19
The injection system was modified in order to
reduce exhaust gas and particle emissions. The main features of the basic engine are the
same as those of the familiar V6 TDI engine
with 132 kW (180 PS).
Power output and torque curve values could
be maintained under conditions which were
well within EU 3 limit values.
NOx
HC+NOxCO
Particle
Limit value [%]
EU 3 limit values 100 %
Particle = 0.05 g/km
CO = 0.64 g/km
HC+NOx = 0.56 g/km
NOx = 0.50 g/km
SSP255_038
Innovations 2.5 l V6 TDI engine
Capacity: 2496 cm
3
Bore: 78.3 mm
Stroke: 86.4 mm
Compression: 18.5 : 1
Power output: 132 kW (180 PS)
Torque: 370 Nm at 1500 rpm
SSP255_039
Power output [kW]Torque [Nm]
Technical data
Injection system: Bosch VE VP 44 S3.5
Turbocharger: VNT 20
Exhaust emissions class: EU 3
Consumption: urban 11.0 l/100 km
(6-gear, quattro) country 6.1 l/100 km
average 7.8 l/100 km
Engine speed in rpm
SSP255_045
Downloaded from www.Manualslib.com manuals search engine
61
In order to account for the resistance of
normal or insulating windows with regard to
the excess force limitation function of the
electric window lifters, the relevant type of
glazing is set in adaption channel 63.
Mirror functions
The mirror heating is switched on together
with the
– rear window heating
– at an outside temperature of below 20 °C
switches on automatically.
When the mirror heating is switched on, the
heating capacity is 100%. Then the heating is
activated intermittently in accordance with
the ambient temperature and vehicle speed.
The mirror glass is kept at a temperature of
around 20 °C.
The mirror fold-in function (optional) returns
the mirrors to the normal position at a vehicle
speed of 15 km/h. The function is disabled at
the same time.
Passenger’s side mirror
Lowering of the mirror (optional) takes place
when the reverse gear is engaged.
The mirror is returned to its original position
by
– operating the mirror selector switch, or
– when the speed of 15 km/h is exceeded.
Diagnostics
The adjustment of various settings can be
performed via the control unit coding and
adaption functions of the convenience
system diagnosis.
Customer requirements relating to the
convenience opening and closing functions
can be taken into account via adaption
channel 62.
SSP254_126
SSP254_127
SSP254_128
