2002 BMW 3 SERIES Business CD Radio Manual

8n

9n

OverviewSettingsReceptionPlayingIndex

Overview
Settings
Reception
Playing
Index

Switching the unit on/off10
Adjusting the volume10
Setting the sound quality11
Displaying time13
Key Memory13

Settings

10n

Switching the unit on/off Adjusting the volume

Press the knob.
The unit will select the audio source
that was last used (radio, CD changer
or CD).

Listening to the radio with the
ignition switched off

The radio and its functions can still be
accessed for up to 20 minutes after the
ignition has been switched off (with the
ignition key in position 0 or removed).
When the ignition is switched off, the
unit switches off as well.
To switch the unit back on
Press the knob.
Operation via the multifunction
steering wheel

*
is not possible
with the ignition switched off.
To save on the battery, you should
always switch the radio off when
leaving the vehicle.

<

Setting volume

Turn the knob.
As soon as you begin talking on
the phone or accept a call, the
radio switches to mute.

<

Setting the speed-dependent
volume

To compensate for increasing noise in
the passenger compartment with
increased vehicle speed, your unit is
equipped with a speed-dependent
volume control (Speed Volume). This
function will increase volume as speed
likewise increases.
You can set the volume increase in
6 levels. The higher the level you
choose, the greater the increase in
volume.

11n

OverviewSettingsReceptionPlayingIndex

Adjusting the volume

Setting the sound quality

1. Call up the current setting
Press and hold the key.
The display changes to the operating
display for SPEED VOL, e.g.:
2. Select the level
Press or keep pressed down.
The selected level will be indicated in
the display
3. Leave the mode display

Reset the setting

The speed-dependent volume can be
reset to the midrange setting.
1. Call up the current setting
Press and hold the key.
The display changes to the operating
display for SPEED VOL
2.
"RESET?" is shown in the display
3. Reset the setting
The speed-dependent volume will be
re-set to level 3.

Sound and tone playback

You can choose from the following
sound settings:

>
Bass:
Amplify or reduce bass tones
> Treble:
Amplify or reduce higher tones >
Front/back volume distribution
(Fader):
Front or rear, louder/softer
>

Right/left volume distribution
(Balance):
Left or right, louder/softer

>

Midrange setting (Tone Linear):
Reset the sound settings to the mid
range.
The sound setting for bass and
treble is source-dependent, i.e.
can be adjusted separately for the
radio, CD changer and CD. Changing
the audio source will call up the last
sound setting used for this particular
audio source.
The sound setting for the front/back
and left/right volume distribution
applies to all audio sources.

<

12n

Setting the sound quality

Changing the sound setting

1. Call up the sound setting
The display changes to the operating
display for BASS, e.g.:
2. Select a different sound setting
(Treble, Fader or Balance) if neces-
sary
Press repeatedly until the desired
operating display is reached.
3. Change the desired sound setting
Press or hold down until the desired
setting comes up.

Resetting the sound setting

By confirming "TONE LIN" you reset all
sound settings for the current audio
source to the midrange setting.
Bass and treble are reset for the
current audio source, front/back
and right/left volume distribution for all
audio sources.

<

1. Call up operating display for the
midrange setting
Press repeatedly until "TONE LIN"
appears
2.
All settings are reset.

13n

OverviewSettingsReceptionPlayingIndex

Displaying time Key Memory

Instead of the current settings you can
show the time in the display.
With the time displayed, the
current settings can no longer be
seen.
As soon as you press a button to
change a setting, the display briefly
shows the respective setting.

<

The time is shown in the display, e.g.:
To set time, refer to the Owner's
Manual for the vehicle.

<

Displaying time with ignition
switched off

The time disappears in the display
as soon as you remove the igni-
tion key.

<

To show the time in the display with the
ignition key removed:
The time appears in the display for
8 seconds.

Storing the settings

Each person must use his or her
own ignition key.
Refer to the Owner's Manual for the
vehicle for additional information about
Key Memory.

<

You can have your BMW center
customize the following settings for
each key ("Key Memory"):

>

the last audio source heard (radio,
CD changer or CD)

>

The last station heard

>

The last sound setting selected.
The last setting stored by key will be
automatically activated from ignition
key position 1.

14n

15n
OverviewSettingsReceptionPlayingIndex
Overview
Settings
Reception
Playing
Index

Selecting a reception range16
Selecting a station by
frequency16
Selecting a station by name17
Scanning and selecting a station
(Scan)18
Type of program (PTY)19
Storing and calling up a
station20
Switching over to CD changer or
CD22

Reception
