DESCRIPTION, A/C HIGH
PRESSURE
.........................24-17
KJINDEX 25
Description Group-Page Description Group-Page Description Group-Page
