2001 PEUGEOT 206 CC DAG height adjustment

1Bonnet opening control
2 Fuse box
3 Storage
4 Steering wheel height adjust- ment control
5 Headlamp height adjustment
6 Lights and fog lamps stalk
7 Adjustable side vent
8 Heated seats switch*
9 Side windows demisting vents
10 Passenger air bag disarmingswitch*
11 Driver's air bag / horn
12 Instrument panel lighting rheostat
13 Windscreen wash/wipe stalk 14
Radio steering column stalk
15 Steering lock
16 Central adjustable vents
17 Hazard warning lights switch
18 Multifunction display
19 Audio equipment
20 Windscreen demisting vents
21 Passenger air bag
22 Glove box
23 Controls for heating, ventila-tion, air conditioning and rearscreen and mirrors demisting
24 Front ashtray
25 Gear lever
26 Lighter
27 Electric mirrors switch 28
Electric windows switch
29 Handbrake
30 Retractable roof switch
* According to specification.
3YOUR AT A GLANCE

10YOUR AT A GLANCE
FRONT SEATS1 - Forwards/backwards
adjustment Lift the control and slide the seat forwards or backwards.
2 - Access to rear seats Place your fingers in one ofthe handles and pushforwards to fold the seat backand move the seat forwards.On repositioning, the seatreturns to its original position.
3 - Head restraint Height adjustment:
Ð to lift the head restraint,push it upwards;
Ð to lower it, press the lug and slide downwards.
The setting is correct when the upper edge of the headrestraint is level with the topof the head.
To remove the head restraint, press the lug.
4 - Seat back angle adjustment Push the control towards the
rear.
5 - Driver's seat height adjustment
Pull the control upwards. Remove your weight from the seat to raise, or press
on the seat to lower.
62

YOUR 206 CC IN DETAIL63
1 - Forwards-backwards adjustment
Lift the lever and slide the seat for- wards or backwards.
2 - Access to the rear seats Pull one of the two handles to folddown the seat back and move theseat forwards. On repositioning, the seat returnsto its initial position.
No person nor object must pre-vent the seat from returning to itsinitial position. Returning to thisposition is necessary for it to belocked.
3 - Adjusting the height and angle of the head restraint
To raise the head restraint, pull it upwards.
The setting is correct when theupper edge of the headrestraint is level with the top ofthe head.
The head restraint has a frame withnotches which prevents it from drop-ping down (safety device in case ofimpact).
To lower the head restraint you must simultaneously:
- press the knob on the left-hand side at its base,
- press downwards.
To remove the head restraint, press the lug.
4 - Adjusting the seat back angle Push one of the two controls
towards the rear.
5 - DriverÕs seat height adjustment Pull the handle upwards.Remove your weight from the seatto raise, or press on the seat
to lower.
6 - Heated seats control* Press the switch. The temperatureis controlled automatically for thetwo front seats.Pressing the switch again stopsoperation.
* According to specification.
Never drive with the head restraints removed. Theseshould be correctly fittedand adjusted.

YOUR 206 CC IN DETAIL
82
Headlamp adjustment
Depending on the load in your vehicle, it is recommended to adjust the headlampbeam.
0.
1 or 2 people in the front seats.
Ð. 3 people.
1. 4 people.
2. 4 people + maximum authorisedload.
3. Driver + maximum authorised load.
Initial setting is position 0. Steering wheel heightadjustment Lower the handle to unlock the steer- ing wheel. Adjust to the desired height and lift the handle to lock the steering wheel.
Horn
Press one of the spokes orthe centre of the steeringwheel.
