INSTRUMENT AND CONTROL FUNCTIONS
3-6
3
EAU00095
SpeedometerThe speedometer shows riding speed.
This speedometer is equipped with an
odometer and trip odometer. The trip
odometer can be reset to “0” with the
reset knob. Use the trip odometer to
estimate how far you can ride on a tank
of fuel. This information will enable you
to plan fuel stops in the future.
EAU00101
TachometerThis model is equipped with an electric
tachometer so the rider can monitor the
engine speed and keep it within the
ideal power range.
EC000003
CAUTION:@ Do not operate in the red zone.
Red zone: 13,200 r/min and above @
1. Odometer
2. Reset knob
3. Trip odometer
1. Tachometer
2. Red zone
