2001 CHEVROLET IMPALA light

2-69
HomeLink
Transmitter (Option)
The HomeLink Transmitter allows you to consolidate
the functions of up to three individual hand
-held
transmitters. It will operate garage doors and gates, or
with the accessory package, other devices controlled by
radio frequency such as home/office lighting systems
and security systems.
The HomeLink Transmitter will learn and transmit the
frequencies of most current transmitters and is powered
by the battery and charging system.This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired operation of
the device.
Changes and modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.

2-70 Programming the HomeLink

Transmitter
Do not use the transmitter with any garage door opener
that does not have the ªstop and reverseº feature. This
includes any garage door opener model manufactured
before April 1, 1982.
Be sure that people and objects are clear of the garage
door you are programming!
The engine should be turned off while programming the
HomeLink Transmitter. Follow these steps to program
up to three channels:
1. If you have not previously programmed a universal
channel, proceed to Step 2. Otherwise, hold down
the two outside buttons on the HomeLink
Transmitter until the indicator light begins to flash
rapidly (approximately 20 seconds). Then release the
buttons. This procedure initializes the memory and
erases any previous settings for all three channels.2. Hold the end of the hand
-held transmitter
approximately one to three inches (three to eight cm)
away from the HomeLink Transmitter making sure
that you can still see the display.
3. Decide which one of the three channels you want to
program. Using both hands, press the hand
-held
transmitter button and the desired button on the
HomeLink Transmitter. Continue to hold both
buttons through Step 4.
4. Hold down both buttons until you see the indicator
light on the HomeLink Transmitter flash, first slowly
then rapidly. The rapid flashing, which could take
up to 90 seconds, indicates that the HomeLink
Transmitter has been programmed. Release both
buttons once the light starts to flash rapidly.

2-71
Canadian Programming: During programming, your
hand
-held transmitter may automatically stop
transmitting. Continue to press and hold the HomeLink
button while you press your hand
-held transmitter
button every two seconds until the HomeLink
Transmitter has been programmed. The indicator light
will flash slowly and then rapidly after several seconds
once it has been successfully programmed.
If you have trouble programming the HomeLink
Transmitter, make sure that you have followed the
directions exactly as described and that the battery in the
hand
-held transmitter is not dead. If you still cannot
program it, flip the hand
-held transmitter end over end
and try again. The HomeLink Transmitter may not work
with older garage door openers that do not meet current
Federal Consumer Safety Standards. If you cannot
program the transmitter after repeated attempts, consult
your dealer.
Be sure to keep the original hand
-held transmitter
in case you need to erase and reprogram the
HomeLink Transmitter.
Operating the Transmitter
Press and hold the appropriate button on the
HomeLink
Transmitter. The house symbol
comes on while the signal is being transmitted.
The effective transmission range of the HomeLink
Transmitter may differ from the hand
-held transmitter
and from one channel to another.

2-72 Training a Garage Opener with a ªRolling
Codeº Feature
If you programmed the HomeLink
Transmitter, but the
garage door will not open, and if your garage door opener
was manufactured after 1995, your garage door may have
a security feature that changes the ªcodeº of your garage
door opener every time it is opened or closed.
To determine if your garage door opener has this ªrolling
codeº feature, press the appropriate button on the
HomeLink Transmitter that was programmed. If the
indicator light flashes rapidly for one or two seconds, then
turns solid, your garage door opener has this feature.
To program a garage door opener with the rolling code
feature, do the following:
1. Program your hand
-held transmitter to the
HomeLink Transmitter by following the steps
provided under ªProgramming the Transmitterº
earlier in this section.
Because of the steps involved, it may be helpful
to have another person available to assist you in
programming the transmitter.2. Remove the cover panel from the garage door
opener receiver. It is located near the garage door
opener motor.
3. Locate the training button on the garage door opener
receiver. The exact location and color will vary
among brands.
4. Press the training button on the garage door opener
receiver. This will activate the training light.
5. Within thirty seconds of pressing the training button,
return to your vehicle and press the programmed
button on the HomeLink Transmitter until the
indicator light flashes rapidly (about two seconds).
6. Release the button, then press it again to confirm it
was programmed to the garage door opener receiver.
It may take more than one attempt to confirm that
the transmitter was programmed.
You may now use either the HomeLink Transmitter or
the hand
-held transmitter to open your garage door.
If you still have difficulty in programming and require
assistance, please call 1
-800-355-3515.

2-73
Erasing Channels
To erase all three programmed channels, hold down the
two outside buttons until the indicator light begins to
flash. Individual channels cannot be erased, but can be
reprogrammed using the procedure for programming
the transmitter explained earlier.
Accessories
Accessories for the HomeLink
Transmitter
are available from the manufacturer of the unit.
If you would like additional information, please
call 1
-800-355-3515.

2-79
Warning Lights, Gages
and Indicators
This part describes the warning lights and gages that
may be on your vehicle. The pictures will help you
locate them.
Warning lights and gages can signal that something is
wrong before it becomes serious enough to cause an
expensive repair or replacement. Paying attention to
your warning lights and gages could also save you or
others from injury.
Warning lights come on when there may be or is a
problem with one of your vehicle's functions. As you
will see in the details on the next few pages, some
warning lights come on briefly when you start the
engine just to let you know they're working. If you are
familiar with this section, you should not be alarmed
when this happens.
Gages can indicate when there may be or is a problem
with one of your vehicle's functions. Often gages and
warning lights work together to let you know when
there's a problem with your vehicle.When one of the warning lights comes on and stays on
when you are driving, or when one of the gages shows
there may be a problem, check the section that tells you
what to do about it. Please follow this manual's advice.
Waiting to do repairs can be costly
-- and even
dangerous. So please get to know your warning lights
and gages. They're a big help.
Your vehicle may also have a driver information center
that works along with the warning lights and gages.
See ªDriver Information Centerº in the Index.
Safety Belt Reminder Light
When the key is turned to ON, a chime will come on
for about eight seconds to remind people to fasten
their safety belts, unless the driver's safety belt is
already buckled.
The safety belt light will
also come on and stay on
for about 20 seconds,
then it will flash for about
55 seconds.

2-80 Air Bag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows the air bag symbol. The system
checks the air bag's electrical system for malfunctions.
The light tells you if there is an electrical problem.
The system check includes the air bag sensors, the
air bag modules, the wiring and the crash sensing and
diagnostic module. For more information on the air bag
system, see ªAir Bagº in the Index.
This light will come on
when you start your vehicle,
and it will flash for a few
seconds. Then the light
should go out. This means
the system is ready.
If the air bag readiness light stays on after you start the
vehicle or comes on when you are driving, your air bag
system may not work properly. Have your vehicle
serviced right away.
CAUTION:
If the air bag readiness light stays on after you
start your vehicle, it means the air bag system
may not be working properly. The air bags in
your vehicle may not inflate in a crash, or they
could even inflate without a crash. To help avoid
injury to yourself or others, have your vehicle
serviced right away if the air bag readiness light
stays on after you start your vehicle.
The air bag readiness light should flash for a few
seconds when you turn the ignition key to ON. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.

2-81
Brake System Warning Light
Your vehicle's hydraulic brake system is divided into
two parts. If one part isn't working, the other part can
still work and stop you. For good braking, though, you
need both parts working well.
If the warning light comes on, there is a brake problem.
The LOW BRAKE FLUID message in the message
center will also appear when there is a brake problem.
See ªLow Brake Fluid Messageº in the Index.
Have your brake system inspected right away.
United States Canada
This light should come on briefly when you turn the
ignition key to ON. If it doesn't come on then,
have it fixed so it will be ready to warn you if there's
a problem.If the light comes on while you are driving, pull off the
road and stop carefully. You may notice that the pedal is
harder to push. Or, the pedal may go closer to the floor.
It may take longer to stop. If the light is still on, have
the vehicle towed for service. See ªAnti
-Lock Brake
System Warning Lightº and ªTowing Your Vehicleº
in the Index.
CAUTION:
Your brake system may not be working properly
if the brake system warning light is on. Driving
with the brake system warning light on can lead
to an accident. If the light is still on after you've
pulled off the road and stopped carefully, have
the vehicle towed for service.
When the ignition is on, the brake system warning light
will also come on when you set your parking brake.
The light will stay on if your parking brake doesn't
release fully. If it stays on after your parking brake is
fully released, it means you have a brake problem.
