2001 PONTIAC FIREBIRD clock

Table of Contents (cont'd)
Defensive Driving
Drunken Driving
Control of a Vehicle
Braking
SteeringDriving Tips for Various Road Conditions
Recreational Vehicle Towing
Loading Your Vehicle
Towing a Trailer Heating and Air Conditioning
Setting the Radio Clock
Radio/Cassette Player/CD PlayerRadio Theft-Deterrent Feature
Steering Wheel Controls (If Equipped)
Hazard Warning Flashers
Jump Starting
Towing Your VehicleEngine Overheating
Changing a Flat Tire
If You're Stuck
Problems on the Road
iii
Section
5
Section
4
Section
3
Your Driving and the Road Comfort Controls and Audio Systems

2-18 Shock Sensor
Coupe Convertible
The shock sensor is what triggers the alarm when it
detects a blow to your vehicle. It is located over the
wheelhouse near the spare tire in the hatch area, on the
passenger's side of the vehicle. There are two levels of
alarms via the shock sensor. Two horn blasts and
parking lamp flashes for non
-threatening blows to
the vehicle and a full two
-minute alarm for harder
blows to the vehicle.Its sensitivity can be adjusted if more or less sensitivity
is desired. If sensitivity is increased too much, it may
give false alarms caused by gusts of wind or other
natural events that may shake the vehicle.
When your vehicle is new, there will be a label covering
the adjustment knob. Remove the label and adjust the
sensor as desired. Turn the knob clockwise to increase
sensitivity and counterclockwise to decrease sensitivity.
The shock sensor is ignored by the alarm system when
the following happens:

The ignition is on,

the hatch is open,

the alarm is disarmed,

when customized to be ignored, or

for five seconds after the horn sounds an alarm
or chirp.
The shock sensor is ignored after triggering three full
alarms until the system is rearmed.

2-57 Headlamp Doors
The headlamp doors are designed to open when you
turn the headlamps on and close when you turn the
headlamps off. The headlamp doors can be opened
without turning on the headlamps by turning the
headlamps on, then turning the switch back to the
parking lamps position.
The headlamp doors should be open when driving in
icy or snowy conditions to prevent the doors from
freezing closed, and when washing the vehicle to help
clean the headlamps.
To open the headlamp doors manually, do the following:
1. Open the hood.
2. Remove the plastic cover from the retractor
motor knob.
3. Turn the retractor motor knob counterclockwise until
the headlamp door is fully open. The knob will get
harder to turn when the headlamp door is all the
way up.
4. Reinstall the plastic cover on the retractor
motor knob.
To manually close the headlamp doors, turn the lamps
off and turn the retractor motor knob clockwise. If the
headlamp doors aren't working properly, see your dealer.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier
for others to see the front of your vehicle during the
day. DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset. Fully
functional daytime running lights are required on
all vehicles first sold in Canada.
For Canadian vehicles, a light sensor on top of the
instrument panel automatically turns the headlamps on,
so be sure it isn't covered.
The DRL system will not activate if the parking brake is
engaged prior to turning the ignition on.
The DRL system will make your front turn signal lamps
come on when:

The ignition is on,

the headlamp switch is OFF,

the parking brake is released, and

it is bright enough outside (on Canadian vehicles).

2-66
1. The door key unlocks the t-top panels. The lock
is located over each door window. Turn the key
counterclockwise to unlock the panel.2. Then pull on the release handle to unlatch the panel.
Lift the outer edge of the panel and pull it toward
you. Then carry the panel to the rear of the vehicle
for storage.

2-79
NOTICE:
The convertible top may be tight when pushing
forward on the latch when your vehicle is new,
but it will loosen up with time. Make sure that
the hooks are properly aligned before using any
kind of force.
If your vehicle has a power loss, such as a dead battery,
you can still raise or lower the top manually by turning
the valve in the driver's side of the trunk area.
1. Open the hatch and find the tab located along the left
side trim panel.
2. Lift up the tab and turn the valve counterclockwise
to release the hydraulic pressure.
3. Turn the ignition key to LOCK.
You can now raise or lower your top manually. Be sure
to close the valve after installing your top so you can
raise or lower it electrically later.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-3 Cooling
3
-3 Heating
3
-4 Defogging and Defrosting
3
-4 Rear Window Defogger
3
-5 Ventilation System
3
-6 Audio Systems
3
-6 Setting the Clock
3
-6 Monsoon
AM-FM Stereo with Cassette Tape
Player and Equalizer
3
-10 AM-FM Stereo with Compact Disc Player and
Equalizer (If Equipped)3
-13 Trunk Mounted CD Changer (Option)
3
-18 Theft-Deterrent Feature
3
-20 Audio Steering Wheel Controls (If Equipped)
3
-21 Understanding Radio Reception
3
-21 Tips About Your Audio System
3
-22 Care of Your Cassette Tape Player
3
-23 Care of Your Compact Discs
3
-23 Care of Your Compact Disc Player
3
-23 Fixed Mast Antenna
3
-24 Power Antenna Mast Care

3-2
Comfort Controls
With this system, you can control the heating, air
conditioning and ventilation in your vehicle.
Your vehicle also has the flow
-through ventilation
system described later in this section.
Fan Control Knob
Turn the fan knob to select the force of air
you want.Temperature Control Knob
Turn the center knob to change the temperature
of the air flowing from the system. Turn it toward the
red (clockwise) for warmer air and toward the
blue (counterclockwise) for cooler air.
Air Control Knob
OFF: In this setting the system is off.
MAX: This setting provides maximum cooling or quick
cool
-down on very hot days. This setting recirculates
most of the air inside your vehicle. If it is used for long
periods of time the air may become dry. This setting
directs air through the upper air vents.
A/C: Use A/C for normal cooling on hot days. This
setting cools outside air and directs it through the upper
air vents.
The air conditioner compressor operates in MAX, A/C,
BI
-LEVEL, BLEND and DEFROST when the outside
temperature is above freezing. When the air conditioner
is on, you may sometimes notice slight changes in your
vehicle's engine speed and power due to the operation of
the compressor.

3-5 Ventilation System
Adjust the direction of airflow by moving the vents.
Your vehicle's flow
-through ventilation system supplies
outside air into the vehicle when it is moving. Outside
air will also enter the vehicle when the blower fan
is running.For mild outside temperature when little heating or
cooling is needed, you can still direct outside air through
your vehicle.
1. Turn the air control knob to VENT.
2. Turn the temperature control knob to a
comfortable setting.
3. Turn the fan control knob to the desired speed.
Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction (such as leaves). The heater
and defroster will work far better, reducing the
chance of fogging the inside of your windows.

When you enter a vehicle in cold weather, turn the
fan control knob clockwise for a few moments
before driving off. This helps clear the intake ducts
of snow and moisture, and reduces the chance of
fogging the inside of your windows.

Keep the air path under the front seats clear of
objects. This helps air to circulate throughout
your vehicle.
