YOUR 206 CC IN DETAIL59
3. Air distribution adjustment
Windscreen and side win- dows (demisting/de-icing).
To quickly de-ice or demist the wind-screen and the side windows:
Ð place the temperature and air flow controls to maximum,
Ð close the central vents.
Ð place the outside air intake control to the left, in the "Outside air" posi- tion,
Ð operate the air conditioning
Windscreen, side windowsand footwells. Footwells.
These settings are recommended for cold climates.
Central and side vents.
This setting is recommended for hotclimates. 5. Air intake control
outside air intake.
This is the norma operating position.
Recirculation of interior air.
This position prevents the entry ofunpleasant odours or fumes from theoutside. Used simultaneously with the air conditioning enables both the heatingand cooling performance to be impro-ved. Used without air conditioning, recircu- lation may result in misting the win-dows. As soon as possible, place the control in the outside air position. Important precaution Operate the air conditioning for 5 to 10 minutes, once or twice a month, to
keep it in perfect working order. If the system does not produce cold
air, do not use it and contact your
PEUGEOT dealer.4. Air flow adjustment
From position 1to position 4.
Turn the knob to obtain suffi- cient flow to ensure your com-fort.
* According to specification.
6. De-misting the rear screen
With the engine running, pressing the button de-miststhe rear screen and the mir-rors*.
It switches off automatically afterapproximately twelve minutes. Press again to resume de-misting for twelve minutes. It is possible to stop the de-misting operation by pressing the button againbefore the end of the twelve minutes. Note: this function is disarmed when
the roof is stored in the boot.
Page 64 of 123
YOUR 206 CC IN DETAIL65
CHILD SEATS Child safety was one of PEUGEOT's main concerns when designing your vehicle; however the safety of your children also depends on you.
For maximum safety, please observe the following precautions:
- All children under the age of 10 are required to travel in approved restraining devices*, suited to their weight, in the seats
fit-
ted with seat belts.
- front passenger seat*: children under the age of 10 must not be transported in the "forwards facing" position, unless the rear seats are already occupied by other children. In this case adjust the front passenger seat to the mid-position. The "rear fac- ing" position is permitted when the air bag is disarmed.
After carrying out numerous tests, PEUGEOT recommends the following systems: Up to 18 months (to 29 lbs or 13 kg) "Ršmer Babysure": is installed with its back to the engine and secured with a three-point seat belt, on either the front or rea r
seat. In the front the passenger seat must be adjusted to the "mid-position".
From 9 months to 3 or 4 years (20 to 40 lbs or 9 to 18 kg) "Ršmer Prince": is fitted to the rear seat with a three-point seat belt. For the safety of your children, the seat and the strap must never be separated.
From 3 to 6 years (33 to 55 lbs or 15 to 25 kg) "Ršmer Vario": is fitted to the rear seat with a three-point seat belt.
1
2
3
Page 68 of 123
YOUR 206 CC IN DETAIL69
Make a careful note of the
number on each key. The keynumber is coded on the label
attached to the key.
If the keys are lost, your PEUGEOT dea-ler can rapidly supply you with new keys. The high frequency remote control is a high-performance system which has apowerful beam. Do not operate it while it is in your pocket as there is a possibility that it may unlockyour vehicle, without you being aware of it. The remote control does not operate when the key is in the ignition, evenwhen the ignition is switched off, exceptfor reprogramming. As a safety precaution (with children on board), remove the ignition key when youleave the vehicle, even for a short time. Do not repeatedly press the button of your remote control out of range of your
vehicle. You risk causing it not to workand the remote control would have to bereprogrammed. When purchasing a second-hand vehicle: - ensure that you are given the confiden- tial card;
- have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the onlyones which can start the vehicle.
Do not make any modifications to theelectronic engine immobiliser system.
Confidential card The confidential card contains the identification code necessary for any
work carried out by a PEUGEOT dea-
ler on the system. This code is hiddenby a film which should be removed
only if necessary. Keep your card in a safe place, never inside the vehicle.
ELECTRONIC ENGINE IMMOBI- LISER This locks the engine control system a few moments as soon as the ignition
has been switched off and thereforeprevents starting of the vehicle by
anyone who does not have the key. The ignition key has an electronic chip which has a special code. When theignition is switched on, the code isrecognised and starting is possible. If the system does not function correctly , an audible signal sounds,
accompanied by a message on themultifunction display*.
WARNING: your vehicle is no longer
protected in this event.
Contact a PEUGEOT dealer as soon as possible. * According to specification
Page 69 of 123
YOUR 206 CC IN DETAIL69
Make a careful note of the
number on each key. The keynumber is coded on the label
attached to the key.
If the keys are lost, your PEUGEOT dea-ler can rapidly supply you with new keys. The high frequency remote control is a high-performance system which has apowerful beam. Do not operate it while it is in your pocket as there is a possibility that it may unlockyour vehicle, without you being aware of it. The remote control does not operate when the key is in the ignition, evenwhen the ignition is switched off, exceptfor reprogramming. As a safety precaution (with children on board), remove the ignition key when youleave the vehicle, even for a short time. Do not repeatedly press the button of your remote control out of range of your
vehicle. You risk causing it not to workand the remote control would have to bereprogrammed. When purchasing a second-hand vehicle: - ensure that you are given the confiden- tial card;
- have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the onlyones which can start the vehicle.
Do not make any modifications to theelectronic engine immobiliser system.
Confidential card The confidential card contains the identification code necessary for any
work carried out by a PEUGEOT dea-
ler on the system. This code is hiddenby a film which should be removed
only if necessary. Keep your card in a safe place, never inside the vehicle.
ELECTRONIC ENGINE IMMOBI- LISER This locks the engine control system a few moments as soon as the ignition
has been switched off and thereforeprevents starting of the vehicle by
anyone who does not have the key. The ignition key has an electronic chip which has a special code. When theignition is switched on, the code isrecognised and starting is possible. If the system does not function correctly , an audible signal sounds,
accompanied by a message on themultifunction display*.
WARNING: your vehicle is no longer
protected in this event.
Contact a PEUGEOT dealer as soon as possible. * According to specification
Page 70 of 123
YOUR 206 CC IN DETAIL
70
Doors Opening the doors from outside Opening the doors from inside
Locking and unlocking the boot Lock
the boot using the key (turn the
key from Ato C) or the remote control.
Unlock it using the key (turn the key
from Ato B) in all cases.
The lighting is controlled by opening the boot.
Locking from the inside
To lock, press button A.
Locking one of the front doors locks the doors and the boot. Unlocking from the inside
To unlock, pull button Aor the handle.
''Door open'' alert With the engine running or the vehicle moving, the flashing of the central
"STOP" warning light, accompanied
by an audible signal and a diagramlocating the problem on the multifunc-tion screen, warns you that a door isnot properly closed.
Page 71 of 123
YOUR 206 CC IN DETAIL71
Bonnet strut Secure the strut to hold the bonnet open. Before closing the bonnet, replace the strut in its housing.
To close Lower the bonnet and release it at the end of its travel. Check that the bonnetis locked.
Opening the bonnet Inside the vehicle:
pull the handle on
the left- hand side, under the fascia. Outside the vehicle: lift the catch and
raise the bonnet. Filling the fuel tank The tank must be filled with fuel with the engine off
.
Insert the key then turn it to the left. Remove the cap.
A label indicates which type of fuel to use. If you fill your tank, do not continue
after the third cut-off of the pump nozz-
le. This could result in vehicle mal-functions. The capacity of the tank is approxi- mately 10,3 gallons (47 litres).
Page 80 of 123
YOUR 206 CC IN DETAIL
80
Electric windows
1. DriverÕs electric window switch.
2. PassengerÕs electric window
switch.
Each switch controls, on its own side, the front window and the rear quarter
panel window. Manual operation Press the switch (to open) or pull it (to close) without going beyond thepoint of resistance. The window stops when the switch is released. The rear quarter panel window can only be opened when the frontwindow is completely open, after aninactive period of one second.
Automatic operation
Opening
The windows open automatically(when the ignition key is in the ÔonÕposition, with the engine running orthe vehicle moving).
Press the switch past the point ofresistance:
- Press briefly to completely open the front window; press brieflyagain to completely open the
rear quarter panel window,
- Sustained pressure opens the front window, then the rear quar-
ter panel, completely.
Closing
Only the front window on the driverÕsside closes automatically (enginerunning or vehicle moving), whenthe rear quarter panel is closed. Briefly pull the switch past the point of resistance to completely
close the driverÕs front window.
Note: the window switches do not
function while the roof is being opera-ted.
Page 85 of 123
YOUR 206 CC IN DETAIL85
Automatic autoadaptive gearbox* Moving Off
To move off, move the selector lever to position
Nor P. Press the brake to exit
position P. Stopped or parked Always leave the lever in position Pwhen you get out of your vehicle.
If not, a buzzer will sound when you open the driver's door.
Positions of the selector lever These positions are displayed on the instrument panel.P
Park: use with the handbrake when parking
R
Reverse: this must only be engaged when the vehicle is stationary, engine at idle.
N
Neutral: if Nis engaged by mistake while the car is moving, allow the
engine to return to idle before engaging a new forward gear.
D
Drive: in this position, the four gears change automatically. The gear change points vary depending on the programme selected.
3
Automatic changes of the first three gears only. Select this position whenyou notice frequent changes between third and fourth gear (town driving oron winding roads).
2
Automatic changes of the first two gears only. This position is particularly suitable for mountain roads, when going uphill (to make the best use of theengine's power) and downhill (engine braking).
* According to specification .
