2002 CADILLAC SEVILLE light

2-47
: Turning the control to this position turns on
the parking lamps together with the following:

Sidemarker Lamps

Taillamps

License Plate Lamps

Instrument Panel Lights
The parking brake indicator light will come on and stay
on when the parking lamps are on with the engine off
and the ignition in ACC or ON.
: Turning the control to this position turns on the
headlamps, together with the previously listed lamps
and lights.
Your vehicle may be equipped with High Intensity
Discharge (HID) headlamps. These headlamps come
on at a lower intensity and gradually increase to
full brightness.Wiper
-Activated Headlamps
This feature activates the headlamps and parking
lamps after the windshield wipers have been in use for
approximately six seconds. To operate, the Twilight
Sentinel
 feature must be turned on. See ªTwilight
Sentinelº in the Index for more information.
When the exterior lamp control is in the off or in the
parking lamp position and the wiper control is on INT,
LO or HI, the HEADLAMPS SUGGESTED message
will appear on the Driver Information Center (DIC).
When the ignition is turned to OFF, the wiper
-activated
headlamps will immediately turn off. The wiper
-activated
headlamps will also turn off if the Twilight Sentinel or
the windshield wipers are turned off.
Lamps On Reminder
A warning chime will sound if the exterior lamp
control is left on in either the headlamp or parking
lamp position and the driver's door is opened with the
ignition off.

2-48 Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier
for others to see the front of your vehicle during
the day. DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset. Fully
functional daytime running lamps are required on all
vehicles first sold in Canada.
The DRL system will make the high
-beam headlamps
come on at reduced brightness when the following
conditions are met:

It is still daylight and the ignition is on,

the exterior lamp control is in the off position and

the transaxle is not in PARK (P).
When DRL are on, only your high
-beam headlamps
(at reduced brightness) will be on. No other exterior
lamps such as the parking lamps, taillamps, etc. will be
on when the DRL are being used. Your instrument panel
won't be lit up either.
When the Twilight Sentinel
 lever is on and it's dark
enough outside, the high
-beam headlamps (at reduced
intensity) will turn off and normal low
-beam headlamp
operation will occur. When the Twilight Sentinel lever is on and it's bright
enough outside, the regular lamps will go off, and the
high
-beam headlamps at reduced brightness will
take over.
If it's dark enough outside and the Twilight Sentinel
lever is off, a HEADLAMPS SUGGESTED message
will display on the Driver's Information Center (DIC).
This message informs the driver that turning on the
exterior lamps is recommended even though the DRL
are still illuminated. Turning on the Twilight Sentinel
or the headlamps will deactivate the DRL and remove
the HEADLAMPS SUGGESTED message. If the
parking lamps or the fog lamps were turned on instead,
the DRL will still deactivate and the HEADLAMPS
SUGGESTED message will continue to be displayed.
To idle your vehicle with the DRL off at night,
turn off the Twilight Sentinel and shift the transaxle
into PARK (P). Placing your vehicle in PARK (P)
disables the DRL. The DRL will stay off until you
shift out of PARK (P).
To drive your vehicle with the DRL off, turn off the
Twilight Sentinel and manually turn on the parking
lamps or fog lamps (if equipped).
As with any vehicle, you should turn on the regular
headlamp system when you need it.

2-49 Fog Lamps (STS Only)
Use the fog lamps for better vision in foggy or
misty conditions.
When the ignition is on and you push the fog lamp
button located next to the exterior lamps control,
a small indicator light in the fog lamp button, the
LIGHTS ON and fog lamp indicator lights on the
instrument panel cluster will come on to indicate that
the fog and the parking lamps are on.
Press the fog lamp button again to turn off the
fog lamps.
If you turn on the high
-beam headlamps, the fog
lamps will turn off. They'll turn back on again when
you switch to low
-beam headlamps.
When the Twilight Sentinel

is on and the fog lamps
are turned on, the fog lamps, headlamps and parking
lamps will remain on.
The ignition must be on for the fog lamps to operate.
Cornering Lamps
The cornering lamps come on when the headlamps
or parking lamps are on and you signal a turn with
the multifunction lever. They provide more light
for cornering.
Twilight Sentinel

This lever is located below
the exterior lamps control.
It automatically turns the
lamps on and off by sensing
how dark it is outside.
To operate the Twilight Sentinel, leave the exterior
lamps control off and slide the TWILIGHT lever to
any position but OFF.
If you move the lever all the way to the right, the lamps
will remain on for approximately three minutes after the
ignition has been turned to OFF. If you move the lever
so it is barely on, the lamps will go off quickly when
you turn the ignition switch out of OFF. You can
adjust the delay time from only a few seconds to
about three minutes.
If it's dark enough outside and the Twilight Sentinel
lever is off, a HEADLAMPS SUGGESTED message
will display on the Driver Information Center (DIC).

2-50
This message informs the driver that turning on the
exterior lamps is recommended (it's become dark enough
outside to require the headlamps and/or other exterior
lamps). Turning on the Twilight Sentinel or turning the
exterior lamp control to the headlamp position will
remove the HEADLAMPS SUGGESTED message.
Light Sensor
The light sensor for the Daytime Running Lamps (DRL)
and the Twilight Sentinel is located on the driver's side
of the front defogger grille. If you cover the sensor, it will read ªdarkº and the
exterior lamps or the HEADLAMPS SUGGESTED
message will be on whenever the ignition is on.
Exterior Lighting Battery Saver
If the manual parking lamps or headlamps have been
left on, the exterior lamps will turn off approximately
ten minutes after the ignition is turned to OFF.
This protects against draining the battery in case you
have accidentally left the headlamps or parking lamps
on. The battery saver does not work if the headlamps
are turned on after the ignition switch is turned to OFF.
If you need to leave the lamps on for more than
10 minutes, use the exterior lamp control to turn the
lamps back on. To delay the lamps from turning off,
see ªTwilight Sentinelº in the Index.

2-51
Interior Lamps
Instrument Panel Brightness Knob
This feature controls the brightness of the instrument
panel lights.
The knob for this feature is
located to the right of the
Twilight Sentinel lever.
Press the knob to release it to the outward position.
Turn the knob clockwise to brighten the lights and
counterclockwise to dim them. Press the knob to
return it to the original storage position.
Interior Lamp Lever
The interior lamp lever,
located in the overhead
console, has three positions:
OFF, AUTO and ON.
When the interior lamp lever is in OFF, the lamps are
turned off. Only the driver's door controls and ignition
switch backlighting functions will operate.
With the lever in AUTO and a front door is opened,
the overhead console light, front hush panel lamps and
rear footwell lamps in the door will automatically come
on. When the rear door is opened, all the front door
lighting and rear overhead lamps will come on.
When the lever is in ON, the courtesy lamps are
turned on. Also, all automatic interior lighting
functions are terminated.

2-52 Illuminated Entry
The illuminated entry system turns on the courtesy
lamps and the backlighting to the door switches and to
the exterior lamp control when a door is opened or if
you press the remote keyless entry transmitter unlock
button. If activated due to the transmitter, the lighting
will remain active for about 40 seconds. Since the
illuminated entry system uses the light sensor, it must be
dark outside in order for the courtesy lamps to turn on.
The courtesy lamps turn off approximately 25 seconds
after the last door is closed. They will dim to off if the
ignition key is placed in ON, or immediately deactivate
if the power locks are activated.
Parade Dimming
This feature prohibits dimming of the digital displays
and backlighting during daylight hours when the key is
in the ignition and the headlamps are on. This feature
operates with the light sensor for the Twilight Sentinel
and is fully automatic. When the light sensor reads
darkness outside and the parking lamps are active,
the digital displays can be adjusted by turning the
instrument panel brightness knob counterclockwise
to dim and clockwise to brighten lighting.
Reading Lamps
The front reading lamps are located in the overhead
console. These lamps and the interior courtesy lamps
come on when a door is opened and it is dark outside.
The rear reading lamps will not come on when a front
door is opened.
The rear courtesy lamps are located on the rear headliner
above the rear seat outboard positions. When a rear door
is opened, both the front and rear reading lamps come
on with the courtesy lamps.
Press the button near each lamp to turn it on and off.
If the reading lamps are left on, they automatically shut
off 10 minutes after the ignition has been turned off.
Battery Load Management
The battery load management feature is designed to
monitor the vehicle's electrical load and determine
when the battery is in a heavy discharge condition.
During times of high electrical loading, the engine
may idle at a higher revolutions per minute (rpm)
setting than normal to make sure the battery charges.
High electrical loads may occur when several of the
following are on: headlamps, high beams, fog lamps,
rear window defogger, the climate control fan at high
speeds, heated seats and engine cooling fans.

2-53
If the battery continues to discharge, even with the
engine idling at a higher rpm setting, some electrical
loads will automatically be reduced. When this occurs,
the rear window defogger may take slightly longer
to clear the glass, the heated seats may not get as
warm as they usually do and the fan may cut back to
a lower speed. For more battery saving information,
see ªBattery Message, Saver Activeº in the Index.
Inadvertent Power Battery Saver
This feature is designed to protect your vehicle's battery
against drainage from the interior lamps, trunk lamp,
glove box lamp, cigarette lighters or the garage door
opener. When the ignition is turned off, the power to
these features will automatically turn off after 10 minutes
(three minutes if a new car has 15 miles (24 km) or less).
Power will be restored for an additional 10 minutes if any
door is opened, the trunk is opened or the courtesy lamp
switch is turned on.
Mirrors
Electrochromic Day/Night Rearview Mirror
with Compass and OnStar
System
Your vehicle has an electrochromic inside rearview
mirror with a compass display. The mirror also contains
OnStar

controls. For more information see ªOnStarº
in the Index.
(On/Off): The on/off button is located on the
lower left side of the mirror for the electrochromic and
compass functions of the rearview mirror.

2-54
The mirror also includes an eight-point compass
display in the upper right corner of the mirror face.
When on, the compass automatically calibrates as the
vehicle is driven.
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror as that may cause
the liquid cleaner to enter the mirror housing.
Mirror Operation
To turn on the automatic dimming feature, press
and hold the on/off button for about three seconds.
To turn off automatic dimming, press and hold
the on/off button for about three seconds again.
The indicator light will illuminate when this feature is
active. The automatic dimming feature is active each
time the vehicle is started.Compass Operation
Press the on/off button once to turn the compass
on or off.
When the ignition and the compass feature are on,
the compass will show two character boxes for
approximately two seconds. After two seconds,
the mirror will display the compass heading.
Compass Calibration
If after two seconds, the display does not show a
compass heading (N for North, for example), there may
be a strong magnetic field interfering with the compass.
Such interference may be caused by a magnetic antenna
mount, magnetic note pad holder or a similar magnetic
item. If the letter C should ever appear in the compass
window, the compass may need calibration.
The mirror can be calibrated by driving the vehicle in
circles at 5 mph (8 km/h) or less until the display
reads a direction.
The compass can be placed in calibration mode by
pressing and holding the on/off button until a C is
shown in the compass display.
