07-10-2002
YOUR 206 CC IN DETAIL
66
From 3 to 10 years (33 to 80 lbs or 15 to 36 kg)
''Recaro Start'': is fitted to the rear with a three-point seat belt. The height and width of the seat back must be adjusted according to the ageand build of your child. "Klippan Optima": is fitted to the rear with a three-point seat belt. From the age of 6 years (approximately 49 lbs or 22 kg), the booster is used on its own.
Remember, even for short journeys, to fasten the three-point seat belts or the childseat straps, keeping the slack in relation to the child's body to a minimum.
* According to current legislation in the country of destination.
** Unless the rear seats are already occupied by other children. In this case, adjust the front passenger seat to the rear-most position and leave the air bag active.
Never leave a child or an animal in a vehicleexposed to the sun, withthe windows closed.
Never leave the keys within
reach of children inside the car. Disarm the passenger air bag when installing a rearwards-facingchild seat in the front. The child would risk being killed or seriously injured if the air bag were toinflate. Observe strictly the recommenda- tions for fitting the child seat asdetailed the instructions.
4
5
07-10-2002
YOUR 206 CC IN DETAIL69
Changing the battery of the remote control
Warning that the battery is flat is given by an audible signal accompanied bythe message
''Remote control bat-
tery low'' on the multifunction display.
To replace the battery, remove thescrew then unclip the casing using acoin at the ring (CR 2016/3 volt battery). If the remote control does not work after the battery has been changed,reprogramme the remote control.
THE KEYS The keys allow you to
independently
operate the locks on the doors, the tailgate (opening), the fuel filler cap,the steering lock, the glove box andthe passenger air bag disarming con-trol and to switch on the ignition. Central locking From the driver's door the keys allow you:
Ðto lock or unlock the doors and tail-
gate simultaneously,
Ð to unlock simultaneously just thedoors.
Unlocking the boot is possible only
by using the boot key. If one of the doors is open, the central locking does not work. The remote control This fulfils the same functions as the
key, at a distance. Locking Pressing button
Alocks the vehicle by
remote control. This is displayed by the continuouslighting of the direction indicators forapproximately two seconds. Unlocking Pressing button Bunlocks just the
doors. This is shown by the rapid flashing ofthe direction indicators. Notes: if the vehicle is locked and the
unlocking control is pressed inadver- tently without the doors being openedwithin 30 seconds, the vehicle will lock
again automatically.
Avoid pressing the buttons of your remote control out of range of your
vehicle. You risk causing it not to workand the remote control would have tobe reprogrammed. Locating your car
To locate your car in a car park, if you have locked it:
press button A, the courtesy light
comes on and the direction indica- tors flash for a few seconds.
Key in ignition
A buzzer sounds on opening the dri-
ver's door, if the key has been left inthe ignition.
Programming the remote control Switch off the ignition.
Switch the ignition on again.
Press button A.
Switch off the ignition and remove the remote control key from the
ignition lock. The remote control isnow working again.
07-10-2002
YOUR 206 CC IN DETAIL
70
Make a careful note of the
number on each key. Thekey number is coded on the
label attached to the key.
If the keys are lost, your PEUGEOT deal-er can rapidly supply you with new keys. The high frequency remote control is a high-performance system which has apowerful beam. Do not operate it while it is in your pocket as there is a possibility that itmay unlock your vehicle, without you
being aware of it. The remote control does not operate when the key is in the ignition, evenwhen the ignition is switched off,except for reprogramming. As a safety precaution (with children on board), remove the ignition key when youleave the vehicle, even for a short time. Do not repeatedly press the button of your remote control out of range of
your vehicle. You risk causing it not towork and the remote control wouldhave to be reprogrammed. When purchasing a second-hand vehi- cle:
Ð ensure that you are given the confi- dential card;
Ð have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the onlyones which can start the vehicle.
Do not make any modifications to theelectronic engine immobiliser system.
Confidential card The confidential card contains the identification code necessary for any
work carried out by a PEUGEOT dealer
on the system. This code is hidden bya film, which should be removed only if
necessary. Keep your card in a safe place, never inside the vehicle.ELECTRONIC ENGINE IMMOBILISER This locks the engine management system as soon as the ignition has
been switched off and therefore pre-vents starting of the vehicle by anyone
who does not have the key. The ignition key has an electronic chip which has a special code. When theignition is switched on, the code isrecognised and starting is possible. If the system does not function
correctly,
you are warned by an audi-
ble signal and a message on the mul-
tifunction display. In this case, the vehicle will not start.
Contact a PEUGEOT dealer as soon as possible.
07-10-2002
YOUR 206 CC IN DETAIL
70
Make a careful note of the
number on each key. Thekey number is coded on the
label attached to the key.
If the keys are lost, your PEUGEOT deal-er can rapidly supply you with new keys. The high frequency remote control is a high-performance system which has apowerful beam. Do not operate it while it is in your pocket as there is a possibility that itmay unlock your vehicle, without you
being aware of it. The remote control does not operate when the key is in the ignition, evenwhen the ignition is switched off,except for reprogramming. As a safety precaution (with children on board), remove the ignition key when youleave the vehicle, even for a short time. Do not repeatedly press the button of your remote control out of range of
your vehicle. You risk causing it not towork and the remote control wouldhave to be reprogrammed. When purchasing a second-hand vehi- cle:
Ð ensure that you are given the confi- dential card;
Ð have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the onlyones which can start the vehicle.
Do not make any modifications to theelectronic engine immobiliser system.
Confidential card The confidential card contains the identification code necessary for any
work carried out by a PEUGEOT dealer
on the system. This code is hidden bya film, which should be removed only if
necessary. Keep your card in a safe place, never inside the vehicle.ELECTRONIC ENGINE IMMOBILISER This locks the engine management system as soon as the ignition has
been switched off and therefore pre-vents starting of the vehicle by anyone
who does not have the key. The ignition key has an electronic chip which has a special code. When theignition is switched on, the code isrecognised and starting is possible. If the system does not function
correctly,
you are warned by an audi-
ble signal and a message on the mul-
tifunction display. In this case, the vehicle will not start.
Contact a PEUGEOT dealer as soon as possible.
07-10-2002
YOUR 206 CC IN DETAIL71
Opening the doors from outside
DOORS
Opening the doors from inside
LOCKING AND UNLOCKING THE BOOT Lock the boot using the key (turn the
key from Ato C) or the remote control.
Unlock it using the key (turn the key
from Ato B).
The lighting is controlled by open- ing the boot.
Locking from the inside
To lock, press button
A.
Locking one of the front doors locks the doors and the boot. Unlocking from the inside
To unlock, pull button Aor the handle.
''Door open'' alert
With the engine running an audible
signal and a message or diagram locating the problem on the multifunc-tion screen, warns you that a door isnot properly closed. Also, when the vehicle is moving ,
with the courtesy light button in the "lighting on opening a door" position,the courtesy light flashes.
07-10-2002
YOUR 206 CC IN DETAIL
72
BONNET STRUT Secure the strut to hold the bonnet open. Before closing the bonnet, replace the strut in its housing.
To close Lower the bonnet and release it at the end of its travel. Check that the bonnetis locked.
OPENING THE BONNET Inside the vehicle:
pull the handle on
the left-hand side, under the fascia. Outside the vehicle: lift the catch and
raise the bonnet. FILLING THE FUEL TANK The tank must be filled with fuel with the engine switched off
.
Insert the key then turn it to the left. Remove the cap.
A label indicates which type of fuel to use. If you fill your tank, do not continue
after the third cut-off of the pump noz-
zle. This could result in vehicle mal-functions. The capacity of the tank is approxi- mately 10.3 gallons (47 litres).
07-10-2002
YOUR 206 CC IN DETAIL
74
Closing the roof
With the vehicle stationary and
the handbrake applied, turn the ignition key to position M.
Press switch 3 until you hear a sig-
nal to indicate that the roof openingoperation is complete.
When carrying out this operation, thefront windows and then the rear quar-ter panel windows open, the boot lidopens and the detachable parcel shelffolds up, the boot lid opens, the roofsunfolds and positions itself, then theboot lid closes again. Lock the two hooks 2.
Note: The control buttons for the win-
dows become operational again at the end of the roof operation. Operating hitch: If the operation is
interrupted, a continuous audible sig- nal sounds: Release switch 3, then press it
again to finish closing the roof.
If the problem persists, contact a
PEUGEOT dealer to have the systemchecked. When the vehicle is moving, if a con-tinuous audible signal can be heard,this means that the roof or the boot lid,or both, are not locked:
Stop the vehicle and apply the handbrake,
Open the roof and close it again
completely, in accordance with theprocedure.
If the problem persists, contact a
PEUGEOT dealer to have the systemchecked. The roof must not be oper-ated when a loaded lug-gage carrier is fitted to theboot lid.
During roof opening and closingoperations, to avoid any risk of
injury, ensure that there is no-onein the proximity of the movingparts.
In the event of danger, release the control knob, the operation
will stop instantly. Never release button 3 for any
length of time, nor switch off theignition when the roof is in anintermediate position (neithercompletely open or closed).
In the case of an electric or hydraulic malfunction of the roof, it is possible
to close the roof manually. When the side windows no longer
open completely, it is impossible tooperate the roof; however it is possibleto close it by using a special proce-
dure. Please consult the breakdown pro- cedure described at the end of thishandbook.
07-10-2002
YOUR 206 CC IN DETAIL
76
AUTOMATIC SWITCHING ON OF LIGHTS Side lights and dipped beam head- lamps switch on automatically if thelight is poor and when the windscreen
wipers operate continuously.
They switch off when the light becomes bright enough or the wind-screen wipers stop. Note:
In foggy weather or in snow, the
brightness sensor can detect sufficient
light. As a consequence, the lights will
not come on automatically. This function is active when the vehi-
cle is supplied to the customer. To dis-arm or activate the function:
Ð Start with the key in the accessories
position (1st notch),
Ð Press the end of the stalk for more than four seconds.
Note: after the ignition is switched off
and depending on the brightness, the lights remain on for 45 seconds or untilthe vehicle is locked.
The brightness sensor, coupled with
the rain sensor, is located in the centre
of the windscreen, behind the interior
mirror. It is used for automatic switch-ing on of the lights. Operating check Activation Acivation of this function is accompanied by an audible signal and the message"Automatic lighting active''
on the mul-
tifunction display. Disarming Disarming of the function is accompa- nied by an audible signal. Note: the function is temporarily dis-
armed when the driver uses the manual lighting controls. If the brightness sensor does not function correctly , the system acti-
vates the function (the lights come on).The driver is alerted by an audible sig-nal, accompanied by the message
"Automatic switching on of lightsfaulty" .
Contact a PEUGEOT dealer to have thesystem checked.
