8W-33 VEHICLE SPEED CONTROL
Component Page
Body Control Module................ 8Wa-33-5
Brake Lamp Switch................. 8Wa-33-2
Clockspring.................... 8Wa-33-3, 4, 5
Controller Antilock Brake............. 8Wa-33-2
Engine Control Module............... 8Wa-33-5
Fuse 12........................... 8Wa-33-2
G112 ............................. 8Wa-33-2Component Page
G202............................. 8Wa-33-2
Junction Block..................... 8Wa-33-2
Left Speed Control Switch............. 8Wa-33-4
Powertrain Control Module.......... 8Wa-33-2, 3
Right Speed Control Switch........... 8Wa-33-4
Shifter Assembly.................... 8Wa-33-2
Speed Control Servo................. 8Wa-33-2
KJ8W-33 VEHICLE SPEED CONTROL8Wa-33-1

8W-35 ANTILOCK BRAKES
Component Page
Body Control Module................ 8Wa-35-3
Brake Lamp Switch................. 8Wa-35-3
Brake Pressure Switch............... 8Wa-35-2
Controller Antilock Brake......... 8Wa-35-2, 3, 4
Data Link Connector................. 8Wa-35-2
Diagnostic Junction Port.............. 8Wa-35-2
Fuse 4............................ 8Wa-35-2
Fuse 12........................... 8Wa-35-3
Fuse 25........................... 8Wa-35-2
Fuse 38........................... 8Wa-35-2Component Page
G110 ............................. 8Wa-35-2
Junction Block.................... 8Wa-35-2, 3
Left Front Wheel Speed Sensor......... 8Wa-35-4
Power Distribution Center............ 8Wa-35-2
Powertrain Control Module............ 8Wa-35-3
Rear Wheel Speed Sensor............. 8Wa-35-4
Right Front Wheel Speed Sensor....... 8Wa-35-4
Shifter Assembly.................. 8Wa-35-2, 3
Speed Control Servo................. 8Wa-35-3
KJ8W-35 ANTILOCK BRAKES8Wa-35-1

8W-40 INSTRUMENT CLUSTER
Component Page
Airbag Control Module............. 8Wa-40-4, 8
Body Control Module........... 8Wa-40-3, 4, 5, 8
Controller Antilock Brake............. 8Wa-40-6
Data Link Connector................. 8Wa-40-4
Diagnostic Junction Port...... 8Wa-40-4, 5, 6, 7, 8
Driver Seat Belt Switch.............. 8Wa-40-8
Engine Control Module............... 8Wa-40-6
Engine Coolant Level Sensor.......... 8Wa-40-3
Fuse 9............................ 8Wa-40-3
Fuse 13........................... 8Wa-40-2
Fuse 34........................... 8Wa-40-2
G103............................. 8Wa-40-3Component Page
G111 ............................. 8Wa-40-3
G202........................... 8Wa-40-2, 3
Hazard Switch/Combination Flasher..... 8Wa-40-3
Instrument Cluster........ 8Wa-40-2, 3, 4, 5, 7, 8
Junction Block.................... 8Wa-40-2, 3
Park Brake Switch.................. 8Wa-40-5
Park Lamp Relay................... 8Wa-40-3
Passenger Seat Belt Switch............ 8Wa-40-8
Powertrain Control Module............ 8Wa-40-6
Red Brake Warning Indicator Switch.... 8Wa-40-3
Transmission Control Module.......... 8Wa-40-6
Washer Fluid Level Switch............ 8Wa-40-2
KJ8W-40 INSTRUMENT CLUSTER8Wa-40-1

8W-45 BODY CONTROL MODULE
Component Page
A/C- Heater Control................. 8Wa-45-5
Ambient Temperature Sensor.......... 8Wa-45-7
Body Control Module . 8Wa-45-10, 11, 2, 3, 4, 5, 6, 7,
8, 9
Brake Lamp Switch................. 8Wa-45-2
Cargo Lamp..................... 8Wa-45-4, 8
Clockspring........................ 8Wa-45-5
Controller Antilock Brake............. 8Wa-45-5
Data Link Connector............. 8Wa-45-10, 11
Defogger Relay..................... 8Wa-45-3
Diagnostic Junction Port.............. 8Wa-45-6
Door Lock Relay.................... 8Wa-45-4
Driver Door Unlock Relay............. 8Wa-45-3
Engine Control Module............... 8Wa-45-5
Flip-Up Glass Release Motor........... 8Wa-45-8
Flip-Up Glass Release Switch.......... 8Wa-45-8
Front Fog Lamp Relay............... 8Wa-45-4
Fuse 3............................ 8Wa-45-7
Fuse 6............................ 8Wa-45-3
Fuse 13........................... 8Wa-45-2
Fuse 32........................... 8Wa-45-2
Fuse 34........................... 8Wa-45-2
G111 ............................. 8Wa-45-7
G202........................... 8Wa-45-2, 6
G300............................. 8Wa-45-9
G302............................. 8Wa-45-9
Hazard Switch/Combination Flasher..... 8Wa-45-5
High Beam Relay................... 8Wa-45-3
Hood Ajar Switch................... 8Wa-45-7
Horn Relay........................ 8Wa-45-7
Ignition Switch..................... 8Wa-45-6
Instrument Cluster.................. 8Wa-45-6Component Page
Junction Block.............. 8Wa-45-2, 3, 4, 7, 8
Left Courtesy Lamp................. 8Wa-45-4
Left Cylinder Lock Switch....... 8Wa-45-10, 11, 4
Left Door Lock Switch.............. 8Wa-45-4, 7
Left Front Door Ajar Switch........... 8Wa-45-9
Left Front Door Lock Motor/Ajar
Switch...................... 8Wa-45-10, 11
Left Rear Door Ajar Switch............ 8Wa-45-9
Left Visor/Vanity Lamp............... 8Wa-45-3
Low Beam Relay.................... 8Wa-45-3
Multi- Function Switch........... 8Wa-45-3, 5, 6
Overhead Map/Reading Lamp........ 8Wa-45-3, 4
Park Lamp Relay................... 8Wa-45-3
Passenger Door Unlock Relay.......... 8Wa-45-3
Powertrain Control Module............ 8Wa-45-5
Rear Fog Lamp Relay................ 8Wa-45-2
Rear Wiper Motor................. 8Wa-45-6, 8
Remote Keyless Entry Module......... 8Wa-45-8
Right Courtesy Lamp................ 8Wa-45-4
Right Cylinder Lock Switch...... 8Wa-45-10, 11, 4
Right Door Lock Switch............ 8Wa-45-4, 7
Right Front Door Ajar Switch.......... 8Wa-45-9
Right Front Door Lock Motor/Ajar
Switch...................... 8Wa-45-10, 11
Right Rear Door Ajar Switch........... 8Wa-45-9
Right Remote Radio Switch............ 8Wa-45-5
Right Visor/Vanity Lamp.............. 8Wa-45-3
Tailgate Cylinder Lock Switch.... 8Wa-45-10, 11, 8
Tailgate Lock Motor/Ajar Switch...... 8Wa-45-7, 8
Washer Pump...................... 8Wa-45-6
Wiper High/Low Relay............... 8Wa-45-4
Wiper On/Off Relay.................. 8Wa-45-4
KJ8W-45 BODY CONTROL MODULE8Wa-45-1

8W-54 TRAILER TOW
Component Page
Back-Up Lamp Switch............... 8Wa-54-3
Body Control Module................ 8Wa-54-2
Brake Lamp Switch................. 8Wa-54-4
Trailer Tow Circuit Breaker........... 8Wa-54-6
Controller Antilock Brake............. 8Wa-54-4
Electric Brake Provision.............. 8Wa-54-3
Fuse 2............................ 8Wa-54-6
Fuse 9............................ 8Wa-54-2
Fuse 10........................... 8Wa-54-6
Fuse 19........................... 8Wa-54-4
Fuse 25........................... 8Wa-54-6
G202............................. 8Wa-54-2Component Page
G310............................. 8Wa-54-5
Hazard Switch/Combination Flasher..... 8Wa-54-4
Junction Block.................. 8Wa-54-2, 4, 6
Park Lamp Relay................... 8Wa-54-2
Power Distribution Center............ 8Wa-54-6
Trailer Tow Brake Lamp Relay....... 8Wa-54-4, 5
Trailer Tow Circuit Breaker........... 8Wa-54-6
Trailer Tow Connector.......... 8Wa-54-2, 3, 5, 6
Trailer Tow Left Turn Relay......... 8Wa-54-4, 5
Trailer Tow Relay................. 8Wa-54-5, 6
Trailer Tow Right Turn Relay........ 8Wa-54-4, 5
Transmission Solenoid/Trs Assembly..... 8Wa-54-3
KJ8W-54 TRAILER TOW8Wa-54-1

Component Page
C316 (Built-Up-Export).............. 8Wa-80-46
C316 (Built-Up-Export).............. 8Wa-80-46
C317 (Except Built-Up-Export)........ 8Wa-80-47
C317 (Except Built-Up-Export)........ 8Wa-80-47
Cabin Heater (Diesel)............... 8Wa-80-47
Camshaft Position Sensor (2.4L)....... 8Wa-80-47
Camshaft Position Sensor (3.7L)....... 8Wa-80-47
Camshaft Position Sensor (Diesel)...... 8Wa-80-48
Capacitor......................... 8Wa-80-48
Cargo Lamp (Except Base)........... 8Wa-80-48
CD Changer...................... 8Wa-80-48
Center High Mounted Stop Lamp...... 8Wa-80-49
Cigar Lighter..................... 8Wa-80-49
Clockspring C1.................... 8Wa-80-49
Clockspring C2.................... 8Wa-80-49
Clockspring C3.................... 8Wa-80-49
Clutch Interlock Switch (M/T)......... 8Wa-80-50
Coil On Plug No. 1 (3.7L)............ 8Wa-80-50
Coil On Plug No. 2 (3.7L)............ 8Wa-80-50
Coil On Plug No. 3 (3.7L)............ 8Wa-80-50
Coil On Plug No. 4 (3.7L)............ 8Wa-80-50
Coil On Plug No. 5 (3.7L)............ 8Wa-80-51
Coil On Plug No. 6 (3.7L)............ 8Wa-80-51
Coil Rail (2.4L).................... 8Wa-80-51
Compass Mini-Trip Computer
(Premium)...................... 8Wa-80-51
Controller Antilock Brake............ 8Wa-80-52
Crankshaft Position Sensor (2.4L)...... 8Wa-80-52
Crankshaft Position Sensor (3.7L)...... 8Wa-80-52
Crankshaft Position Sensor (Diesel).... 8Wa-80-53
Data Link Connector................ 8Wa-80-53
Diagnostic Junction Port............. 8Wa-80-53
Dome Lamp (Base)................. 8Wa-80-54
Driver Airbag Squib 1............... 8Wa-80-54
Driver Airbag Squib 2............... 8Wa-80-54
Driver Seat Belt Switch............. 8Wa-80-54
Driver Seat Belt Tensioner........... 8Wa-80-54
EGR Solenoid (Diesel)............... 8Wa-80-55
Engine Control Module C1........... 8Wa-80-55
Engine Control Module C2........... 8Wa-80-56
Engine Coolant Level Sensor (Diesel) . . . 8Wa-80-57
Engine Coolant Temp Sensor (Diesel) . . . 8Wa-80-57
Engine Coolant Temperature
Sensor (Gas).................... 8Wa-80-58
Engine Oil Pressure Sensor........... 8Wa-80-58
Evap/Purge Solenoid................ 8Wa-80-58
Flip-Up Glass Release Motor.......... 8Wa-80-58
Flip-Up Glass Release Switch......... 8Wa-80-58
Front Wiper Motor................. 8Wa-80-59
Fuel Heater (Diesel)................ 8Wa-80-59
Fuel Injector No. 1 (Diesel)........... 8Wa-80-59
Fuel Injector No. 1 (Gas)............. 8Wa-80-59
Fuel Injector No. 2 (Diesel)........... 8Wa-80-59
Fuel Injector No. 2 (Gas)............. 8Wa-80-60Component Page
Fuel Injector No. 3 (Diesel)........... 8Wa-80-60
Fuel Injector No. 3 (Gas)............. 8Wa-80-60
Fuel Injector No. 4 (Diesel)........... 8Wa-80-60
Fuel Injector No. 4 (Gas)............. 8Wa-80-60
Fuel Injector No. 5 (3.7L)............ 8Wa-80-61
Fuel Injector No. 6 (3.7L)............ 8Wa-80-61
Fuel Pressure Sensor (Diesel)......... 8Wa-80-61
Fuel Pressure Solenoid (Diesel)........ 8Wa-80-61
Fuel Pump Module................. 8Wa-80-61
G202............................ 8Wa-80-61
Generator........................ 8Wa-80-62
Glow Plug Assembly (Diesel).......... 8Wa-80-62
Hazard Switch/Combination Flasher.... 8Wa-80-62
Headlamp Leveling Switch
(Built-Up-Export)................ 8Wa-80-63
Heated Seat Module (Highline)........ 8Wa-80-63
High Note Horn.................... 8Wa-80-63
Hood Ajar Switch (Except Base)....... 8Wa-80-63
Idle Air Control Motor............... 8Wa-80-64
Ignition Switch.................... 8Wa-80-64
Input Speed Sensor (3.7L)............ 8Wa-80-64
Instrument Cluster................. 8Wa-80-64
Intake Air Temperature Sensor (Gas) . . . 8Wa-80-65
Intrusion Sensor (Built-Up-Export)..... 8Wa-80-65
Junction Block Body Control Module-JB . 8Wa-80-65
Junction Block C1.................. 8Wa-80-66
Junction Block C2.................. 8Wa-80-67
Junction Block C3.................. 8Wa-80-68
Knock Sensor (3.7L)................ 8Wa-80-69
Leak Detection Pump............... 8Wa-80-69
Left Courtesy Lamp................ 8Wa-80-69
Left Curtain Airbag................. 8Wa-80-69
Left Cylinder Lock Switch (Except Base) . 8Wa-80-69
Left Door Lock Switch (Except Base) . . . 8Wa-80-70
Left Fog Lamp..................... 8Wa-80-70
Left Front Door Ajar Switch (Base)..... 8Wa-80-70
Left Front Door Lock Motor/Ajar Switch
(Except Base)................... 8Wa-80-70
Left Front Door Speaker (Base)........ 8Wa-80-70
Left Front Door Speaker (Premium).... 8Wa-80-71
Left Front Impact Sensor............ 8Wa-80-71
Left Front Park/Turn Signal Lamp..... 8Wa-80-71
Left Front Power Window Motor
(Midline/Highline)................ 8Wa-80-71
Left Front Wheel Speed Sensor (ABS) . . . 8Wa-80-72
Left Headlamp (Built-Up-Export)...... 8Wa-80-72
Left Headlamp (Except Built-Up-Export) . 8Wa-80-72
Left Heated Seat Assembly (Highline) . . . 8Wa-80-72
Left Heated Seat Switch (Highline)..... 8Wa-80-72
Left Instrument Panel Speaker........ 8Wa-80-73
Left Leveling Motor (Built-Up-Export) . . 8Wa-80-73
Left Position Lamp (Built-Up-Export) . . . 8Wa-80-73
Left Power Mirror (Except Base)....... 8Wa-80-73
8Wa - 80 - 2 8W-80 CONNECTOR PIN-OUTSKJ

CONTROLLER ANTILOCK BRAKE - LT.GRAY 24 WAY
CAV CIRCUIT FUNCTION
1 Z101 12BK/OR GROUND
2- -
3- -
4- -
5 D25 18YL/VT PCI BUS
6 B6 18WT/DB RIGHT FRONT WHEEL SPEED SENSOR SIGNAL
7 B7 18WT RIGHT FRONT WHEEL SPEED SENSOR 12 VOLT
SUPPLY
8 D24 18WT/DG FLASH ABS
9 A20 12RD/DB FUSED B(+)
10 F22 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
11 - -
12 - -
13 B12 18DG/OR VEHICLE SPEED SIGNAL
14 - -
15 - -
16 Z102 12BK/OR GROUND
17 S43 18LB/YL FLUID PRESSURE SWITCH SIGNAL
18 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
19 B1 18YL/DB REAR WHEEL SPEED SENSOR SIGNAL
20 B2 18YL REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY
21 - -
22 B8 18RD/DB LEFT FRONT WHEEL SPEED SENSOR SIGNAL
23 B9 18RD LEFT FRONT WHEEL SPEED SENSOR 12 VOLT SUP-
PLY
24 A10 12RD/DG FUSED B(+)
CRANKSHAFT POSITION SENSOR (2.4L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K24 18GY/BK CRANKSHAFT POSITION SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
3 K7 18OR 5 VOLT SUPPLY
CRANKSHAFT POSITION SENSOR (3.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K24 18GY/BK CRANKSHAFT POSITION SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
3 K7 18OR 5 VOLT SUPPLY
8Wa - 80 - 52 8W-80 CONNECTOR PIN-OUTSKJ

CONNECTOR NAME/NUMBER COLOR LOCATION FIG.
Coil On Plug No.5 (3.7L) BK Left Side of Engine Near
Fuel Injector No.51
Coil On Plug No.6 (3.7L) BK Right Side of Engine Near
Fuel Injector No.62
Coil Rail (2.4L) BK Right Side of Engine 11, 12
Combination Flasher WT Under Left Side of
Instrument PanelN/S
Compass Mini-Trip Computer BK At Overhead Console N/S
Controller Antilock Brake BK Left Side of Engine
Compartment30
Crankshaft Position Sensor (2.4L) BK Top of Engine N/S
Crankshaft Position Sensor (3.7L) BK Right Lower Side of Engine 4
Crankshaft Position Sensor (Diesel) BK Right Rear Side of Engine 17
Data Link Connector BK Under Center of Instrument
PanelN/S
Diagnostic Junction Port BK Under Center of Instrument
Panel49
Dome Lamp (Base) BK On Headliner N/S
Driver Airbag Squib 1 GY In Steering Wheel N/S
Driver Airbag Squib 2 BK In Steering Wheel N/S
Driver Seat Belt Switch LG At Drive Seat N/S
Driver Seat Belt Tensioner (LHD) YL Lower Left B-Pillar 35
Driver Seat Belt Tensioner (RHD) YL Lower Right B-Pillar 39
EGR Solenoid Right Rear Side of Engine
Compartment27
Engine Control Module C1 BK Left Rear Side of Engine
Compartment19
Engine Control Module C2 BK Left Rear Side of Engine
Compartment19
Engine Coolant Level Sensor (Diesel) LG Rear Side of Engine
Compartment18
Engine Coolant Temperature Sensor
(Diesel)BK Left Side of Engine 20
Engine Coolant Temperature Sensor
(Gas)BK Front Side of Engine 2
Engine Oil Pressure Sensor (2.4L) BK Top of Engine N/S
Engine Oil Pressure Sensor (3.7L) BK Left Front Side of Engine 3
Engine Oil Pressure Sensor (Diesel) BK Right Rear Side of Engine 17
Engine Starter Motor Right Front Side of Engine 20
Evap/Purge Solenoid BK At Solenoid N/S
Flip-Up Glass Release Motor BK In Tailgate 46
Flip-Up Glass Release Switch WT In Tailgate 46
Front Washer Pump BK Right Front Side of Engine
Compartment28
Front Wiper Motor (LHD) BK Left Side of Cowl 24
8Wa - 91 - 4 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONKJ
CONNECTOR/GROUND/SPLICE LOCATION (Continued)
