Page 50 of 88
PERIODIC MAINTENANCE AND MINOR REPAIR
6-18
6
EW000079
WARNING
_ l
Have a Yamaha dealer replace
excessively worn tires. Besides
being illegal, operating the
motorcycle with excessively
worn tires decreases riding sta-
bility and can lead to loss of
control.
l
The replacement of all wheel-
and brake-related parts, includ-
ing the tires, should be left to a
Yamaha dealer, who has the
necessary professional knowl-
edge and experience.
_
Tire information
This motorcycle is equipped with tube
tires.
EW000078
WARNING
_ l
The front and rear tires should
be of the same make and de-
sign, otherwise the handling
characteristics of the motor-
cycle cannot be guaranteed.
l
After extensive tests, only the
tires listed below have been ap-
proved for this model by
Yamaha Motor Co., Ltd.
_CE-10EEAU00681
WARNING
_ l
Have a Yamaha dealer replace
excessively worn tires. Besides
being illegal, operating the
motorcycle with excessively
worn tires decreases riding sta-
bility and can lead to loss of
control.
l
The replacement of all wheel-
and brake-related parts, includ-
ing the tires, should be left to a
Yamaha dealer, who has the
necessary professional knowl-
edge and experience.
l
It is not recommended to patch
a punctured tube. If unavoid-
able, however, patch the tube
very carefully and replace it as
soon as possible with a high-
quality product.
_
FRONT
Manufacturer Size Model
CHENG SHIN 80/100-18 47P C-916
INOUE 80/100-18 47PMARBELLA
NF27
REAR
Manufacturer Size Model
CHENG SHIN 130/90-15 M/C 66P C-915
INOUE 130/90-15 M/C 66PMARBELLA
NR31
E_5kr.book Page 18 Tuesday, September 12, 2000 4:46 PM
Page 79 of 88
8-1
8
EAU01038
8-SPECIFICATIONS
Specifications CS-01E
Model XVS250
Dimensions
Overall length 2,320 mm
Overall width 910 mm
Overall height 1,075 mm
Seat height 670 mm
Wheelbase 1,530 mm
Ground clearance 150 mm
Minimum turning radius 2,900 mm
Basic weight (with oil and full
fuel tank)
159 kg
Engine
Engine type Air-cooled 4-stroke, SOHC
Cylinder arrangement V type 2-cylinder
Displacement 249 cm
3
Bore ´ stroke 49 ´ 66 mm
Compression ratio 10:1
Star ting system Electric star ter
Lubrication system Wet sumpEngine oil
Ty p e
Recommended engine oil
classification API Service SE, SF, SG or
higher
Quantity
Without oil filter element
replacement 1.4 L
With oil filter element
replacement 1.6 L
Total amount (dry engine) 1.75 L
-20 -10 0
10 20 30
40
50 ˚C
SAE 10W-30
SAE 15W-40SAE 20W-40SAE 20W-50
SAE 10W-40
CAUTION:Be sure to use motor oils that do not contain anti-fric-
tion modifiers. Passenger car motor oils (often labeled
“ENERGY CONSERVING II”) contain anti-friction addi-
tives which will cause clutch and/or starter clutch slip-
page, resulting in reduced component life and poor
engine performance.
E_5kr.book Page 1 Tuesday, September 12, 2000 4:46 PM
Page 80 of 88
SPECIFICATIONS
8-2
8
Air filterDry type element
Fuel
Type Regular unleaded gasoline
Fuel tank capacity 11 L
Fuel reserve amount 3.4 L
Carburetor
Manufacturer MIKUNI
Model ´ quantity BDS26 ´ 1
Spark plug
Manufacturer/model NGK / CR6HSA or
DENSO / U20FSR-U
Gap 0.6–0.7 mm
Clutch typeWet, multiple-disc
Transmission
Primary reduction system Spur gear
Primary reduction ratio 3.130
Secondary reduction system Chain drive
Secondary reduction ratio 2.800
Number of drive chain
sprocket teeth (front/rear) 20/56
Transmission type Constant-mesh 5-speed
Operation Left footGear ratio
1st 2.643
2nd 1.684
3rd 1.261
4th 1.000
5th 0.821
Chassis
Frame type Double cradle
Caster angle 35°
Trail 135 mm
Tires
Fr o n t
Type Tube tire
Size 80/100-18 47P
Manufacturer/
modelCHENG SHIN / C-916
INOUE / MARBELLA NF27
Rear
Type Tube tire
Size 130/90-15 M/C 66P
Manufacturer/
modelCHENG SHIN / C-915
INOUE / MARBELLA NR31
E_5kr.book Page 2 Tuesday, September 12, 2000 4:46 PM
Page 84 of 88
9-1
9
EAU01039
9-CONSUMER INFORMATION
EAU02944
Identification numbers Record the key identification number,
vehicle identification number and mod-
el label information in the spaces pro-
vided below for assistance when
ordering spare parts from a Yamaha
dealer or for reference in case the vehi-
cle is stolen.
1. KEY IDENTIFICATION NUMBER:CA-02E2. VEHICLE IDENTIFICATION
NUMBER:CA-02E3. MODEL LABEL INFORMATION:CA-01EEAU01041
Key identification number The key identification number is
stamped into the key tag. Record this
number in the space provided and use
it for reference when ordering a new
key.
EAU01043
Vehicle identification number The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space
provided.NOTE:_ The vehicle identification number is
used to identify your motorcycle and
may be used to register your motor-
cycle with the licensing authority in
your area. _
1. Key identification number
1. Vehicle identification number
E_5kr.book Page 1 Tuesday, September 12, 2000 4:46 PM
Page 85 of 88
CONSUMER INFORMATION
9-2
9
EAU03757
Model label The model label is affixed to the loca-
tion shown. Record the information on
this label in the space provided. This in-
formation will be needed when ordering
spare parts from a Yamaha dealer.1. Model label
