2002 BUICK CENTURY remote start

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-10 Remote Keyless Entry
2
-17 Trunk
2
-22 Theft
2
-23 PASS-Key
II
2
-24 New Vehicle ªBreak-Inº
2
-24 Ignition Positions
2
-26 Starting Your Engine
2
-27 Engine Coolant Heater (If Equipped)
2
-28 Automatic Transaxle Operation
2
-32 Parking Brake
2
-33 Shifting Into PARK (P)
2
-35 Shifting Out of PARK (P)
2
-35 Parking Over Things That Burn
2
-36 Engine Exhaust2
-36 Running Your Engine While You're Parked
2
-37 Horn
2
-37 Tilt Wheel
2
-38 Turn Signal/Multifunction Lever
2
-43 Exterior Lamps
2
-46 Interior Lamps
2
-48 Mirrors
2
-52 Storage Compartments
2
-54 Sun Visors
2
-54 Auxiliary Power Outlet (If Equipped)
2
-56 Auxiliary Power Connection (Power Drop)
2
-57 OnStar
System (If Equipped)
2
-61 Sunroof (Option)
2
-62 The Instrument Panel -- Your
Information System
2
-64 Instrument Panel Cluster
2
-66 Warning Lights, Gages and Indicators

2-12
Programmable Modes
Your vehicle can be programmed to one of the
following modes.
Mode 1: No Verification
Mode 2: Horn Chirp only
Mode 3: Headlamp Flash only
Mode 4: Horn Chirp and Headlamp Flash
Before your vehicle was shipped from the factory, it
was programmed to Mode 3. The mode to which your
vehicle was programmed may have been changed since
it left the factory. To determine the security feedback
lock mode to which your vehicle is programmed or
to program your vehicle to a different mode, do
the following:
1. Close all doors and turn the ignition key to RUN.
2. Press and hold the power door lock switch in the
lock position.3. While holding the door lock switch in the lock
position, press and release the remote keyless
entry transmitter LOCK button. This will start the
customization mode. While in the customization
mode, the feature will sound the number of chimes
corresponding to the current lock mode. (If you do
not wish to change the current mode, you can either
exit the programming mode by following the
instructions listed here or program the next feature
available on your vehicle.)
4. Each additional press of the remote keyless entry
transmitter LOCK button will cause your vehicle to
advance the lock mode by one, starting from the
current lock mode.
5. If cycled beyond lock Mode 4, the vehicle will enter
Mode 1. When the door lock switch is released, the
vehicle will remain in the most recent lock mode.

2-13
Before your vehicle was shipped from the factory,
it was programmed to Mode 3. The mode to which
your vehicle was programmed may have been changed
since it left the factory. To determine the security
feedback unlock mode to which your vehicle is
programmed or to program your vehicle to a
different mode, do the following:
1. Close all doors and turn the ignition key to RUN.
2. Press and hold the power door lock switch in the
unlock position. While holding the door lock switch
in the unlock position, press and release the remote
keyless entry transmitter UNLOCK button. This will
start the customization mode. While in the
customization mode, the feature will sound the
number of chimes corresponding to the current
unlock mode. (If you do not wish to change the
current mode, you can either exit the programming
mode by following the instructions listed here or
program the next feature available on your vehicle.)3. Each additional press of the remote keyless entry
transmitter UNLOCK button will cause your vehicle
to advance the unlock mode by one, starting from the
current unlock mode.
4. If cycled beyond Mode 4, the vehicle will enter
Mode 1. When the door lock switch is released, the
vehicle will remain in the most recent unlock mode.
The mode you selected is now set. You can either exit
the programming mode by following the previous
instructions or program the next feature available on
your vehicle.
Disconnecting the vehicle's battery for up to a year will
not change the programmed mode for the lock and
unlock security feedback features.

2-46
Interior Lamps
Instrument Panel Brightness Control
This feature control the brightness of the instrument
panel lights.
You can brighten or dim the instrument panel lights by
adjusting the exterior lamps control located to the right
of the exterior lamps control.
If you turn to control clockwise the interior lamps will
come on and become brighter as the control is turned
further to MAX. Turning the control all the way
clockwise turns on the courtesy lamps. If you turn the
control counterclockwise the lamps will begin to dim
and continue to get dimmer as the control is turned
closer toward LIGHTS MIN. If the control is turned
all the way counterclockwise, the lamps and lights will
turn off.
Courtesy Lamps
When any door is opened, several lamps come on. These
lamps are courtesy lamps. They make it easy for you to
enter and leave your vehicle. You can also turn these
lamps on by turning the exterior lamps control all the
way clockwise to MAX.
Illuminated Entry
Your courtesy lamps will come on and stay on for a set
time whenever you press UNLOCK on the remote
keyless entry transmitter.
If you open a door, the lamps will stay on while it's open
and then turn off automatically about 25 seconds after
you close it. If you press UNLOCK and don't open a
door, the lamps will turn off after about 40 seconds.
Illuminated entry includes a feature called theater
dimming. With theater dimming, the lamps don't just
turn off at the end of the delay time. Instead, they slowly
dim after the delay time until they go out. The delay
time is canceled if you turn the ignition key to RUN or
START, so the lamps will dim right away.
When the ignition is on, illuminated entry is inactive,
which means the courtesy lamps won't come on unless a
door is opened.
Delayed Entry Lighting
Delayed entry lighting lights your vehicle's interior for a
period of time after all the doors have been closed.

5-4
2. Get the vehicles close enough so the jumper cables
can reach, but be sure the vehicles aren't touching
each other. If they are, it could cause a ground
connection you don't want. You wouldn't be able
to start your vehicle, and the bad grounding could
damage the electrical systems.
To avoid the possibility of the vehicles rolling, set the
parking brake firmly on both vehicles involved in the
jump start procedure. Put an automatic transaxle in
PARK (P) before setting the parking brake.
NOTICE:
If you leave your radio on, it could be badly
damaged. The repairs wouldn't be covered by
your warranty.
3. Turn off the ignition on both vehicles. Unplug
unnecessary accessories plugged into the cigarette
lighter or in the auxiliary power outlet. Turn off the
radio and all lamps that aren't needed. This will
avoid sparks and help save both batteries. And it
could save your radio!
4. Open the hoods and locate the batteries. Find the
positive (+) and negative (
-) terminal location on
each vehicle. You will not need to access your
battery for jump starting. Your vehicle has a remote
positive (+) jump starting terminal for that purpose.
The terminal is located on the same side of the
engine compartment as your battery. See ªEngine
Compartment Overviewº in the Index for more
information on location.

5-5
To uncover the remote positive (+) terminal,
squeeze the sides of the red plastic cap and pull the
cap upward. You should always use the remote
positive (+) terminal instead of the positive (+)
terminal on your battery.
CAUTION:
An electric fan can start up even when the engine
is not running and can injure you. Keep hands,
clothing and tools away from any underhood
electric fan.
CAUTION:
Using a match near a battery can cause battery
gas to explode. People have been hurt doing this,
and some have been blinded. Use a flashlight if
you need more light.
Be sure the battery has enough water. You don't
need to add water to the ACDelco
battery
installed in every new GM vehicle. But if a
battery has filler caps, be sure the right amount
of fluid is there. If it is low, add water to take
care of that first. If you don't, explosive gas
could be present.
Battery fluid contains acid that can burn you.
Don't get it on you. If you accidentally get it in
your eyes or on your skin, flush the place with
water and get medical help immediately.

5-8
10. Now start the vehicle with the good battery and
run the engine for a while.
11. Try to start the vehicle that had the dead battery.
If it won't start after a few tries, it probably
needs service.
NOTICE:
Damage to your vehicle may result from
electrical shorting if jumper cables are removed
incorrectly. To prevent electrical shorting, take
care that the cables don't touch each other or any
other metal. The repairs wouldn't be covered by
your warranty.
Jumper Cable Removal
A. Heavy, Unpainted Metal Engine Part or Remote
Negative (
-) Terminal
B. Good Battery or Remote Positive (+) and Remote
Negative (
-) Terminals
C. Dead Battery or Remote Positive (+) Terminal

6-62
Fuse Usage
PARK LOCK Ignition Key Solenoid
Blank Not Used
Blank Not Used
PCM, BCM,
U/H RELAYIgnition Signal: Hot in Run and
Start, Powertrain Control
Module, Body Control Module,
Underhood Relay
RADIO
PREM. SOUNDRemote Radio Premium Sound
POWER MIRRORS Power Mirrors
Blank Not Used
PANEL DIMMING Panel Dimming
Blank Not Used
IGN 0, CLUSTER,
PCM, BCMIgnition Signal: Hot in Run,
Unlock and Start, Cluster,
Powertrain Control Module,
Body Control ModuleFuse Usage
Blank Not Used
Blank Not Used
Blank Not Used
INADV
POWER BUSRetained Accessory Power
DOOR LOCKS Door Locks
TRAP ALERT Trap Alert

TAIL LAMPS,
LIC LAMPSTaillamps, License Lamps
RADIO Radio
HEATED MIRROR Heated Mirrors
CRUISE Cruise Control
Blank Not Used
CLUSTER Instrument Panel Cluster
CIGAR LTR Cigarette Lighter,
Auxiliary Power Connection
(Power Drop)
