2001 CADILLAC SEVILLE mirror

2-57
Curb View Assist Mirror (If Equipped)
If your vehicle is equipped with memory mirrors,
it will also be equipped with the curb view assist mirror
feature. This feature will cause the passenger's mirror to
tilt when the vehicle is in REVERSE (R). This feature is
especially useful in allowing you to view the curb when
you are parallel parking. If further adjustment is needed
after the mirror is tilted, the power mirror controls may
be used to adjust the mirror. If the mirror control is
pressed while the passenger's mirror is tilted, the mirror
will move in that direction, but will return to its original
position once the vehicle is shifted out of REVERSE (R)
and a five
-second delay has occurred.
To program the feature, see ªMirror to Curb in Reverseº
in the Index.
Storage Compartments
Glove Box
The glove box is located in front of the passenger's seat.
To lock the glove box door, insert the master key into
the lock cylinder and turn it clockwise. Turn the key
counterclockwise to unlock the door.
Map Pocket
The map/storage pockets are located on each front door as
well as on the passenger's and driver's front seatbacks.
Center Console Storage
The center console comes with a storage tray, a storage
compartment for CDs or tapes, a dual cupholder that
unfolds, a coinholder, an optional phone and an armrest.
The cupholder can be opened by pressing on the surface
panel located in front of the armrest and unfolding it.
Close the lid to secure it.

2-59
Cigarette Lighter
The front cigarette lighter is located near the ashtray.
Press it all the way in and release. It will pop back out
by itself when it's ready to light. You may also have a
lighter on the back of the center console near the rear
seat air outlet.
Power to the cigarette lighter will shut off 10 minutes
after the ignition is turned off. This helps to prevent
battery drainage. For more information, see ªInadvertent
Power Battery Saverº in the Index.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.
Sun Visors
Swing down the visor to block out glare. It can be
detached from the center mount and moved to the side.
When moved to the side, the sun visor will also move
forward and rearward. The sun visors are equipped with
a storage flap that can be used for small items such as
toll tickets.
There is also a secondary visor attached separately to
the headliner.
Lighted Visor Vanity Mirror
Turn the sunshade down and lift the cover to see the
mirror. Move the slide switch up or down to brighten or
dim the lamp.

2-100
TRANS HOT IDLE ENGINE - 112: This message
indicates that the transaxle fluid in your vehicle is too
hot. Stop and allow your vehicle to idle until it cools
down or until this message is removed.
TRUNK OPEN
- 24: This message indicates that the
trunk is open when the ignition is on.
TURN SIGNAL ON
- 20: This message is a reminder,
after driving about a mile, that you have the turn signal
on. A multiple chime will also sound when this message
is displayed.
VEHICLE OVERSPEED
- 52: This message is
displayed when the vehicle speed exceeds a certain limit
as required by some export countries. A continuous
chime will also sound when this message is displayed.
Vehicle Programming and
Personalization Features
(If Equipped)
If your vehicle is equipped with personalization,
you can program certain features to a preferred setting
for up to two people. If your vehicle does not have
personalization, then some of the features on your
vehicle have been programmed for all drivers.
On all vehicles, certain features such as climate control
settings, radio preset settings, exterior lighting at
unlock, remote lock and unlock confirmation and
automatic door locks have already been programmed
for your convenience. If the vehicle is equipped with
Personalization, then the seat position, steering column
position (if equipped) and the outside mirror positions
can also be programmed. The navigation screen
preferences (if equipped) will remain at the last
set position.

2-101
If your vehicle is equipped with personalization, the
driver's preferences are recalled by pressing the unlock
button on the Remote Keyless Entry (RKE) transmitter
or by pressing the appropriate memory button ª1º or ª2º
located on the driver's door. Certain features can be
programmed not to recall until the key is placed in the
ignition. To change feature preferences you must enter
FEATURE PROGRAMMING (see below).
Entering FEATURE PROGRAMMING
To begin programming, the ignition must be in ON
and your vehicle in PARK (P). If your vehicle has
memory, you must press the appropriate memory
button ª1º or ª2º, located on the driver's door panel
before programming. Press the INFO button one or
more times until the FEATURE PROGRAMMING
prompt appears on the DIC display. Press the ON/OFF
button to enter FEATURE PROGRAMMING. To exit,
press the INFO RESET button.
Remote Recall Memory (If Equipped)
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow
on the INFO button one or more times until the
REMOTE RECALL MEMORY prompt appears.
To turn the feature on, press the ON/OFF button
until ON is displayed on the DIC. The seat and mirror
memory settings that have been previously programmed
can be recalled by pressing the unlock button on the
RKE transmitter. The steering column will move when
the key is inserted in the ignition and turned to ON.
To turn the feature off, press the ON/OFF button
until OFF is displayed.
Key in Recall (If Equipped)
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the KEY IN
RECALL prompt appears on the DIC display. To turn
the feature on, press the ON/OFF button until ON
appears. The seat and mirror memory settings that
have been previously programmed will be recalled when
the key is inserted in the ignition. The power steering
column (if equipped) will move when the key is turned
to ON. To turn the feature off, press the ON/OFF button
until OFF appears.

2-105
Mirror To Curb In Reverse (If Equipped)
Press the down arrow on the INFO button one or more
times until the MIRROR TO CURB IN REV prompts
appears on the DIC display. This feature will move the
passenger's outside rearview mirror to a curb view
position when the console shifter is placed in
REVERSE (R) and it will return the mirror to the last
known driving position when the console shifter is
moved out of REVERSE (R). To turn this feature on,
press the ON/OFF button until ON is displayed on the
DIC. To turn the feature off, press the ON/OFF button
until OFF is displayed. For more information, see ªCurb
View Assist Mirrorº in the Index.
Tire Pressure Display (If Equipped)
To enter feature programming follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the TIRE
PRESSURE DISPLAY prompt appears. This feature
will allow each of the four (left front, right front, left
rear, right rear) tire pressure readings to be displayed
when using the INFO button to scroll through the
DIC displays. To turn the feature on, press ON/OFF
until ON is displayed on the DIC. To turn the feature
off, press ON/OFF until OFF is displayed.Even with this feature programmed to be turned off a
low or high tire pressure condition will still cause the
CHECK TIRE PRESSURE message to be displayed on
the DIC. See ªDriver Information Center (DIC)
Messagesº in the Index for more information.
Driver's Names Set/Recall (If Equipped)
After the FEATURE PROGRAMMING prompt is
displayed on the DIC and the ON/OFF button is pressed,
the prompts DRIVER NO 1 or DRIVER NO 2 will
appear. These prompts correspond to which RKE
transmitter button or memory recall button has been
pressed on the driver's door armrest. You may have your
name and a second driver's name displayed here,
replacing the prompts DRIVER NO 1 and DRIVER
NO 2. A dealership can program your vehicle to display
the names you want. The names will appear whenever
the key is turned to ON only if RKE transmitters 1 or 2
are used to enter the vehicle or buttons 1 or 2 on the
driver's door are pressed.

2-109
Ultrasonic Rear Parking Assist
(URPA) (Option)
Ultrasonic Rear Parking Assist can help you to
determine how close an object is to your rear bumper
within a given area, making parking easier.
The URPA display is
located inside the vehicle,
above the rear window.
It has three color
-coded
lights that can be seen
through the rearview
mirror or by turning around.
How the System Works
URPA comes on automatically when the shift lever is
moved into REVERSE (R) and the vehicle speed is less
than 3 MPH (5 km/h). When the system comes on,
the three lights on the display will illuminate to let
you know that the system is working. URPA senses
how close your vehicle is to an object. The distance is
determined by the four ultrasonic sensors located on the
rear bumper. When shifting into REVERSE (R) and an
object is detected, one of the following will occur:

3-7 Defrosting and Defogging
Use defrost (front) on cool and humid days to keep the
windshield and side windows clear. This setting will
remove fog or ice from the windshield quickly in
extremely humid or cold conditions. If you desire to
have more air on your feet, turn the control to the defog
mode. You may do this by pressing the right or left
arrow on the MODE button.
Press the up or down arrow on the fan button to control
the blower speed. You may also adjust the temperature
by turning the TEMP knob.
The recirculation mode and the A/C OFF message are
not available in the defrost mode.
Rear Window Defogger
The grid lines you see on
the rear window warm the
glass. Press this button to
turn on the rear defogger.With it, the rear window and both outside rearview
mirrors are heated. The light on the button will come on
while the system is activated.
The system will automatically shut off after 10 minutes.
If further defogging is desired, press the button again.
The system will automatically shut off after five minutes
for any cycles after the initial activation.
The lines along the top of the window are for the
diversity antenna and are not intended to defog the
rear window.
Do not attach a temporary vehicle license, tape or decals
across the defogger grid on the rear window.
NOTICE:
Scraping the inside of your rear window could
cut and damage the heating grids. Your warranty
would not cover this damage. Don't put decals
there because you might have to scrape them off.

4-15

Check your mirrors, glance over your shoulder, and
start your left lane change signal before moving out
of the right lane to pass. When you are far enough
ahead of the passed vehicle to see its front in your
inside mirror, activate your right lane change signal
and move back into the right lane. (Remember that
your right outside mirror is convex. The vehicle you
just passed may seem to be farther away from you
than it really is.)

Try not to pass more than one vehicle at a time
on two
-lane roads. Reconsider before passing the
next vehicle.

Don't overtake a slowly moving vehicle too rapidly.
Even though the brake lamps are not flashing,
it may be slowing down or starting to turn.

If you're being passed, make it easy for the
following driver to get ahead of you. Perhaps
you can ease a little to the right.
Loss of Control
Let's review what driving experts say about what
happens when the three control systems (brakes, steering
and acceleration) don't have enough friction where the
tires meet the road to do what the driver has asked.
In any emergency, don't give up. Keep trying to
steer and constantly seek an escape route or area of
less danger.
Skidding
In a skid, a driver can lose control of the vehicle.
Defensive drivers avoid most skids by taking
reasonable care suited to existing conditions, and by
not ªoverdrivingº those conditions. But skids are
always possible.
The three types of skids correspond to your vehicle's
three control systems. In the braking skid, your wheels
aren't rolling. In the steering or cornering skid, too
much speed or steering in a curve causes tires to slip
and lose cornering force. And in the acceleration skid,
too much throttle causes the driving wheels to spin.
