2002 CHRYSLER VOYAGER compressor

8W-15 GROUND DISTRIBUTION
Component PageA/C Compressor Clutch...................8W-15-7, 8
A/C- Heater Control....................8W-15-9, 11
Adjustable Pedals Module..................8W-15-17
Airbag Control Module....................8W-15-12
Auto Temp Control.......................8W-15-9
Automatic Day/Night Mirror.................8W-15-21
Autostick Switch........................8W-15-10
Back-Up Lamp Switch....................8W-15-3, 7
Battery.............................8W-15-2, 3
Body Control Module.....................8W-15-22
Brake Fluid Level Switch...................8W-15-17
Brake Lamp Switch......................8W-15-17
Cabin Heater Assist.......................8W-15-8
Center Dome Lamp......................8W-15-21
Center High Mounted Stop Lamp..............8W-15-26
Clutch Pedal Upstop Switch.................8W-15-18
Controller Antilock Brake..................8W-15-2, 3
Crank Case Ventilation Heater................8W-15-8
Crankshaft Position Sensor..................8W-15-3
Data Link Connector..................8W-15-2, 3, 17
Dosing Pump...........................8W-15-8
Driver Door Courtesy Lamp...............8W-15-15, 20
Driver Door Lock Switch.................8W-15-15, 20
Driver Heated Seat Cushion.................8W-15-11
Driver Heated Seat Module.................8W-15-11
Driver Power Seat Switch..................8W-15-11
Driver Power Window Switch..............8W-15-15, 20
Engine Control Module.....................8W-15-3
Floor Console Lamp......................8W-15-25
Floor Console Power Outlet.................8W-15-25
Front Blower Module.....................8W-15-11
Front Cigar Lighter.......................8W-15-9
Front Control Module..................8W-15-7, 8, 18
Front Reading Lamps/Switch................8W-15-21
Fuel Heater...........................8W-15-25
Fuel Heater Relay........................8W-15-3
Fuel Pump Module.......................8W-15-25
G100..............................8W-15-2, 3
G101..............................8W-15-2, 3
G102.............................8W-15-4, 5, 6
G103..............................8W-15-7, 8
G200...........................8W-15-9, 10, 11
G201...............................8W-15-12
G202...............................8W-15-13
G300........................8W-15-14, 16, 17, 18
G301........................8W-15-19, 20, 21, 22
G302...........................8W-15-23, 24, 25
G400.............................8W-15-25, 26
Glove Box Lamp........................8W-15-10
Halo Lamp............................8W-15-10
Headlamp Switch........................8W-15-9
Headlamp Washer Pump Motor................8W-15-6
High Note Horn........................8W-15-5, 6
Hood Ajar Switch........................8W-15-18
Instrument Cluster.......................8W-15-9
Instrument Panel Switch Bank...............8W-15-10
Integrated Power Module............8W-15-2, 3, 7, 8, 18
Left B-Pillar Switch......................8W-15-17
Left Cinch/Release Motor...................8W-15-14
Left Combination Relay....................8W-15-24
Left Cylinder Lock Switch................8W-15-15, 16
Left Door Speaker.......................8W-15-13
Left Fog Lamp........................8W-15-5, 6
Left Front Door Ajar Switch.................8W-15-16
Left Front Door Lock Motor/Ajar Switch.......8W-15-15, 16
Left Front Park/Turn Signal Lamp..............8W-15-5
Left Full Open Switch.....................8W-15-14
Left Headlamp.........................8W-15-18
Left Headlamp Leveling Motor................8W-15-6
Left High Beam Lamp....................8W-15-18
Left Liftgate Flood Lamp...................8W-15-26
Left Low Beam Lamp.....................8W-15-18
Left Mid Reading Lamp....................8W-15-21
Left Park Lamp.........................8W-15-18
Left Power Mirror.......................8W-15-10
Left Rear Lamp Assembly..................8W-15-24
Left Rear Reading Lamp...................8W-15-21
Left Side Impact Airbag Control Module.........8W-15-12
Left Sliding Door Control Module..............8W-15-14
Left Sliding Door Latch Sensing Switch..........8W-15-14
Left Sliding Door Lock Motor................8W-15-14Component PageLeft Sliding Door Lock Motor/Ajar Switch.........8W-15-14
Left Sliding Door Motor....................8W-15-14
Left Stop/Turn Signal Relay.................8W-15-24
Left Turn Signal Lamp....................8W-15-18
Left Visor/Vanity Lamp....................8W-15-21
License Lamp........................8W-15-23, 26
Lift Pump Motor........................8W-15-25
Liftgate Ajar Switch......................8W-15-26
Liftgate Cinch/Release Motor................8W-15-23
Liftgate Cylinder Lock Switch................8W-15-26
Liftgate Right Pinch Sensor.................8W-15-23
Low Note Horn........................8W-15-5, 6
Memory Seat/Mirror Module.................8W-15-11
Overhead Console.......................8W-15-21
Oxygen Sensor 1/2 Downstream...............8W-15-7
Park/Neutral Position Switch.................8W-15-7
Passenger Door Courtesy Lamp............8W-15-16, 20
Passenger Door Lock Switch..............8W-15-16, 20
Passenger Heated Seat Module...............8W-15-22
Passenger Power Seat Switch................8W-15-22
Passenger Power Window Switch............8W-15-16, 20
Power Folding Mirror Switch................8W-15-11
Power Liftgate Module....................8W-15-23
Power Liftgate Motor.....................8W-15-23
Power Mirror Switch......................8W-15-11
Power Outlet...........................8W-15-9
Power Window Switch.....................8W-15-15
Powertrain Control Module..................8W-15-2
Radiator Fan No. 1.......................8W-15-4
Radiator Fan No. 2.......................8W-15-4
Radiator Fan Relay.......................8W-15-4
Radiator Fan Relay No. 3...................8W-15-4
Radio...............................8W-15-13
Rear Auto Temp Control Switch...............8W-15-17
Rear Blower Front Control Switch.............8W-15-11
Rear Blower Motor Power Module...........8W-15-11, 25
Rear Blower Rear Control Switch..............8W-15-17
Rear Dome Lamp........................8W-15-21
Rear Power Outlet.......................8W-15-25
Rear Window Defogger Grid.................8W-15-26
Rear Wiper Motor.......................8W-15-26
Remote Keyless Entry Module................8W-15-10
Right B-Pillar Switch.....................8W-15-22
Right Cinch/Release Motor..................8W-15-19
Right Combination Relay...................8W-15-24
Right Cylinder Lock Switch.................8W-15-20
Right Door Speaker......................8W-15-13
Right Fog Lamp........................8W-15-5, 6
Right Front Door Ajar Switch................8W-15-20
Right Front Door Lock Motor/Ajar Switch.........8W-15-20
Right Front Park/Turn Signal Lamp.............8W-15-5
Right Full Open Switch....................8W-15-19
Right Headlamp........................8W-15-18
Right Headlamp Leveling Motor...............8W-15-6
Right High Beam Lamp....................8W-15-18
Right Liftgate Flood Lamp..................8W-15-26
Right Low Beam Lamp....................8W-15-18
Right Mid Reading Lamp...................8W-15-21
Right Park Lamp........................8W-15-18
Right Power Mirror......................8W-15-10
Right Rear Lamp Assembly.................8W-15-25
Right Rear Reading Lamp..................8W-15-21
Right Side Impact Airbag Control Module.........8W-15-12
Right Sliding Door Control Module.............8W-15-19
Right Sliding Door Latch Sensing Switch.........8W-15-19
Right Sliding Door Lock Motor...............8W-15-19
Right Sliding Door Lock Motor/Ajar Switch........8W-15-19
Right Sliding Door Motor...................8W-15-19
Right Stop/Turn Signal Relay................8W-15-24
Right Turn Signal Lamp...................8W-15-18
Right Visor/Vanity Lamp...................8W-15-21
Sentry Key Immobilizer Module...............8W-15-10
Speed Control Servo.......................8W-15-7
Traction Control Switch....................8W-15-10
Trailer Tow Connector.....................8W-15-24
Transmission Control Module.................8W-15-2
Transmission Control Relay..................8W-15-2
Transmission Range Sensor..................8W-15-7
Washer Fluid Level Switch.................8W-15-5, 6
Wiper Module..........................8W-15-17
RS8W-15 GROUND DISTRIBUTION8W-15-1
ProCarManuals.com

8W-30 FUEL/IGNITION SYSTEM
Component Page
A/C Compressor Clutch............... 8W-30-18
A/C Compressor Clutch Relay........ 8W-30-3, 18
A/C Pressure Sensor............ 8W-30-9, 15, 25
Accelerator Pedal Position Sensor....... 8W-30-32
Adjustable Pedals Module............. 8W-30-17
Adjustable Pedals Switch............. 8W-30-17
Auto Shut Down Relay.... 8W-30-2, 5, 7, 8, 12, 13
Battery...................... 8W-30-2, 18, 26
Battery Temperature Sensor........... 8W-30-25
Body Control Module.............. 8W-30-4, 19
Boost Pressure Sensor................ 8W-30-25
Brake Lamp Switch............. 8W-30-6, 21, 31
Cabin Heater Assist................. 8W-30-22
Camshaft Position Sensor........ 8W-30-7, 13, 24
Clockspring...................... 8W-30-3, 23
Clutch Pedal Upstop Switch........... 8W-30-30
Crank Case Ventilation Heater......... 8W-30-19
Crankshaft Position Sensor....... 8W-30-7, 13, 24
Data Link Connector............... 8W-30-4, 22
Diagnostic Junction Port......... 8W-30-4, 23, 17
Dosing Pump....................... 8W-30-22
ECM/PCM Relay........ 8W-30-18, 20, 24, 26, 28
EGR Solenoid.................... 8W-30-5, 28
Engine Control Module . . . 8W-30-18, 19, 20, 21, 22,
23, 24, 25, 26, 27, 28, 29, 30, 31, 32
Engine Coolant Temp Sensor...... 8W-30-9, 15, 25
Engine Oil Pressure Sensor........... 8W-30-21
Engine Oil Pressure Switch............ 8W-30-6
Engine Oil Temperature Sensor........ 8W-30-24
Evap/Purge Solenoid.................. 8W-30-3
Front Control Module...... 8W-30-3, 4, 17, 22, 30
Fuel Heater........................ 8W-30-29
Fuel Heater Relay................ 8W-30-19, 29
Fuel Injector No. 1............. 8W-30-8, 12, 27
Fuel Injector No. 2............. 8W-30-8, 12, 27
Fuel Injector No. 3............. 8W-30-8, 12, 27
Fuel Injector No. 4............. 8W-30-8, 12, 27
Fuel Injector No. 5.................. 8W-30-12
Fuel Injector No. 6.................. 8W-30-12
Fuel Pressure Sensor................ 8W-30-31
Fuel Pressure Solenoid............... 8W-30-20
Fuel Pump Module................ 8W-30-4, 19
Fuel Pump Relay.................... 8W-30-4
Fuse 14........................... 8W-30-17
Fuse 15........................ 8W-30-22, 29
Fuse 16 . . 8W-30-2, 5, 7, 8, 12, 13, 18, 20, 24, 26, 28
Fuse 17.................... 8W-30-2, 4, 19, 29Component Page
Fuse 18........................ 8W-30-18, 17
Fuse 26........................... 8W-30-31
Fuselink.......................... 8W-30-26
G100.............................. 8W-30-2
G101........................... 8W-30-2, 18
G103................... 8W-30-5, 6, 18, 19, 22
G300..................... 8W-30-6, 17, 21, 30
G302........................ 8W-30-4, 19, 29
Generator....................... 8W-30-2, 19
Glow Plug No. 1.................... 8W-30-26
Glow Plug No. 2.................... 8W-30-26
Glow Plug No. 3.................... 8W-30-26
Glow Plug No. 4.................... 8W-30-26
Glow Plug Relay.................... 8W-30-26
Idle Air Control Motor............. 8W-30-11, 14
Ignition Coil..................... 8W-30-7, 13
Ignition Switch..................... 8W-30-16
Inlet Air Temperature Sensor....... 8W-30-10, 14
Integrated Power
Module.......... 8W-30-2, 3, 4, 5, 7, 8, 12, 13,
18, 19, 20, 22, 24, 26, 28, 29, 30, 31
Knock Sensor.................... 8W-30-9, 15
Leak Detection Pump................ 8W-30-16
Left Speed Control Switch........... 8W-30-3, 23
Lift Pump Motor.................... 8W-30-29
Lift Pump Relay.................... 8W-30-29
Manifold Absolute Pressure Sensor.... 8W-30-9, 15
Mass Air Flow Sensor................ 8W-30-20
Oxygen Sensor 1/1 Upstream........... 8W-30-5
Oxygen Sensor 1/2 Downstream......... 8W-30-5
Park/Neutral Position Switch.......... 8W-30-11
Power Mirror Switch................. 8W-30-17
Powertrain Control Module . 8W-30-2, 3, 4, 5, 6, 10,
11, 7, 8, 9, 12, 13, 14, 15, 16
Radiator Fan Relay................... 8W-30-3
Radiator Fan Relay No. 1............. 8W-30-31
Radiator Fan Relay No. 2............. 8W-30-31
Radiator Fan Relay No. 3............. 8W-30-31
Right Speed Control Switch......... 8W-30-3, 23
Speed Control Servo.................. 8W-30-6
Starter Motor Relay............... 8W-30-4, 19
Throttle Position Sensor........... 8W-30-10, 14
Torque Converter Clutch Solenoid....... 8W-30-16
Transmission Control Module . . 8W-30-7, 10, 11, 14
Transmission Range Sensor......... 8W-30-11, 14
Vehicle Speed Sensor............ 8W-30-7, 11, 28
Water In Fuel Sensor................ 8W-30-30
RS8W-30 FUEL/IGNITION SYSTEM8W-30-1
ProCarManuals.com

8W-42 AIR CONDITIONING-HEATER
Component Page
A/C Compressor Clutch............ 8W-42-14, 16
A/C Compressor Clutch Relay....... 8W-42-14, 16
A/C Pressure Sensor.............. 8W-42-14, 16
A/C- Heater Control.......... 8W-42-2, 3, 4, 5, 7
ATC Remote Sensor................. 8W-42-11
Auto Temp Control...... 8W-42-8, 9, 10, 11, 12, 13
Battery........................... 8W-42-17
Blower Motor Resistor................ 8W-42-2
Body Control Module........... 8W-42-4, 7, 9, 13
Diagnostic Junction Port............. 8W-42-4, 9
Driver Blend Door Actuator......... 8W-42-5, 10
ECM/PCM Relay.................... 8W-42-17
Electric Wiper De-Icer............... 8W-42-3, 8
Engine Control Module............ 8W-42-16, 17
Evaporator Temperature Sensor...... 8W-42-5, 10
Front Blower Module................ 8W-42-11
Front Blower Motor................ 8W-42-2, 11
Front Blower Motor Relay........... 8W-42-2, 11
Front Control Module......... 8W-42-2, 6, 11, 12
Fuse 10......................... 8W-42-2, 11
Fuse 12......................... 8W-42-6, 12
Fuse 14............................ 8W-42-8
Fuse 16........................... 8W-42-17
Fuse 18........................ 8W-42-14, 16
Fuse 27........................ 8W-42-15, 18
Fuselink.......................... 8W-42-17
G102.......................... 8W-42-15, 18Component Page
G103.......................... 8W-42-14, 16
G200.............. 8W-42-2, 3, 4, 6, 8, 9, 11, 12
G300........................... 8W-42-7, 13
G302............................. 8W-42-12
Integrated Power
Module . . 8W-42-2, 6, 8, 11, 12, 14, 15, 16, 17, 18
Mode Door Actuator............... 8W-42-5, 10
Passenger Blend Door Actuator....... 8W-42-5, 10
Powertrain Control Module......... 8W-42-14, 15
Radiator Fan No. 1............ 8W-42-15, 17, 18
Radiator Fan No. 2............... 8W-42-15, 18
Radiator Fan Relay.................. 8W-42-15
Radiator Fan Relay No. 1.......... 8W-42-17, 18
Radiator Fan Relay No. 2............. 8W-42-18
Radiator Fan Relay No. 3............. 8W-42-18
Rear A/C-Heater Unit............... 8W-42-6, 7
Rear Auto Temp Control Switch........ 8W-42-13
Rear Blower Front Control Switch....... 8W-42-6
Rear Blower Motor.................. 8W-42-12
Rear Blower Motor Power Module...... 8W-42-12
Rear Blower Motor Relay........... 8W-42-6, 12
Rear Blower Rear Control Switch...... 8W-42-6, 7
Rear Mode Motor................... 8W-42-12
Rear Temperature Motor.............. 8W-42-12
Recirculation Door Actuator......... 8W-42-5, 10
TXV Solenoid...................... 8W-42-12
RS8W-42 AIR CONDITIONING-HEATER8W-42-1
ProCarManuals.com

8W-80 CONNECTOR PIN-OUTS
Component Page
A/C Compressor Clutch................ 8W-80-6
A/C Pressure Sensor.................. 8W-80-6
A/C-Heater Control C1 (MTC)........... 8W-80-6
A/C-Heater Control C2 (MTC)........... 8W-80-7
Accelerator Pedal Position Sensor
(Diesel).......................... 8W-80-7
Adjustable Pedals Module
(Except Built-Up-Export)............ 8W-80-7
Adjustable Pedals Switch
(Except Built-Up-Export)............ 8W-80-7
Airbag Control Module (ORC)........... 8W-80-8
Ambient Temp Sensor (Except Base)..... 8W-80-8
ATC Remote Sensor (ATC)............. 8W-80-8
Auto Temp Control C1................ 8W-80-9
Auto Temp Control C2................ 8W-80-9
Auto Temp Control C3................ 8W-80-9
Automatic Day/Night Mirror
(Premium/Luxury)................. 8W-80-9
Autostick Switch (Except
Built-Up-Export).................. 8W-80-10
Back-Up Lamp Switch (MTX).......... 8W-80-10
Battery Temperature Sensor (Diesel).... 8W-80-10
Blower Motor Resistor C1 (MTC)....... 8W-80-10
Blower Motor Resistor C2 (MTC)....... 8W-80-10
Body Control Module C1.............. 8W-80-11
Body Control Module C2.............. 8W-80-11
Body Control Module C3.............. 8W-80-12
Body Control Module C4.............. 8W-80-13
Body Control Module C5.............. 8W-80-14
Boost Pressure Sensor (Diesel)......... 8W-80-14
Brake Fluid Level Switch............. 8W-80-14
Brake Lamp Switch................. 8W-80-15
Brake Transmission Shift Interlock Solenoid
(EATX) ......................... 8W-80-15
C100............................. 8W-80-15
C100............................. 8W-80-16
C101............................. 8W-80-16
C101............................. 8W-80-16
C102 (2.4L)........................ 8W-80-17
C102 (2.4L)........................ 8W-80-17
C102 (3.3L/3.8L).................... 8W-80-17
C102 (3.3L/3.8L).................... 8W-80-18
C103 (Diesel)....................... 8W-80-18
C103 (Diesel)....................... 8W-80-18
C106 (Built-Up-Export)............... 8W-80-18
C106 (Built-Up-Export)............... 8W-80-19
C107 (Built-Up-Export)............... 8W-80-19
C107 (Built-Up-Export)............... 8W-80-19
C200............................. 8W-80-20
C200............................. 8W-80-22
C201............................. 8W-80-23
C201............................. 8W-80-24Component Page
C202............................. 8W-80-24
C202............................. 8W-80-24
C203 (United Kingdom).............. 8W-80-24
C203 (United Kingdom).............. 8W-80-25
C300 (LHD)........................ 8W-80-25
C300 (LHD)........................ 8W-80-25
C300 (RHD)....................... 8W-80-26
C300 (RHD)....................... 8W-80-26
C301............................. 8W-80-26
C301............................. 8W-80-26
C302............................. 8W-80-27
C302............................. 8W-80-27
C303 (LHD)........................ 8W-80-27
C303 (LHD)........................ 8W-80-28
C303 (RHD)....................... 8W-80-28
C303 (RHD)....................... 8W-80-28
C304............................. 8W-80-29
C304............................. 8W-80-29
C305............................. 8W-80-29
C305............................. 8W-80-29
C306............................. 8W-80-30
C306............................. 8W-80-30
C307............................. 8W-80-30
C307............................. 8W-80-30
C308............................. 8W-80-31
C308............................. 8W-80-31
C309............................. 8W-80-31
C309............................. 8W-80-32
C310 (Front Console)................ 8W-80-32
C310 (Front Console)................ 8W-80-32
C311 ............................. 8W-80-32
C311 ............................. 8W-80-33
C312............................. 8W-80-33
C312............................. 8W-80-34
C313 (Rear Console)................. 8W-80-34
C313 (Rear Console)................. 8W-80-34
C314 (High Line)................... 8W-80-35
C314 (High Line)................... 8W-80-35
C315 (High Line)................... 8W-80-35
C315 (High Line)................... 8W-80-36
C316 (Power Sliding Door)............ 8W-80-36
C316 (Power Sliding Door)............ 8W-80-36
C317 (Power Sliding Door)............ 8W-80-36
C317 (Power Sliding Door)............ 8W-80-37
C318 (Trailer Tow).................. 8W-80-37
C318 (Trailer Tow).................. 8W-80-37
C319 (Except Built-Up-Export/Low Line) . 8W-80-37
C319 (Except Built-Up-Export/Low Line) . 8W-80-38
C320............................. 8W-80-38
C320............................. 8W-80-38
C321............................. 8W-80-38
C321............................. 8W-80-38
RS8W-80 CONNECTOR PIN-OUTS8W-80-1
ProCarManuals.com

A/C COMPRESSOR CLUTCH - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 C3 18DB/YL A/C COMPRESSOR CLUTCH RELAY OUTPUT
2 Z153 18BK/GY GROUND
A/C PRESSURE SENSOR - GRAY 4 WAY
CAV CIRCUIT FUNCTION
1 C918 20BK/LB (DIESEL) A/C PRESSURE SENSOR GROUND
1 K900 18DB/DG (GAS) SENSOR GROUND
2 F851 20LB/PK (DIESEL) SENSOR REFERENCE VOLTAGE B
2 F855 18PK/YL (GAS) 5 VOLT SUPPLY
3 C18 20LB/BR (DIESEL) A/C PRESSURE SENSOR SIGNAL
3 C18 18LB/BR (GAS) A/C PRESSURE SENSOR SIGNAL
4- -
A/C-HEATER CONTROL C1 (MTC) - BLACK/RED 20 WAY
CAV CIRCUIT FUNCTION
1 Z24 18BK/OR GROUND
2 C121 20DB/DG SENSOR GROUND
3 C22 20LB/WT (3 ZONE HVAC) REAR TEMPERATURE FEEDBACK SIGNAL
4- -
5 F850 20LB/PK (3 ZONE HVAC) 5 VOLT SUPPLY
6 C900 18LB/VT WIPER DE-ICER DRIVER
7 C32 20DB/TN RECIRCULATION DOOR DRIVER (A)
8 C54 20LB/YL (3 ZONE HVAC) REAR BLEND DOOR DRIVER
9 C34 20DB/LB COMMON DOOR DRIVER (B)
10 D25 20WT/VT PCI BUS
11 - -
12 C121 20DB/DG (3 ZONE HVAC) REAR TEMPERATURE RETURN
13 F504 20GY/PK IGNITION SWITCH OUTPUT (RUN)
14 E12 20OR/GY PANEL LAMPS DRIVER
15 C21 20DB/LG EVAPORATOR TEMPERATURE SENSOR SIGNAL
16 C33 20LB/BR PASSENGER BLEND DOOR DRIVER (A)
17 C61 20DB/LG DRIVER BLEND DOOR DRIVER (A)
18 C35 20LB/OR MODE DOOR DRIVER (A)
19 C53 20LB (3 ZONE HVAC) REAR MODE DOOR DRIVER
20 C154 20LB/OR (3 ZONE HVAC) REAR COMMON DOOR DRIVER
8W - 80 - 6 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com

ENGINE CONTROL MODULE C1 (DIESEL) - BLACK 81 WAY
CAV CIRCUIT FUNCTION
55 N7 20DB/OR VEHICLE SPEED SENSOR SIGNAL
56 C918 20BK/LB A/C PRESSURE SENSOR GROUND
57 - -
58 K4 20BK/LB LOW IDLE POSITION SWITCH GROUND
59 - -
60 K9 20LB FUEL PRESSURE SENSOR 5 VOLT SUPPLY
61 K51 20BR/WT ECM/PCM RELAY CONTROL
62 - -
63 D21 20WT/BR SCI TRANSMIT
64 K151 20WT LOW IDLE POSITION SWITCH SENSE
65 - -
66 K936 20BR/YL ENGINE OIL PRESSURE SENSOR GROUND
67 - -
68 - -
69 C13 20LB/OR A/C COMPRESSOR CLUTCH RELAY CONTROL
70 N210 20DB/DG LOW SPEED RADIATOR FAN RELAY CONTROL
71 - -
72 N21 20DB/TN LIFT PUMP RELAY CONTROL
73 - -
74 T752 20DG/OR ENGINE STARTER MOTOR RELAY CONTROL
75 - -
76 - -
77 K152 20DB/WT GLOW PLUG RELAY CONTROL
78 N122 20DB/YL HIGH SPEED RADIATOR FAN DUAL RELAY CONTROL
79 - -
80 K87 20BR FUEL PRESSURE SOLENOID CONTROL
81 K87 20BR FUEL PRESSURE SOLENOID CONTROL
8W - 80 - 56 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com

INTEGRATED POWER MODULE C3 (DIESEL) - YELLOW/RED 20 WAY
CAV CIRCUIT FUNCTION
1 N21 20DB/TN LIFT PUMP RELAY CONTROL
2- -
3 T751 20YL FUSED IGNITION SWITCH OUTPUT (START)
4 T2 18DG/WT TRS REVERSE SENSE
5 N2 18DB/YL LIFT PUMP RELAY OUTPUT
6 F202 18PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START)
7 C3 18DB/YL A/C COMPRESSOR CLUTCH RELAY OUTPUT
8 Z114 18BK/LG GROUND
9 C13 20LB/OR A/C COMPRESSOR CLUTCH RELAY CONTROL
10 A119 16RD/OR FUSED B(+)
11 C41 20LB/DG CABIN HEATER ASSIST CONTROL
12 T753 20DG/YL FUSED IGNITION SWITCH OUTPUT (START)
13 - -
14 T752 20DG/OR ENGINE STARTER MOTOR RELAY CONTROL
15 Z116 18BK/VT GROUND
16 K51 20BR/WT ECM/PCM RELAY CONTROL
17 F202 18PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START)
18 - -
19 K342 16BR/WT ECM/PCM RELAY OUTPUT
20 - -
INTEGRATED POWER MODULE C3 (GAS) - NATURAL/RED 20 WAY
CAV CIRCUIT FUNCTION
1 Z115 20BK/OR (EATX) (3.3L/3.8L) GROUND
1 Z115 18BK/OR (EATX) (2.4L) GROUND
2 F1 18PK/WT (EATX) FCM OUTPUT (UNLOCK-RUN-START)
3 T751 18YL (EATX) FUSED IGNITION SWITCH OUTPUT (START)
4 T2 18DG/WT TRS REVERSE SENSE
5 T16 18YL/OR (EATX) TRANSMISSION CONTROL RELAY OUTPUT
6 T15 18YL/BR (EATX) TRANSMISSION CONTROL RELAY CONTROL
7 C3 18DB/YL A/C COMPRESSOR CLUTCH RELAY OUTPUT
8 K31 18BR FUEL PUMP RELAY CONTROL
9 C13 18LB/OR A/C COMPRESSOR CLUTCH RELAY CONTROL
10 A104 18YL/RD (EATX) FUSED B(+)
11 - -
12 - -
13 D25 18WT/VT (EATX) PCI BUS (EATX)
14 T752 18DG/OR ENGINE STARTER MOTOR RELAY CONTROL
15 Z116 18BK/VT GROUND
16 K51 18BR/WT AUTOMATIC SHUT DOWN RELAY CONTROL
17 F202 18PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START)
18 K173 18BR/VT RADIATOR FAN RELAY CONTROL
19 F202 18PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START)
20 A109 18OR/RD FUSED B(+)
8W - 80 - 68 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com

POWERTRAIN CONTROL MODULE C2 (GAS) - GRAY/GRAY 40 WAY
CAV CIRCUIT FUNCTION
41 V37 18VT SPEED CONTROL SWITCH SIGNAL
42 C18 18LB/BR A/C PRESSURE SENSOR SIGNAL
43 K900 18DB/DG SENSOR GROUND
44 F888 18BR/PK 8 VOLT SUPPLY
45 - -
46 A109 18OR/RD FUSED B(+)
47 - -
48 K40 18BR/LG (2.4L) IDLE AIR CONTROL NO. 3 DRIVER
49 K60 18VT/LG (2.4L) IDLE AIR CONTROL NO. 2 DRIVER
49 K39 18VT/DG (3.3L/3.8L) IDLE AIR CONTROL NO. 1 DRIVER
50 Z131 18BK/DG GROUND
51 K141 18DB/YL OXYGEN SENSOR 1/2 SIGNAL
52 - -
53 - -
54 - -
55 - -
56 V36 18VT/YL SPEED CONTROL VACUUM SOLENOID CONTROL
57 K39 18VT/DG (2.4L) IDLE AIR CONTROL NO. 1 DRIVER
57 K60 18VT/LG (3.3L/3.8L) IDLE AIR CONTROL NO. 2 DRIVER
58 K59 18BR/DG (2.4L) IDLE AIR CONTROL NO. 4 DRIVER
59 D25 18WT/VT PCI BUS
60 - -
61 F855 18PK/YL 5 VOLT SUPPLY
62 B29 18DG/WT SECONDARY BRAKE SWITCH SIGNAL
63 T10 18DG/LG (EATX) TORQUE MANAGEMENT REQUEST SENSE
64 C13 18LB/OR A/C COMPRESSOR CLUTCH RELAY CONTROL
65 D21 18WT/BR SCI TRANSMIT
66 N7 18DB/OR VEHICLE SPEED SENSOR SIGNAL
67 K51 18BR/WT AUTOMATIC SHUT DOWN RELAY CONTROL
68 K52 18DB/WT EVAPORATIVE EMISSION SOLENOID CONTROL
69 - -
70 K70 18DB/BR EVAPORATIVE EMISSION SOLENOID SENSE
71 - -
72 K107 18VT/WT (EXCEPT
BUILT-UP-EXPORT)LEAK DETECTION PUMP SWITCH SENSE
73 K173 18BR/VT RADIATOR FAN RELAY CONTROL
74 K31 18BR FUEL PUMP RELAY CONTROL
75 D20 18WT/LG SCI RECEIVE
76 T41 18YL/DB PARK/NEUTRAL POSITION SWITCH SENSE (TRS T41)
77 K106 18VT/WT (EXCEPT
BUILT-UP-EXPORT) (2.4L EATX W/ABS)LEAK DETECTION PUMP SOLENOID CONTROL
77 K106 18VT/LB (EXCEPT
BUILT-UP-EXPORT) (EXCEPT 2.4L EATX
W/ABS)LEAK DETECTION PUMP SOLENOID CONTROL
78 K54 18DB/WT (ATX) TORQUE CONVERTER CLUTCH SOLENOID CONTROL
79 - -
80 V35 18VT/OR SPEED CONTROL VENT SOLENOID CONTROL
RS8W-80 CONNECTOR PIN-OUTS8W-80-95
