2001 GMC ENVOY clock

6-39 One-Piece Front Turn Signal
Lamp Assembly
1. Remove the headlamp assembly as shown under
ªOne
-Piece Composite Headlamp Systemº earlier
in this section.
2. Twist the bulb socket to
remove it from the
headlamp assembly.3. Pull the bulb straight out to remove it from
the socket.
4. Push the new bulb into the socket until it snaps
into place.
5. Put the bulb socket into the lamp assembly and turn
it clockwise until it is tight.
6. Put the headlamp assembly back into the vehicle.
Install the two retaining clips.
7. Install the two retaining clips.
ProCarManuals.com

6-40 Two-Piece Front Turn Signal
Lamp Assembly
1. Remove the headlamp assembly as shown under
ªTwo
-Piece Composite Headlamp Systemº earlier
in this section.
2. Locate the locking tabs
on the assembly.
Squeeze the tabs
together and push that
end of the assembly out
while holding the tabs.
The assembly will
swing out.
3. Unplug the electrical connector.
4. Turn the harness bulb socket counterclockwise to
remove it.
5. Pull the bulb straight out to remove it from the socket.
6. Push the new bulb into the socket until it snaps into place.
7. Reinstall the harness bulb socket with the new bulb
into the headlamp assembly and turn it clockwise
until it is tight.
8. To reinstall the assembly, snap the outboard end of
the lamp assembly back into the vehicle. Then swing
the assembly in and snap it into place.
9. Install the two retaining clips.
ProCarManuals.com

6-41 Taillamps
1. Open the endgate/liftgate.
2. Remove the two screws
from the lamp assembly.3. Pull the assembly away from the vehicle.
4. Turn the socket counterclockwise to remove it.
Push the tab in while you turn the
socket counterclockwise.
5. Holding the base of the bulb, pull the bulb straight
out of the socket.
6. Push the new bulb straight into the socket until
it clicks.
7. Put the socket into the assembly and turn the socket
clockwise until it locks in place.
8. Install the lamp assembly and tighten the screws.
9. Close the endgate/liftgate.
ProCarManuals.com

6-64 Instrument Panel Fuse Block
The instrument panel fuse
block is located at the
driver's end of the
instrument panel.
Remove the cover by turning the fastener
counterclockwise. Extra fuses and the fuse extractor are
provided in the cover. To reinstall the fuse panel cover,
push in and turn the fastener clockwise.
Fuse/Circuit
BreakerUsage
A Not Used
B Not Used
1 Not Used
2 Cigarette Lighter,
Data Link Connector
ProCarManuals.com

6-66 Engine Compartment Fuse Block
The fuse block is located under the hood at the
driver's side of the engine compartment. See ªEngine
Compartment Overviewº in the Index for more
information on location. Before using this fuse block
picture and chart, check to see that it matches the fuse
block in your vehicle. If the fuse block pictured here is
different than your vehicle's, use the fuse block picture
and chart located later in this section.
Remove the cover by turning the fastener
counterclockwise. To reinstall the fuse panel cover,
push in and turn the fastener clockwise.
ProCarManuals.com

6-69 Engine Compartment Fuse Block
(Vehicles with HID Headlamps)
The fuse block is located under the hood at the driver's
side of the engine compartment. See ªEngine
Compartment Overviewº in the Index for more
information on location. Before using this fuse block
picture and chart, check to see that it matches the fuse
block in your vehicle. If the fuse block pictured here is
different than your vehicle's, use the fuse block picture
and chart located earlier in this section.
Remove the cover by turning the fastener
counterclockwise. To reinstall the fuse panel cover,
push in and turn the fastener clockwise.
