2002 CADILLAC DEVILLE display

2-134
URPA can detect objects 3 inches (7.6 cm) and wider,
and at least 10 inches (25.4 cm) tall, but it cannot detect
objects that are above trunk level. In order for the rear
sensors to recognize an object, it must be within
operating range.
If the URPA system is not functioning properly, the
display will flash red, indicating that there is a problem.
The light will also flash red while driving if a trailer is
attached to your vehicle, or a bicycle or object is on
the back of, or hanging out of your trunk. The light
will continue to flash until the trailer or the object is
removed and your vehicle is driven forward at
least 15 mph (25 km/h).
It may also flash red if the ultrasonic sensors are not
kept clean. So be sure to keep your rear bumper free of
mud, dirt, snow, ice and slush or materials such as paint
or the system may not work properly. If after cleaning
the rear bumper and driving forward at least 15 mph
(25 km/h), the display continues to flash red, see your
dealer. For cleaning instructions, see ªCleaning, Outside
of Your Vehicleº in the Index.It may also flash red if your vehicle is moving in
REVERSE (R) at a speed greater than 3 mph (5 km/h).
Other conditions that may affect system performance
include things like the vibrations from a jackhammer or
the compression of air brakes on a very large truck.
As always, drivers should use care when backing up a
vehicle. Always look behind you, being sure to check
for other vehicles, obstructions and blind spots.

3-2
Comfort Controls
This section tells you how to make your air system work
for you.
Climate Control Panel
Your vehicle is equipped with an electronic climate
control system. This system can automatically adjust
and control temperature, fan speed, air delivery mode,
air conditioning operation and air intake. You can use
the AUTO (automatic) setting or override the automatic
operation by manually adjusting the controls. If your
vehicle is equipped with the climate control
personalization feature, you will be able to recall your
preferred climate control settings using your remote
keyless entry transmitter. See ªClimate Control
Personalizationº in the Index.Manual Operation
To turn the system on, press the knob located on the left
side of the climate control panel.
~MODE!: Press MODE to deliver air through the
floor, instrument panel or windshield outlets. The
system will stay in the selected mode until MODE is
pressed again. The current mode is displayed on the
climate control panel when MODE is pressed. Press the
up or down arrow to cycle through the following modes:


(Upper): This setting directs the airflow
through the instrument panel outlets.


(Bi-Level): This setting directs airflow into
your vehicle in two ways. Cooler air is directed to
the upper portion of your body through the four
instrument panel outlets while warmer air is directed
to the floor.


(Floor/Defrost): This setting directs airflow to
the floor outlets and toward the windshield.


(Floor): This setting directs airflow through
the floor outlets. Some air is diverted to the
windshield to minimize fogging.

3-3
!~(Fan): This switch adjusts the fan speed. Press the
up arrow to increase fan speed and the down arrow to
decrease it.
(Recirculation): Press this button to limit the
amount of outside air entering your vehicle. This is
helpful when you are trying to cool the air quickly or
limit odors entering your vehicle. Press this button again
to turn off the recirculation feature. If you notice the
windows fogging, turn off the recirculation feature.
Recirculation is not available in the defrost mode.
FRONT (Defrost): Press this button to quickly
remove fog or frost from the windshield. This setting
sends most of the airflow to the windshield with only a
small amount to the floor outlets. The air conditioning
compressor will operate in this mode.
A/C (Air Conditioning): Press this button to turn the
air conditioning compressor on and off. The system will
cool and dehumidify the air inside the vehicle. A/C
cannot be turned off in defrost mode.PASS OFF (Passenger's Climate Control): Pressing
this button will turn off or on the climate controls for the
passengers. When this feature is active, the driver's
climate control settings are used for both the front and
rear seating areas.
Driver's Temperature Knob: The knob located on the
left side of the climate control panel is used to adjust the
air temperature coming through the system for the
driver's side of the vehicle while the passenger's side
controls are active. Turn the knob clockwise to increase
the temperature displayed on the climate control panel,
or turn the knob counterclockwise to decrease the
temperature. Press the knob to turn the climate control
system off.
~PASS TEMP! (Passenger's Temperature): This
switch is used to increase or decrease the temperature of
the air for the right front passenger independent of the
driver's setting.
Press the up arrow to increase the temperature setting or
the down arrow to decrease it.

3-4
Automatic Operation
AUTO: This button is used to select the automatic
operation of the climate control system. When the
automatic operation is active, AUTO will appear on
the display.
A sensor will control the air delivery mode. Air will
come from the floor, the instrument panel or windshield
outlets. The fan speed and use of air conditioning
will vary as the system maintains the selected
temperature setting.
Do not cover the electronic solar sensor located on top
of the instrument panel near the windshield. The sensor
is used by the automatic system to regulate temperature.
See ªElectronic Solar Sensorº later in this section for
more information.
To find your comfort zone, start with the 75
F (24
C)
setting and allow about 30 minutes for the system to
regulate. Turn the driver's temperature knob to adjust
the temperature if necessary. If you choose 60
F
(16
C), the system will remain at that maximum cooling
setting and will not regulate fan speed. If you choose
90
F (32
C), the system will remain at that maximum
heating setting and will not regulate fan speed. Choosing
either maximum setting will not cause the system to heat
or cool any faster.In cold weather, when the system senses the need for
heat, the airflow will be directed out of the floor outlets.
As the interior temperature approaches the desired
setting, the fan speed will decrease. To maintain interior
comfort, the airflow may move to the instrument panel
air outlets and floor outlets (bi
-level mode). On bright
sunny days in cold weather, the airflow may come out of
the instrument panel outlets in A/C mode to maintain
comfort and prevent stuffiness.
When the automatic setting is active, the air
conditioning compressor cycles when needed to cool the
air. If your vehicle is sitting out on a hot day and AUTO
is active, the air will first flow out of the floor outlets for
a few seconds. This is normal. This is to remove hot air
from the air outlets. As the air is cooled, the airflow will
move through the instrument panel outlets. If you start
your vehicle with the fan setting on HI, it will skip the
air conditioning purge and the system will be in
manual mode.

3-8 Rear Climate Control
Your vehicle is equipped with a rear climate control.
With this system, the rear passengers can control the
temperature of the air flow for his/her own zones.The rear climate control has three switches:
~ MODE !: Press this switch to select the direction
of the airflow. Press the up or down arrow to cycle
through the available modes. The current mode appears
on the display above the climate control panel. If you
press the down arrow until AUTO is displayed,
automatic mode will be active. The automatic mode
selects the airflow mode for you.
See ªManual Operationº previously in this section for
more information on the modes available.
!
~
(Fan): Press this switch to manually adjust the fan
speed. Press the up arrow to increase the speed or the
down arrow to decrease it. The current speed will appear
on the display above the climate control panel. You can
turn the system off by pressing the down arrow until
OFF appears on the display.

3-9
~ TEMP ! (Temperature): Press this switch to
manually adjust the temperature. Press the up arrow to
increase the temperature or the down arrow to decrease
it. The current temperature will appear on the display
above the climate control panel.
The front seat climate control panel has an AUTO
button that can override the climate controls of the rear
seating area automatically. When AUTO is pressed, the
rear automatic mode is selected and the rear air
temperature and mode will readjust to coincide with the
setting selected for the front seating area.
The PASS OFF button on the front climate control panel
allows the settings for the driver to be used for the front
and rear seat areas.Ventilation System
Your vehicle's flow-through ventilation system supplies
outside air into the vehicle when it is moving. Outside
air will also enter the vehicle when the heater or the air
conditioning fan is in operation. See ªRecirculationº
listed previously in this section for more information.
The front outlets are located in the center and at each
side of the instrument panel. You can adjust the
direction of airflow by moving the center control levers
or you can stop the airflow by moving the thumbwheel
located on each outlet downward.

3-12
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all of its controls to be sure you're getting the
most out of the advanced engineering that went into it.
Your vehicle has a feature called Retained Accessory
Power (RAP). With RAP, you can play your audio
system even after the ignition is turned off. See
ªRetained Accessory Powerº in the Index.
Setting the Clock
Press and hold HR or MN until the time display begins
to change. Release the button as you get close to the
correct time. The time may be set anytime the clock is
displayed. There is a two
-second delay before the clock
goes into time
-set mode.
AM-FM Stereo with Cassette Tape and
Compact Disc Player
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn this knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.
HR (Hour) or MN (Minute): Display the time with the
ignition off by pressing one of these buttons.

3-13
SOURCE: Press this button to select a source, either
cassette or compact disc. The audio source must be
loaded to play. Available loaded sources are shown on
the display. If a source is being used, it will be
underlined on the display. If none of the audio sources
are loaded, NO SOURCE LOADED will appear on the
display. Press this button again or press BAND to switch
back to the radio.
Finding a Station
BAND: Press this button to select AM, FM1 or FM2.
~' TUNE SEEK !': When this button is pressed it
has two positions. Press this button to the first position
to manually tune to the next or previous stations. If this
button is held at the first position for a few seconds, the
radio will continue tuning until this button is released.
Press this button to the second position and release it to
seek to the next or previous radio station.
SCAN: Press this button for less than two seconds
to scan radio stations and associated tone settings.
The radio will go to a station, play for five seconds,
then go on to the next station. Press this button again
to stop scanning.To scan preset stations, press and hold SCAN for more
than two seconds until you hear a beep. The radio will
go to the first preset station stored on your pushbuttons,
play for five seconds, then go on to the next preset
station. Press SCAN again to stop scanning. The radio
will scan preset stations with a strong signal only.
Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2), by performing the
following steps:
1. Turn the radio on.
2. Press BAND to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press and hold one of the six numbered pushbuttons
for more than two seconds until you hear a beep.
5. Repeat the steps for each pushbutton. Whenever
you press that numbered pushbutton for less than
two seconds, the station you set will return.
When battery power is removed and later applied, you
will not have to reset your radio presets because the
radio remembers them.
