2001 BMW Z8 center console

79n
IndexDataTechnologyRepairsCar careControlsOverview
Storage compartmentsIn the center consoleTo open:
Flip the cover up (arrow 1) Ð access to
the ashtray and cigarette lighter.
When the glove compartment has been
unlocked, press the button (arrow 2) Ð
cellular phone holder.
To close:
Flip the cover back into place.Manual operation(in the event of electrical malfunction)
For operating
the cellular phone holder
,
refer to page 140.
520de050
Behind the seatsBy way of example, the illustration
shows the storage compartment behind
the driver's seat.
To open:
Unlock by turning the master key all the
way to the left.
The cover will open slightly and can
then be flipped all the way up.
To close:
Press down until you hear it snap into
place. The cover has been locked
again.
If you turn over only your door and
ignition key (refer to page 30) for
valet parking access is impossible.<520de082
Rechargeable flashlight Located in the storage compartment
behind the driver's seat.
Because of overload-protection, the
flashlight can remain in its holder.
Be sure that the flashlight is
switched off when it is inserted
into its holder. Failure to do so could
lead to overcharging and damage.<520de070

80n
Storage compartments Drink holderNavigation computerLocated in the storage compartment
behind the passenger's seat.
For further information regarding the
navigation system, refer to the separate
Owner's Manual.520de103
CD changerLocated in the storage compartment
behind the driver's seat.
For further information regarding the
CD changer, refer to the separate
Owner's Manual.520de138
1 Push the front passenger seat all the
way back
2 Take the drink holder out of the glove
compartment and
3 place it in the bracket located on
the center console on the front
passenger side. Refer to the
illustration.
By using the removable plastic insert,
you can place beverage cans or cups of
various sizes in the holder.
Do not place any open drinks in
the holder while driving, otherwise
the liquid could slop over the side and
either stain the upholstery or cause
burns.<520us015

81n
IndexDataTechnologyRepairsCar careControlsOverview
Cellular phone Ashtray Located in the storage compartment in
the center console.To remove 1 Press the button (arrow 1) and
remove the plug.
2 Press the button (arrow 2) and
remove the telephone.
Return the phone to its original position
by proceeding in reverse sequence.
For further information on the cellular
phone, refer to the separate Owner's
Manual.520de159
Hands free systemLocated over the interior rearview
mirror.
For further information on the cellular
phone, refer to the separate Owner's
Manual.520de131
To openLift cover.
To extinguish a cigarette, brush off the
ash and gently press the tip into the
funnel (arrow 1). To empty Press button (arrow 2): the ashtray rises
and can now be extracted. 520de052
