2001 SUBARU IMPREZA warning

Seat, seat belt and SRS airbag2-15
–
CONTINUED –

3-point type seatbelt (Combination lap/shoulder belts)
WARNING
Never place the shoulder belt under the arm or behind the back. If an accident occurs, this can increase the risk or severity of inju-
ry.
OM-H0044OM-H0043
1. Ad just the seat p osition:
Driver’ s seat: Ad just the seatb ac k to the up rig ht p osition. Move the
seatb ac k as far from the steering wheel as p rac tic a l while still main-
taining full vehic le c ontrol.Front passenger ’s seat: Ad just the seatb ac k to the up rig ht p osition.
Move the seat as far b ac k as p ossib le.
2. Sit well b ac k in the seat.
3. Pic k up the tong ue p late and p ull the b elt out sl owly. Do not let it
g et twisted . If the b elt stop s b efore reac hing the b uc kle, return the
b elt slig htly and p ull it out more slowly. If the b elt still c annot b e un-
loc ked , let the b elt retrac t slig htly after g iving a strong p ull on it, then
p ull it out slowly ag ain.
4. Insert the tong ue p late into the b uc kle until you hear a c lic k.
5. To make the lap p art tig ht, p ull up on the should er b elt. And p lac e
the lap b elt as low as p ossib le on your hip s, not o n your waist.

2-16n
Adjusting the front seat shoulder belt anchor height
WARNING
When wearing the front seatbelts, make sure the shoulder portion of the webbing does not pass over your neck. If it does, adjustthe seatbelt anchor to a lower position. Placing the shoulder beltover the neck may result in neck injury during sudden braking orin a collision.
OM-H0046
The should er b elt anc hor heig ht should b e ad justed to the p osition
b est suited for you.
To ad just the anc hor heig ht, p ull the release knob and move the an-
c hor to the d esired p osition.
Always ad just the anc hor heig ht so that the should e r b elt p asses over
the mid d le of the should er without touc hing the nec k.
n Seatbelt guide (Coupe)
WARNING
The seatbelt guide must be in its fully raised position when the
seatbelt is worn.Otherwise, the seatbelt will be less effective in prevailing injury inan accident.

2-20Child restraint systems
WARNING
Never let a passenger hold a child on his or her lap while the
vehicle is moving. The passenger cannot protect the child from injury in a collision, because the child will be caught between the
passenger and objects inside the vehicle. Additionally, holding achild in your lap or arms in the front seat exposes that child to
another serious danger. Since the SRS airbag deploys with con-
siderable speed and force, the child could be injured or evenkilled. Put children aged 12 and under in the rear seat properly re-
strained at all times. The SRS airbag deploys with considerablespeed and force and can injure or even kill children, especially ifthey are 12 years of age and under and are not restrained or im-properly restrained. Because children are lighter and weaker than
adults, their risk of being injured from deployment is greater. Forthat reason, be sure to secure ALL types of child restraint
devices (including forward facing child seats) in the REAR seats
at all times. You should choose a restraint device which isappropriate for the child ’s age, height and weight. According to
accident statistics, children are safer when properly restrained inthe rear seating positions than in the front seating positions. SINCE YOUR VEHICLE IS EQUIPPED WITH A PASSENGER ’S
SRS AIRBAG, DO NOT INSTALL A REARWARD FACING CHILD
SEAT IN THE FRONT PASSENGER ’S SEAT. DOING SO RISKS SE-
RIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE
CHILD’ S HEAD TOO CLOSE TO THE SRS AIRBAG.
Children should be properly restrained in the rear seat at all
times. Never allow a child to stand up, or to kneel on the front
passenger’ s seat. The SRS airbag deploys with considerable
force and can injure or even kill the child.

Seat, seat belt and SRS airbag2-21
–
CONTINUED –
HS0042 OM-H0051
Never install rearward facing child seat in the front passenger
’s seat.
HS0228
Never allow a child to stand up, or to kneel on the front passenger ’s seat
or any other seat.
Secure child restraint devices in the REAR seats at all times.
HS0229
Never hold a child on your lap or in your arms in the front passenger ’s
seat or any other seat.
WARNING
Child restraint systems and seat belts can become hot in a ve-
hicle that has been closed up in sunny weather; they could burn a small child. Check the child restraint system before you place achild in it. Do not leave an unsecured child restraint system in your vehi-
cle. Unsecured child restraint systems can be thrown around in-
side of the vehicle in a sudden stop, turn or accident; it can strikeand injure vehicle occupants as well as result in serious injuriesor death to the child.

Seat, seat belt and SRS airbag2-27
–
CONTINUED –
*SRS airbag (Supplemental Restraint System airbag)
*SRS: This stand s for sup p lemental restraint system
. This name is used
b ec ause the airb ag system sup p lements the vehic le ’s seatb elts.
Vehicle with driver ’s and front passenger ’s SRS air-
bags and lap/shoulder restraint
WARNING
To obtain maximum protection in the event of an accident, the
driver and all passengers in the vehicle should always wear seat- belts when the vehicle is moving. The SRS airbag is designed
only as a supplement to the primary protection provided by the
seatbelt. It does not do away with the need to fasten seatbelts. In
combination with the seatbelts, it offers the best combinedprotection in case of a serious accident.Not wearing a seatbelt increases the chance of severe injury ordeath in a crash even when the car has the SRS airbag.
For instructions and precautions concerning the seatbelt system,see the “Seatbelts” sections in this chapter.
Do not sit or lean unnecessarily close to the SRS airbag. Be-
cause the SRS airbag deploys with considerable speed – faster
than the blink of an eye – and force to protect in high speed colli-
sions, the force of an airbag can injure an occupant whose bodyis too close to SRS airbag. It is also important to wear your seatbelt to help avoid injuriesthat can result when the SRS airbag contacts an occupant not inproper position such as one thrown forward during pre-accidentbraking.Even when properly positioned, there remains a possibility thatan occupant may suffer minor injury such as abrasions andbruises to the face or arms because of the SRS airbag deploy-ment force.

2-28
Do not place any objects over or near the SRS airbag cover or
between you and the SRS airbag. If the SRS airbag deploys, those objects could interfere with its proper operation and could
be propelled inside the car and cause injury. The SRS airbags deploy with considerable speed and force.
Occupants who are out of proper position when the SRS airbag
deploys could suffer very serious injuries. Because the SRS air-bag needs enough space for deployment, the driver should al-ways sit upright and well back in the seat as far from the steeringwheel as practical while still maintaining full vehicle control and
the front passenger should move the seat as far back as possibleand sit upright and well back in the seat.
HS0233
Adjust the seatback to upright position. Sit well back and upright.
Move the seat as far from the steering wheel as practical.HB0290
Adjust the seatback to upright position. Sit well back and upright.
Move the seat as far back as possible.
WARNING
Put children aged 12 and under in the rear seat properly re-
strained at all times. The SRS airbag deploys with considerable speed and force and can injure or even kill children, especially ifthey are 12 years of age and under and are not restrained or im-properly restrained. Because children are lighter and weaker than
adults, their risk of being injured from deployment is greater.
For that reason, we strongly recommend that ALL children (in-cluding those in child seats and those that have outgrown child
restraint devices) sit in the REAR seat properly restrained at alltimes in a child restraint device or in a seatbelt, whichever is ap-

2-30
HB0307
Never allow a child to stand up, or to kneel on the front passenger’s
seat
HB0308
Never hold a child on your lap or in your arms.
WARNING
Do not put any objects over the steering wheel pad and dash-
board. If the SRS airbag deploys, those objects could interfere
with its proper operation and could be propelled inside the vehi-
cle and cause injury. Do not attach accessories to the windshield, or fit an extra-
wide mirror over the rear view mirror. If the SRS airbag deploys,those objects could become projectiles that could seriously in-jure vehicle occupants.
HS0245
HS0244
Do not put any objects over the steering wheel pad and dashboardDo not attach accessories to the windshield, or fit an extra-wide mir-
ror over the rear view mirror.

Seat, seat belt and SRS airbag2-37
–
CONTINUED –

SRS airbag system monitors
HG0341
SRS airbag system warning light
A d iag nostic system c ontinually monitors the read in
ess of the SRS air-
b ag system while the vehic le is b eing d riven. The S RS airb ag system
warning lig ht “AIRBAG ” will show normal system op eration b y lig hting for
ab out 6 sec ond s when the ig nition key is turned to the “ON ” p osition.
The following c omp onents are monitored b y the ind ic ator:
Front sub sensor (Rig ht hand sid e)
Front sub sensor (Left hand sid e)
Airb ag c ontrol mod ule (inc lud ing imp ac t sensors)
Airb ag mod ule (Driver ’s sid e)
Airb ag mod ule (Passeng er ’s sid e)
All related wiring
In the event of a malfunc tion ind ic ated b y any of f ollowing , the vehic le
should b e taken p romp tly to your nearest SUBARU d ea ler to have the
system c hec ked . Unless c hec ked and rep aired , the SR S airb ag s will not
func tion reliab ly: Flashing or flic kering of the ind ic ator lig ht.
No illumination of the warning lig ht when the ig nit ion switc h is first
turned to the “ON ” p osition.
Continuous illumination of the warning lig ht.
Illumination of the warning lig ht while d riving .
