2001 CHEVROLET MALIBU Owners Manual

2-64 Cruise Light (If Equipped)
The CRUISE light comes
on whenever you set your
cruise control.
Low Washer Light
The LOW WASH light will
come on briefly when you
turn on the ignition.
It will also stay on or come on and chime, if the fluid
reservoir is less than one
-third full.

2-65 Service Vehicle Soon Light
This light will come on
briefly when you turn
on the ignition.
It will stay on or come on and chime if it detects a
problem on the vehicle, such as a Daytime Running
Lamp (DRL) or an Automatic Light Control (ALC)
malfunction. If this happens, see your dealer service
department as soon as possible.
Door Ajar Light
When the ignition is on,
this light will stay on until
all doors are closed and
completely latched.
You will hear a chime if a door is unlatched after the
engine is started and the vehicle is not in PARK (P)
or NEUTRAL (N).

2-66 Fuel Gage
United States Canada
Your fuel gage tells you about how much fuel you have
left, when the ignition is on. When the indicator nears
empty, the light, located near the empty symbol, will
come on and you will hear a chime. You still have a
little fuel left, but you should get more soon.Here are four things that some owners ask about. None
of these show a problem with your fuel gage:

At the service station, the gas pump shuts off before
the gage reads full.

It takes a little more or less fuel to fill up than the
gage indicated. For example, the gage may have
indicated the tank was half full, but it actually took a
little more or less than half the tank's capacity to fill
the tank.

The gage moves a little when you turn a corner or
speed up.

The gage goes back to empty when you turn off
the ignition.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Climate Control System with
Air Conditioning
3
-4 Air Conditioning
3
-4 Heating
3
-5 Defogging and Defrosting Windows
3
-6 Rear Window Defogger
3
-6 Ventilation System
3
-7 Audio Systems
3
-7 Setting the Clock for Systems without Radio
Data System
3
-8 Setting the Clock for Systems with Radio
Data System
3
-8AM-FM Stereo
3
-11 AM-FM Stereo with Cassette Tape Player
with Radio Data System (RDS) and Automatic
Tone Control (If Equipped)3
-20 AM-FM Stereo with Compact Disc Player
with Radio Data System (RDS) and Automatic
Tone Control (If Equipped)
3
-27 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Radio Data
System (RDS) and Automatic Tone
Control (If Equipped)
3
-38 Personal Choice Radio Controls (If Equipped)
3
-38 Theft-Deterrent Feature
3
-39 Understanding Radio Reception
3
-39 Tips About Your Audio System
3
-40 Care of Your Cassette Tape Player
3
-41 Care of Your Compact Discs
3
-41 Care of Your Compact Disc Player
3
-41 Fixed Mast Antenna
3
-41 Chime Level Adjustment

3-2
Comfort Controls
This section tells you how to make your air system work
for you.
With this system, you can control the ventilation and
heating in your vehicle. Your vehicle also has the
flow
-through ventilation system described later in
this section.
Climate Control System with
Air Conditioning
Fan Knob
The left knob selects the force of air you want.
Turn the knob clockwise to increase fan speed or
counterclockwise to decrease fan speed. To turn the fan
off (which will also turn the climate control system off),
turn the knob all the way counterclockwise. In any
other setting, the fan will run continuously with the
ignition on. The fan must be on to run the air
conditioning compressor.
Temperature Knob
The center knob controls the temperature of the air
coming through the system. Turn it counterclockwise
(toward the blue area) for cooler air. Turn it clockwise
(toward the red area) for warmer air.
Mode Knob
The right knob selects the location of where the air will
enter the vehicle. The available modes are the following:
UPPER: In this position most of the air comes
through the instrument panel outlets. A small amount
of air comes through the floor outlets.

3-3
BI-LEVEL: In this position the air comes
through the instrument panel outlets and through the
floor outlets.
FLOOR: In this position most of the air comes
through the floor outlet. The rest of the air comes
through the windshield and side window outlets.
DEFOG: This position divides the air between
the floor outlets and the windshield defroster outlet.
The air conditioning compressor will run automatically
in this position when it is needed to help dry the air in
the vehicle.
DEFROST: This position directs most of the air
through the windshield defroster outlet. Some of the air
goes to the floor outlets. The air conditioning
compressor will run automatically in this position when
it is needed to help dry the air in the vehicle.
Mode Buttons
A/C: Press A/C to operate the air conditioner
compressor. The indicator light will glow when the
button is pressed to indicate that the air conditioning
system has been requested.
OUTSIDE AIR: Press this button to allow the
circulation of outside air in the vehicle. The indicator
light on the button will glow when pressed. OUTSIDE
AIR is available in all modes including OFF. OUTSIDE
AIR is the default setting and is automatically activated
in DEFOG and DEFROST or when turning the climate
control system on or turning the ignition switch from
OFF to ON.
Pressing this button will cancel the
RECIRCULATION button.
RECIRCULATION: Press this button to limit
the amount of outside air entering your vehicle. This is
also helpful when you are trying to limit odors entering
your vehicle. The indicator light on the button will glow
when it is pressed. RECIRCULATION is available in all
modes, except DEFOG and DEFROST.
Pressing this button will cancel the
OUTSIDE AIR button.
It is not recommended to use this button in the FLOOR
mode with heat. It is useful to quickly cool the vehicle
on hot days.

3-4 Air Conditioning
The air conditioner and heater work best if you keep
your windows closed while using them. Your vehicle
also has the flow
-through ventilation system described
later in this section.
For normal cooling on hot days, after the vehicle has
started to cool down, use UPPER with the temperature
knob in the blue area and the A/C button pushed in.
The system will bring in outside air and cool it.
On very hot days, open the windows long enough to
let hot inside air escape. This reduces the time it takes
for your vehicle to cool down, which should help
fuel economy.
For quicker cool
-down on very hot days, use UPPER
with the temperature knob all the way in the blue area
and the A/C and RECIRCULATION buttons pressed.
If this setting is used for long periods of time, the air in
your vehicle may become too dry.
On cool, but sunny days, the sun may warm your upper
body, but your lower body may not be warm enough.
You can use BI
-LEVEL with the temperature knob in
the middle and the A/C button pushed in. The system
will bring in outside air and direct slightly warmer air to
your lower body.
Heating
On cold days, use FLOOR and the OUTSIDE AIR
button with the temperature knob all the way in the red
area. The system will bring in outside air, heat it and
send it to the floor outlets.
Your vehicle has heat ducts that are directed toward
the rear seat. Keep the area under the front seats clear
of obstructions so the heated air can reach the rear
seat passengers.
If your vehicle has an engine coolant heater, you can use
it to help your system provide warm air faster when it's
cold outside (0
F (
-18
C) or lower). An engine coolant
heater warms the coolant your engine and heating
system uses to provide heat. See ªEngine Coolant
Heaterº in the Index.

3-5 Defogging and Defrosting Windows
Your system has two settings for clearing the front and
side windows. For each setting, adjust the temperature
control as desired.
To defrost the front window quickly, turn the temperature
knob all the way in the red area. Use DEFROST and
adjust the fan to the highest speed. To warm passengers
while keeping the front window clean, use DEFOG.
If you select RECIRCULATION while in UPPER,
BI
-LEVEL or FLOOR modes, humid air can recirculate
inside the vehicle and allow moisture to form on the
windows. If this happens, select either the DEFOG or
DEFROST mode.Your vehicle is equipped with side window defogger
vents. The side window defogger outlets are located on
the outside of the side instrument panel vents. To defrost
the side windows, turn the temperature knob all the way
in the red area. Use FLOOR and adjust the fan to the
highest speed. To control fogging of the windows, turn
the temperature knob all the way in the red area. Use
DEFOG and adjust the fan to the highest speed.
To DEFOG the side windows while using air
conditioning, use BI
-LEVEL and adjust the fan to the
highest speed and press the A/C button. For additional
airflow to the side windows, aim the side outlets toward
the windows and close the center outlets.
RECIRCULATION will not work in DEFOG or
DEFROST. This is done to prevent recirculation of
humid inside air and allow the system to work properly.
The system will automatically default to OUTSIDE AIR
when DEFOG or DEFROST is selected.
