2001 YAMAHA MAJESTY 250 ECO mode

EAU03740
Self-diagnosis deviceThis model is equipped with a self-
diagnosis device for the throttle posi-
tion sensor, oil change indicator light,
speedometer unit circuits. If any of
those circuits are defective, the oil
change indicator light will flash.
If the indicator light flashes or comes
on, have a Yamaha dealer check the
motorcycle as soon as possible.NOTE:
The oil change indicator light may
flash when the engine is revved with
the scooter on the centerstand, but
this does not indicate a malfunction.
3-3
EAU01586
Speedometer unit The speedometer unit is equipped
with a speedometer, an odometer
and a tripmeter. The speedometer
shows riding speed. The odometer
shows the total distance traveled.
The tripmeter shows the distance
traveled since it was last set to zero.
Pushing the ÒTRIPÓ button switches
the display between the odometer
mode ÒODOÓ and the tripmeter mode
ÒTRIPÓ. To reset the tripmeter, enter
the ÒTRIPÓ mode, and then hold downthe ÒTRIPÓ button for at least one
second. The tripmeter can be used
together with the fuel gauge to esti-
mate the distance that can be trav-
eled with a full tank of fuel. This infor-
mation will enable you to plan future
fuel stops.INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
123
1.Speedometer
2.Odometer/tripmeter
3.ÒTRIPÓ button
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 18

Specifications
ModelYP250
Dimensions
Overall length2,140 mm
Overall width780 mm
Overall height1,350 mm
Seat height730 mm
Wheelbase1,535 mm
Ground clearance120 mm
Minimum turning radius2,700 mm
Basic weight (with oil and full
fuel tank)168 kg
Engine
Engine typeLiquid-cooled 4-stroke, SOHC
Cylinder arrangementForward inclined single
cylinder
Displacement249 cm
3
Bore ´Stroke69.0 ´66.8 mm
Compression ratio10:1
Starting systemElectric starter
Lubrication systemWet sump
EAU01038
SPECIFICATIONS
1
2
3
4
5
6
78
9
8-1
Engine oil
Type
Recommended engine oil
classificationAPI Service SE, SF, SG type
or highercCBe sure to use motor oils that do not contain anti-friction
modifiers. Passenger car motor oils (often labeled ÒEnergy
ConservingÓ) contain anti-friction additives which will cause
clutch and/or starter clutch slippage, resulting in reduced
component life and poor engine performance.
Quantity
Periodic oil change1.2 L
Total amount (dry engine)1.4 L
–10° 0° 10° 20° 30°
40°
SAE 10W/30
SAE 10W/40
SAE 20W/40
SAE 20W/50
–20°
SAE 15W/40 50°C
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 92

8-2
SPECIFICATIONS
1
2
3
4
5
6
78
9
Final gear case oil
TypeEngine oil SAE 10W-30
(API SE)
Total amount0.25 L
Radiator capacity
(including all routes)1.4 L
Air filterWet type element
Fuel
TypeRegular unleaded gasoline
Fuel tank capacity12 L
Carburetor
ManufacturerTEIKEI
Model ´ quantityY28V-1E ´ 1
Spark plug
Manufacturer/modelNGK / DR8EA
Spark plug gap0.6Ð0.7 mm
Clutch typeDry, centrifugal automatic
Transmission
Primary reduction systemHelical gear
Primary reduction ratio40/15 (2.666)
Secondary reduction systemHelical gear
Secondary reduction ratio38/15 (2.533)
Transmission typeV-belt automatic
OperationCentrifugal automatic typeChassis
Frame typeSteel tube underbone
Caster angle28¡
Trail103 mm
Tires
Front
TypeTubeless
Size110/90-12 64L
Manufacturer/INOUE / MB67
modelMICHELIN / BOPPER
Rear
TypeTubeless
Size130/70-12 62L
Manufacturer/INOUE / MB67
modelMICHELIN / BOPPER
Maximum load*187 kg
Air pressure (cold tire)
up to 90 kg load*
Front175 kPa (1.75 kg/cm
2, 1.75 bar)
Rear200 kPa (2.00 kg/cm2, 2.00 bar)
90 kg loadÐmaximum load*
Front200 kPa (2.00 kg/cm2, 2.00 bar)
Rear225 kPa (2.25 kg/cm2, 2.25 bar)
* Total weight of rider, passenger, cargo and accessories
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 93

1
1
EAU02944
Identification numbersRecord the key identification number,
vehicle identification number and
model label information in the spaces
provided below for assistance when
ordering spare parts from a Yamaha
dealer or for reference in case the
vehicle is stolen.
1.KEY IDENTIFICATION
NUMBER:
2.VEHICLE IDENTIFICATION
NUMBER:
3.MODEL LABEL INFORMATION:
EAU01041
Key identification numberThe key identification number is
stamped into the key tag.
Record this number in the space pro-
vided and use it for reference when
ordering a new key.
EAU01044
Vehicle identification numberThe vehicle identification number is
stamped into the frame.NOTE:
The vehicle identification number is
used to identify your scooter and may
be used to register your scooter with
the licensing authority in your area.
1.Key identification number1.Vehicle identification number
9-1
EAU01039
CONSUMER INFORMATION
1
2
3
4
5
6
7
89
1
6
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 98

9-2
CONSUMER INFORMATION
1
2
4
5
6
7
89
1
EAU03097
Model labelThe model label is affixed to the
inside of the rear storage compart-
ment. (See page 3-13 for rear stor-
age compartment opening and clos-
ing procedures.) Record the
information on this label in the space
provided. This information will be
needed when ordering spare parts
from a Yamaha dealer.1.Model label
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 99
