2002 CADILLAC SEVILLE ignition

2-50
This message informs the driver that turning on the
exterior lamps is recommended (it's become dark enough
outside to require the headlamps and/or other exterior
lamps). Turning on the Twilight Sentinel or turning the
exterior lamp control to the headlamp position will
remove the HEADLAMPS SUGGESTED message.
Light Sensor
The light sensor for the Daytime Running Lamps (DRL)
and the Twilight Sentinel is located on the driver's side
of the front defogger grille. If you cover the sensor, it will read ªdarkº and the
exterior lamps or the HEADLAMPS SUGGESTED
message will be on whenever the ignition is on.
Exterior Lighting Battery Saver
If the manual parking lamps or headlamps have been
left on, the exterior lamps will turn off approximately
ten minutes after the ignition is turned to OFF.
This protects against draining the battery in case you
have accidentally left the headlamps or parking lamps
on. The battery saver does not work if the headlamps
are turned on after the ignition switch is turned to OFF.
If you need to leave the lamps on for more than
10 minutes, use the exterior lamp control to turn the
lamps back on. To delay the lamps from turning off,
see ªTwilight Sentinelº in the Index.

2-51
Interior Lamps
Instrument Panel Brightness Knob
This feature controls the brightness of the instrument
panel lights.
The knob for this feature is
located to the right of the
Twilight Sentinel lever.
Press the knob to release it to the outward position.
Turn the knob clockwise to brighten the lights and
counterclockwise to dim them. Press the knob to
return it to the original storage position.
Interior Lamp Lever
The interior lamp lever,
located in the overhead
console, has three positions:
OFF, AUTO and ON.
When the interior lamp lever is in OFF, the lamps are
turned off. Only the driver's door controls and ignition
switch backlighting functions will operate.
With the lever in AUTO and a front door is opened,
the overhead console light, front hush panel lamps and
rear footwell lamps in the door will automatically come
on. When the rear door is opened, all the front door
lighting and rear overhead lamps will come on.
When the lever is in ON, the courtesy lamps are
turned on. Also, all automatic interior lighting
functions are terminated.

2-52 Illuminated Entry
The illuminated entry system turns on the courtesy
lamps and the backlighting to the door switches and to
the exterior lamp control when a door is opened or if
you press the remote keyless entry transmitter unlock
button. If activated due to the transmitter, the lighting
will remain active for about 40 seconds. Since the
illuminated entry system uses the light sensor, it must be
dark outside in order for the courtesy lamps to turn on.
The courtesy lamps turn off approximately 25 seconds
after the last door is closed. They will dim to off if the
ignition key is placed in ON, or immediately deactivate
if the power locks are activated.
Parade Dimming
This feature prohibits dimming of the digital displays
and backlighting during daylight hours when the key is
in the ignition and the headlamps are on. This feature
operates with the light sensor for the Twilight Sentinel
and is fully automatic. When the light sensor reads
darkness outside and the parking lamps are active,
the digital displays can be adjusted by turning the
instrument panel brightness knob counterclockwise
to dim and clockwise to brighten lighting.
Reading Lamps
The front reading lamps are located in the overhead
console. These lamps and the interior courtesy lamps
come on when a door is opened and it is dark outside.
The rear reading lamps will not come on when a front
door is opened.
The rear courtesy lamps are located on the rear headliner
above the rear seat outboard positions. When a rear door
is opened, both the front and rear reading lamps come
on with the courtesy lamps.
Press the button near each lamp to turn it on and off.
If the reading lamps are left on, they automatically shut
off 10 minutes after the ignition has been turned off.
Battery Load Management
The battery load management feature is designed to
monitor the vehicle's electrical load and determine
when the battery is in a heavy discharge condition.
During times of high electrical loading, the engine
may idle at a higher revolutions per minute (rpm)
setting than normal to make sure the battery charges.
High electrical loads may occur when several of the
following are on: headlamps, high beams, fog lamps,
rear window defogger, the climate control fan at high
speeds, heated seats and engine cooling fans.

2-53
If the battery continues to discharge, even with the
engine idling at a higher rpm setting, some electrical
loads will automatically be reduced. When this occurs,
the rear window defogger may take slightly longer
to clear the glass, the heated seats may not get as
warm as they usually do and the fan may cut back to
a lower speed. For more battery saving information,
see ªBattery Message, Saver Activeº in the Index.
Inadvertent Power Battery Saver
This feature is designed to protect your vehicle's battery
against drainage from the interior lamps, trunk lamp,
glove box lamp, cigarette lighters or the garage door
opener. When the ignition is turned off, the power to
these features will automatically turn off after 10 minutes
(three minutes if a new car has 15 miles (24 km) or less).
Power will be restored for an additional 10 minutes if any
door is opened, the trunk is opened or the courtesy lamp
switch is turned on.
Mirrors
Electrochromic Day/Night Rearview Mirror
with Compass and OnStar
System
Your vehicle has an electrochromic inside rearview
mirror with a compass display. The mirror also contains
OnStar

controls. For more information see ªOnStarº
in the Index.
(On/Off): The on/off button is located on the
lower left side of the mirror for the electrochromic and
compass functions of the rearview mirror.

2-54
The mirror also includes an eight-point compass
display in the upper right corner of the mirror face.
When on, the compass automatically calibrates as the
vehicle is driven.
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror as that may cause
the liquid cleaner to enter the mirror housing.
Mirror Operation
To turn on the automatic dimming feature, press
and hold the on/off button for about three seconds.
To turn off automatic dimming, press and hold
the on/off button for about three seconds again.
The indicator light will illuminate when this feature is
active. The automatic dimming feature is active each
time the vehicle is started.Compass Operation
Press the on/off button once to turn the compass
on or off.
When the ignition and the compass feature are on,
the compass will show two character boxes for
approximately two seconds. After two seconds,
the mirror will display the compass heading.
Compass Calibration
If after two seconds, the display does not show a
compass heading (N for North, for example), there may
be a strong magnetic field interfering with the compass.
Such interference may be caused by a magnetic antenna
mount, magnetic note pad holder or a similar magnetic
item. If the letter C should ever appear in the compass
window, the compass may need calibration.
The mirror can be calibrated by driving the vehicle in
circles at 5 mph (8 km/h) or less until the display
reads a direction.
The compass can be placed in calibration mode by
pressing and holding the on/off button until a C is
shown in the compass display.

2-60
Accessory Power Outlets
Your vehicle is equipped with accessory power outlets.
The outlets can be used to plug in electrical equipment
such as a cellular telephone, CB radio, etc.
The accessory power outlets are located at the rear of the
center console and on the lower inboard carpeted panel
on the passenger's side of the vehicle.
Your vehicle may have a small cap that must be removed
to access the accessory power outlet. If it does, when
not using the outlet be sure to cover it with the
protective cap.
The accessory power outlet will only operate when the
ignition is in ACC or ON and for 10 minutes after
turning the ignition OFF. If you would like the accessory
power outlet to operate regardless of ignition position,
and for extended periods of time, see your dealer for
more information.NOTICE:
When using accessory power outlets:

Maximum load of any electrical equipment
should not exceed the maximum amperage
for the outlet.

Be sure to turn off any electrical equipment
when not in use. Leaving electrical
equipment on for extended periods can
drain the battery.
Certain accessory power plugs may not be compatible
to the accessory power outlet and could result in blown
vehicle or adapter fuses. If you experience a problem see
your dealer for additional information on the accessory
power plugs.

2-66
Sunroof (Option)
The two switches that operate the sunroof are located
on the overhead console and include VENT, ROOF,
open and close.
Press and hold the ROOF switch rearward to the
first position to open the glass panel and sunshade.
The sunshade also can be opened or closed manually.
To close the glass panel, press and hold the ROOF
switch forward. As the sunroof reaches the closed
position, it will open slightly toward the vent position
and then drop down to the closed position to provide
a better seal.Press and release the ROOF switch rearward to the
second position to express
-open the glass panel to
the comfort stop position, approximately half
-way
open. The comfort stop position is designed to help
reduce noise and make the rear seat passengers
more comfortable.
The glass panel may then be fully opened by pressing
the ROOF switch again.
If you press and hold the ROOF switch in the
express
-open position for more than one second,
the express
-open operation will be over-ridden and
the sunroof will stop when the switch is released.
To stop the glass panel when express opening,
press the the ROOF or VENT switch forward or
rearward and release.
To vent the glass panel, press and hold the VENT
switch in the open position. The sunshade must be
opened manually when using the vent position.
To close the glass panel, press and hold the VENT
switch in the close position.
The ROOF and VENT switches work only when the
ignition is on or when RAP is active. See ªRetained
Accessory Powerº in the Index.

2-71
The main components of the instrument panel are the following:
A. Air Outlets
B. Driver Information Center (DIC) Buttons
C. Turn Signal/Multifunction Lever
D. HVAC Steering Wheel Controls
(or Cellular Telephone Controls, If Equipped)
E. Instrument Panel Cluster
F. Windshield Wiper/Washer Lever
G. Audio Steering Wheel Controls
H. Ignition Switch
I. Air Vent Control Thumbwheel
J. Hazard Warning Flasher Button
K. Audio SystemL. Exterior Lamp Controls
M. Hood Release
N. Fuel Door Release
O. Trunk Release
P. Cruise Control
Q. Horn
R. Heated Seat Controls
S. Traction Control Switch
T. Console Shift Lever
U. Convenience Storage/Optional Ashtray
V. Climate Controls
W. Glove Box
