2001 MAZDA MODEL TRIBUTE 4WD audio

Audio system(pg. 23)
4WD control*(pg. 19)
Climate controls (pg. 20)
Auxiliary power point
(pg. 54)
Rear window defroster
control
(pg. 19) Hazard flasher control
(pg. 19)
Instrumentation
7

USING YOUR AUDIO SYSTEM
AM/FM Radio with Compact Disc Player
Volume/power control
Ensure that the ignition switch is in
the ACC or ON position.
Press the control to turn the audio
system on. Turn the control to raise
or lower the volume.
Press the control again to turn the
audio system off.
NOTE:To prevent the battery from being discharged, do not leave the
audio system on for a long period when the engine is not running.
AM/FM select
The AM/FM control works in radio
mode.
AM/FM select in radio mode
This control allows you to select AM or FM frequency bands. Press the
control to toggle between AM, FM1 or FM2 memory preset stations. The
selected mode will be indicated in the display. If FM stereo is enabled,
ST will be illuminated in the display.
NOTE: If the FM broadcast signal becomes weak, reception
automatically changes from STEREO to MONO for reduced noise, and
the ST indicator will go out.
CLOCK
PUSH
POWER-VOL
AUDIODISC1RDM2RPT SCAN
AUTO
M
AM
FM CD H
M
TUNE
SEEK
TRACK345
DISC IN
PUSHPOWER-VOL
AM
FM
Controls and features
23

Scan function
The scan function works in radio
mode.
Scan function in radio mode
Press the SCAN control to hear a sampling of strong stations on the
frequency band. Each station will play for approximately 5 seconds.
Press the SCAN control again to remain on a station and disable this
mode.
CD select
²To begin CD play (if CD is
loaded), press the CD control, or
² Insert the compact disc, label side
up into the CD slot (if no CD is
loaded). The auto loading mechanism will pull in the CD. There will be
a short lapse before play begins.
² The first track of the disc will begin playing. The DISC IN control will
illuminate.
² The track number will appear in the display.
To disable CD mode, press the power/volume control.
Treble adjust
The treble adjust control allows you
to increase or decrease the audio
system's treble output.
Press the AUDIO control until TREB is illuminated in the display.
Turn the volume control to adjust to the desired level of treble.
NOTE: The volume can be adjusted without pressing the AUDIO
function control.
SCAN
CD
PUSHPOWER-VOL
+AUDIO
Controls and features
25

Bass adjust
The bass adjust control allows you
to increase or decrease the audio
system's bass output.
Press the AUDIO control until BASS is illuminated in the display.
Turn the volume control to adjust to the desired level of bass.
Speaker fade adjust
Speaker sound can be adjusted
between the front and rear
speakers.
Press the AUDIO control until FADE is illuminated in the display.
Turn the volume control to adjust the speaker output.
Speaker balance adjust
Speaker sound distribution can be
adjusted between the right and left
speakers.
Press the AUDIO control until BAL is illuminated in the display.
Turn the volume control to adjust the speakers.
NOTE:Approximately 5 seconds after selecting any AUDIO mode
(treble, bass, fade, balance or volume), the system will automatically
default to the volume function. To reset these modes, press and
momentarily hold the AUDIO control. The unit will beep and CL will
appear in the display.
PUSHPOWER-VOL
+AUDIO
PUSHPOWER-VOL
+AUDIO
PUSHPOWER-VOL
+AUDIO
Controls and features
26

Radio station memory preset
The radio is equipped with five station memory preset controls. These
controls can be used to select up to five preset AM stations and ten FM
stations (five in FM1 and five in FM2).
Setting memory preset stations
1. Select the frequency band with the AM/FM control.
2. Select the desired station.
3. Press and momentarily hold the desired preset control until a beep isheard.
The preset control number will illuminate in the display. This indicates
the station is held in memory on the control you selected. Repeat this
procedure to store other stations in memory.
Auto memory tuning
Auto memory tuning allows you to set strong radio stations without
losing your original manually set preset stations. This is especially useful
when you are in an area where the local stations are not known.
Starting auto memory tuning
1. Select a frequency using the AM/FM control.
2. Press and momentarily hold the AUTO M (auto memory)
control.
3. The audio system will select the five strongest stations on the frequency band. When the stations are filled, the station stored in
memory preset control 1 will start playing.
Press the AUTO M control to recall stations in the auto memory. One
station will be selected each time you press the AUTO M control and the
auto memory number will be displayed.
NOTE: If the power supply is interrupted (the fuse blows or the battery
is disconnected), the preset channels will be canceled.
Random play
The random play feature works in
CD mode and plays the selections
on the current CD in random order.
AUTO M
RDM2
Controls and features
27

3:24, the time will change to 3:00. If the clock's current time setting is
within the latter part of the hour (from 30 to 59 minutes), the hour
setting will automatically advance one hour. For example, if the original
setting is 3:45, the time will change to 4:00.
Changing the display mode
Press the CLOCK control to
alternate the display between time
and audio.
NOTE:If audio operation is selected while the time mode is on, the
selected audio mode will be displayed for 10 seconds, then the display
will revert to the time mode.
AM/FM Radio with Cassette and 6 Disc CD ChangerCLOCK
AM/FMTAPE CD
SCAN
12 3
45 6
LOAD
CLOCK
AUTO-M
PRO
RPT
RDM/BS
TR/APC TR/APC
FF
REW
TUNE
SEEK
DISC
PUSH
POWER VOLPUSH
AUDIO CONT
Controls and features
29

Volume/power control
Press the control to turn the audio
system on or off.
Turn the control to raise or lower
volume.
If the volume is set above a certain level and the ignition is turned off,
the volume will come back on at a ªnominalº listening level when the
ignition switch is turned back on.
If the ignition or power is turned off, the last function prior to turning
the power off (i.e., radio, CD or tape) will activate when the power is
restored.
AM/FM select
The AM/FM select control works in
radio, tape and CD modes.
AM/FM select in radio mode
This control allows you to select AM or FM frequency bands. Press the
control to switch between AM, FM1 or FM2 memory preset stations.
AM/FM select in tape mode
Press this control to stop tape play and begin radio play.
AM/FM select in CD mode
Press this control to stop CD play and begin radio play.
Tune/Seek/Disc function
The tune/seek/disc control works in radio or CD mode.
PUSH
POWER VOL
AM/FM
Controls and features
30

Treble adjust
The treble adjust control allows you
to increase or decrease the audio
system's treble output.
Press the AUDIO control twice to
access the system's treble adjust
mode.
Turn the control to increase (right)
or decrease (left) the amount of
treble output.
Bass adjust
The bass adjust control allows you
to increase or decrease the audio
system's bass output.
Press the AUDIO once to access the
system's bass adjust mode.
Turn the control to increase (right)
or decrease (left) the amount of
bass output.
Speaker fade adjust
Speaker sound can be adjusted
between the front and rear
speakers.
Press the AUDIO control three
times to access the system's fade
adjust mode.
Turn the control (right or left) to
adjust between the front and rear
speakers.
PUSH
AUDIO CONT
PUSH
AUDIO CONT
PUSH
AUDIO CONT
Controls and features
32
