2001 NISSAN MAXIMA fuse box

Windshield wiper/washer switch (P.2-14)
Instrument brightness control switch (P.2-17)Meters/gauges (P.2-3)
Security indicator light (P.2-12)
Headlight, fog light (if so equipped)
and turn signal switch (P.2-16)
Outside mirror remote control (P.3-15)Fuse box cover (P.8-21)
Tilting steering wheel lock lever (P.3-13)Driver supplemental air bag (P.1-9)
Ignition switch/steering lock (P.5-4) Cruise control main/set switch (P.5-14)
Power outlet (P.2-21) or cigarette lighter (accessory) (P.2-22)Hazard warning flasher switch (P.2-19) Ventilator (P.4-2)
Heater/air conditioner control (P.4-3)
Clock (P.2-29)
Radio/cassette player (P.4-14)/CD player (P.4-19) Rear window and outside mirror (if so equipped) defogger switch (P.2-15)
Passenger supplemental air bag (P.1-9)
Glove box (P.2-24)
Tray (P.2-22) or ashtray (accessory) (P.2-22)
SIC1566
See the page indicated in parentheses for operating details.
Traction control system (TCS) cancel switch (if so equipped) (P.2-21)
Steering switch for audio control (if so equipped) (P.4-24)
INSTRUMENT PANEL2-2
Instruments and controls
Z
00.1.17/A33-D/V5.0
X

CAUTION
Never use a fuse of higher amperage
rating than that specified on the fuse
box cover. This could damage the elec-
trical system or cause a fire.
ENGINE COMPARTMENTIf any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and headlight
switch are OFF.
2. Open the engine hood.
3. Remove the fusible link cover.
4. Remove the fuse with the fuse puller.
5. If the fuse is open, replace it with a new
fuse.
6. If a new fuse also opens, have the electricalsystem checked and repaired by your
NISSAN dealer.
SDI0964
FUSES8-20
Do-it-yourself
Z
00.1.17/A33-D/V5.0
X

Fusible linksIf any electrical equipment does not operate
and fuses are in good condition, check the
fusible links. If any of these fusible links are
melted, replace only with genuine NISSAN
parts.
PASSENGER COMPARTMENTIf any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and the headlight
switch are OFF.
2. Pull to open the fuse box lid.
3. Remove the fuse with the fuse puller.
4. If the fuse is open, replace it with a new
fuse.
5. If a new fuse also opens, have the electrical
system checked and repaired by your
NISSAN dealer.
SDI0965
SDI0966
Do-it-yourself
8-21
Z
00.1.17/A33-D/V5.0
X

Filler lid ...................................................... 3-12
Filler lid and cap ........................................ 3-12
Filler lid opener lever................................. 3-12
Fuel economy ............................................ 5-16
Fuel octane rating ..................................... 10-3
Fuel recommendation................................ 10-3
Gauge .......................................................... 2-5
Fuses .............................................................. 8-20
Fusible links .................................................... 8-21
G
Garage door opener, Integrated HomeLink
Universal Transceiver ..................................... 2-32
Gas cap .......................................................... 3-12
Gauge ............................................................... 2-3
Engine coolant temperature gauge ............. 2-5
Fuel gauge .................................................. 2-5
Odometer..................................................... 2-4
Speedometer ............................................... 2-4
Tachometer ................................................. 2-4
General maintenance ................................ 9-2, 9-3
Glasses case .................................................. 2-23
Glove box........................................................ 2-24
Glove box lock ................................................ 2-24
H
Hazard warning flasher switch........................ 2-19
Head restraints ................................................. 1-7
Headlamps, (Bulb replacement) ..................... 8-24
Headlights
(Bulb replacement) .................................... 8-24Headlight switch ........................................ 2-16
Heated seats................................................... 2-20
Heater
Engine coolant heater ............................... 5-22
Heater and air conditioner controls ............. 4-3
Heater operation.......................................... 4-3
Heater operation, Semiautomatic air
conditioner ........................................................ 4-4
HomeLink
Universal Transceiver .................. 2-32
Hood, release ................................................... 3-9
Horn ................................................................ 2-19
How to stop alarm, Vehicle security
system............................................................. 2-13
I
Ignition switch ................................................... 5-4
Automatic transmission models .................. 5-4
Key positions ............................................... 5-6
Manual transmission models....................... 5-5
Immobilizer system ......................................... 2-13
Indicator lights and chimes (See warning/indicator
lights and chimes) ............................................. 2-9
Inside mirror .................................................... 3-14
Inspection/maintenance (I/M) test................. 10-21
Instrument panel ............................................... 2-2
Integrated HomeLink
Universal
Transceiver ..................................................... 2-32
Interior and cargo light .................................... 2-29
Interior light ..................................................... 2-29
Interior light replacement ................................ 8-25J
Jump starting .................................................... 6-7
K
Keyless entry, (See multi-remote control
system) ............................................................. 3-4
Keys .................................................................. 3-2
L
Label, Air conditioner specification label ...... 10-12
Label, Emission control information label ..... 10-11
Label, F.M.V.S.S. certification label.............. 10-11
Labels
Air bag warning labels............................... 1-19
Air conditioner specification label................ 4-3
Engine serial number .............................. 10-11
Vehicle identification number (VIN)......... 10-10
License plate, Installing front license plate... 10-13
Light
Air bag warning light ................................. 1-19
Bulb replacement ...................................... 8-23
Headlamps (Bulb replacement)................. 8-24
Headlight switch ........................................ 2-16
Headlights (Bulb replacement) .................. 8-24
Interior and cargo light .............................. 2-29
Interior light................................................ 2-29
Personal light............................................. 2-30
Replacement ............................................. 8-23
Trunk light.................................................. 2-32
Vanity mirror light ...................................... 2-31
Z
00.1.17/A33-D/V5.0
X
11-3
