2001 BUICK CENTURY Owner's Manual

2-75 Service Vehicle Soon Light
The SERVICE VEHICLE
SOON light will come
on if you have certain
non
-emission related
vehicle problems.
These problems may not be obvious and may affect
vehicle performance or durability. Consult a qualified
dealership for necessary repairs to maintain top vehicle
performance. The light will come on briefly when your
ignition is turned on to show that it is working properly.
Low Washer Fluid Warning Light
The LOW WASH light
will come on when your
windshield washers are
working and the fluid
container is low.
The light will also come on briefly when your ignition is
turned on to show that it is working properly.
Door/Trunk Ajar Warning Light
The DOOR/TRUNK light
will come on if your trunk
or any door is not
completely closed.
Fuel Gage
United States Canada
Your fuel gage tells you about how much fuel you have
left when the ignition is on. When the indicator nears
empty, you still have a little fuel left, but you should
get more soon.

2-76
Here are four things that some owners ask about. All
these things are normal and do not indicate that anything
is wrong with the fuel gage:

At the gas station, the pump shuts off before the gage
reads full.

It takes more (or less) fuel to fill up than the gage
reads. For example, the gage reads half full, but it
took more (or less) than half of the tank's capacity
to fill it.

The gage pointer may move while cornering, braking
or speeding up.

The gage may not indicate empty when the ignition
is turned off.Low Fuel Light
United States Canada
If your fuel is low, a circular light on your instrument
panel cluster will come on and stay on and a chime will
sound periodically until you add fuel.
It will also come on for a few seconds when you first
turn on the ignition as a check to show you it's working.
If it doesn't come on then, have it fixed.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Dual ComforTemp
Climate Control
3
-4 Dual Automatic ComforTemp
Climate
Control (If Equipped)
3
-7 Defogging and Defrosting
3
-8 Rear Window Defogger
3
-9 Ventilation System
3
-10 Audio Systems
3
-10 Setting the Clock
3
-10 AM-FM Stereo
3
-12 AM-FM Stereo with Cassette Tape Player
(If Equipped)
3
-16 AM-FM Stereo with Cassette Tape Player and
Automatic Tone Control (If Equipped)3
-20 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Automatic
Tone Control (If Equipped)
3
-25 Theft-Deterrent Feature (If Equipped)
3
-28 Audio Steering Wheel Controls
(If Equipped)
3
-29 Understanding Radio Reception
3
-29 Tips About Your Audio System
3
-30 Care of Your Cassette Tape Player
3
-31 Care of Your Compact Discs
3
-31 Care of Your Compact Disc Player
3
-31 Fixed Mast Antenna
3
-31 Backglass Antenna (If Equipped)
3
-32 Diversity Antenna System (If Equipped)

3-2
Comfort Controls
Dual ComforTemp Climate Control
With this system, the driver and passenger can maintain
separate temperatures. The system works best if you
keep your windows closed while using it.
Fan Control Knob
The left knob labeled FAN controls the fan speed selection.
If the airflow seems very low when the fan is adjusted
to the highest setting regardless of the mode setting,
your passenger compartment air filter may need to be
replaced. See ªMaintenance Scheduleº or ªPassenger
Compartment Air Filterº in the Index.Driver's Temperature Lever
The lever on the left adjusts the air temperature on the
driver's side outlets independent of the temperature set by
the passenger. Slide the lever up to raise the temperature.
Slide the lever down to lower the temperature.
Passenger's Temperature Lever
The lever on the right adjusts the air temperature on the
passenger's side independent of the temperature set by
the driver. Slide the lever up to raise the temperature.
Slide the lever down to lower the temperature.
Mode Knob
The right knob has several settings to control the
direction of airflow. To access the various modes
available, turn the mode knob to the desired mode.
MAX: This setting recirculates much of the air inside
your vehicle and sends it through the instrument
panel outlets. The air conditioning compressor will
run automatically in this setting unless the outside
temperature is below 40
F (4
C). (Even when the
compressor is running, you can control the temperature.)
VENT: This setting brings in outside air and directs it
through the instrument panel outlets.

3-3
BI-LEV: This setting brings in outside air and
directs it two ways. Half of the air is directed through
the instrument panel outlets. Most of the remaining air is
directed through the floor ducts and a little to the defrost
and side window vents.
HTR: This setting sends most of the air through the
ducts near the floor. The rest comes out of the defroster
and side window vents.
BLEND: This setting allows half of the air to go to
the floor ducts and half to the defroster and side
window vents. The air conditioning compressor will
run automatically in this setting unless the outside
temperature is below 40
F (4
C). (Even when the
compressor is running, you can control the temperature.)
DEF: This setting directs most of the air through
the defroster and side window vents. Some of the air
goes to the floor ducts and the side window vents.
The air conditioning compressor will run automatically
in this setting unless the outside temperature is below
40
F (4
C). (Even when the compressor is running,
you can control the temperature.)
A/C: Press this button to turn the air conditioning
on and off. The system will cool and dehumidify the
air inside the vehicle when the A/C light is on.Heating
On cold days, use HTR with the driver and passenger
levers all the way in the red area. This system will bring
in outside air, heat it, and send it to the floor ducts.
Heating (Engine Coolant Heater)
If your vehicle has an engine coolant heater, you can use
it to help your system provide warm air faster when it's
cold outside
-- 0
F (-18
C) or lower. An engine
coolant heater warms the coolant your engine and
heating system use to provide heat. See ªEngine Coolant
Heaterº in the Index.
Air Conditioning
On very hot days, open the windows long enough
to let hot, inside air escape. This reduces the time for
the vehicle to cool down.
For a quick cool
-down on very hot days, use MAX
with the temperature levers all the way in the blue area.
If this setting is used for long periods of time, the air in
your vehicle may become too dry.
For normal cooling on hot days, use VENT with the
temperature levers in the blue area. The system will
bring in outside air and cool it.

3-4
On cool, but sunny days, the sun may warm your upper
body, but your lower body may not be warm enough.
You can use BI
-LEV and set the temperature levers to a
comfortable setting. The system will bring in outside air
and direct it to your upper body, while sending slightly
warmed air to your lower body. You may notice this
temperature difference more at some times than others.
Push the A/C button on for cooling.
Dual Automatic ComforTemp Climate
Control (If Equipped)
With this system, you set a temperature. You can
then either let the system automatically control airflow
direction and force to maintain the temperature, or you
can manually adjust it. The system works best if you
keep your windows closed while using it.
Automatic Control
For the most efficient operation, you should set the
system temperature and press AUTO. The system will
select the best fan speed and airflow settings to keep
you comfortable. The air conditioning compressor will
run if the outside temperature is above 40
F (4
C).
You may notice a delay of two to three minutes before
the fan comes on at start up in cool weather.
Temperature Control
The TEMP switch sets the temperature for the entire
system when the light on the DUAL button isn't lit.
If the DUAL button light is lit, this master temperature
control sets the temperature for the driver only. Press the
up arrow to raise the temperature and press the down
arrow to lower the temperature. The display will show
your selection for a few seconds, then the outside
temperature will be displayed. If you push the AUTO
button, the system will control the fan speed and airflow.
For the automatic system to function, the temperature
must be set between 61
F (16
C) and 89
F (31
C).
The driver's temperature and passenger's temperature
settings will be automatically maintained even if manual
overrides have been selected except for settings at
60
F (15
C) and 90
F (32
C).

3-5
Setting the temperature to 90
F (32
C) will lock control
in full hot, direct air to the floor, and increase the fan speed
to high. The system will not return to automatic temperature
control until the temperature setting is lowered.
Setting the temperature to 60
F (15
C) will lock control
in full cold, recirculate interior air, direct air to outlets on
panel and increase blower speed to high. The system will
not return to automatic temperature control until the
temperature setting is raised.
Passenger's Temperature Control
The PASSENGER CONTROL buttons with the arrows
adjust the temperature on the passenger's side so it is
warmer or cooler than the temperature for the driver's
side. Push the DUAL button so that the indicator light is
lit. Press the right arrow button to raise the temperature.
Press the left arrow button to lower the temperature.
The display will not show the passenger's temperature,
only that of the driver. Indicators in the passenger control
section will show passenger's side temperature relative to
the driver's set temperature.

The amber light indicates the same temperature as
set for the driver.

The red lights indicate a warmer temperature than
that of the driver.

The blue lights indicate a cooler temperature than
that of the driver.Hot Weather Example: When you start the vehicle
in hot weather, 80F (27C) or after being parked
during the day in full sun, if your driver set temperature
is 75F (23C) and you are in full automatic mode,
the system will automatically move the temperature to
full cold. The fan will be at low speed momentarily
and then go to the high speed. The air intake will be
recirculated for maximum cooling performance.
As the interior of the vehicle cools down to your
desired comfort point, the fan speed will decrease and
the temperature will move to a warmer position to
maintain your desired comfort. As the interior cools
down or the sun load decreases the system could switch
to air delivered to A/C vents and the floor.
Cold Weather Example: When you start the vehicle
in cold weather, (below freezing) or after being parked
overnight. If your Driver Set Temperature is 75F (23C)
and you are in Full Automatic mode, the system will
automatically move the temperature doors to full hot.
The fan will start out at a low speed and will increase to
a higher speed as the engine warms up. The air will be
delivered to the floor. As the interior of the vehicle
warms up to your desired comfort point, the fan speed
will decrease and the temperature will move to a cooler
position to maintain your desired comfort. As the cabin
warms up or the sun load increases the system could
switch to air delivered to the windshield and the floor
(DEFOG mode).

3-6
Manual Control
If you prefer to manually control the heating, cooling and
ventilation in your vehicle, you can select airflow direction,
fan speed, outside or recirculated air, air compressor and
temperature operation with the following:
AIR FLOW: This control has several settings to control
the direction of airflow when the system is not in AUTO.
To access the various modes available, continue to press
the AIR FLOW rocker button up or down until the
desired mode appears in the display:
WINDSHIELD/FLOOR: This setting directs half of
the air to the floor ducts and half to the defroster and
side window vents. The air conditioning compressor
will run automatically in this setting unless the outside
temperature is below 40
F (4
C).
MID/FLOOR: This setting directs half of the air
through the instrument panel outlets. Most of the
remaining air is directed through the floor ducts and
a little to the defroster and side window vents.
MID: This setting directs air through the instrument
panel outlets.FLOOR: This setting sends most of the air through
the ducts near the floor. The rest comes out of the
defroster and side window vents. When in this setting
and the RECIRC setting, the windows can fog up.
See ªRECIRCº in the Index.
FRONT: This setting brings in outside air
and directs most of the air through the defrost vent.
Some of the air also goes to the floor ducts and the side
window defogger outlets. The indicator on the button
will light and WINDSHIELD will be lit in the display.
The air conditioning compressor will run automatically
in this setting unless the outside temperature is below
40
F (4
C).
VENT: This setting turns the air conditioning
compressor on and off. The indicator is lit when the
compressor is turned off. Recirculation is not permitted
when the compressor is off. The system will try to
control the temperature automatically, but without
the compressor.
VENT is not permitted in FRONT defrost mode. If the
VENT button is pushed while in FRONT defrost mode,
the indicator will light briefly and then turn off.
