Page 4 of 159

BMW 330Ci CONVERTIBLE 2002 E46 Owners Manual
Contents

© 2001 Bayerische Motoren Werke
Aktiengesellschaft
Munich, Germany
Reprinting, including excerpts, only with the
written consent of BMW AG, Munich.
Order No. 01 41 0 156 190
US English

Page 48 of 159

BMW 330Ci CONVERTIBLE 2002 E46 Owners Manual 48n
Correct sitting posture SeatsFor relaxed and fatigue-free driving you
should select a sitting position that
reflects your personal requirements.
Correct posture combines with safety
belts and

48n
Correct sitting posture SeatsFor relaxed and fatigue-free driving you
should select a sitting position that
reflects your personal requirements.
Correct posture combines with safety
belts and airbags to enhance occupant
safety in the event of an accident. To
ensure that the vehicle's safety systems
provide you with optimal protection, we
request that you direct your careful
attention to the following section.
For supplementary information on
transporting children refer to page 59. Sitting correctly with airbags
Always maintain an adequate
distance between yourself and the
airbags. Always hold the steering wheel
by the rim to keep any chance of injury
to hands or arms to an absolute
minimum should the airbag be
deployed. Never allow any objects,
individuals or animals to obstruct the
areas between passengers and airbags.
Never use the front airbag's cover as a
storage tray or support for objects of
any kind. Never allow front passengers
to rest their feet or legs on the airbag
cover.<
For airbag locations and additional
information on airbags refer to page 56.
Safe with safety belts
Never allow more than one person
to wear a single safety belt. Never
allow infants or small children to ride in
a passenger's lap. Avoid twisting the
belt while routing it firmly across the
hips and shoulder, wear it as snugly
against your body as possible. Do not
allow the belt to rest against hard or
fragile objects. Do not route the belt
across your neck, or run it across sharp
edges. Be sure that the belt does not
become caught or jammed. Avoid
wearing bulky clothing and pull on the
lap belt periodically to retension it over
your shoulders. In the event of a frontal
impact, a loose lap belt could slide over
your hips, leading to abdominal injury.
In addition, the safety belt's restraint
effectiveness is reduced if it is worn
loosely. Expectant mothers should
always wear their safety belts, taking
care to position the lap belt against the
lower hips, where it will not exert pres-
sure against the abdominal area.<
For information on using the safety
belts refer to page 52.
When adjusting your seat, always
observe the following precautions
Never try to adjust your seat while
operating the vehicle. The seat
could respond with unexpected move-
ment, and the ensuing loss of vehicle
control could lead to an accident. Never
ride with the backrest reclined to an
extreme horizontal angle (important for
front passengers to remember). Keep
the backrest relatively upright to mini-
mize the risk of sliding under the safety
belt and sustaining injury in an acci-
dent.<
Seat adjustment>Power seat, refer to page 49
>Head restraint, refer to page 50
>Entering the rear, refer to page 51

Page 110 of 159

BMW 330Ci CONVERTIBLE 2002 E46 Owners Manual 110n
Brake system Hardtop
*
Disc brakesLimited vehicle use, extended periods
with the vehicle parked or in storage,
and operating conditions in which
braking is restricted to gentle, low-
pressure

110n
Brake system Hardtop
*
Disc brakesLimited vehicle use, extended periods
with the vehicle parked or in storage,
and operating conditions in which
braking is restricted to gentle, low-
pressure applications will all increase
the tendency for corrosion to form on
the rotors; this is often accompanied by
a simultaneous accumulation of
contamination on the brake pads. The
pads must exert a certain minimal level
of pressure against the rotors for the
disc brakes' inherent self-cleaning
effect to remain effective.
If the brake rotors are corroded, they
will tend to respond to braking with a
pulsating effect that even extended
brake applications will fail to cure.
When driving in heavy rain and on wet
roads it is useful to apply light pressure
to the brake pedal every few miles.
Monitor traffic conditions to ensure that
this maneuver does not pose a hazard
to you or to other road users. The heat
generated in this process helps dry the
pads and rotors to ensure that your
brake system will respond with undi-
minished efficiency when you need it.
When descending steep hills and
extended grades, downshift to a gear
that will allow you to continue safely with only a minimal amount of braking.
By minimizing the loads placed on the
brake system, this strategy helps
ensure that optimal brake system
response will remain available at all
times. Use care to avoid exceeding the
approved engine-speed range, refer to
page 74.
Do not coast with the clutch
depressed or with the transmission
or selector lever in neutral. Do not coast
with the engine shut off. The engine
provides no braking effect when the
clutch is depressed and there is no
power-assist for braking or steering
when the engine is not running.
Never allow floor mats, carpets or any
other objects to protrude into the area
around the accelerator, clutch and brake
pedals and obstruct their movement.<
Brake pads
For your own safety: use only
brake pads that the manufacturer
has released for your particular vehicle
model. The manufacturer cannot eval-
uate non-approved brake pads to
determine if they are suited for use, and
therefore cannot ensure the operating
safety of the vehicle if they are
installed.<
It is not necessary to remove the fabric
top even in the winter, when the
hardtop is generally in constant use.
But you can also remove it at any time
with no problem. Before the fabric top
is stored in the convertible top
compartment, it must be absolutely dry
in order to avoid water spots and
mildew from forming.
The hardtop offers reading lamps and
clothes hooks that can be used just by
pressing. In addition, a roof-rack can be
mounted, for more information, please
contact your BMW center.
When suspending articles of
clothing from the hooks, be sure
that they will not obstruct the driver's
vision. Do not hang heavy objects on
the hooks. If you do so, they could
cause personal injury during braking or
evasive maneuvers.<
Two people are required for installation
or removal. Work with extreme caution
in order to avoid paint damage and
damage to the body or hardtop.
To facilitate hardtop installation or
removal, you can obtain a specially
designed hardtop lift
* or hardtop rack
*
at your BMW center.

Page 121 of 159

BMW 330Ci CONVERTIBLE 2002 E46 Owners Manual 121n
OverviewControlsMaintenanceRepairsDataIndex
Engine oilChecking oil level1. Park the vehicle on a level surface
2. Switch the engine off after it has
reached normal operating tempera-
ture
3. Aft

Page 150 of 159

BMW 330Ci CONVERTIBLE 2002 E46 Owners Manual Everything from A to ZA
ABS (Antilock Brake
System)19, 109
Access to the rear51
Accessories10
Activated-charcoal filter96
Adaptive Transmission
Control (ATC)68
ADB (Automatic Differential
Bra

Page 154 of 159

BMW 330Ci CONVERTIBLE 2002 E46 Owners Manual Everything from A to ZManual transmission66
Manually controlled recircu-
lated-air95
Master keys28
MFL (Multifunction steering
wheel)22
Microfilter92, 96
Mirror defrosting55
Mirror memory53
Mi

Everything from A to ZManual transmission66
Manually controlled recircu-
lated-air95
Master keys28
MFL (Multifunction steering
wheel)22
Microfilter92, 96
Mirror defrosting55
Mirror memory53
Mirrors55
Mobile phone, refer to
cellular phone100
Modifications,
technical10, 126
Motion sensor, refer to
interior motion sensor36
Mounting the roof rack110
Multifunction steering wheel
(MFL)22 O
OBD interface socket127
Odometer74
Oil
additives121
capacity147
consumption121
quality122
specifications122
viscosity122 Oil change intervals, refer to
the Service and Warranty
Information Booklet (US
models) or the Warranty
and Service Guide Booklet
(Canadian models)
Oil dipstick121
Oil filter change147
OIL SERVICE75
Onboard computer76
refer also to the "Owner's
Manual for Onboard
Computer"
Onboard tool kit130
Opening and closing
from the inside32
via the door lock31
via the remote control29
Original hand-held
transmitter97
Outside temperature
display77
P
Paint care, refer to the
"Caring for your vehicle"
manual
Park assistant79
Park Distance Control
(PDC)79 Parking aid79
Parking brake66
Parking lamps
bulb replacement131
PDC (Park Distance
Control)79
Phone, refer to cellular
phone100
Pocket light96
Power windows38
Q
Quality Grades, tires114 R
Radiator147
Rain sensor70
RDC (Tire Pressure
Monitor)83
Reading lamps
front89
rear89
Rear fog lamps
bulb replacement133
Rear lamps133
Rear reading lamps89
Rear window
defroster91, 95 Rearview mirror55
Recirculated-air mode91
Refueling22
Remote control29
Remove window
condensation92, 94
Replace windshield wiper
blades130
Replacement keys28
Replacing lamps and
bulbs130
Reporting safety defects11
Reverse66
Rollover protection
system61
Roof weight146
Roof-mounted luggage
rack105
S
Safe with safety belts48
Safety belts48, 52
seat-integrated51
Safety defects, reporting11
Safety tires115, 138
Seat heating54
Seat memory53
Seat-integrated safety belt
system (SGS)51
