2002 CADILLAC SEVILLE display

2-114
Ultrasonic Rear Parking Assist (URPA)
Ultrasonic Rear Parking Assist can help you to determine
how close an object is to your rear bumper within a given
area, making parking easier.
The URPA display is located inside the vehicle, above the
rear window. It has three color
-coded lights that can be
seen through the rearview mirror or by turning around.
How the System Works
URPA comes on automatically when the shift lever is
moved into REVERSE (R) and the vehicle speed is
less than 3 MPH (5 km/h). When the system comes on,
the three lights on the display will illuminate to let you
know that the system is working. URPA senses how
close your vehicle is to an object. The distance is
determined by the four ultrasonic sensors located on
the rear bumper. When you shift into REVERSE (R) and an object is
detected, the following will occur in sequence
depending on the distance from the object:

At 5 feet (1.5 m) one amber light will be lit;

at 40 inches (1.0 m) both amber lights will be lit;

at 20 inches (0.5 m) a continuous chime will sound
and all three lights (amber/amber/red) will be lit; and

at 1 foot (0.3 m) a continuous chime will sound and
all three lights (amber/amber/red) will flash.
URPA can detect objects 3 inches (7.6 cm) and wider,
and at least 10 inches (25.4 cm) tall, but it cannot
detect objects that are above trunk level. In order for
the rear sensors to recognize an object, it must be within
operating range.

2-115
If the URPA system is not functioning properly, the
display will flash red, indicating that there is a problem.
The light will also flash red while driving if a trailer is
attached to your vehicle, or a bicycle or object is on
the back of, or hanging out of your trunk. The light
will continue to flash until the trailer or the object is
removed and your vehicle is driven forward at least
15 mph (25 km/h).
It may also flash red if the ultrasonic sensors are not
kept clean. So be sure to keep your rear bumper free
of mud, dirt, snow, ice and slush or materials such as
paint or the system may not work properly. If after
cleaning the rear bumper and driving forward at least
15 mph (25 km/h), the display continues to flash red,
see your dealer. For cleaning instructions, see ªCleaning,
Outside of Your Vehicleº in the Index.It may also flash red if your vehicle is moving in
REVERSE (R) at a speed greater than 3 mph (5 km/h).
Other conditions that may affect system performance
include things like the vibrations from a jackhammer or
the compression of air brakes on a very large truck.
As always, drivers should use care when backing up a
vehicle. Always look behind you, being sure to check
for other vehicles, obstructions and blind spots.

3-4
(Recirculation): Press this button to limit the
amount of outside air entering your vehicle. This is
helpful when you are trying to cool the air quickly or
limit odors entering your vehicle. Press this button again
to turn off the recirculation feature.
If you notice the windows fogging, press the
recirculation button to exit the recirculation mode.
Recirculation is not available in the defrost mode.
A/C (Air Conditioning): Press this button to turn the
air conditioning compressor on and off. The system will
cool and dehumidify the air inside the vehicle.
When the compressor is off, A/C OFF appears on the
climate control panel display. Press the button again and
the compressor will turn back on.
The A/C OFF feature is not available in the
defrost mode.
AUTO (Automatic): The AUTO button will turn on the
system and automatically adjust the fan speed, air
delivery mode and temperature to your previously
programmed settings.When the system is set for automatic operation, sensors
will control the air delivery mode. Air will come from
the floor ducts, the instrument panel or windshield
outlets. The fan speed will vary as the system maintains
the selected temperature setting.
To find your comfort zone, start with the 75
F (24
C)
setting and allow about 30 minutes for the system to
regulate. Turn the TEMP knob to adjust the temperature if
necessary. If you choose 60
F (16
C), the system will
remain at that maximum cooling setting and will not
regulate fan speed. If you choose 90
F (32
C), the system
will remain at that maximum heating setting and will not
regulate fan speed. Choosing either maximum setting will
not cause the system to heat or cool any faster.
With the automatic setting, the air conditioning
compressor cycles on and off when needed to cool the
air. In cold weather, when the system senses the need for
heat, the airflow will be directed out the floor ducts. As
the interior temperature approaches a desired setting, the
fan speed will decrease. To maintain interior comfort,
the airflow may move to the instrument panel air outlets
and floor ducts. On bright sunny days in cold weather,
the airflow may come out of the instrument panel outlets
to maintain comfort and prevent stuffiness.

3-12
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all of its controls to be sure you're getting the
most out of the advanced engineering that went into it.
Your vehicle has a feature called Retained Accessory
Power (RAP). With RAP, you can play your audio
system even after the ignition is turned off. See
ªRetained Accessory Powerº in the Index.
Setting the Clock
Press and hold HR or MN until the time display begins
to change. Release the button as you get close to the
correct time. The time may be set anytime the clock is
displayed. There is a two
-second delay before the clock
goes into time
-set mode.
AM-FM Stereo with Cassette Tape and
Compact Disc Player
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn this knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.

3-13
HR (Hour) or MN (Minute): Display the time with the
ignition off by pressing this button.
SOURCE: Press this button to select a source, either
cassette or compact disc. The audio source must be
loaded to play. Available loaded sources are shown on
the display. If a source is being used, it will be
underlined on the display. If none of the audio sources
are loaded, NO SOURCE LOADED will appear on the
display. Press this button again or press BAND to switch
back to the radio.
Finding a Station
BAND: Press this button to select AM, FM1 or FM2.
~' TUNE SEEK !': When this button is pressed it
has two positions. Press this button to the first position
to manually tune to the next or previous stations. If this
button is held at the first position for a few seconds, the
radio will continue tuning until this button is released.
Press this button to the second position and release it to
seek to the next or previous radio station.
SCAN: Press this button for less than two seconds
to scan radio stations and associated tone settings.
The radio will go to a station, play for five seconds,
then go on to the next station. Press this button again
to stop scanning.To scan preset stations, press and hold SCAN for more
than two seconds until you hear a beep. The radio will
go to the first preset station stored on your pushbuttons,
play for five seconds, then go on to the next preset
station. Press SCAN again to stop scanning. The radio
will scan preset stations with a strong signal only.
Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2), by performing the
following steps:
1. Turn the radio on.
2. Press BAND to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press and hold one of the six numbered pushbuttons
for more than two seconds until you hear a beep.
5. Repeat the steps for each pushbutton. Whenever you
press that numbered pushbutton for less than
two seconds, the station you set will return.
When battery power is removed and later applied, you
will not have to reset your radio presets because the
radio remembers them.

3-14
Setting the Tone (Bass/Treble)
TONE: Press and release this button until the desired
tone control (bass, treble or midrange) is found. The
radio keeps separate tone settings for each band, each
preset and each source.
- LEVEL +: After selecting the desired tone control,
press the plus or minus symbol on this button to select
the desired level.
To save the tone settings for your presets, press and hold
the numbered pushbutton for the desired preset for more
than two seconds until you hear a beep.
Adjusting the Speakers (Balance/Fade)
(Speaker): Press and release this button until the
desired control (balance or fade) is found.
- LEVEL +: After selecting the desired control, press
the plus or minus symbol on this button to select the
desired level.
PTY (Program
-Type): This button is inoperable on
this radio.Playing a Cassette Tape
With the radio on, insert a cassette tape. The tape will
begin playing as soon as it is inserted. When one side of
your cassette tape is done playing, auto reverse plays the
other side of your cassette tape. Cassette tapes may be
loaded with the radio off but they will not start playing
until the radio is on. If you want to insert a cassette tape
when the ignition is off, first press the eject button.
While the tape is playing, use the VOL, TONE, LEVEL,
and speaker controls just as you do for the radio. Other
controls may have different functions when a tape is
inserted. The display will show an underlined tape
symbol. TAPE PLAY will appear on the display when a
tape is playing, with an arrow to indicate which side of
the tape is playing.
Your cassette tape player automatically reduces
background noise. Dolby Noise Reduction is manufactured
under a license from Dolby Laboratories Licensing
Corporation. Dolby and the double
-D symbol are
trademarks of Dolby Laboratories Licensing Corporation.
Auto CrO
2 allows the cassette tape player to adjust to
the type of cassette tape for clearer sound for CrO
2cassette tapes.
If an error appears on the display, see ªCassette Tape
Messagesº later in this section.

3-15

RW (Rewind): Press the left arrow to rewind the
tape rapidly. The radio will play while the tape rewinds.
You may use your station pushbuttons to tune to another
radio station while in rewind. Press the left arrow again
to return to playing speed.
FF
 (Fast Forward): Press the right arrow to fast
forward to another part of the tape. The radio will play
while the tape advances. You may use your station
pushbuttons to tune to another radio station while in
fast forward. Press the right arrow again to return to
playing speed.
~' SEEK !': Press the up or down arrow to seek to
the next or previous selection on the tape. Your tape
must have at least three seconds of silence between each
selection for the SEEK arrows to work. The sound will
mute while seeking.
SCAN: Press this button to listen to selections for a
few seconds. The tape will go to a selection, play for a
few seconds, then go on to the next selection. Press this
button again to stop scanning.
SIDE: Press this button to change the side of the tape
that is playing.
(Eject): Press this button to the right of the
cassette tape player to remove a tape. The radio will
play. Eject may be activated with the radio off and/or
the ignition off.
Cassette Tape Messages
If an error occurs while trying to play a cassette tape, it
could be for one of the following reasons:

The cassette tape is tight and the cassette player
cannot turn the hubs of the tape. Hold the cassette
tape with the open end down and try turning the right
hub counterclockwise with a pencil. Flip the tape
over and repeat. If the hubs do not turn easily, your
cassette tape may be damaged and should not be
used in the player. Try a new tape to be sure your
player is working properly.

The cassette tape is broken. (Check to see if your
tape is broken. Try a new tape.)
CLEAN TAPE: If this message appears on the display,
the cassette tape player needs to be cleaned. It will still
play tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer.

3-16
Playing a Compact Disc
Insert a disc partway into the slot, label side up. The
player will pull it in. If the ignition and the radio are on
and the underlined compact disc symbol appears on the
display, the disc will begin playing. Compact discs may
be loaded with the radio off but they will not start
playing until the radio is on. If you want to insert a disc
when the ignition is off, first press the eject button.
The integral CD player can play the smaller 8 cm
compact discs. Full
-size compact discs and the smaller
compact discs are loaded in the same manner.
If an error appears on the display, see ªCompact Disc
Messagesº later in this section.

RW (Rewind): Press and hold the left arrow to
reverse the compact disc. Release it to return to playing
speed.
FF
 (Fast Forward): Press and hold the right arrow
to fast forward to another part of the compact disc.
Release it to return to playing speed.
~' SEEK !': When this button is pressed, it has two
positions. This button works the same, whether it is
pressed to the first or second position. Press this button
to seek to the next or previous track on the compact disc.
SCAN: Press this button to listen to tracks for a few
seconds. The compact disc will go to a track, play for a
few seconds, then go on to the next track. Press this
button again to stop scanning.
RDM (Random): Press this button to hear the tracks in
random, rather than sequential, order. Press RDM again
to turn off random play.
(Eject): Press this button, located to the right of the
CD slot, to stop a CD when it is playing or to eject a CD
when it is not playing. Eject may be activated with the
radio off and/or the ignition off.
