2002 BMW 330Ci CONVERTIBLE engine

Contents

© 2001 Bayerische Motoren Werke
Aktiengesellschaft
Munich, Germany
Reprinting, including excerpts, only with the
written consent of BMW AG, Munich.
Order No. 01 41 0 156 190
US English VIII/01
Printed in Germany
Printed on environmentally friendly paper
(bleached without chlorine, suitable for recycling).
Overview
Controls and features

Cockpit14
Instrument cluster15
Indicator and warning lamps17
Multifunction steering wheel
(MFL)21
Hazard warning triangle22
Refueling22
Fuel specifications23
Tire inflation pressures24

Opening and closing:

Keys28
Central locking system28
Opening and closing
Ð via the remote control29
Ð via the door lock31
Ð from the inside32
Luggage compartment lid33
Luggage compartment35
Alarm system36
Electric power windows38
Manual convertible top39
Fully-automatic convertible
top42
Wind deflector46

Adjustments:

Correct sitting posture48
Seats48
Adjusting electric power
seats49
Lumbar support50
Head restraints50
Entering the rear51
Safety belts52
Seat and mirror memory53
Seat heating54
Steering wheel54
Mirrors55

Passenger safety systems:

Airbags56
Transporting children safely59Rollover protection system61
Vehicle Memory, Key
Memory63

Driving:

Ignition lock64
Starting the engine64
Switching off the engine65
Parking brake66
Manual transmission66
Automatic transmission with
Steptronic67
Indicator/Headlamp flasher69
Washer/Wiper system/
Rain sensor70
Cruise control72

Everything under control:

Odometer74
Tachometer74
Energy control74
Fuel gauge75
Temperature gauge75
Service Interval Display75
Check Control76
Computer76

Technology for safety and
driving convenience:

Park Distance Control (PDC)79
Automatic Stability Control plus
Traction (ASC+T)80

Contents

5n

OverviewControlsMaintenanceRepairsDataIndex

Controls and features
Operation, maintenance

Dynamic Stability Control
(DSC)81
Tire Pressure Monitor (RDC)83
Flat Tire Monitor85

Lamps:

Parking lamps/Low beams87
Instrument lighting88
High beams/Standing lamps88
Fog lamps88
Interior lamps89

Controlling the climate for
pleasant driving:

Air conditioning90
Automatic climate control93

Interior conveniences:

Glove compartment96
BMW Universal Transmitter97
Storage compartments99
Cellular phone100
Ashtray, front100
Ashtray, rear101

Loading and transporting:

Ski bag102
Cargo loading103
Roof-mounted luggage rack for
the hardtop105

Special operating instructions:

Break-in procedures108
Driving notes109
Antilock Brake System
(ABS)109
Brake system109
Hardtop110

Wheels and tires:

Tire inflation pressure113
Tire condition113
Tire replacement114
Wheel and tire
combinations116
Winter tires116

In the engine compartment:

Hood118
Engine compartment
essentials119
Washer fluids120
Engine oil121
Coolant123
Brake fluid124

Maintenance:

The BMW Maintenance
System125

Laws and regulations:

Technical modifications126
California Proposition
65 Warning126
OBD interface socket127

Contents

Owner service procedures
Technical data
Index

Replacement procedures:

Onboard tool kit130
Windshield wiper blades130
Lamps and bulbs130
Changing a wheel135
Battery139
Fuses139

Assistance, giving and
receiving:

Jump-starting140
Towing the vehicle141Engine data144
Dimensions145
Weights146
Capacities147Everything from A to Z150

15n

OverviewControlsMaintenanceRepairsDataIndex

1 Fuel gauge75
2 Indicator lamps for turn signals203 Speedometer
4 Indicator and warning
lamps17 to 205 Tachometer and Energy control74
6 Engine coolant temperature
gauge75

Instrument cluster

17n

OverviewControlsMaintenanceRepairsDataIndex

Indicator and warning lamps

Technology that monitors itself

The system runs an operational check
on the indicator and warning lamps
identified with the

l

symbol each time
you switch on the ignition. They each
light up once for different periods of
time.
If a fault should occur in one of these
systems, the corresponding lamp does
not go out after the engine is started, or
it lights up while the vehicle is moving.
You will see how to react in the
following section.

Red: stop immediately

Battery charge current



l

The battery is no longer being
charged. Indicates a defective
alternator drive belt or a problem with
the alternator's charge circuit. Please
contact the nearest BMW center.
If the drive belt is defective, stop
and switch off the engine immedi-
ately to prevent overheating and
serious engine damage. If the drive belt
is defective, increased steering effort is
also required.

<

Engine oil pressure


l

Stop the vehicle immediately
and switch off the engine.
Check the engine oil level; top off as
required. If the oil level is correct:
please contact the nearest BMW
center.
Do not continue driving, as the
engine could sustain serious
damage from inadequate lubrication.

<

Brake warning lamp

l

If the lamp comes on when the
parking brake is not engaged:
check the brake fluid level. Before
driving further, be sure to comply with
the instructions on pages 109 and 124
Brake warning lamp for Cana-
dian models.
Tire Pressure Monitor (RDC)/
Flat Tire Monitor

l

In addition, an acoustic signal is
sounded: a tire failure has occurred.
Reduce vehicle speed immediately and
stop the vehicle. Avoid hard brake
applications. As you steer the vehicle,
use caution to avoid overcorrecting.
For additional information refer to
pages 83, 85

19n

OverviewControlsMaintenanceRepairsDataIndex

Indicator and warning lamps

Yellow: check as soon as possible

Antilock Brake System (ABS)

l

ABS has been deactivated in
response to system malfunction.
Conventional braking performance
remains available with no loss of effi-
ciency. Please have the system
inspected at your BMW center.
For additional information refer to
page 109
ABS warning lamp for Canadian
models.
Engine oil level
Comes on during driving: the
engine oil level has fallen to the
absolute minimum; refill as soon as
possible. Do not drive more than
approx. 30 miles (50 km) until you do.
For additional information refer to
page 121
Engine oil level
Comes on after the engine has
been switched off: add engine
oil at the earliest opportunity (next time
you stop to refuel).
For additional information refer to
page 121

Brake pads

l

Have the brake pads checked.
For additional information refer
to page 109
Tire Pressure Monitor (RDC)/
Flat Tire Monitor

l

Check tire inflation pressures,
refer to pages 24, 83, 85
Automatic Stability Control plus
Traction (ASC+T)/Dynamic
Stability Control (DSC)


l

Indicator lamp flashes:
The system is actively regulating drive
torque and braking force.
The indicator lamp stays lit:
ASC+T has been switched off with the
button or it is defective, or the DSC has
been switched off, ADB is operational.
Please contact a BMW center in case of
a malfunction.
Additional information beginning on
page 80

Automatic Stability Control plus
Traction (ASC+T)/Dynamic
Stability Control (DSC) indicator
lamp and brake warning lamp

l

The indicator lamps remain on:
the DSC


and ADB/DBC have
been switched off with the button or are
defective.
Please consult the nearest BMW
center.
For additional information refer to
page 81
DSC and ADB indicator and
warning lamps for Canadian
models.
Dynamic Brake Control (DBC)

l

Malfunction in DBC system.
Conventional braking efficiency
is available and unrestricted.
Have the system repaired by your BMW
center.
For additional information refer to
page 82

20n

Indicator and warning lamps

Add washer fluid
The washer fluid is too low. Top
off the fluid at the earliest
opportunity. For additional information
refer to page 120
SERVICE ENGINE SOON

l

If the indicator lamp comes on
either continuously or intermit-
tently, this indicates a fault in the emis-
sions-related electronic systems.
Although the vehicle remains opera-
tional, you should have the systems
checked at your BMW center at the
earliest possible opportunity. For addi-
tional information refer to page 127
SERVICE ENGINE SOON
warning lamp for Canadian
models.
Engine electronics

l

There is a fault in the electronic
engine-management system.
You can continue to drive with reduced
engine output or engine speed. Please
have the system inspected at your
BMW center.
Add coolant
The coolant level is too low. Add
coolant at the earliest opportu-
nity. For additional information refer to
page 123

Green: for your information

Turn signal indicator
Flashes when the turn signal is
operated.
Rapid flashing indicates a system
malfunction.
For additional information refer to
page 69
Cruise control
Lights up when the cruise
control is activated: available for
operation via the multifunction steering
wheel.
For additional information refer to
page 72
Fog lamps
Lights up whenever you switch
on the fog lamps.
For additional information refer to
page 88

Blue: for your information

High beams
Comes on when the high beams
are on or the headlamp flasher
is actuated.
For additional information refer to
pages 69, 88

22n

Hazard warning triangle

*
Refueling

The hazard warning triangle is stored in
the luggage compartment lid inside the
container for the onboard tools.
To open the container, loosen the wing
nut.
Always observe all legal regula-
tions requiring a warning triangle
to be carried in the vehicle.

<

Fuel filler door

Always switch off the engine
before refueling, as it is not
possible to add fuel with the engine
running, and attempts may also trigger
the SERVICE ENGINE SOON lamp.

<

Press on the rear edge of the fuel filler
door to open and close it.
If an electrical malfunction occurs, you
can unlock the fuel filler door manually:
1. Unlock the trim panel on the right
side of the luggage compartment
2. Pull the button with the fuel pump
symbol.

Always observe all safety precau-
tions posted at the service station
when handling fuel.
Never carry spare fuel containers in
your vehicle. Whether empty or full,
these containers can leak, cause an
explosion, or lead to fire in the event of
a collision.

<
