193In Case of Emergency
Rear Wheels off the Ground
1.
Transfer case in 2
H (4WD
model only).
2. Transmission in Neutral
position.
3. Maximum speed 30 mph
(50 km/h).
4. Maximum distance 50 miles
(80 kilometers).
If you need to tow your vehicle by
this method, secure the steering
wheel to keep the front wheels
pointed straight ahead. Do not
rely on the steering column lock;
it is not strong enough to hold the
front wheels straight while
towing. The ignition switch must
be in the
OFF position. If you have electrical problems
without extreme damage to any
electrical parts, check for burned
out fuses, broken wires, poor
connections or poor grounding.
Correct as necessary.
The fuse boxes are located under
the left hand side of the
instrument panel and in the right
hand side of the engine
compartment. (See
“Fuses” on
page 240.)

Replacing a fuse with one that has
a higher rating greatly increases
the chances of damaging the
electrical system. If you do not
have a replacement fuse with the
proper rating for the circuit,
install one with a lower rating.
Inoperative Electrical Devices

240Technical Data
Fuses
Fuse boxes are installed on the left side of the
instrument panel and the right side of the engine
compartment. Each fuse box contains spare fuse
cartridges.
Replacing a fuse with one that has a higher rating
greatly increases the chances of damaging the
electrical system. If you do not have a replacement
fuse with the proper rating for the circuit, install one
with a lower rating.

Technical Data241
Fuse Box: Instrument Panel
AmperageApplicability
120AAccessory power sockets
2––––
315ACigarette lighter
415ADash/parking lights
510AInterior lights
615ABrake lights, cruise control
720APower door locks
810AMirror defoggers
915ARear window defogger
1015ARear window defogger
1115AGauges, indicators
1215ACharging system, fuel injection
1315AIgnition system
1415ATurn signals, backup lights
1515AABS, 4WD, cruise control
1620AWindshield wiper/washer
1710ARear wiper/washer
1810ASecurity & keyless entry
1915AAudio system
2020AStarter
2130APower windows, moonroof
2210ASRS
23––––

242Technical Data
Fuse Box: Engine Compartment
AmperageApplicability
115AHazard Warning Light
210AHorn
3––––
420ABlower
510AAir conditioner
6––––
7––––
810AHeadlight; left
910AHeadlight; right
1015AFog lights
1110AO2 Sensor
1220AFuel pump
1315AECM
14––––
1560APower distribution
16100AMain
1760AABS
1830ACondenser fan
19––––

259
