2002 CADILLAC SEVILLE stop start

2-79 Anti-Lock Brake System Warning Light
With the anti-lock brake
system, the light(s) will
come on when your
engine is started and may
stay on for several seconds.
That's normal.
If the light stays on, turn the ignition to OFF. Or, if the
light comes on when you're driving, stop as soon as
possible and turn the ignition off. Then start the engine
again to reset the system. If the light still stays on, or
comes on again while you're driving, your vehicle needs
service. If the regular brake system warning light isn't
on, you still have brakes, but you don't have anti
-lock
brakes. If the regular brake system warning light is
also on, you don't have anti
-lock brakes and there's a
problem with your regular brakes. See ªBrake System
Warning Lightº earlier in this section.
The anti
-lock brake system warning light should
come on briefly when you turn the ignition key to ON.
If the light doesn't come on then, have it fixed so it will
be ready to warn you if there is a problem.
Traction Control System Warning Light
United States Canada
This warning light should come on briefly when the
engine is started.
If the warning light doesn't come on then, have it fixed
so it will be ready to warn you if there's a problem.
If it stays on, or comes on when you're driving, there
may be a problem with your traction control system and
your vehicle may need service. When this warning light
is on, the system will not limit wheel spin. Adjust your
driving accordingly.

2-80
The traction control system warning light may come on
for the following reasons:

If there's a brake system problem that is specifically
related to traction control, the traction control system
will turn off and the warning light will come on.

If the traction control system is affected by an
engine
-related problem, the system will turn off
and the warning light will come on.
If the traction control system warning light comes on
and stays on for an extended period of time when the
system is turned on, your vehicle needs service.
Engine Coolant Temperature Warning Light
This light tells you that
your engine has overheated.
As a check, the light should
come on for a few seconds
when you start your engine.
If this light comes on and stays on, you should stop
your vehicle and turn the engine off as soon as possible.
A warning chime should also sound if this light comes on.
See ªEngine Overheatingº in the Index.

2-83
This light will also come on during a malfunction in one
of two ways:

Light Flashing
-- A misfire condition has been
detected. A misfire increases vehicle emissions and
may damage the emission control system on your
vehicle. Dealer or qualified service center diagnosis
and service may be required.

Light On Steady
-- An emission control system
malfunction has been detected on your vehicle.
Dealer or qualified service center diagnosis and
service may be required.
If the Light Is Flashing
The following may prevent more serious damage to
your vehicle:

Reducing vehicle speed.

Avoiding hard accelerations.

Avoiding steep uphill grades.

If you are towing a trailer, reduce the amount of
cargo being hauled as soon as it is possible.
If the light stops flashing and remains on steady,
see ªIf the Light Is On Steadyº following.If the light continues to flash, when it is safe to do so,
stop the vehicle. Find a safe place to park your vehicle.
Turn the key off, wait at least 10 seconds and restart the
engine. If the light remains on steady, see ªIf the Light
Is On Steadyº following. If the light is still flashing,
follow the previous steps, and drive the vehicle to your
dealer or qualified service center for service.
If the Light Is On Steady
You may be able to correct the emission system
malfunction by considering the following:
Did you recently put fuel into your vehicle?
If so, reinstall the fuel cap, making sure to fully
install the cap. See ªFilling Your Tankº in the Index.
The diagnostic system can determine if the fuel cap
has been left off or improperly installed. A loose or
missing fuel cap will allow fuel to evaporate into the
atmosphere. A few driving trips with the cap properly
installed should turn the light off.
Did you just drive through a deep puddle of water?
If so, your electrical system may be wet. The condition
will usually be corrected when the electrical system
dries out. A few driving trips should turn the light off.

2-89

AVG MPH (Average Miles per Hour): This
message shows the average speed you have traveled
at since the last time you reset the value. To reset the
value, press the INFO button to display AVG MPH
then press and hold the INFO RESET button until
0.0 AVG MPH is displayed.

TIMER: This feature is like a stopwatch, in that
you can clock the time it takes to get from one point
to another.
To operate, press the INFO button to display TIMER.
Each of the fields for the hours, minutes and seconds
are two numeric digits.
Once TIMER 00:00:00 is displayed, press the
ON/OFF button to start the timing feature. Press the
ON/OFF button again to stop it. If you will be starting
and stopping your vehicle, during a trip for instance,
the TIMER feature will automatically start timing
where it left off when you last stopped. To reset it,
press and hold the INFO RESET button until the
display reads TIMER 00:00:00. Press the INFO
button to exit from the TIMER display.
ENGINE OIL LIFE: Press the INFO button to
display ENGINE OIL LIFE, then press and hold the
INFO RESET button until 100% ENGINE OIL
LIFE is displayed. (This only needs to be reset after
you have had the oil changed.)

TRANSMISSION FLUID LIFE MONITOR:
Under normal conditions, the rate of deterioration
of the transmission fluid is slow. See ªMaintenance
Scheduleº in the Index for proper fluid and change
intervals. To reset the transmission fluid life, press
the INFO button to display TRANS FLUID LIFE,
then press and hold the INFO RESET button
until 100% TRANS FLUID LIFE is displayed.
(This only needs to be reset after you have had the
fluid changed.)
ON/OFF: Pressing this button turns the Programming
and Personalization Features on and off. (FEATURE
PROGRAMMING must be displayed on the DIC to
begin actual programming.) This button also starts and
stops the timer.

2-93
CHECK TIRE PRESSURE - 144: This message is
displayed when the Tire Pressure Monitor (TPM) system
detects a low or high tire pressure condition in one or
more of the road tires. By pressing the INFO button
up or down, the DIC display will show which tire or
tires do not have the correct inflation pressure.
A ªLOW TIREº condition exists when the tire's air
pressure is under 25 psi (172 kPa) and a ªHIGH TIREº
condition exists when the tire's air pressure is above
38 psi (262 kPa). The system will display the air
pressure, the tire location (LF, RF, RR or LR) and
if the air pressure is low or high. The tire pressure
information is available in English or metric
measurements. For example, a driver's side front tire
that is low may be shown as: 22 PSI LF TIRE LOW.
The correct tire inflation pressure should be set
to those shown on the Tire Loading
-Information
Label, located on the rear edge of the driver's door.
For more information regarding proper tire inflation,
see ªInflation
-- Tire Pressureº in the Index. If a tire
is low, you should stop as soon as possible and inspect
your tire(s) for damage. If a tire is flat, see ªIf a Tire
Goes Flatº in the Index.Once the TPM system detects the low or high tire
pressure condition, the message ªCHECK TIRE
PRESSUREº will be displayed whenever you start
the engine. To remove or clear the CHECK TIRE
PRESSURE message, you will need to set the tire(s) to
the proper tire pressure. See ªInflation
-- Tire Pressureº
in the Index.
CAUTION:
When the CHECK TIRE PRESSURE message is
displayed on the Driver Information Center and
the tire pressure is low, your vehicle handling
capabilities will be reduced during severe
maneuvers. If you drive too fast, you could lose
control of your vehicle. You or others could be
injured. Don't drive over 55 mph (90 km/h) when
the tire pressure is low. Drive cautiously and
correct the tire pressure as soon as you can.

2-96
SERVICE CHARGING SYS - 102: This message
will display when a problem with the charging system
has been detected. Have your vehicle serviced at
your dealership.
SERVICE ELECTRICAL SYS
- 106: This message
will display if an electrical problem has occurred within
the Powertrain Control Module (PCM) or the ignition
switch. Have your vehicle serviced by your dealership.
SERVICE FUEL SYSTEM
- 101: The Powertrain
Control Module (PCM) has detected a problem within
the fuel system when this message appears. Have your
vehicle serviced by your dealership.
SERVICE IDLE CONTROL
- 107: A problem
with the idle control has occurred when this message
displays. Have your vehicle serviced by your dealership.
SERVICE STABILITY SYS
- 54: If you ever see
the SERVICE STABILITY SYS message, it means
there may be a problem with your stability enhancement
system. If you see this message, try to reset the system
(stop, turn off the engine, then start the engine again).
If the SERVICE STABILITY SYS message still
comes on, it means there is a problem. You should see
your dealer for service. Reduce your speed and drive
accordingly. A single chime will also sound when this
message is displayed.SERVICE STEERING SYS
- 127: This message
is displayed when a problem has been detected in
the magnetic speed variable assist steering system.
If message comes on, service is required.
SERVICE SUSPENSION SYS
- 84: This message is
displayed to indicate that the suspension system is not
operating properly. To correct this problem, have your
vehicle serviced at your dealership.
SERVICE THEFT SYSTEM
- 34: This message
means there is a problem with the PASS
-Key
III
system. A fault has been detected in the system which
means that the system is disabled and is not protecting
the vehicle. The vehicle usually restarts, however, you
may want to take your vehicle to your dealer before
turning off the engine.
SERVICE TPM SYSTEM
- 51: When this message
is displayed, the Tire Pressure Monitor (TPM) system is
not working properly. See your dealer for service.
SERVICE TRANSMISSION
- 100: See your dealer
for repair.
SERVICE VEHICLE SOON
- 3: This message is
displayed when a non
-emissions related powertrain
malfunction occurs. Have your vehicle serviced by a
technician as soon as possible.

3-16
Playing a Compact Disc
Insert a disc partway into the slot, label side up. The
player will pull it in. If the ignition and the radio are on
and the underlined compact disc symbol appears on the
display, the disc will begin playing. Compact discs may
be loaded with the radio off but they will not start
playing until the radio is on. If you want to insert a disc
when the ignition is off, first press the eject button.
The integral CD player can play the smaller 8 cm
compact discs. Full
-size compact discs and the smaller
compact discs are loaded in the same manner.
If an error appears on the display, see ªCompact Disc
Messagesº later in this section.

RW (Rewind): Press and hold the left arrow to
reverse the compact disc. Release it to return to playing
speed.
FF
 (Fast Forward): Press and hold the right arrow
to fast forward to another part of the compact disc.
Release it to return to playing speed.
~' SEEK !': When this button is pressed, it has two
positions. This button works the same, whether it is
pressed to the first or second position. Press this button
to seek to the next or previous track on the compact disc.
SCAN: Press this button to listen to tracks for a few
seconds. The compact disc will go to a track, play for a
few seconds, then go on to the next track. Press this
button again to stop scanning.
RDM (Random): Press this button to hear the tracks in
random, rather than sequential, order. Press RDM again
to turn off random play.
(Eject): Press this button, located to the right of the
CD slot, to stop a CD when it is playing or to eject a CD
when it is not playing. Eject may be activated with the
radio off and/or the ignition off.

4-7
Avoid needless heavy braking. Some people drive in
spurts
-- heavy acceleration followed by heavy
braking
-- rather than keeping pace with traffic. This is
a mistake. Your brakes may not have time to cool
between hard stops. Your brakes will wear out much
faster if you do a lot of heavy braking. If you keep pace
with the traffic and allow realistic following distances,
you will eliminate a lot of unnecessary braking. That
means better braking and longer brake life.
If your engine ever stops while you're driving, brake
normally but don't pump your brakes. If you do, the
pedal may get harder to push down. If your engine
stops, you will still have some power brake assist. But
you will use it when you brake. Once the power assist is
used up, it may take longer to stop and the brake pedal
will be harder to push.
Anti-Lock Brake System (ABS)
Your vehicle has anti-lock brakes. ABS is an advanced
electronic braking system that will help prevent a
braking skid.
When you start your engine and begin to drive away,
your anti
-lock brake system will check itself. You may
hear a momentary motor or clicking noise while this test
is going on, and you may even notice that your brake
pedal moves a little. This is normal.
If there's a problem with the
anti
-lock brake system, this
warning light will stay on.
See ªAnti
-Lock Brake
System Warning Lightº in
the Index.
