2001 CHEVROLET IMPALA ECO mode

2-28
3. Press the DISP button to start programming. When
the message PUSH FOB flashes, press and hold the
LOCK and UNLOCK buttons on the first transmitter
at the same time for 15 seconds. A chime will be
heard to verify the transmitter is learned.
4. Repeat Step 3 for each additional transmitter.
The transmitter is programmed now. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
EXIT (Exit Feature Customization Mode): This
feature allows you to exit the vehicle customization
programming. To exit do the following:

Scroll until EXIT appears on the display.

Press the DISP button to exit programming.
A chime will be heard to verify the exit.Passlock
Your vehicle is equipped with the Passlock
theft
-deterrent system.
Passlock is a passive theft
-deterrent system. Passlock
enables fuel if the ignition lock cylinder is turned with a
valid key. If a correct key is not used or the ignition lock
cylinder is tampered with, fuel is disabled and the
engine will not start.
During normal operation, the SECURITY message will
be displayed after the key is turned to the ON ignition
position. See ªMessage Center, Securityº in the Index.
If the engine stalls and the SECURITY message flashes,
wait until the light stops flashing before trying to restart
the engine.
If the engine is running and the SECURITY message
comes on, you will be able to restart the engine if you turn
the engine off. However, your Passlock system is not
working properly and must be serviced by your dealer.
Your vehicle is not protected by Passlock at this time. You
may also want to check the fuse (see ªFuses and Circuit
Breakersº in the Index). See your dealer for service.
In an emergency, contact Chevrolet Roadside
Assistance. See ªRoadside Assistanceº in the Index for
more information.

2-56 Delayed Entry Lighting
Delayed entry lighting illuminates the interior for a
period of time after all the doors have been closed.
The ignition must be off for delayed entry lighting to
work. Immediately after all the doors have been closed,
the delayed entry lighting feature will continue to work
until one of the following occurs:

The ignition is in ON,

the doors are locked or

an illumination period of 25 seconds has elapsed.
If during the illumination period a door is opened,
the timed illumination period will be canceled and the
interior lamps will remain on because a door is open.
Delayed Exit Lighting
This feature illuminates the interior for a period
of time after the key is removed from the ignition.
The ignition must be off for delayed exit lighting to
work. When the key is removed, interior illumination
will activate and remain on until one of the
following occurs:

The ignition is in ON,

the power door locks are activated or

an illumination period of 25 seconds has elapsed.If during the illumination period a door is opened, the
timed illumination period will be canceled and the
interior lamps will remain on because a door is open.
Parade Mode
The instrument panel has an added feature called parade
mode. This feature prohibits the dimming of your
instrument panel displays during the daylight while
the headlamps are on so that you'll still be able to see
the displays.
Rearview Mirror Reading Lamps
Use the switch next to each lamp to turn them on
and off.
Reading Lamps (If Equipped)
The reading lamps are located on the assist handles in
the headliner. These lamps and the interior courtesy
lamps come on when any door is opened. Press the lens
to turn them on. Press it again to turn them off.
Dome Lamp
The dome lamp will come on when you open a door.
You can also turn this lamp on by turning the headlamp
knob clockwise as far as it will go.

2-70 Programming the HomeLink

Transmitter
Do not use the transmitter with any garage door opener
that does not have the ªstop and reverseº feature. This
includes any garage door opener model manufactured
before April 1, 1982.
Be sure that people and objects are clear of the garage
door you are programming!
The engine should be turned off while programming the
HomeLink Transmitter. Follow these steps to program
up to three channels:
1. If you have not previously programmed a universal
channel, proceed to Step 2. Otherwise, hold down
the two outside buttons on the HomeLink
Transmitter until the indicator light begins to flash
rapidly (approximately 20 seconds). Then release the
buttons. This procedure initializes the memory and
erases any previous settings for all three channels.2. Hold the end of the hand
-held transmitter
approximately one to three inches (three to eight cm)
away from the HomeLink Transmitter making sure
that you can still see the display.
3. Decide which one of the three channels you want to
program. Using both hands, press the hand
-held
transmitter button and the desired button on the
HomeLink Transmitter. Continue to hold both
buttons through Step 4.
4. Hold down both buttons until you see the indicator
light on the HomeLink Transmitter flash, first slowly
then rapidly. The rapid flashing, which could take
up to 90 seconds, indicates that the HomeLink
Transmitter has been programmed. Release both
buttons once the light starts to flash rapidly.

2-78 Speedometer and Odometer
Your speedometer lets you see your speed in both miles
per hour (mph) and kilometers per hour (km/h). Your
odometer shows how far your vehicle has been driven in
either miles (used in the United States) or in kilometers
(used in Canada).
Your vehicle has a tamper
-resistant odometer. If you see
ERROR, you'll know someone has probably tampered
with it and the numbers may not be accurate.
You may wonder what happens if your vehicle needs a
new odometer installed. If the new one can be set to the
mileage total of the old odometer, then that will be done.
But if it can't, then it will be set at zero and a label must
be put on the driver's door to show the old mileage
reading when the new odometer was installed.
Trip Odometer
Your trip odometer tells how far you have driven since
you last reset it.
Your trip/select reset switch will go back and forth
between the odometer and the trip odometer if the
button is pressed and released within 1.5 seconds. If the
button is pressed and held for longer than 1.5 seconds
while in the trip odometer mode, it will be reset to zero.If the button is pressed and held for longer than
1.5 seconds while in the odometer mode, it will
have no effect.
Your trip odometer will work no matter what position
your key is in, and even if the key isn't in.Tachometer (If Equipped)
The tachometer displays the
engine speed in thousands
of revolutions per minute
(rpm). (3800 V6 engine
cluster tachometer shown.)
NOTICE:
Do not operate the engine with the tachometer in
the shaded area, or engine damage may occur.

2-89
Modes
Service Traction System (If Equipped)
United States Canada
If this message appears when you are driving, there is a
problem with your traction control system and your
vehicle is in need of service.
When this message is displayed, the system will
not limit wheel spin. The message will stay on for
60 seconds and then go out. Four chimes will also
be heard. Adjust your driving accordingly.
When the ignition is turned off, this message will be
displayed again for three seconds to remind you that
your traction control system is not working properly.
Be sure to have your vehicle serviced right away.Traction Active (If Equipped)
United States Canada
This message will appear when the traction control
system is limiting wheel spin.
The message will stay on a few seconds after the
traction system stops limiting wheel spin.

2-98
RESET (Reset Button):

You can reset the AVG ECON, FUEL USED or
AVG SPEED trip computer modes by pressing and
holding this button for three seconds while you are
in the mode you wish to reset. A chime will sound
to confirm that your requested change has been
made and all the segments of the display will briefly
light up.
To change the display to a metric or English reading,
press the RESET and MODE buttons at the same
time. Hold them down for three seconds, and the
display will change. A chime will be heard to
confirm the new selection.

The reset button can be used to set the compass zone
variation. See ªCompass Varianceº in the Index.

The reset button can also be used to manually
calibrate the compass. See ªManual Compass
Calibrationº in the Index.MODE (Mode Button):

Press this button to cycle through three modes of
operation
-- Off, Compass/Temperature and Trip
Computer mode.

In the Trip Computer mode, pressing the MODE
button cycles through the five displays. Press the
MODE button after the last Trip Computer display to
return the DIC to the OFF mode.
Off: No driver information is displayed in this mode
of operation.
Compass/Temperature Mode: One of eight compass
readings and the outside temperature are displayed.
If the temperature is below 38F (3C), the word
ªICEº is displayed for two minutes.

2-99
Compass Variance
Compass variance is the difference between magnetic
north and geographic north. In some areas of the
country, the difference is great enough to cause the
compass to give false readings. If this occurs, the
compass variance must be set.
Setting the Variance
Turn the ignition on and cycle the DIC to the
Compass/Temperature mode. Press the RESET
button for approximately five seconds. The last entered
variance zone number and ªVARº will be displayed.
Press the MODE button until the proper variance
number on the map is shown. Press the RESET button to
set the new variance zone and resume normal operation.
All the display segments will be illuminated briefly to
acknowledge the change in zone number. A chime will
sound to confirm that the new zone number has been set.
Automatic Compass Calibration
The compass is self
-calibrating, which eliminates the
need to manually set the compass. When the vehicle
is new, the calibration process may not be complete.
In these cases ªCALº will be displayed, and all
segments of the compass will be illuminated where
the compass reading is normally displayed.
All Segments Illuminated

2-100
To calibrate the compass, in an area free from large
metal objects, make one to two 360
turns.
The calibration symbol will turn off and the compass
reading will be displayed.
Manual Compass Calibration
If the compass appears erratic and the calibration
symbol does not appear, you must manually put the
compass into the calibration mode.
Turn the ignition on and cycle the DIC to the
Compass/Temperature mode. Press the RESET button
for at least 10 seconds until the calibration symbol
appears and all segments of the compass display are
illuminated. A chime will sound to confirm that the
calibration mode is active. Release the button and
complete two or three 360
turns in an area free from
large metal objects. The calibration symbol will turn off
and the compass reading will be displayed. A chime will
sound to verify that the calibration is complete.
Error Displays

An error of the speed sensor or fuel sender will
cause
-E- to be displayed.

In the absence of vehicle communications, a
dash ª
--º is displayed.
If one of these error messages appear, see your dealer.
Trip Computer
There are five trip computer displays which may be
stepped through by pushing the MODE button.
The information will appear in the following order:

AVG ECON (Average Fuel Economy): This shows
the average fuel economy since the last reset.

INST ECON (Instantaneous Fuel Economy): This
shows fuel economy for the most recent second
of driving.

RANGE (Trip Range): This shows the estimated
distance that can be traveled with the remaining fuel.
The fuel economy used to calculate range is based on
the last few hours of driving. When in a low fuel
condition, the word ªLOº is displayed.

FUEL USED (Trip Fuel Used): This shows the
accumulated fuel used since the last reset.

AVG SPEED (Average Speed): This shows the
average speed since the last reset.
Resetting the Trip Computer
Press and hold the RESET button for at least three
seconds. The reset is acknowledged with all segments of
the display lit briefly and a chime. A reset can only be
done in AVG ECON, FUEL USED and AVG SPEED
displays. Each setting must be reset individually.
