To adjust the drive chain slack
1. Loosen the brake pedal free play
adjusting nut and the axle nut.
2. To tighten the drive chain, turn
the adjusting plate on each side
of the swingarm in direction a.
To loosen the drive chain, turn
the adjusting plate on each side
of the swingarm in direction b,
and then push the rear wheel for-
ward.NOTE:
Make sure that both adjusting plates
are in the same position for proper
wheel alignment.1. Axle nut
2. Chain adjusting plate
3. Rear brake pedal free play adjusting nut
21
a
b
3
EC000096
cCImproper drive chain slack will
overload the engine as well as
other vital parts of the motorcycle
and can lead to chain slippage or
breakage. To prevent this from
occurring, keep the drive chain
slack within the specified limits.3. Tighten the brake pedal free play
adjusting nut, and then tighten
the axle nut to the specified
torque.
4. Adjust the brake pedal free play.
(See page 6-21 for brake pedal
free play adjustment proce-
dures.)
EW000103
wAfter adjusting the brake pedal
free play, check the operation of
the brake light.
EAU01106
Lubricating the drive chainThe drive chain must be cleaned and
lubricated at the intervals specified in
the periodic maintenance and lubrica-
tion chart, otherwise it will quickly
wear out, especially when riding in
dusty or wet areas. Service the drive
chain as follows.
EC000097
cCThe drive chain must be lubricated
after washing the motorcycle or
riding in the rain.1. Remove all dirt and mud from
the drive chain with a brush or
cloth.
2. Spray a drive chain lubricant on
both sides and on the middle of
the chain, making sure that all
side plates and rollers have been
sufficiently oiled.NOTE:
For a thorough cleaning, have a
Yamaha dealer remove the drive
chain and soak it in solvent.
Tightening torque:
Axle nut:
90 Nm (9.0 mákg)
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 55
Page 58 of 88
6-27
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU02962
Checking and lubricating the
cablesThe operation of all control cables
and the condition of the cables
should be checked before each ride,
and the cables and cable ends
should be lubricated if necessary. If a
cable is damaged or does not move
smoothly, have a Yamaha dealer
check or replace it.
EW000112
wDamage to the outer sheath may
interfere with proper cable opera-
tion and will cause the inner cable
to rust. Replace a damaged cable
as soon as possible to prevent
unsafe conditions.
Recommended lubricant:
Engine oil
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 56
Page 59 of 88

6-28
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU03209
Checking and lubricating the
throttle grip and cableThe operation of the throttle grip and
the condition of the throttle cable
should be checked before each ride,
and the cable should be lubricated or
replaced if necessary.NOTE:
Since the throttle grip must be
removed to access the throttle cable
end, the throttle grip and the cable
should always be lubricated at the
same time.1. Remove the throttle grip by
removing the screws.
2. Disconnect the throttle cable,
hold it up, and then apply several
drops of oil to the cable end,
allowing it to trickle into the
sheath.
3. Connect the throttle cable, and
then grease the inside of the
throttle grip housing.
EAU03370
Checking and lubricating the
brake and shift pedalsThe operation of the brake and shift
pedals should be checked before
each ride, and the pedal pivots
should be lubricated if necessary.
Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
4. Grease the metal-to-metal con-
tact surface of the throttle grip,
and then install the grip by
installing the screws.
Recommended lubricant:
Throttle cable:
Engine oil
Throttle grip housing and grip:
Lithium-soap-based grease
(all-purpose grease)
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 57
Page 60 of 88

6-29
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU03166
Lubricating the rear
suspensionThe pivoting points of the rear sus-
pension must be lubricated at the
intervals specified in the periodic
maintenance and lubrication chart.1. Grease nipple (´2)
1
Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
EAU03165
Checking and lubricating the
sidestandThe operation of the sidestand
should be checked before each ride,
and the sidestand pivot and metal-to-
metal contact surfaces should be
lubricated if necessary.
EW000113
wIf the sidestand does not move up
and down smoothly, have a
Yamaha dealer check or repair it.
Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
EAU03164
Checking and lubricating the
brake and clutch leversThe operation of the brake and clutch
levers should be checked before
each ride, and the lever pivots should
be lubricated if necessary.
Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 58
Page 61 of 88

6-30
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU02939
Checking the front forkThe condition and operation of the
front fork must be checked as follows
at the intervals specified in the peri-
odic maintenance and lubrication
chart.
To check the condition
EW000115
wSecurely support the motorcycle
so that there is no danger of it
falling over.Check the inner tubes for scratches,
damage and excessive oil leakage.To check the operation
1. Place the motorcycle on a level
surface and hold it in an upright
position.
2. While applying the front brake,
push down hard on the handle-
bars several times to check if the
front fork compresses and
rebounds smoothly.
EC000098
cCIf any damage is found or the front
fork does not operate smoothly,
have a Yamaha dealer check or
repair it.
EAU00794
Checking the steeringWorn or loose steering bearings may
cause danger. Therefore, the opera-
tion of the steering must be checked
as follows at the intervals specified in
the periodic maintenance and lubrica-
tion chart.
1. Place a stand under the engine
to raise the front wheel off the
ground.
EW000115
wSecurely support the motorcycle
so that there is no danger of it
falling over.
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 59
Page 62 of 88
6-31
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU03503
BatteryA poorly maintained battery will cor-
rode and discharge quickly. The elec-
trolyte level, battery lead connections
and breather hose routing should be
checked before each ride and at the
intervals specified in the periodic
maintenance and lubrication chart.
EAU01144
Checking the wheel bearingsThe front and rear wheel bearings
must be checked at the intervals
specified in the periodic maintenance
and lubrication chart. If there is play
in the wheel hub or if the wheel does
not turn smoothly, have a Yamaha
dealer check the wheel bearings.
2. Hold the lower ends of the front
fork legs and try to move them
forward and backward. If any
free play can be felt, have a
Yamaha dealer check or repair
the steering.
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 60
Page 63 of 88

6-32
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
4
1
23
5
1. Battery
2. Negative lead (brack)
3. Positive lead (red)
4. Breather hose
5. BandTo check the electrolyte level
1. Remove the rider seat. (See
page 3-9 for rider seat removal
and installation procedures.)
2. Disconnect the negative battery
lead from the battery.
3. Disconnect the positive battery
lead and the battery breather
hose from the battery.
4. Unhook the battery band, and
then pull the battery out of the
battery compartment.
1
2
5. Place the battery on a level sur-
face, and then check the elec-
trolyte level in the battery.NOTE:
The electrolyte should be between
the minimum and maximum level
marks.6. If the electrolyte is at or below
the minimum level mark, add dis-
tilled water to raise the elec-
trolyte to the maximum level
mark.1. Maximum level mark
2. Minimum level mark
EW000116
w8Electrolyte is poisonous and
dangerous since it contains
sulfuric acid, which causes
severe burns. Avoid any con-
tact with skin, eyes or clothing
and always shield your eyes
when working near batteries.
In case of contact, administer
the following FIRST AID.
8EXTERNAL: Flush with
plenty of water.
8INTERNAL: Drink large quan-
tities of water or milk and
immediately call a physician.
8EYES: Flush with water for
15 minutes and seek prompt
medical attention.
8Batteries produce explosive
hydrogen gas. Therefore, keep
sparks, flames, cigarettes,
etc., away from the battery and
provide sufficient ventilation
when charging it in an
enclosed space.
8KEEP THIS AND ALL BATTER-
IES OUT OF THE REACH OF
CHILDREN.
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 61
Page 64 of 88

6-33
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9To store the battery
1. If the motorcycle will not be used
for more than one month,
remove the battery, fully charge
it, and then place it in a cool, dry
place.
2. If the battery will be stored for
more than two months, check the
specific gravity of the electrolyte
at least once a month and fully
charge the battery whenever
necessary.
3. Fully charge the battery before
installation.
4. After installation, make sure that
the battery leads are properly
connected to the battery termi-
nals and that the breather hose
is properly routed, in good condi-
tion, and not obstructed.
1. Battery
2. Battery breather hose
1
2
9. Connect and tighten the positive
battery lead to the batteryÕs posi-
tive (+) terminal.
10. Connect and tighten the negative
battery lead to the batteryÕs neg-
ative (-) terminal.
11. Install the seat.
1. Battery breather hose
1
EC000100
cCUse only distilled water, as tap
water contains minerals that are
harmful to the battery.7. Place the battery in the battery
compartment, and then hook the
battery band onto the holder.
8. Connect the breather hose to the
battery and make sure that it is
properly routed.
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 62
