2001 JEEP GRAND CHEROKEE Owners Manual

DRIVER DOOR MODULE C3 - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 BK MEMORY SWITCH RETURN
2 BR MEMORY SWITCH MUX
3 OR MEMORY SET INDICATOR DRIVER
4 GY SWITCH ILLUMINATION DRIVER
DRIVER FRONT DOOR COURTESY LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 M21 20PK/DG COURTESY LAMP DRIVER
2 L121 20BK/RD COURTESY LAMP GROUND
DRIVER FRONT POWER WINDOW MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Q21 16WT DRIVER WINDOW DRIVER (DOWN)
2 Q11 16LB DRIVER WINDOW DRIVER (UP)
DRIVER HEATED SEAT BACK (PREMIUM I/III)-3WAY
CAV CIRCUIT FUNCTION
1 P88 16BK/BR HEATED SEAT DRIVER
2 Z6 16BK/YL GROUND
3- -
8Wa - 80 - 56 8Wa-80 CONNECTOR PIN-OUTSWJ

DRIVER HEATED SEAT SWITCH - WHITE 6 WAY
CAV CIRCUIT FUNCTION
1 P133 20LG/RD DRIVER SEAT HEATER SWITCH MUX
2 E2 20OR PANEL LAMPS DRIVER
3 F22 20WT/PK FUSED IGNITION SWITCH OUTPUT (RUN)
4- -
5 Z1 20BK GROUND
6 P132 20OR/BK SEAT HEATER SWITCH SENSOR GROUND
DRIVER LUMBAR MOTOR (MIDLINE/PREMIUM) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 P105 16LG/DB LUMBAR FORWARD SWITCH SENSE
2 P104 16YL/RD LUMBAR REARWARD SWITCH SENSE
DRIVER LUMBAR SWITCH (MIDLINE/PREMIUM) - WHITE 6 WAY
CAV CIRCUIT FUNCTION
1- -
2 Z1 16BK GROUND
3 P105 16LG/DB (RHD) LUMBAR FORWARD SWITCH SENSE
3 P104 16YL/RD (LHD) LUMBAR REAR WARD SWITCH SENSE
4 P104 16YL/RD (RHD) LUMBAR REAR WARD SWITCH SENSE
4 P105 16LG/DB (LHD) LUMBAR FORWARD SWITCH SENSE
5 Z1 16BK GROUND
6 F35 16RD FUSED B(+)
WJ8Wa-80 CONNECTOR PIN-OUTS 8Wa - 80 - 57

DRIVER POWER SEAT FRONT RISER MOTOR SENSOR (PREMIUM II/III)-3WAY
CAV CIRCUIT FUNCTION
A P28 20BR/RD SEAT POSITION SENSOR GROUND
B P26 20BR FRONT RISER POSITION SIGNAL
C P29 20BR/WT SEAT SENSOR 5V SUPPLY
DRIVER POWER SEAT FRONT RISER MOTOR - RED 2 WAY
CAV CIRCUIT FUNCTION
1 P119 16YL/RD (PREMIUM II/III) SEAT FRONT UP DRIVER
1 P19 16YL/LG (EXCEPT PREMIUM II/III) DRIVER SEAT FRONT UP DRIVER
2 P121 16RD/GY (PREMIUM II/III) SEAT FRONT DOWN DRIVER
2 P21 16RD/LG (EXCEPT PREMIUM
II/III)DRIVER SEAT FRONT DOWN DRIVER
DRIVER POWER SEAT HORIZONTAL MOTOR SENSOR (PREMIUM II/III) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
A P29 20BR/WT SEAT SENSOR 5V SUPPLY
B P25 20VT/RD SEAT HORIZONTAL POSITION SIGNAL
C P28 20BR/RD SEAT POSITION SENSOR GROUND
DRIVER POWER SEAT HORIZONTAL MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 P17 16RD/YL (EXCEPT PREMIUM
II/III)DRIVER SEAT HORIZONTAL REARWARD DRIVER
1 P117 16RD/BR (PREMIUM II/III) SEAT HORIZONTAL REARWARD DRIVER
2 P15 16YL/LB (EXCEPT PREMIUM II/III) DRIVER SEAT HORIZONTAL FORWARD DRIVER
2 P115 16GY/G (PREMIUM II/III) SEAT HORIZONTAL FORWARD DRIVER
8Wa - 80 - 58 8Wa-80 CONNECTOR PIN-OUTSWJ

DRIVER POWER SEAT REAR RISER MOTOR - RED 2 WAY
CAV CIRCUIT FUNCTION
1 P11 16YL/WT (EXCEPT PREMIUM
II/III)DRIVER SEAT REAR UP DRIVER
1 P111 16YL/DB (PREMIUM II/III) SEAT REAR UP DRIVER
2 P13 16RD/WT (EXCEPT PREMIUM
II/III)DRIVER SEAT REAR DOWN DRIVER
2 P113 16RD/BK (PREMIUM II/III) SEAT REAR DOWN DRIVER
DRIVER POWER SEAT RECLINER MOTOR SENSOR (PREMIUM II/III) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
A P29 20BR/WT SEAT SENSOR 5V SUPPLY
B P47 20LB RECLINER POSITION SIGNAL
C P28 20BR/RD SEAT POSITION SENSOR GROUND
DRIVER POWER SEAT RECLINER MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A P41 16GY/WT (EXCEPT PREMIUM
II/III)DRIVER SEAT RECLINER DOWN DRIVER
A P141 16GY/WT (PREMIUM II/III) SEAT RECLINER DOWN DRIVER
B P43 16GY/LB (EXCEPT PREMIUM
II/III)DRIVER SEAT RECLINER UP DRIVER
B P143 16GY/LB (PREMIUM II/III) SEAT RECLINER UP DRIVER
DRIVER POWER SEAT SWITCH (MIDLINE/PREMIUM) - GREEN 10 WAY
CAV CIRCUIT FUNCTION
1 Z1 16BK GROUND
2 P43 16GY/LB (MIDLINE/PREMIUM I) DRIVER SEAT RECLINER UP DRIVER
2 P43 20GY/LB (PREMIUM II/III) RECLINER UP SWITCH SENSE
3 P17 16RD/YL (MIDLINE/PREMIUM I) DRIVER SEAT HORIZONTAL REARWARD DRIVER
3 P17 20RD/YL (PREMIUM II/III) DRIVER SEAT HORIZONTAL REARWARD SWITCH
SENSE
4 P41 16GY/WT (MIDLINE/PREMIUM I) DRIVER SEAT RECLINER DOWN DRIVER
4 P41 20GY/WT (PREMIUM II/III) RECLINER DOWN SWITCH SENSE
WJ8Wa-80 CONNECTOR PIN-OUTS 8Wa - 80 - 59

DRIVER REAR POWER WINDOW MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Q124 16DG/WT WINDOW DRIVER (DOWN)
2 Q114 16GY/WT WINDOW DRIVER (UP)
DRIVER REAR POWER WINDOW SWITCH - BLUE 6 WAY
CAV CIRCUIT FUNCTION
1 Q14 16GY DRIVER REAR WINDOW DRIVER UP
2 Q114 16GY/WT WINDOW DRIVER UP
3 E21 20OR/RD DRIVER REAR DOOR SWITCH ILLUMINATION
4 Q24 16DG DRIVER REAR WINDOW DRIVER DOWN
5 Q124 16DG/WT WINDOW DRIVER DOWN
6 Z1 16BK GROUND
EGR SOLENOID (DIESEL) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
A F15 18DB/WT FUSED AUTOMATIC SHUT DOWN RELAY OUTPUT
B K35 18GY/YL EGR SOLENOID CONTROL
C- -
D Z1 18BK GROUND
8Wa - 80 - 60 8Wa-80 CONNECTOR PIN-OUTSWJ

ELECTRONIC SPEED CONTROL SERVO - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 V36 20TN/RD (RHD/GAS) SPEED CONTROL VACUUM SOLENOID CONTROL
1 V36 18TN/RD (LHD DIESEL) SPEED CONTROL VACUUM SOLENOID CONTROL
2 V35 20LG/RD (RHD/GAS) SPEED CONTROL VENT SOLENOID CONTROL
2 V35 18LG/RD (LHD DIESEL) SPEED CONTROL VENT SOLENOID CONTROL
3 V30 20DB/RD SPEED CONTROL BRAKE SWITCH OUTPUT
4 Z1 20BK GROUND
ENGINE CONTROL MODULE C1 (DIESEL) - GRAY 52 WAY
CAV CIRCUIT FUNCTION
1 Z12 14BK/TN GROUND
2 A142 14DG/OR AUTOMATIC SHUT DOWN RELAY OUTPUT
3- -
4- -
5 C13 18DB/OR A/C COMPRESSOR CLUTCH RELAY CONTROL
6 K159 16GY ENGINE SPEED SENSOR SIGNAL
7- -
8 C90 18LG A/C SWITCH SIGNAL
9 K29 18WaT/PK SECONDARY BRAKE SWITCH SENSE
10 C18 18DB A/C PRESSURE SIGNAL
11 K440 18VT/WT 5V SUPPLY
12 K151 18WaT/RD LOW IDLE POSITION SWITCH SENSE
13 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
14 - -
15 - -
16 - -
17 - -
18 G8 18LB/BK FUEL MONITOR SIGNAL
19 - -
20 L50 18WaT/TN PRIMARY BRAKE SWITCH SIGNAL
21 - -
22 - -
23 K255 18WaT/DB ACCELERATOR PEDAL POSITION SENSOR SIGNAL
24 K167 18BR SENSOR GROUND (ECM)
25 - -
26 - -
27 Z12 14BK/TN GROUND
28 A142 14DG/OR AUTOMATIC SHUT DOWN RELAY OUTPUT
29 K35 18GY/YL EGR SOLENOID CONTROL
WJ8Wa-80 CONNECTOR PIN-OUTS 8Wa - 80 - 61

ENGINE CONTROL MODULE C2 (DIESEL) - GRAY 28 WAY
CAV CIRCUIT FUNCTION
53 K156 18GY FUEL TEMPERATURE SENSOR SIGNAL
54 K2 18TN/BK ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
55 K68 18LG/YL NEEDLE MOVEMENT SENSOR SIGNAL
56 K134 18LB/BK REFERENCE COIL
57 K57 18LG/OR CONTROL SLEEVE POSITION SENSOR SIGNAL
58 K135 18WaT/BK MEASURE COIL
59 K140 18TN/WT FUEL QUANTITY ACTUATOR CONTROL
60 - -
61 K121 18BK/VT FUEL TEMPERATURE SENSOR GROUND
62 K67 18BR/BK NEEDLE MOVEMENT SENSOR GROUND
63 - -
64 - -
65 - -
66 K140 18TN/WT FUEL QUANTITY ACTUATOR CONTROL
67 K24 18GY/BK ENGINE SPEED SENSOR SIGNAL
68 - -
69 Z3 18BK/OR GROUND
70 - -
71 - -
72 - -
73 - -
74 - -
75 - -
76 - -
77 K153 18OR FUEL SHUT DOWN SOLENOID CONTROL
78 - -
79 K238 18VT FUEL TIMING SOLENOID CONTROL
80 K140 18TN/WT FUEL QUANTITY ACTUATOR CONTROL
8Wa - 80 - 62 8Wa-80 CONNECTOR PIN-OUTSWJ

ENGINE COOLANT TEMPERATURE SENSOR - ECM (DIESEL)-2WAY
CAV CIRCUIT FUNCTION
1 K2 18TN/BK ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
2 K121 18BK/VT SENSOR GROUND
ENGINE COOLANT TEMPERATURE SENSOR - PCM (DIESEL)-2WAY
CAV CIRCUIT FUNCTION
1 K222 18TN/RD ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
ENGINE OIL PRESSURE SENSOR - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K6 18VT/BK (GAS) 5V SUPPLY
1 K6 18VT/WT (DIESEL) 5V SUPPLY
2 G60 18GY/YL ENGINE OIL PRESSURE SENSOR SIGNAL
3 K4 18BK/LB SENSOR GROUND
ENGINE SPEED SENSOR (DIESEL) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z3 18BK/OR GROUND
2- -
3 K24 18GY/BK ENGINE SPEED SENSOR SIGNAL
WJ8Wa-80 CONNECTOR PIN-OUTS 8Wa - 80 - 63
