2002 CHEVROLET CAMARO engine

6-69
Fuse and Relay Center 2
Fuse Usage
INJ
-2 Fuel Injectors (Not Used for V6)
(LH Injectors for V8 and
Ignition Module)
INJ
-1 Fuel Injectors (All for V6)
(RH Injectors for V8 and
Ignition Module)Fuse Usage
ENG SEN Mass Air Flow, Heated Oxygen
Sensor, Skip Shift Solenoid (V8
Only), Reverse Lockout Solenoid,
Brake Switch
STRTR Powertrain Control Module
(PCM) and Clutch Pedal Switch
ABS IGN Anti
-Lock Brake System Module
PCM IGN Powertrain Control
Module (PCM)
ETC Electronic Throttle
Control (V6 Only)
ENG CTRL Ignition Module (V6 Only),
Automatic Transmission and
Charcoal Canister Purge Solenoid
A/C CRUISE Air Conditioning Compressor
Relay, Cruise Control Switches
and Module
ENG CTRL Engine Controls, Fuel Pump,
Powertrain Control Module
(PCM), A.I.R. and Cooling Fans

6-70
Fuse Usage
I/P
-1 HVAC Blower Control and Relay
IGN Ignition Switch, Relay and Starter
Enable Relay
I/P
-2 Instrument Panel Fuse Center
Relay Description
Blank Not Used
AIR PUMP Air Pump
A/C COMP Air Conditioning Compressor
FUEL PUMP Fuel Pump
STARTER Starter
IGN Engine Controls, Cruise Control,
Air Conditioning
Replacement Bulbs
Back-Up3155 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stoplamp921 . . . . . . . . . . .
Front Parking and Turn Signal3157 K . . . . . . . . .
Headlamps
Low Beam 9006. . . . . . . . . . . . . . . . . . . . . . . . . . . .
High Beam 9005. . . . . . . . . . . . . . . . . . . . . . . . . . .
Taillamps Only194 . . . . . . . . . . . . . . . . . . . . . . . . . .
Tail/Stop/Turn Lamps3057 . . . . . . . . . . . . . . . . . . .
For any bulb not listed here contact your dealer.

6-71
Capacities and Specifications
The following approximate capacities are given in
English and metric conversions. Please refer to
ªRecommended Fluids and Lubricantsº in the Index
for more information.
Automatic Transmission
Drain and Refill Overhaul 5.0 quarts (4.7 L). . . . . .
3800 V6 8.8 quarts (8.3 L). . . . . . . . . . . . . . . . . . . .
5.7L V8 10.8 quarts (10.2 L). . . . . . . . . . . . . . . . . .
Manual Transmission
Five
-Speed 3.4 quarts (3.2 L). . . . . . . . . . . . . . . . .
Six
-Speed 4.0 quarts (3.8 L). . . . . . . . . . . . . . . . . . Cooling System
3800 V6
With Manual Transmission 11.6 quarts (11.0 L). . . .
With Automatic Transmission 11.4 quarts (10.8 L). .
5.7L V8
With Manual Transmission 11.9 quarts (11.3 L). . . .
With Automatic Transmission 11.8 quarts (11.2 L).
Engine Oil with Filter
3800 V6 4.5 quarts (4.2 L). . . . . . . . . . . . . . . . . . . .
5.7L V8 5.5 quarts (5.2 L). . . . . . . . . . . . . . . . . . . .
Fuel Tank16.8 U.S. gallons (63 L) . . . . . . . . . . . . . .
Wheel Nut Torque100 lb-ft (140 N´m) . . . . . . . . . .
All capacities are approximate. When adding, be sure to
fill to the approximate level, as recommended in this
manual. Recheck fluid level after filling.
Engine Specifications
Type
VIN Engine Code K 3800 V6. . . . . . . . . . . . . . . . . . .
VIN Engine Code G 5.7L V8. . . . . . . . . . . . . . . . . . . .

6-72
Air Conditioning
Refrigerant Capacity
If you do your own service work, you'll need the proper
service manual. See ªDoing Your Own Service Workº in
the Index for additional information. It is recommended
that service work on your air conditioning system be
performed by a qualified technician.
Air Conditioning R
-134a 1.5 lbs (0.68 kg) . . . . . . . .
Use Refrigerant Oil, R134a Systems
Normal Maintenance
Replacement Parts
Engine Air Cleaner/FilterA917C* . . . . . . . . . . . . . .
Engine Oil Filter
3800 V6 PF47*. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 PF44*. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Filter
3800 V6 G627*. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 GF578*. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spark Plug
3800 V6 41
-921 (0.060 inch gap)* . . . . . . . . . . . . . .
5.7L V8 41
-974 (0.060 inch gap)* . . . . . . . . . . . . . .
Windshield Wiper Blade Replacement
Type Hook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Length 24.0 inches (60.1 cm). . . . . . . . . . . . . . . . . .
*ACDelco

part number.

Scheduled Maintenance
7-6Engine Oil Scheduled Maintenance
Change engine oil and filter as indicated by the
GM Oil Life System
(or every 12 months,
whichever occurs first). Reset the system.
Your vehicle has a computer system that lets you know
when to change the engine oil and filter. This is based
on engine revolutions and engine temperature, and not
on mileage. Based on driving conditions, the mileage
at which an oil change will be indicated can vary
considerably. For the oil life system to work properly,
you must reset the system every time the oil is changed.When the system has calculated that oil life has been
diminished, it will indicate that an oil change is
necessary. A OIL CHANGE light will come on. Change
your oil as soon as possible within the next two times
you stop for fuel. It is possible that, if you are driving
under the best conditions, the oil life system may not
indicate that an oil change is necessary for over a year.
However, your engine oil and filter must be changed at
least once a year and at this time the system must be
reset. It is also important to check your oil regularly and
keep it at the proper level.
If the system is ever reset accidentally, you must change
your oil at 3,000 miles (5 000 km) since your last oil
change. Remember to reset the oil life system whenever
the oil is changed. See ªOil Life Systemº in the Index
for information on resetting the system.
An Emission Control Service.

Scheduled Maintenance
7-9
7,500 Miles (12 500 km)
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
15,000 Miles (25 000 km)
Inspect engine air cleaner filter if you are driving in dusty conditions.
Replace filter if necessary.
An Emission Control Service. (See footnote
.)
Change automatic transmission fluid and filter if the vehicle is mainly driven
under one or more of these conditions:
± In heavy city traffic where the outside temperature regularly
reaches 90F (32C) or higher.
± In hilly or mountainous terrain.
± When doing frequent trailer towing.
± Uses such as found in taxi, police or delivery service.
If you do not use your vehicle under any of these conditions, change the fluid
and filter every 50,000 miles (83 000 km).
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE

Scheduled Maintenance
7-10
22,500 Miles (37 500 km)
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
30,000 Miles (50 000 km)
Change automatic transmission fluid and filter if the vehicle is mainly driven
under one or more of these conditions:
± In heavy city traffic where the outside temperature regularly
reaches 90
F (32
C) or higher.
± In hilly or mountainous terrain.
± When doing frequent trailer towing.
± Uses such as found in taxi, police or delivery service.
If you do not use your vehicle under any of these conditions, change the fluid
and filter every 50,000 miles (83 000 km).
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
Replace engine air cleaner filter.
An Emission Control Service.
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE

Scheduled Maintenance
7-11
37,500 Miles (62 500 km)
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
45,000 Miles (75 000 km)
Inspect engine air cleaner filter if you are driving in dusty conditions.
Replace filter if necessary.
An Emission Control Service. (See footnote
.)
Change automatic transmission fluid and filter if the vehicle is mainly driven
under one or more of these conditions:
± In heavy city traffic where the outside temperature regularly
reaches 90F (32C) or higher.
± In hilly or mountainous terrain.
± When doing frequent trailer towing.
± Uses such as found in taxi, police or delivery service.
If you do not use your vehicle under any of these conditions, change the fluid
and filter every 50,000 miles (83 000 km).
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE
