2002 CHEVROLET CAMARO Owners Manual

2-60 Fog Lamps (Option)
Use your fog lamps for better vision in foggy or
misty conditions.
Your fog lamp switch is
located on your console,
above the audio system.Your parking lamps must be on or your fog lamps
won't work.
To turn the fog lamps on, push the right side of the fog
lamp switch and a light on the switch will come on
indicating that the fog lamps are on. Push the left side
of the switch to turn the fog lamps off.
The fog lamps will go off whenever your high
-beam
headlamps come on. When the high
-beam headlamps
go off, the fog lamps will come on again.
If your vehicle has the content theft
-deterrent/alarm
system and your fog lamp switch is on, the fog lamps
may flash along with the parking lamps to indicate
operation of the content theft
-deterrent/alarm system.
See ªContent Theft
-Deterrent/Alarm Systemº in
the Index.

2-61
Interior Lamps
Instrument Panel Brightness Control
This feature controls the brightness of the instrument
panel lights.
The thumbwheel for this feature is located on the
instrument panel to the left of the steering column.
Move the thumbwheel up or down to brighten or dim
the lights. If you move the thumbwheel all the way up,
your courtesy lamps will come on.
Courtesy Lamps
When either door is opened, several interior lamps go
on. These lamps are courtesy lamps. They make it easier
for you to enter and leave your vehicle.
Courtesy lamps include two map lamps on the inside
rearview mirror and other lamps throughout the interior
of your vehicle.
To prevent battery rundown, your interior lamps will be
disabled about 10 minutes after the ignition is turned to
OFF. The 10
-minute timer will be restarted if you do
any of the following:

Turn the ignition on.

Open either door.

Press any button on your remote keyless entry
transmitter (option).

Turn the interior lamps from off to on.

Open the hatch.

2-62 Delayed Illumination
With delayed illumination, the courtesy lamps will come
on and stay on for 25 seconds after you enter the vehicle
and close the door. They will also stay on for five
seconds after you exit the vehicle and close the doors.
Delayed illumination will be shortened if the ignition is
turned to RUN or if the power locks are activated. To
turn this feature on or off, see ªFeature Customizationº
in the Index.
Exit Lighting
With exit lighting, the interior lamps will come on when
you remove the key from the ignition to help you see
while exiting the vehicle. To turn this feature on or off,
see ªFeature Customizationº in the Index.
Front Map Lamps
Your inside rearview mirror includes two map lamps.
Each lamp has its own switch. Use the switch closest to
the lamp to turn it on. The lamps will also come on
when a door is opened.
Mirrors
Inside Day/Night Rearview Mirror
An inside rearview mirror is attached to your
windshield. The mirror pivots so that you can adjust it.
You can adjust the mirror for day or night driving. Pull
the tab for night driving to reduce glare. Push the tab for
daytime driving.

2-63
Power Remote Control Mirrors
(If Equipped)
The power mirror control is located on the driver's door.
To adjust either mirror, turn the selector switch to
L (left) or R (right). Then push the control in the
direction that you want the mirror to go.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.

2-64
Storage Compartments
Glove Box
To open the glove box, lift up on the lever. Use your
door key to lock or unlock it.
Front Console
To use the storage area, push in the button located on
the driver's side of the console and pull up on the
console cover.
Compact Disc Storage
There is a storage area for compact discs in the console.
Cargo Cover
Using the Cargo Cover
The cargo cover can be closed for hidden storage in the
rear area of your vehicle. It can also help reduce noise in
the vehicle when placed in the upright position, closing
out the rear area.
When carrying large or heavy items, it is a good idea
to open the cover and place the items in the rear area of
the vehicle.

2-65
Removing the Cargo Cover
1. Close the cover. If the cargo cover is not closed and
resting on the trim panel, it cannot be removed.
2. Pull the cover toward you to unsnap it. Then slide
the cargo cover along the groove in the trim panel.
Reverse the steps to install the cover.
CAUTION:
An improperly stored cargo cover could be
thrown about the vehicle during a collision or
sudden maneuver. You or others could be
injured. If you remove the cover, always store it
outside your vehicle. When you put it back,
always be sure that it is securely reattached.

2-66
Ashtray and Cigarette Lighter
Lift up the cover to open the ashtray. To remove it, lift
up on the right side of the ashtray. If you have an
automatic transmission, the ashtray is near the front of
the console. If you have a manual transmission, the
ashtray is near the cupholder.
NOTICE:
Don't put papers and other things that burn into
your ashtrays. If you do, cigarettes or other
smoking materials could set them on fire,
causing damage.
To use the lighter, push it in all the way and let go.
When it's ready, it will pop back out by itself.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.
If you plug accessories into your cigarette lighter, such
as heating devices or air compressors, these accessories
should have a rated current of less than 15 amps.
Exceeding this limit will result in a blown fuse.
Sun Visors
To block out glare, you can swing down the visors.
You can also swing them to the side.
Visor Vanity Mirror
Pull down the sun visor and lift the cover to expose the
vanity mirror.

2-67
Accessory Power Outlet
The accessory power outlet can be used to connect
electrical equipment such as a cellular phone or
CB radio.
The accessory power outlet is located behind a closed
cover in front of the parking brake on the console.
NOTICE:
When using the accessory power outlet:

The maximum load of any electrical
equipment should not exceed three amps.

Be sure to turn off any electrical equipment
when not in use. Leaving electrical
equipment on for extended periods can
drain your battery.
Certain electrical accessories may not be compatible
with the accessory power outlet and could result in
blown vehicle or adapter fuses. If you experience a
problem, see your dealer for additional information on
the accessory power outlet.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by
your warranty.
When adding electrical equipment, be sure to follow the
installation instructions included with the equipment.
We recommend that you see a qualified technician or
your dealer for the proper installation of your equipment.
NOTICE:
Power outlets are designed for accessory plugs
only. Do not hang any type of accessory or
accessory bracket from the plug. Improper use of
the power outlet can cause damage not covered
by your warranty.
